Toa C-A854H User manual

HEATER UNIT
INSTRUCTION MANUAL
C-A854H
Thank you for purchasing TOA’s Heater unit.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your
equipment.
1. SAFETY PRECAUTIONS
• Before installation or use, be sure to carefully read all the instructions in this section for correct
and safe operation.
• Make sure to observe the instructions in this manual as the conventions of safety symbols and
messages regarded as very important precautions are included.
• We also recommend you keep this instruction manual handy for future reference.
Indicates a potentially hazardous situation which, if mishandled, could
result in death or serious personal injury.
WARNING
Indicates a potentially hazardous situation which, if mishandled, could
result in moderate or minor personal injury, and/or property damage.
CAUTION
• Use the unit only with the voltage specified on the unit. Using a voltage higher than that which is
specified may result in fire or electric shock.
• Avoid touching the unit's sharp metal edge to prevent injury.
• When attaching or detaching the unit, be sure to switch off the camera's power and heater's
power. Failure to do so may cause a burn or personal injury.
• Leave the installation of the unit to your TOA dealer because the installation requires expert
experience and skills. The unit may fall off if incorrectly installed, resulting in possible personal
injury.
• Have the unit checked periodically by the shop from where it was purchased. Failure to do so may
result in corrosion or damage to the unit that could cause the unit to fall, possibly causing
personal injury.
• Switch off the power for safety purposes when cleaning or leaving the unit unused for 10 days or
more. Doing otherwise may cause a fire or electric shock.
Printed in Japan
133-05-402-80
Note: The design and specifications are subject to change without notice for improvement.
• Accessories
Mounting screw M3 x 6 ..................................... 3
24V AC, 50/60 Hz
15 W (630 mA)
Turns on at under approx.10°C (50°F)
- 30°C to + 50°C ( - 22°F to 122°F)
103 (W)x 35 (H)x 29 (D)mm (4.0 (W)x 1.4 (H)x 1.1 (D)inch)
(excluding connector and thermostat)
35 g (1.2 oz)
Vandal Resistant Day/Night Camera: C-CV854D-3
Power Source
Power Consumption
Heater operating
temperature
Operating Temperature
Dimensions
Weight
Option
Detach the
connector.
Thermostat
Heat sink Mounting screw
M3x6
2. GENERAL DESCRIPTION
The C-A854H heater unit is designed to be used in conjunction with the 24V AC-type Vandal resist-
ant day/night camera. Installing this heater unit inside the camera allows the camera to be used at
low temperature environment as low as
- 30°C ( - 22°F). The heater turns on when internal
temperature of the camera drops below approx.10°C (50°F), and turns off when it rises.
3. HANDLING PRECAUTIONS
• Heater unit could be very hot. Do not touch the heater unit by hand directly while it is operating or
just after its power has been turned off. Do not touch the heater unit for over 30 minutes after the
heater's power has been turned off.
• When the ambient temperature of the camera is below
- 10°C (14°F), turn on the heater's power,
then turn on the camera's power after internal temperature of the camera has risen.
• Condensation in the dome cover due to rapid temperature change, snow and ice on the dome
cover cannot be removed.
4. ATTACHING THE HEATER
1. Detach the dome cover from the case.
For details, refer to the instruction manual
attached to the camera.
2. Detach the inner cover.
For details, refer to the instruction manual
attached to the camera.
3. Attach the thermostat and heat sink using the
supplied mounting screws.
4. Detach the connector of the camera itself
and insert the connector of the heater unit in
place.
5. SPECIFICATIONS
