TLS Prime User manual

How to use and care for your TLS Preset
Torque Screwdriver
Tool Specification
Models:Pro, ESD (Torque Range from 0.05 – 13.5 N.m)
Models: Prime (Torque Range from 0.20 – 4.5 N.m)
Repeatability: +/- 6% of Torque Setting (Pro & ESD)
+/- 10% of Torque Setting (Prime)
ISO 6789 Class: Type 2, Class F (Pro & ESD only)
Calibration Period: Every 12 Months or 5000 cycles minimum (Pro & ESD)
Mechanism: Slipping - Incorrect tightening is impossible
EPA Compliant: ESD versions only
Safety & Maintenance
This Torque Tool is a precision instrument and should be used for its
intended purpose only
Only hold the tool using the handgrip
Always ensure that the tool is in correct alignment with the fastener
Torque tools should be regularly calibrated and inspected to ensure correct
operation
Ensure the tool is clean and free from oil, grease and water before use
Do not use extension bars to increase the leverage of the handle
Never dip into cleaning fluid or petroleum
Torque Limiting Screwdriver
–
Prime, Pro &ESD
Operators Manual
Instructions Part umber P34980 Issue 6
Preset Torque Screwdrivers
Prime, Pro & ESD
Drehmomentbegrenzende Schraubendreher,
Tournevis dynamométrique a Pre-Reglage,
Atornilladores Con Limitador De Par – Grifiviti Limitadori Di Coppia

How to adjust your Torque Screwdriver
To check setting:
Use a Torque Analyser.
To adjust the torque setting:
Use a 5 mm hexagon key to remove the end cap
Fitted to Pro and ESD models, in an anti-clockwise
Direction. Also remove the T-bar where fitted.
To increase the torque:
Use a 2.5mm hexagon key to loosen the adjuster
locking screw by ½ a turn. Insert the
5mm hexagon key into the adjuster and turn PRIME
Clockwise. Tighten the locking screw to 1.5N.m
Using the 2.5mm hexagonal key once required
torque value is reached. PRO
To reduce the torque:
Use a 2.5mm hexagon key to loosen the adjuster
locking screw by ½ a turn.
Insert the 5mm hexagon key into the adjuster
and turn anti-clockwise below the required setting,
then turn clockwise to approach the new value.
Tighten the locking screw to 1.5N.m using the 2.5mm
hexagonal key once required torque value is reached.
Take 10 consistent readings on the Analyser to
confirm the torque setting.
To use Torque Screwdriver:
The Pro, ESD and Prime Screwdrivers are designed
for use with sockets, screwdriver bits and blades
.
Servicing Information
Regular servicing of your Torque Tool by competent personnel is important to
ensure it continues to perform correctly.
TLS Screwdrivers
–
Prime, Pro & ESD
