TMI Products VD3 Series Installer manual

ANALOGUE QUARTZ
TECHNICAL GUIDE
&
PARTS CATALOGUE
Cal.VD3 Series
(VD33B/34B)
01032021

Version-01
Cal.VD3 Series
(VD33B/34B)
3 Hands (Hour, Minute, Second) 3 Hands (Hour, Minute, Second)
24 hour hand, Calendar
Two pole stepping motor
Step motor 2 pieces
Electronic circuit reset switch
Electronic circuit reset switch
Second setting device Second setting device
Date setting
Time difference correction
Time difference correction
[ Time ]
Indicated by Hour, Minute, Second and 24 hour hands
[ Dual time of 12 hour regulator and dual time of 60 minute regulator ]
± 1 hour / push
SR920SW (Silver oxide battery)
Battery life is approximately 3 years
Use 10 second gate
*Set the winding stem with crown at the normal position
0 Jewel
Free Free
Free
Date setting
- 1 hour / push Time difference correction
+ 1 hour / push Time difference correction
Additional mechanism
Buttons
Button A
Button B
Normal position
First
click
Left rotation
Right rotation
Crown
position
Jewels
Second click
1
SPECIFICATION
Cal. No.
Item
Movement
Movement
size
Outside diameter
Casing diameter
Total height
Time indication
Driving system
Antimagnetic
Accuracy
Battery
Measuring gate by quartz tester
VD33B
VD34B
3.97 mm
4.57 mm
φ29.50 mm × 26.00 mm (3H-9H)
φ28.80 mm
Dual time of 12 hour regulator and dual time of 60 minute regulator hands
Dual time of 12 hour regulator hand
Dual time of 60 minute regulator hand
Dual time of 12 hour regulator hand
Dual time of 60 minute regulator hand
-
Time setting with stop-second device
Time setting with stop-second device
Less than ± 20 seconds : Monthly rate at normal temperature range
≧1600 A/m

Version-01
Cal.VD3 Series
(VD33B/34B)
Lubricating : Types of oil
Oil quantity
Disassembling procedures Figs.
→Moebius 9010 NORMAL QUANTITY
Reassembling procedures Figs.
→Moebius 9030
S-6
0012 079
0808 368 (Cal.VD33 only)
Auxiliary train wheel bridge screw
Date dial guard
*Date dial (Cal.VD33 only)
*Auxiliary train wheel bridge
0806 368 (Cal.VD33 only)
0810 368 (Cal.VD33 only)
Date corrector wheel Date jumper
0737 891 (Cal.VD33 only)
0836 369 (Cal.VD33 only)
0886 003 Intermediate wheel for date
corrector holder
0962 891 (Cal.VD33 only)
*12 hours
wheel
0962 891 (Cal.VD33 only)
0886 001 0885 002
*Hour wheel
*Refer to page 5 foreach parts code
PARTS CATALOGUE
⑯
⑰
①
③
④
⑥
⑦
⑧
⑨
⑫
Intermediate 12 hours
wheel and pinion (B)
②
⑤
⑩
Intermediate wheel for
date corrector (D)
⑱
⑪
2
⑭
⑮
*Small minutes
wheel
Intermediate wheel for date corrector (C)
Intermediate wheel for date corrector (B)
Intermediate small minute
wheel
Intermediate
12 hours
wheel and
pinion (A)
⑬
㊺
㊺
①
*Refer to page 5 for each parts code
*Refer to page 5 for each parts code
①

Version-01
Cal.VD3 Series
(VD33B/34B)
Lubricating : Types of oil
Oil quantity
Disassembling procedures Figs.
→Moebius 9010 NORMAL QUANTITY
Reassembling procedures Figs.
→Moebius 9030
S-6
Battery
Winding stem
0351 177 (Cal.VD33)
0012 079 0351 178 (Cal.VD34)
Switch spring screw 0012 079
Switch spring screw
Switch spring
4250 332 (Cal.VD33)
4250 342 (Cal.VD34)
4004 319
Circuit block
0012 079
Train wheel bridge (B) screw
4270 358
0125 331 Battery connection (-)
Train wheel bridge (B)
4146 177
Step rotor (B)
4002 923
Coil block (B)
4239 357
Rotor stator (B)
0701 014
Fifth wheel and pinion (B)
㉕
PARTS CATALOGUE
①
㊺
㊺
①
⑲
⑳
㉑
㉑
㉒
㉓
3
㉔
㉖
㉗
㉘
㉘
㉚

Version-01
Cal.VD3 Series
(VD33B/34B)
Lubricating : Types of oil
Oil quantity
Disassembling procedures Figs.
→Moebius 9010 NORMAL QUANTITY
Reassembling procedures Figs.
→Moebius 9030
S-6
0125 248
Train wheel bridge (A)
*Fourth wheel and pinion
0701 904
Fifth wheel and pinion (A) 0231 904
Third wheel and pinion
4146 890
Step rotor (A) 0261 150
Minute wheel and pinion
Center wheel and pinion
0221 203 (Cal.VD33)
0221 205 (Cal.VD34)
0281 904
Setting wheel
4002 904
Coil block (A)
0384 470
Yoke
4239 357
Rotor stator (A) 0282 890
Clutch wheel
0962 890
(Cal.VD33 only)
*Refer to page 5 for each parts code
㉛
㉜
PARTS CATALOGUE
①
㊺
㊺
①
㉞
㉝
㉟
㊱
㊲
4
㊳
㊴
㊶
*Train wheel
setting lever
㊷
*Setting lever
㊸
㊵
㊹
㊺
Intermediate wheel
for date corrector
(A)
*1
*1

Version-01
Cal.VD3 Series
(VD33B/34B)
Remarks:
Date dial (Cal.VD33 only)
*All parts code are subject to change without notice.
5
3H
3H
White
Black
Page
㊶
4
㉜
㊷
⑱
White
⑰
PARTS CATALOGUE
Position of
date frame
Color of
figure
Color of
background
No
Parts form
Parts code
Small hour hand wheel
(Cal.VD33)
0157 006
0157 130
12 hours wheel
0902 016
③
Part code
Position of
crown
0878 221
Parts name
0878 220
3H
3H
Parts code
Black
2
④
⑦
⑧
⑭
Parts form
VD33
VD34
Auxiliary train wheel bridge
0126 368
0126 357
24 hour hand wheel
(Cal.VD34)
Intermediate date driving wheel
(Cal.VD33)
0817 368
0817 357
Intermediate small hour hand
wheel (Cal.VD34)
0902 015
Small minutes wheel
0888 014
0888 013
Hour wheel
0271 407
0271 406
Fourth wheel and pinion
0241 178
0241 177
Train wheel setting lever
0391 368
0391 357
Setting lever
0383 368
0383 470

Version-01
Cal.VD3 Series
(VD33B/34B)
・The explanation here is only for the particular point of Cal.VD33&VD34
1.REMARKS ON INSTALLING THE BATTERY
(1) Battery
・How to install the battery
Remove the hook of the switch springs battery clamp portion.
Insert the battery sideways, and have the hook of the switch springs battery clamp portion catch
the main plate.
Battery clamp position
Hook Main plate
Hook
(2) After the battery is replaced with a new one or after the
battery is reinstalled following the repairing procedures,
Be sure to touch the short-circuit the AC terminal of circuit Tweezers
block and the switch spring with conductive tweezers
to reset the circuit as illustrated at right.
(3) When the battery replaced with a new one, the time information stored in the built-in IC and the time
indicated by the dual time of 12 hour regulator and dual time of 60 minute regulator hands do not
correspond with each other.
Reset the dual time of 12 hour regulator and dual time of 60 minute regulator hands to "0" position
following the procedure below.
If the dual time of 12 hour regulator and dual time of 60 minute regulator hands should move
improperly, also follow the same procedure.
Note
Refer to page 8 for each adjustment method.
6
TECHNICAL GUIDE
①
②

Version-01
Cal.VD3 Series
(VD33B/34B)
2.To remove the winding stem
(1) set the winding stem to normal position.
(2) While pushing the indented portion of the arrow, pull out the winding stem.
Push
3.How to attach hands
Please put on the metal plate so as to
avoid 6 protrusions.(Right figure:place of red circle)
*Install the hour, minute and second hands at the "12" o'clock position.
*Install the 24 hour indicator at the "24" position.
*Install the dual time of 12 hour regulator and
dual time of 60 minute regulator hands
at the "12" and "60" position respectively.
[ Reference ] The power of press hands
Minute & Hour Hands < 5kg
Second Hand < 5kg
24 hour indicator < 3kg
Dual time of 12 hour regulator hand < 3kg
Dual time of 60 minute regulator hand < 3kg
TECHNICAL GUIDE
7
Metal plate

Version-01
Cal.VD3 Series
(VD33B/34B)
Minute hand Button A: - 1 hour / push
Hour hand First position
VD33:First setting
VD34:Time setting
(Difference in time correct, move Second setting
together with dual time 60 minute
VD33:Time setting
regulator hand) Crown at normal position
Second hand Button B: + 1 hour / push
Dual time of 60 minute regulator hand
(Difference in time correct, move together 24 hour hand
with dual time 12 hour regulator hand) (Indicates the time on a 24 hour basis)
Note
*Dual time of 60 minute regulator hand rotates one revolution every 15 minute.
There is no problem because this is typical function.
Before setting the time, check if the dual time of 12 hour regulator and dual time of 60 minute regulator
hands are in the "0" (12 o'clock) position.
If either of the dual time of 12 hour regulator and dual time of 60 minute regulator hands are not in the
"0" position, reset them following the procedure below.
The battery setting and after battery change, please execute the "0" position adjustment.
1.Pull out the crown.
3.Press button A or B to reset the
4.Push the crown back to
VD33:second click dual time of 12 hour regulator and the normal position.
VD34:first click dual time of 60 minute regulator
hands to "0" position.
2.Keep the buttons A & B *By pressing button A the hands
pressed at the same time move counter clockwise.
more than 2 seconds, *By pressing button B the hands
and then release the buttons. move clockwise.
*Dual time of 60 minute regulator *Press and hold the button,
hand moves. Returned to where possible to fast-forward modification.
it was. *Dual time of 12 hour regulator hand are
linked to dual time of 60 minute regulator hand.
Note
Please repeat above 4 steps, as 0 position adjustment, if the dual time of 60 minute regulator hand
moves as follows;
Up to 1 minute to 14 minutes, one step / push, in 15 minutes, repeat the one rotation / push
8
OPERATION
DISPLAY AND CROWN / BUTTON OPERATION
Dual time of 12 hour regulator hand adjustment
Dual time of 12 hour regulator hand
Dual time of 12 hour regulator hand adjustment
A
B
A
B
ADJUSTING THE DUAL TIME OF 12 HOUR REGULATOR AND DUAL TIME OF 60 MINUTE REGULATOR HANDS POSITION

Version-01
Cal.VD3 Series
(VD33B/34B)
1.Pull out the crown when the second hand is at the
12 o'clock position.
[ Crown position ]
VD33:Second click
VD34:First click
2.Turn the crown to set the hour and minute hands.
(Check that 24 hour hand is set correctly)
3.Push the crown back normal position in accordance with
a time signal.
Note
*The 24 hour hand moves correspondingly with the hour hand.
*The moment the date changes is midnight. when setting the hour hand, make sure that AM/PM
is correctly set by using the 24 hour hand as an AM/PM indicator.
*At the time of carrying, dual time of 60 minute regulator hand rotates one revolution every 15 minutes.
There is no problem because this is typical function.
■Using the time different correction
When moving to a country or area which is in a different timezone, the current time in the local time
can be corrected.
1.Crown the normal position.
2.To adjust the time by pressing the button A or B.
*By pressing button A the hands move counter clockwise. - 1 hour / push
*By pressing button B the hands move clockwise. + 1 hour / push
1.Pull out the crown when the second hand is at the
12 o'clock position.
[ Crown position ]
VD33:Second click
VD34:First click
2.To adjust the time by pressing the buttons A or B.
By pressing button A the hands move counter clockwise.
By pressing button B the hands move clockwise.
*Press and hold the button, possible to fast-forward modification.
3.Push the crown back in to the normal position.
Note
Every 15 minutes, dual time of 60 minute hand is one rotation / push.
OPERATION
9
TIME SETTING
TIME SETTING (DUAL TIME OF 12 HOUR REGULATOR AND
DUAL TIME OF 60 MINUTE REGULATOR HANDS)
A
B

Version-01
Cal.VD3 Series
(VD33B/34B)
*Before setting the date, be sure to set the time.
1.Pull out the crown to the first click.
2.Turn the crown to clockwise until the next date appears.
3.Push the crown back in to the normal position.
Note
*Do not set the date during any time between 9:00 P.M. and 1:00 A.M.
Otherwise, the date may not change properly. If it is necessary to set the date during that time period,
First change the time to any time outside it, set the date and then reset the correct time.
OPERATION
10
DATE SETTING (Cal.VD33 only)
