Titan TTB776VAC User manual

Wet/Dry Vacuum
Cleaner 1400 W
TTB776VAC
Original Instructions_MNL_TTB776VAC_GB
EAN: 5059340106212
WARNING: Read the instructions before using the product!
BX220IM

This TITAN product carries a 2 year guarantee. If your product develops a fault within this
period, you should, in the first instance contact the retailer where the item was purchased.
This guarantee specifically excludes losses caused due to:
- Fair wear and tear
- Misuse or abuse
- Lack of routine maintenance
- Failure of consumable items (such as batteries)
- Accidental damage
- Cosmetic damage
- Failure to follow manufacturer’s guidelines
- Loss of use of the goods
This guarantee does not affect your statutory rights. This guarantee is only valid in the UK.
GUARANTEE
Wet/Dry Vacuum Cleaner 1400 W - TTB776VAC
Congratulations on your purchase of a TITAN power tool from
Kingsher International Products B.V.. We want you to continue
getting the best performance from it so this handbook includes
information on safety, handling and care. Please retain this handbook
in case you need to refer to any of the information in the future.
Your TITAN power tool comes with a 2 year guarantee, so should
it develop a fault within this period contact your retailer.

TTB776VAC by TITAN
Let’s
get started...
These instructions are for your safty. Please read through them
thoroughly before use and retain them for future reference.
Getting started... 03
Safety information 04
Your product 14
Technical specications 15
Before you start 16
In more detail 25
Product functions 26
Operation 29
Care and maintenance 33
Troubleshooting 38
Recycling and disposal 39
3
Wet/Dry Vacuum Cleaner 1400 W - TTB776VAC

4
TTB776VAC by TITAN
Getting Started ...
Safety warnings
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND
KEEP FOR FUTURE REFERENCE!
> This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
> If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualied
persons in order to avoid a hazard.
> Before vacuuming, remove any large, sharp or
sharpedged objects to avoid damage to the dust bag,
lters and / or product.
> Do not vacuum any hot or incandescent objects, liquids,
chemicals or ammable materials.
> Do not use the product without tting a lter and / or dust
bag rst.
> Carry, pull and push the product only by the handle, not
by the hose or power cord.
> Lay out the cord in such a way that no unintentional
pulling or tripping over is possible.
> Do not attempt to modify the product in any way.
> Only use attachments and accessories recommended
by the manufacturer.
> Never use the product to vacuum up ammable or
Safety information

5
TTB776VAC by TITAN
Getting Started ...
Safety information
combustible liquids, such as gasoline, photocopier
powder or volatile substances; and do not use the
product in areas where these liquids are present. Do not
vacuum up acids.
> Do not vacuum up any objects which are toxic, cancer
causing, combustible, or any other dangerous materials,
such as asbestos, asbestos dust, arsenic, barium,
beryllium, lead, pesticides, or any other substances
hazardous to health.
> DANGER OF FIRE! Never vacuum up any objects which
are burning or smoldering, such as cigarettes, cigarette
butts, matches, or hot ashes.
> WARNING! Operators shall be adequately instructed on
the use of this product!
> WARNING! The product is not suitable for picking up
hazardous dust!
> CAUTION! This product is for indoor use only!
> CAUTION! This product shall be stored indoors only!
> WARNING! Switch the product off and disconnect it
from power supply by pulling the plug before cleaning,
maintaining, replacing attachments / accessories or
converting to another function!
> The plug must be removed from the socket-outlet before
cleaning or maintaining the appliance.
Blower safety warnings
Training
> Read the instructions carefully. Be familiar with the
controls and the proper use of the product.
> Never allow people unfamiliar with these instructions to
use the product. Local regulations may restrict the age

6
TTB776VAC by TITAN
Getting Started ...
Safety information
of the operator.
> The operator or user is responsible for accidents or
hazards occurring to other people or their property.
Preparation
> Obtain ear protection and safety glasses. Wear them at
all times while operating the product.
> While operating the product always wear substantial
footwear and long trousers. Do not operate the product
when barefoot or wearing open sandals. Avoid wearing
clothing that is loose tting or that has hanging cords or
ties.
> Do not wear loose clothing or jewellery that can be
drawn into the air inlet. Keep long hair away from the air
inlets.
> Operate the product in a recommended position and
only on a rm, level surface.
> Do not operate the product on a paved or gravel surface
where blown material could cause injury.
> Before using, always visually inspect to see that the
bolts and other fasteners are secure and the housing
is undamaged. Replace worn or damaged components
in sets to preserve balance. Replace damaged or
unreadable labels.
> Never operate the product while people, especially
children or pets are nearby.
> To prevent dust irritation the wearing of a face mask is
recommended.
Operation
> Keep proper balance and footing at all times. Do not
overreach.

7
TTB776VAC by TITAN
Getting Started ...
Safety information
> If the product should start making any unusual noise
or vibration, immediately shut off the power source and
allow the product to stop. Disconnect the product from
the supply and take the following steps before restarting
and operating the product:
- inspect for damage;
- replace or repair any damaged parts;
- check for and tighten any loose parts.
> Keep the power source clean of debris and other
accumulations to prevent damage to the power source
or possible re.
> Do not transport this product while the power source is
running.
> Stop the product, shut off the power source and
disconnect the product from the supply. Make sure that
all moving parts have come to a complete stop
- whenever you leave the product,
- before clearing blockages or unclogging chute,
- before checking, cleaning or working on the product,
> Do not tilt the product while the power source is running.
> Walk, never run.
> Operate the product only in daylight or in good articial
light.
> Do not blow hard objects such as nails, bolts, or rocks.
> Apply extra care when cleaning debris from stairs or
other tight areas.
Follow below recommendations when using the
product:
> Use rakes and brooms to loosen debris before blowing/
vacuuming.

8
TTB776VAC by TITAN
Getting Started ...
Safety information
> Slightly dampen surfaces in dust conditions or use
mister attachment.
Electrical safety
> Ensure the rated voltage shown on the rating label
corresponds with the voltage of the power supply.
> Do not operate any product with a damaged power cord
or plug, when the product malfunctions or has been
damaged in any manner.
> Protect the power cord against damage. Do not let it
hang over sharp edges; do not squeeze or bend it. Keep
the power cord away from hot surfaces and ensure that
nobody can trip over it.
> Do not insert ngers or foreign objects in any opening of
the product and do not obstruct the air vents.
> Protect the product against heat. Do not place close to
heat sources such as stoves or heating appliances.
Emergency
Familiarise yourself with the use of this product by
means of this instruction manual. Memorise the safety
warnings and follow them to the letter. This will help
to prevent risks and hazards.
> Always be alert when using this product, so that you can
recognise and handle risks early. Fast intervention can
prevent serious injury and damage to property.
> Switch off and disconnect from the power supply if
there are malfunctions. Have the product checked by a
qualied professional and repaired, if necessary, before
you operate it again.

9
TTB776VAC by TITAN
Getting Started ...
Safety information
Residual risks
Even if you are operating this product in accordance
with all the safety requirements, potential risks of
injury and damage remain. The following dangers can
arise in connection with the structure and design of
this product:
> Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
> Injuries and damage to property due to broken
accessories or the sudden impact of hidden objects
during use.
> Danger of injury and property damage caused by ying
objects.
The following information applies to professional users
only but is good practice for all users:
Additional safety warnings for construction dust
The updated Control of Substances Hazardous to Health
Regulations 1st October 2012 now also targets to reduce
the risks associated with silica, wood and gypsum dusts.
Construction workers are one of the at-risk groups within
this because of the dust that they breathe: silica dust is not
just a nuisance; it is a real risk to your lungs!
Silica is a natural mineral present in large amounts
in things like sand, sandstone and granite. It is also
commonly found in many construction materials such as
concrete and mortar. The silica is broken into very ne
dust (also known as Respirable Crystalline Silica or RCS)
during many common tasks such as cutting, drilling and

10
TTB776VAC by TITAN
Getting Started ...
Safety information
grinding Breathing in very ne particles of crystalline silica
can lead to the development of:
Lung cancer Silicosis Chronic Obstructive Pulmonary
Disorder (Chronic obstructive pulmonary disease (COPD))
And breathing in ne particles of wood dust can lead to the
development of Asthma The risk of lung disease is linked
to people who regularly breathe construction dust over a
period of time, not on the odd occasion.
To protect the lung, the COSHH Regulations sets a limit
on the amount of these dusts that you can breathe (called
a Workplace Exposure Limit or WEL) when averaged over
a normal working day. These limits are not a large amount
of dust: when compared to a penny it is tiny – like a small
pinch of salt:
This limit is the legal maximum; the most you can breathe
after the right controls have been used.
How to reduce the amount of dust?
> Reduce the amount of cutting by using the best sizes of
building products.
> Use a less powerful tool e.g. a block cutter instead of
angle grinder.
> Using a different method of work altogether – e. g. using
a nail gun to direct fasten cable trays instead of drilling
holes rst.
Please always work with approved safety equipment, such
as those dust masks that specially designed to lter out
microscopic particles and use the dust extraction facility at
all time.
For more information, please see the HSE website:

11
TTB776VAC by TITAN
Getting Started ...
http://www.hse.gov.uk/construction or http://www.hse.gov.
uk/pubns/cis69.pdf
WARNING! Some dust created by power sanding, sawing, grinding,
drilling and other construction activities contains chemicals known to
cause cancer, birth defects or other reproductive harm.
Some examples of these chemicals are:
- Lead from lead-based paint.
- Crystalline silica from bricks and cement and other masonry
products.
- Arsenic and chromium from chemically treated timber.
Your risk from these exposures varies, depending upon how often you do
this type of work. To reduce your exposure to these chemicals:
- Work in a well-ventilated area.
- Work with approved protective equipment, such as those dust masks
that are specially designed to lter microscopic particles.
Safety information

12
TTB776VAC by TITAN
Getting Started ...
Symbols
On the product, the rating label and within these instructions you will nd among
others the following symbols and abbreviations. Familiarise yourself with them to
reduce hazards like personal injuries and damage to property.
V~ Volt (alternating voltage) kg Kilogram
Hz Hertz kPa Kilopascal
W Watt dB(A) Decibel (A-rated)
mm Millimetre m/s² Metres per second squared
L Litre
IPX4 Protection against penetration of dust, protection against vertical water
drips.
Lock / to tighten or secure. Unlock / to loosen.
Note / Remark. Caution / Warning.
Read the instruction manual. Wear eye protection
Wear a dust mask. Wear hearing protection.
Wear protective gloves. Wear face protection.
Wear tight-tted protective
clothes. Beware of electric voltage!
Only use in dry indoor rooms.
yyWxx Manufacturing date code; year of manufacturing (20yy) and week of
manufacturing (Wxx).
Switch the product off and disconnect it from the power supply
before assembly, cleaning, adjustments, maintenance, storage and
transportation.
Safety information

13
TTB776VAC by TITAN
Getting Started ...
Safety information
Dry Wet or damp
Blowing
Keep bystanders away!
Objects thrown by the product could hit the user or other bystanders.
Always ensure that other people and pets remain at a safe distance
from the product when it is in operation. In general, children must
not come near the area where the product is.
The product complies with the applicable European directives and an
evaluation method of conformity for these directives was done.
WEEE symbol. Waste electrical products should not be disposed of
with household waste. Please recycle where facilities exist. Check
with your Local Authority or local store for recycling advice.
RATING LABEL EXPLANATION
TTB776VAC
TT = TITAN
B= 240V AC
776 = Model Number
VAC = Vacuum Cleaner

14
TTB776VAC by TITAN
Getting Started ...
Your product
Your product
16b
17 18
24a
24
19
22 23
16a
16
1
8
20
21
2
3
4
5
6
7
9
10 11
12
14
15
13

15
TTB776VAC by TITAN
Getting Started ...
Your product / Technical specications
1. On / off switch 14. Hook (for cord storage)
2. Synchro socket 15. Air outlet
3. Plastic clasp (x 2) 16. Hose
4. Tank a. Hose handle
5. Rear wheel (x 2) b. Hose connector
a. Screw* (x 2) 17. Extension tube (x 2)
6. Anti-static chain 18. Crevice nozzle
7. Castor (x 2) 19. Brush with rubber/bristle blade
a. Screw* (x 2) 20. Round dust brush
8. Drainage port 21. Power tool hose adaptor
a. Drain cap* 22. Foam sleeve
9. Air inlet 23. Cartridge lter
10. Motor unit 24. Dust bag
a. Safety valve* a. Opening
11. Transportation handle
12. Attachment storage
13. Power cord
NOTE: Parts marked with * are not shown in this overview. Please refer
to the respective section in the instruction manual.
Technical specications
> Rated voltage, frequency : 220 - 240 V~, 50/60 Hz
> Rated power input : 1400 W
> Maximum wattage from synchro socket : 1720 W
> Vacuum pressure : Max 20kPa
> Tank volume : 30 L
> Degree of protection : IPX4
> Protection class : Class I
> Net weight : 7.5 kg
> Dimensions : 36 x 35 x 59.2 cm

16
TTB776VAC by TITAN
Getting Started ...
Before you start
Unpacking
Unpack all parts and lay them on a at, stable surface.
> Remove all packing materials and shipping devices, if applicable.
> Make sure the delivery contents are complete and free of any damage. If you
nd that parts are missing or show damage do not use the product but contact
your dealer. Using an incomplete or damaged product represents a hazard to
people and property.
> Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
WARNING! The product and the packaging are not children’s toys!
Children must not play with plastic bags, sheets and small parts! There is
a danger of choking and suffocation!
You will need
(items not supplied) (items supplied)
Suitable personal protective equipment
Suitable crosshead screwdriver
Hose (16)
Extension tube (x 2) (17)
Crevice nozzle (18)
Brush with rubber/bristle blade (19)
Round dust brush (20)
Power tool hose adaptor (21)
Foam sleeve (22)
Cartridge lter (23)
Dust bag (24)
Accessories
A choice of accessories and attachments are supplied with this product. These
are stored inside the product and need to be removed before assembly.
> Unlock the plastic clasps (3) and
disassemble the motor unit (10)
and tank (4) (Fig. 1).
> Take the accessories /
attachments out of the
tank.
> Check all components for
damage and wear before
assembly and operation.
4
3.
1.
2.
10
3
Fig. 1

17
TTB776VAC by TITAN
Getting Started ...
17
Illustration Description Possible application
Castors (7) /
Rear wheels (5) /
Hose (16) Connect the hose (16) to the air
inlet / outlet (9, 15)
Hose handle (16a) Connect attachments / accessories
onto the hose handle (16a)
Extension tube (17)
Connect onto the hose handle
(16a) with other attachments /
accessories
Crevice nozzle (18)
Crevices, corners, cracks and
other places hard to reach.
Brush with rubber/bristle
blade (19)
Rugs, carpets, car seats and oors.
Brush with rubber/bristle
blade (19)
Tiles, wooden oors, linoleum.
Round dust brush (20) Furniture
Power tool hose adaptor (21)
Connect onto the hose handle (16a)
with power tool during synchro
socket operation.
Foam sleeve (22) Prevent liquid mist entering the
motor.
Before you start

18
TTB776VAC by TITAN
Getting Started ...
Cartridge lter (23) Filter ner particles to protect the
motor (10).
Dust bag (24) Collect debris and large dust
particles.
Assembly
WARNING! The product must be fully assembled before operation!
Do not use a product that is only partly assembled or assembled with
damaged parts!
Follow the assembly instructions step-by-step and use the pictures
provided as a visual guide to easily assemble the product! Do not
connect the product to power supply before it is completely assembled!
NOTE: Take care of small parts that are removed during assembly or
when making adjustments. Keep them secure to avoid loss.
Tank
> Place the tank (4) upside down on a at, stable surface.
> Align and slide the castors (7) onto the supports. Secure the connection with the
screws (7a), using a suitable crosshead screwdriver (Fig. 2).
Before you start
7a
4
2.
7
1.
Fig. 2

19
TTB776VAC by TITAN
Getting Started ...
Before you start
> Align and slide the rear wheels (5) onto the supports. The rear wheels and the
vacuum base are marked with the numbers 1 and 2. Insert wheel 1 into slot 1
on the back of the vacuum; insert wheel 2 into slot 2 on the back of the vacuum.
Secure the connection with the screws (5a), using a suitable crosshead
screwdriver (Fig. 3 & 4).
> Turn the assembled main body with the castors (7) and rear wheels (5) right way
up and place it on a at, stable surface. Ensure that castors rotate smoothly.
Product congurations
This product is designed for dry and wet vacuuming as well as blowing. Assemble
the accessories and attachments according to the desired operation.
NOTE: Always use the product:
– with cartridge lter (23) and dust bag (24) assembled for dry
vacuuming and blowing (Fig. 5)
– with foam sleeve (22) for wet vacuuming (Fig. 6).
4
5a
5
2.
1.
Fig. 3
Fig. 4

20
TTB776VAC by TITAN
Getting Started ...
Operation
Parts
Dry vacuuming Blowing Wet vacuuming
Motor unit (10) ● ● ●
Tank (4) ● ● ●
Hose (16) ● ● ●
Foam sleeve (22) ●
Cartridge lter (23) ● ●
Dust bag (24) ● ●
Dust collection and blowing
> Place the dust bag (24) into the tank (4). Ensure the dust bag opening (24a) is
located on top.
> Hold the side aps of the dust bag opening (24a) and slide the dust bag opening
(24a) onto the inner opening of the air inlet (9) (Fig. 7). Ensure the connection is
properly sealed.
> Assemble the cartridge lter (23) onto the motor unit (10) (Fig. 8). Ensure the
Before you start
4
4
10
23
24
16 16
10
22
Fig. 5, Dry vacuuming and blowing Fig. 6, Wet vacuuming
