TMG TMG-TFN72 User manual

v.2022.12.05
3PT FINISH MOWER
TMG-TFN48/60/72
tttttTFM60/TFM
68/TFM72TFM60/
TFM68/TFM72

www.tmgindustrial.com 2 / 22 TOLL FREE: 1-877-761-2819
CONTENTS
IMPORTANT SAFETY INFORMATION.......................................................................................................................................3
Safety always ..........................................................................................................................................................................3
Transport machinery safely .....................................................................................................................................................4
Safety Labels...........................................................................................................................................................................4
INTRODUCTION.......................................................................................................................................................................5
Using This Manual...................................................................................................................................................................5
Terminology............................................................................................................................................................................5
Owner Assistance....................................................................................................................................................................5
SECTION 1: ASSEMBLY AND SET-UP ......................................................................................................................................6
Tractor Requirements..............................................................................................................................................................6
Packing Description.................................................................................................................................................................6
Installation Wizard.................................................................................................................................................................10
Tractor Hook-Up....................................................................................................................................................................12
Driveline Installation..............................................................................................................................................................12
SECTION 2: OPERATING INSTRUCTIONS...............................................................................................................................12
Transporting .........................................................................................................................................................................12
Mowing Instructions..............................................................................................................................................................13
Operating Instructions...........................................................................................................................................................13
SECTION 3: ADJUSTMENTS ..................................................................................................................................................13
Leveling the Mower ...............................................................................................................................................................13
Cutting Height Adjustment ....................................................................................................................................................13
3-Point Hitch Adjustments ....................................................................................................................................................14
Belt Tension..........................................................................................................................................................................14
SECTION 4: MAINTENANCE AND LUBRICATION....................................................................................................................14
Maintenance .........................................................................................................................................................................14
Knife Replacement ................................................................................................................................................................14
V-Belt Installation..................................................................................................................................................................14
Storage .................................................................................................................................................................................15
Lubrication............................................................................................................................................................................15
SECTION 5: SPECIFICATIONS & CAPACITIES ........................................................................................................................15
SECTION 6: TROUBLESHOOTING...........................................................................................................................................16
SECTION 7: APPENDIX ..........................................................................................................................................................16
Warranty ...............................................................................................................................................................................16
Bolt Torque ...........................................................................................................................................................................17
PART BREAKDOWN LIST .......................................................................................................................................................17

www.tmgindustrial.com 3 / 22 TOLL FREE: 1-877-761-2819
IMPORTANT SAFETY INFORMATION
Safety always
Thoroughly read and understand the instructions given in this manual before operation. Refer to the “Safety Decal”, read all
instructions noted on them.
Do not allow anyone to operate this equipment who has not fully read and comprehended this manual and who has not been
properly trained in the safe operation of the equipment.
1. Operator should be familiar with all functions of the unit. Operate implement from the driver’s seat only.
2. Make sure all guards and shields are in place and secured before operating the implement.
3. Do not leave tractor or implement unattended with engine running.
4. Dismounting from a moving tractor could cause serious injury or death.
5. Do not stand between tractor and implement during hitching.
6. Keep hands, feet, and clothing away from power-driven parts.
7. Wear snug fitting clothing to avoid entanglement with moving parts.
8. Watch out for wires, trees, etc., when raising implement. Make sure all persons are clear of working area.
9. Turning tractor too tight may cause implement to ride up on wheels. This could result in injury or equipment damage.
Look For the Safety Alert Symbol
The SAFETY ALERT SYMBOL indicates there is a potential hazard to personal safety involved and extra safety precaution
must be taken. When you see this symbol, be alert and carefully readthe message that follows it. In addition to design and
configuration of equipment,hazard controland accident prevention are dependent upon the awareness, concern,
prudence, and proper training of personnel involved in the operation, transport, maintenance and storage of equipment.
Be aware of signal words
A signal word designates a degree or level of hazard seriousness. The signal words are:
DANGER
Indicates an imminently hazardous situation which, if not avoids, will result in death or serious injury. This signal word is limited to
the most extreme situations, typically for machine components that, for functional purpose, cannot be guarded.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury, and includes hazards that
are exposed when guards are removed. It may also be used to alert against unsafe practices.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury. It may also be used to
alert against unsafe practices.
For you protection
Thoroughly read and understand the “safety label” section, read all instructions noted on them.
Shut down and storage
Lower machine to ground, put tractor in park, turn off engine, and remove the ignition key.
Detach and store implements in a area where children normally do not play. Secure implement by using blocks and supports.
Use safety lights and devices
Slow moving tractors, self-propelled equipment, and towed implements can create a hazard when driven on public roads. They
are difficult to see, especially at night.
Flashing warning lights and turn signals are recommended whenever driving on public roads. Use lights and devices provided
with implement.

www.tmgindustrial.com 4 / 22 TOLL FREE: 1-877-761-2819
Transport machinery safely
1. Comply with state and local laws.
2. Maximum transport speed for implement is 20 mph. Do not exceed. Never travel at a speed which does not allow adequate
control of steering and stopping. Some rough terrain require a slower speed.
3. Sudden braking can cause a towed load to swerve and upset. Reduce speed if towed load is not equipped with brakes.
4. Use the following maximum speed - tow load weight ratios as a guideline:
5. 20 mph when weight is less than or equal to the weight of tractor.
6. 10 mph when weight is double the weight of tractor.
7. IMPORTANT: Do not tow a load that is more than double the weight of tractor.
Keep riders off machinery.
Riders obstruct of operator’s view, they could be struck by foreign objects or thrown from the machine.
Never allow children to operate equipment.
Practice safe maintenance
1. Understand procedure before doing work. Use proper tools and equipment. refer to Operator’s
2. Manual for additional information.
3. Work in a clean dry area.
4. Lower the implement to the ground, put tractor in park, turn off engine, and remove key before performing maintenance.
5. Allow implement to cool completely.
6. Do not grease or oil implement while it is operation.
7. Inspect all parts. Make sure parts are in good condition and installed properly.
8. Remove buildup of grease, oil or debris.
9. Remove all tools and unused parts from implement before operation.
10. Prepare for emergencies
11. Be prepared if a fire starts.
12. Keep a fist aid kit and fire extinguisher handy.
13. Keep emergency numbers for doctor, ambulance, hospital and fire department near phone.
Wear protective equipment.
1. Protective clothing and equipment should be worn.
2. Wear clothing and equipment appropriate for the job. Avoid loose fitting clothing.
3. Prolonged exposure to loud noise can cause hearing impairment or hearing loss. Wear suitable hearing protection such as
earmuffs or earplugs.
4. Operating equipment safely requires the full attention of the operator. Avoid wearing radio headphones while operating
machinery.
Avoid high pressure fluids hazard.
1. Escaping fluid under pressure can penetrate the skin causing serious injury.
2. Avoid the hazard by relieving pressure before disconnecting hydraulic lines.
3. Use a piece of paper or cardboard, not body parts, to check for suspected leaks. Wear protective gloves and safety
glasses or goggles when working with hydraulic systems.
4. If an accident occurs, see a doctor immediately. Any fluid injected into the skin must be treated within a few hours or
gangrene may result.
Safety Labels
Your Flail Mower comes equipped with all safety labels in place. They were designed to help you safely operate your implement.
Read and follow their directions.
1. Keep all safety labels clean and legible.
2. Replace all damaged or missing labels. To order new labels go to your nearest TMG dealer or visit our dealer locator at
TMG.com.

www.tmgindustrial.com 5 / 22 TOLL FREE: 1-877-761-2819
3. Some new equipment installed during repair requires safety labels to be affixed to the replaced component as specified
by TMG. When ordering new components make sure the correct safety labels are included in the request.
4. Refer to this section for proper label placement. To install new labels:
a. Clean the area the label is to be placed.
b. Spray soapy water on the surface where the label is to be placed.
c. Peel backing from label. Press firmly onto the surface.
d. Squeeze out air bubbles with the edge of a credit card.
Safety labels
Introduction
TMG welcomes you to the growing family of new product owners. This
implement has been designed with care and built by skilled workers using quality materials. Proper assembly, maintenance, and
safe operating practices will help you get years of satisfactory use from the machine.
The Finish Mowers are designed for Category 1 - three point hitch or Quick-Hitch System mounting. These Fixed Bar Finish
Mowers are ideal for ripping, leveling, finish grading, and backfilling applications at feedlots, outdoor arenas, building sites, and
maintenance operations on farm and ranch lanes or roadways.
Using This Manual
1. This Operator’s Manual is designed to help familiarize you with safety, assembly, operation, adjustments, troubleshooting,
and maintenance. Read this manual and follow the recommendations to help ensure safe and efficient operation.
2. The information contained within this manual was current at the time of printing. Some parts may change slightly to
assure you of the best performance.
3. To order a new Operator’s or Parts Manual contact your authorized dealer. Manuals can also be printed from the TMG
Service & Support Center by your dealer.
Terminology
“Right” or “Left” as used in this manual is determined by facing the direction the machine will operate while in use unless
otherwise stated.
Note: A special point of information that the operator must be aware of before continuing.
Important: A special point of information related to its preceding topic. The intention is that this information should be read and
noted before continuing.
Owner Assistance
The Warranty Registration card should be filled out by the dealer at the time of purchase. This information is necessary to
provide you with quality customer service. If customer service or repair parts are required contact a dealer. A dealer has trained
personnel, repair parts and equipment needed to service the machine.
The parts on your machine have been specially designed and should only be replaced with genuine parts.
Serial Number Plate
For prompt service always use the serial number and model number when ordering parts from your dealer. Be sure to include
your serial and model numbers in correspondence also.

www.tmgindustrial.com 6 / 22 TOLL FREE: 1-877-761-2819
Section 1: Assembly and Set-up
Tractor Requirements
This mower is designed with a 3-Point category 1 hitch. Tractor horsepower rating should not exceed 50 PTO horsepower.
Packing Description
Remove any loose parts or packaging from the crate. Check goods without damage and omission.
FIGURE 1: Your New Mower As It Is Shipped To You
FIGURE 2: The Mower and Accessory In The Crate Packing List
The detailed packing list as the following table.
Item
Description
Qty.
Package Form
1
Wheel bracket assy.
1
Bubble film
2
Mower deck body
1
None
3
Discharge guide and fittings
1
Bubble film
4
Short pivot bar and fittings
2
Bubble film
5
Long pivot bar and fittings
2
Bubble film
6
Wheel frame and fittings
2
Bubble film
7
Upper lift bracket and fittings
1
Bubble film

www.tmgindustrial.com 7 / 22 TOLL FREE: 1-877-761-2819
The detailed description of wheel bracket assembly
FIGURE 3: Wheel Bracket Assembly
Item
Description
Qty.
1
Wheel bracket sub-assembly
1
2
Safety lock pin
1
3
Spacer H=6
1
4
Damping spring
1
5
Spacer H=32
1
6
Spacer H=12
1
The detailed description of discharge guide and fittings
FIGURE 4: Discharge Guide and Fittings
Item
Description
Qty.
1
Discharge guide plate
1
2
Large plain washer 10
7
3
Locknut M10
5
4
Bolt M10x25
5
5
Plain washer 10
3

www.tmgindustrial.com 8 / 22 TOLL FREE: 1-877-761-2819
The detailed description of short pivot bar and fittings
FIGURE 5: Short Pivot Bar and Fittings
Item
Description
Qty.
1
Short pivot bar
1
2
Locknut M16
1
3
Plain washer 16
2
4
Bolt M16x50
1
The detailed description of long pivot bar and fittings
FIGURE 6: Long Pivot Bar and Fittings
Item
Description
Qty.
1
Long pivot bar
1
2
Locknut M16
1
3
Plain washer 16
2
4
Bolt M16x50
1

www.tmgindustrial.com 9 / 22 TOLL FREE: 1-877-761-2819
The detailed description of Wheel Frame and fittings
FIGURE 7: Wheel Frame and Fittings
Item
Description
Qty.
1
Bolt M16x95
2
2
Plain washer 16
4
3
Wheel frame
1
4
Spring washer 16
2
5
Nut M16
2
6
Large plain washer 8
1
7
Spring washer 8
1
8
Bolt M8x16
1
The detailed description of Upper Lift Bracket and fittings
FIGURE 8: Upper Lift Bracket and Fittings
Item
Description
Qty.
1
Upper lift bracket
1
2
Hitch pin -Upper
1
3
Safety lock pin
1
4
Bushing
2
5
Plain washer 16
1
6
Locknut M16
1
7
Bolt M16x110
1

www.tmgindustrial.com 10 / 22 TOLL FREE: 1-877-761-2819
Installation Wizard
The installation wizard will guide you to finish the final assembly of your new mower easily.
1. Tool Required
1/2” Ratchet Wrench with 13mm,16mm,24mm sleeves
17-19,22-24Spanner
Side cutter or Industrial Scissors
Safety Goggles and Gloves Installation
2. Installation
Cut all zip ties and disassemble shipping crate.
Step1: Installing Long, Short Pivot Bar, Upper Lift bracket and Fittings
Remove the packaging of long, short pivot bar, upper lift bracket and fittings
Assemble all above parts on the mower deck body.
Parts:2pcs of long pivot bars, 2pcs of short pivot bars, 1pcs of upper lifting bracket, 4pcs of bolts M16x50, 9pcs of plain
washers 16, 5pcs of locknut M16, 1pcs of bolt M16x110and 2pcs of bushings.
Tighten locknut completely.
FIGURE 9: Installing Long, Short Pivot Bar, Upper Lift Bracket and Fittings
Step2: Installing Wheel Frame and Fittings
Remove the packaging of wheel frame and fittings.
Assemble 2pcs of wheel frames on the mower deck body.
Parts:4pcs of BoltsM16x95, 8pcs of plain washers16, 4pcs of spring washers 16, 4pcs of nuts M16, 2pcs of bolt M8x16, 2pcs
of plain washers 8 and 2pcs of large plain washers 8.
Tighten nut and bolt completely.
WARNING
Raise the mower deck body to ensure that the wheel frame can be installed with enough height.

www.tmgindustrial.com 11 / 22 TOLL FREE: 1-877-761-2819
FIGURE 10: Installing Wheel Frame and Fittings
Step3: Installing wheel bracket assembly and Fittings
Remove the packaging of wheel bracket assembly and fittings.
Assemble wheel bracket assemblies on wheel frame as well as spacers.
Through the combination of spacers with different height to get the mowing height you need.
Parts:4pcs of wheel bracket assemblies.
Use safety lock pin to hold wheel bracket.
WARNING
Make sure all wheel height adjustments are same, otherwise it will lead to uneven mowing.
FIGURE 11: Installing wheel Bracket and Fittings
Step4: Installing discharge guide and Fittings
Remove the packaging of discharge guide and fittings.
Assemble discharge guide on mower deck body using included fittings.
Parts:4pcs of boltsM10x25,3pcsofplainwashers10,7pcsoflargeplainwasher10and5pcsoflocknutsM10.
Tighten all locknuts and bolts completely.

www.tmgindustrial.com 12 / 22 TOLL FREE: 1-877-761-2819
FIGURE 12: Installing Discharge Guide and Fittings
Tractor Hook-Up
1. Be certain that tractor draw bar will not interfere. Move draw bar ahead or remove if required. Draw bar should also be
checked for clearance when unit is being raised for the first time.
2. Align lower link arms of tractor to hitch clevises on mower. Insert lower hitch pins into lower ball swivels and attach link
pins.
3. Attach tractor top link to upper floating hitch on mower with pin supplied. Secure with lock pin.
4. Adjust tractor top link in or out to place upper hitch pin vertically above or slightly behind lower hitch pins to allow mower
flotation. The mower should be run with the back 15 degrees lower than the front.
Driveline Installation
1. Slide driveline end with extended safety cone over spline shaft of gearbox and secure with attaching device.
2. Slide driveline over tractor’s spline PTO shaft and secure with locking device of driveline.
3. Driveline should now be moved back and forth to ensure that it is secure on the PTO shaft of the tractor and mower
gearbox.
4. Attach chain from the driveline shield to one of the upper hitch braces to ensure that the shield does not rotate.
5. Should driveline require shortening:
a. Hold the half-shafts next to each other in the shortest working position andmark them.
b. Shorten inner and outer guard tubes equally.
c. Shorten inner and outer sliding profiles by the same length as the guard tubes.
d. Proper overlap is a minimum of one-half the length of each tube, with both tubes being of equallength.
e. Round off all sharp edges and remove burrs. Grease sliding profiles.
CAUTION
Tractor PTO shield and all mower guards must be always in place during operation!
Section 2: Operating Instructions
Transporting
NOTE: Always disengage PTO before raising mower to transport position.

www.tmgindustrial.com 13 / 22 TOLL FREE: 1-877-761-2819
1. When raising the mower to transport position, be sure that driveline does not contact tractor or mower. Adjust and set the
tractor’s 3-point hitch lift height so that the driveline does not contact mower deck in the fully raised position.
2. Be sure to reduce tractor ground speed when turning, leaving enough clearance so that the mower does not contact
obstacles such as buildings, trees or fences.
3. Select a safe ground travel speed when transporting from one area to another. When traveling on roadways, transport in
such a way that faster moving vehicles may pass safely.
4. When traveling over rough or hilly terrain, shift tractor to a lower gear.
CAUTION
When traveling on publicroads,whether at night or during the day, use accessory lights and devices foradequate warning to
operators of other vehicles. Comply with all Federal, State, and local laws.
Mowing Instructions
1. Clear area to be mowed of objects and debris that might be picked up and thrown by the mower blades.
2. Grass is best cut when it is dry. Mowing wet grass can cause plugging resulting in grass clumps behind the mower.
3. Grass should be mowed frequently as shorter clippings deteriorate faster.
4. If mowing extremely tall grass, it is best to raise cutting height and mow the area, then lower cutting height and mow a
second time at the desired height.
Operating Instructions
Proper servicing and adjustments are the key to the long life of any machine. With careful and systematic inspection of the mower,
costly maintenance, time and repair can be avoided.
Before beginning to mow, the following inspection should be performed:
1. Check oil level in gearbox.
2. Check that all plugs in gearbox have been replaced and tightened properly.
3. Be sure all mower knives, bolts and nuts are tight.
4. Be certain all guards and shields are in place and secure.
5. Grease driveline shaft and all other grease fittings.
6. Clear area to be mowed of rocks, branches and other foreign objects.
7. Lower mower to ground. Set tractor throttle at approximately 1/4 open. Engage PTO to start blades rotating.
8. Operate with 540 rpm PTO tractor.
9. At first begin mowing at a slow forward speed and shift up until the desired speed is achieved - maintaining 540 PTO rpm.
10. Mower knives will cut better at a faster blade speed than at reduced throttle.
11. After mowing the first 50 feet, stop and check to see that the mower is adjusted properly.
12. Do not make sharp turns or attempt to back up while mower is on the ground.
13. Do not engage PTO with mower in the fully raised position. Do not engage PTO at full throttle.
Section 3: Adjustments
Leveling the Mower
NOTE: Tractor and mower should be on level ground.
Leveling can be adjusted at the tractor’s 3-point arms and center link.
Cutting Height Adjustment
The machines cutting height depends upon the position of the rear roller.
1. Remove the bolts that fix the roller on both sides.
2. Lift or lower both sides of roller in equal measurements.
3. Replace bolts and re-tighten.

www.tmgindustrial.com 14 / 22 TOLL FREE: 1-877-761-2819
3-Point Hitch Adjustments
The 3-point hitch system on this mower has been designed for front to back flotation when mowing on uneven terrain. Adjust tractor’s
top center link to place the upper hitch pin vertically above or slightly behind the lower hitch pins. The mower should be run with the
back 15 degrees lower than the front.
The hitch can also be adjusted from side to side by turning the adjustment handle. Turn handle until you have achieved your desired
location.
CAUTION
Engage parking brake, shut off tractor, remove key and disengage PTO before making any heightadjustments!
Belt Tension
CAUTION
Belt drive system under spring tension; use care to avoid bodily harm!
The Belt tension should be checked after the first 20 hours of use. And then every 40 hours of use.
1. Tension on the belt can be adjusted with the belt tension bolt. Turn the bolt until desired tension is achieved. When the
belt has the correct tension the gearbox should be adjusted so that the gearbox extension is running straight (parallel)
with the flail mower. Loosen bolts at the bottom of the gearbox and move gearbox until gearbox extension is running
straight.
2. Excessive tension on the belt may lead to premature failure of belt and drive components.
CAUTION
Excessive tension on the belt may lead to premature failure of belt and drive components. Excessivetension on the belt
may also lead to a safety hazard to the operator or bystanders.
Section 4: Maintenance and Lubrication
Maintenance
Proper servicing and adjustment is the key to the long life of any farm implement. With careful and systematic inspection, you can
avoid costly maintenance, time and repair.
CAUTION
For safety reasons, each maintenance operation must be performed with tractor PTO disengaged,mower lowered completely to
ground and tractor engine shut off with ignition key removed.
1. After using the mower for several hours, check all bolts to be sure they are tight and check drive belt tension.
2. Replace any worn, damaged or illegible safety decals by obtaining new decals from dealer.
Knife Replacement
IMPORTANT：Make sure that the knife is the same length as the others on the mower. This will keep the rotor rotation balanced.
1. Remove bolt and nut.
2. Remove old knife.
3. Install new knife and existing bolt.
4. Secure with nut.
V-Belt Installation
CAUTION
Belt drive system under spring tension; use care to avoid bodily harm!
1. Remove belt guard fender and belt cover.

www.tmgindustrial.com 15 / 22 TOLL FREE: 1-877-761-2819
2. Disengage belt tension by loosening belt tension bolt until belt can be removed.
3. With tension relieved from belt remove old belt from pulleys.
4. Tighten belt tension bolt.
5. Reinstall belt guard and belt guard fender.
Storage
At the end of the working season or when the mower will not be used for a long period, it is good practice to clean off any dirt or
grease that may have accumulated on the mower and any of moving parts.
1. Clean as necessary.
2. Check knives for wear and replace if necessary.
3. Inspect mower for loose, damaged or worn parts and adjust or replace as needed.
4. Store unit inside if possible for longer life.
5. Repaint parts where paint is worn or scratched to prevent rust.
6. Replace all damaged or missing decals.
Lubrication
Driveline Shaft U-Joints
Type of Lubrication: Multi-purpose Grease
Roller Bearing (Both Ends)
Type of Lubrication: Multi-purpose Greas
Cutter Rotor Bearing (Both Ends)
Type of Lubrication: Multi-purpose Grease
Gearbox
Type of Lubrication: SAE 90W Gear Lube
Check oil level in gearbox by removing the plug located on the right-hand side. Oil should be level with bottom of plug hole. Add oil if
necessary, by removing top fill plug and side plug. Add oil until it flows from side plug hole.
Do not overfill!
IMPORTANT: Mower should be level when checking oil in gearbox!
Driveline Profiles
Type of Lubrication: Multi-purpose Grease
Section 5: Specifications & Capacities
Model
TMG-TFN48
TMG-TFN60
TMG-TFN72
Cutting width (W1)
48''(1200mm)
60''(1500mm)
72''(1800mm)
Dimensions (L*W*H)
49''x61''x29''
55''x61''x29''
73''x61''x29''
Cutting Height
1''-4''(25mm-100mm)
Wheel Sizes
210x80mm
No. of Blades
3
Blade Material
65Mn
CAT Type
CAT 1
PTO Speed
540rpm
Power Required
18-30HP
25-40HP
30-50HP
Product Weight
425LBS
458LBS
500LBS
Shipping Weight (G.W.)
525LBS
565LBS
630LBS

www.tmgindustrial.com 16 / 22 TOLL FREE: 1-877-761-2819
Section 6: Troubleshooting
Problem
Solution
Do not try to clean rear discharge area when mower is running. Bodily harm may occur!
Belt slipping
Unplug and clean mower deck.
Remove belt guard shields and clean sheaves.
Replace belt.
Mow at full throttle (540 PTO rpm), check PTO speed and tractor engine.
Patches of uncut grass
Shift transmission to a lower gear.
Tighten belts.
Replace missing knives.
Replace knives.
Excessive vibration
Replace drive belt.
Replace pulleys or align.
Remove belt guard shields & clean debris from belt area & sheaves.
Gearbox noisy
Check lubricant level.
Knives scalping grass
Raise cutting height by adjusting roller.
Change mowing pattern.
Reduce speed turns.
Uneven cut
Shift to a lower gear.
Level mower.
Replace missing knives.
Tractor loaded down by
mower
Mow at full throttle (540 PTO rpm).
Shift to a lower gear.
Clean mower.
Section 7: Appendix
Warranty
TMG warrants to the original purchaser that this product will be free from defects in material and workmanship beginning on
the date of purchase by the end user according to the following schedule when used as intended and under normal service and
conditions for personal use.
Overall Unit and Driveline: One-year.
Blades and Belts: Considered wear items.
This warranty is limited to the replacement of any defective part by manufacturer and the installation by the dealer of any such
replacement part, and does not cover common wear items such as blades, belts, tines, etc. TMG reserves the right to inspect
any equipment or parts which are claimed to have been defective in material or workmanship.
This warranty does not apply to any part or product which in TMG’s judgment shall have been misused or damaged by accident
or lack of normal maintenance or care, or which has been repaired or altered in a way which adversely affects its performance
or reliability, or which has been used for a purpose for which the product not designed. Misuse also specifically includes failure
to properly maintain oil levels, grease points, and driveline shafts.
Claims under this warranty must be made to the dealer which originally sold the product and all warranty adjustments must be
made through such dealer. TMG reserves the right to make changes in materials or design of the product at any time without
notices.

www.tmgindustrial.com 17 / 22 TOLL FREE: 1-877-761-2819
This warranty shall not be interpreted to render TMG liable for damages of any kind, direct, consequential, or contingent to
property. Furthermore, TMG shall not be liable for damages resulting from any cause beyond its reasonable control. This
warranty does not extend to loss of crops, any expense or loss for labor, supplies, rental machinery or for any other reason.
No other warranty of any kind whatsoever, express or implied, is made with respect to this sale; and all implied warranties of
merchantability and fitness for a particular purpose which exceed the obligations set forth in this written warranty are hereby
disclaimed and excluded from this sale.
Bolt Torque
The tables shown below give correct torque values for various bolts and cap screws. Tighten all bolts to the torques specified
unless otherwise noted. Check tightness of bolts periodically, using bolt torque chart as a guide. Replace hardware with the
same strength bolt.
ENGLISH TORQUE SPECIFICATIONS
Bolt Diameter
Bolt Torque
SAE 2
N.m lb-ft
SAE 5
N.m lb-ft
SAE 8
N.m lb-ft
1/4”
8
6
12
9
17
12
5/16”
13
10
25
19
36
27
3/8”
27
20
45
33
63
45
7/16”
41
30
72
53
100
75
1/2”
61
45
110
80
155
115
9/16”
95
60
155
115
200
165
5/8”
128
95
215
160
305
220
3/4”
225
165
390
290
540
400
7/8”
230
170
570
420
880
650
METRIC TORQUE SPECIFICATIONS
Bolt Diameter
Bolt Torque
8.8
N.m lb-ft
10.9
N.m lb-ft
M3
0.5
0.4
1.8
1.3
M4
3
2.2
4.5
3.3
M5
6
4
9
7
M6
10
7
15
11
M8
25
18
35
26
M10
50
37
70
52
M12
90
66
125
92
M14
140
103
200
148
M16
225
166
310
229
M20
435
321
610
450
M24
750
553
1050
744
M30
1495
1103
2100
1550
M36
2600
1917
3675
2710
Torque figures indicated above are valid for non-greased or non-oiled threads and heads otherwise specified. Therefore, do not
grease or oil bolts or cap screws unless otherwise specified in this manual. When using locking elements, increase torque
values by 5%.
Part Breakdown List

www.tmgindustrial.com 18 / 22 TOLL FREE: 1-877-761-2819
TMG-TFN48/TMG-TFN60/TMG-TFN72 Part Breakdown
TMG-TFN48/TMG-TFN60/TMG-TFN72 Part Breakdown List
PART NO.
REF. NO.
PART DESCRIPTION
QTY.
REMARK
1
4030200024
Mower deck weldment
1
TMG-TFN48
4030200025
1
TMG-TFN60
4030200026
1
TMG-TFN72
2
FM120.00.00.000-1
Wheel beam assembly
2
TMG-TFN48
ATFM150.00.00.000-2
2
TMG-TFN60,TMG-TFN72
3
7040100008
Plain washer 16
17
4
7040400008
Spring washer 16
4
5
7030100008
Nut M16
4
6
7010200011
Bolt M16x95
4
7
7040300005
Large plain washer 10
7

www.tmgindustrial.com 19 / 22 TOLL FREE: 1-877-761-2819
8
7040100005
Plain washer 10
27
9
7030500017
Locknut M10
5
10
7010100013
Bolt M10×25
5
11
ATFM150.00.00.000-4
Spindle assembly
3
12
7040400005
Spring washer 10
12
13
7030100005
Nut M10
12
14
7010100019
Bolt M10×35
12
15
4290200009
Blade
3
TMG-TFN48
4290200010
3
TMG-TFN60
4290200011
3
TMG-TFN72
16
7040400011
Spring washer 24
3
17
7030400003
Hex. Nut M24x2 - L thread
3
18
7040100006
Plain washer 12×2.5
12
19
7030500006
Locknut M12
6
20
7010100004
Bolt M12×30
6
21
4010000139
Pulley cover -L
1
TMG-TFN48
4010000143
1
TMG-TFN60
4010000147
1
TMG-TFN72
22
4100200021
Rubber plug φ30
2
23
7040300004
Large plain washer 8
6
24
7040400004
Plain washer 8
6
25
7010100017
Bolt M8×16
6
26
4010000138
Pulley cover -R
1
TMG-TFN48
4010000142
1
TMG-TFN60
4010000146
1
TMG-TFN72
27
FM150.00.00.000-1
Gearbox drive assembly
1
28
4050000015
Single sheave pulley
2
29
4050000014
Driven pulley
1
30
4150100013
Belt B1448Li (1488Ld)
2
4150100012
Belt B1626Li (1666Ld)
2
4150100015
Belt B1829Li (1869Ld)
2
31
4010000137
Long pivot bar
2
TMG-TFN48
4010000140
2
TMG-TFN60
4010000145
2
TMG-TFN72
32
7030500008
Locknut M16
4
33
7010100034
Bolt M16x50
4

www.tmgindustrial.com 20 / 22 TOLL FREE: 1-877-761-2819
34
4010000141
Short pivot bar
2
35
4020000001
Hitch pin - lower
2
36
7040200010
Plain washer 22
2
37
7040400010
Spring washer 22
2
38
7030100010
Nut M22
2
39
4300100004
Safety lock pin φ11x50
3
40
4020000170
Driven pulley sleeve
2
41
7030500020
Locknut M16
1
42
7010200010
Bolt M16x110
1
43
4020000017
Hitch pin - upper
1
44
4010000076
Discharge guide
1
TMG-TFN48
4010000070
1
TMG-TFN60
4010000148
1
TMG-TFN72
45
4010000144
Hitch connecting bracket
1
46
7040100013
Plain washer 18x34x3
3
47
7030800002
Locknut M18x1.5
3
TMG-TFN48/TMG-TFN60/TMG-TFN72 Gearbox Assembly Breakdown
