Toa ER-604W User manual

HIGHLIGHTS
Portable Shoulder Megaphone for applications requiring mobile
sound reinforcement such as tour guides,product demonstrators and
event announcers.
Compact and Lightweight
Rugged Construction
ProvenTOA Quality and Reliability
Powerful 10 Watt Amplifier
Rated Distance:525’
Detachable Handheld Microphone with press-to-talk switch and
adjustable volume control
Whistle Alert Tone — pushbutton-activated
Two Microphone Inputs — for optional headset and/or handheld
microphones
Line Input for CD player or other sound source
Battery Powered (8 x AA) —with low battery indicator
Standby Mode — preserves battery life when using external
microphone or line inputs.
Five YearWarranty
THETOA ER-604W SHOULDER MEGAPHONE
is the ideal solution for applications requiring
mobile sound reinforcement such as tour
guides,product demonstrators and sporting
events.
Compact,lightweight and easy to operate,
the ER-604W has a built-in 10 watt amplifier,
cone speaker,detachable handheld micro-
phone and a pushbutton-activated whistle
alert tone. Other features include two
microphone inputs for optional headset
and/or handheld microphones plus a line
input for CD player or other sound source.
Eight AA batteries provide twenty hours of
continuous operation with a flashing low
battery status indicator.A standby mode
preserves battery life when using the external
microphone or line inputs.An external AC
input allows fixed location use.
The ER-604W Shoulder Megaphone is
backed with a five year warranty.
APPLICATIONS
 Auctions
 AV Rentals
 Crowd &Traffic Control
 Emergency & Event Control
 Evacuation Instructions
 Factory Tours
 Industrial
 Marine
 Police & Paramedic
 Fire & Rescue
 Public Address
 MuseumTours
 Parks & Recreation
 Press Conferences
 Product Presentations
 Public Gatherings
 Sporting Events
 Tour Guides
 Tradeshows
 Training Seminars
ER SERIES
ER-604W
SHOULDER
MEGAPHONE
OPTIONAL ACCESSORIES
WH-4000H Headset Microphone
WH-4000A Headset Microphone,Moisture-Resistant
DM-1200 Handheld Microphone w/ 25 ft.Cable

ER-604W
SHOULDER MEGAPHONE
Tel:[phone]
Fax:[phone]
www.toaelectronics.com
SPECIFICATIONS
LiteratureOrder#:L-ER-604W
Specificationssubjecttochangewithoutnotice.
©2003TOAElectronics,Inc.
DIMENSIONAL DRAWING
Rear View
Top View
Side View
UNIT:mm
Front View
258
1000 mm in length
219
102 216
N29
"
WITH WHISTLE SIGNAL
ASSEMBLED IN INDONESIA
ENGINEERED IN JAPAN,
TO PREVENT DAMAGE THE EAR.
NEVER USE CLOSE TO THE EARS.
!
!
BATTERY: R6P, SIZE C15"8PCS. (DC12V)
OUTPUT POWER: RATED 6W / MAX.10W
COMPACT MEGAPHONE
TOA Corporation
model ER-604W
WARNING
AUXMIC1
R6P,SIZE"AA"
8PCS
EXTERNAL INPUT
MIC2
C
O
P
N
E
S
E
L
O
EXT.
ON OFF
PUSH
VOICE
SWITCH
ORIENTATION
BATTERY
POWER
CONDENSER
ELECTRET
MOVING COIL
0.8A
DC 12V
MIC.
MIC.
PUSH ON
WHISTLE
CHECK
BATTERY
OFF
ON
PUSH
EXT. MIC/AUX
VOLUME
ModelNo. ER-604W
PowerSource 8xAAbatteries(LR6)
ExternalPower: 12VDC/0.8A
RatedOutput 6W
MaximumOutput 10W
BatteryLife Voice: Approx.20hours(w/alkalinebatteries)
Whistle: Approx.90minutes(continuoususe)
AudibleRange Voice/Whistle: 525ft.(160m)
(ambientnoiselevelof55dB)
Microphone Close-talkingtypew/press-to-talkswitchand
volumecontrol
Signal Whistletone,pushbuttonactivation
Input MIC1: -40dBV,1.5kΩ,6.3mm(1/4”)phonejack
MIC2:-18dBV,3kΩ,3.5mm(0.14”)mini
jack,w/phantompower
AUX: -12dBV,18kΩ,3.5mm(0.14”)minijack
ExternalPower: 12VDC
OtherFunctions Voiceswitch: preservesbatterypowerwhen
noexternalinputsignalispresent(MIC1/2
andAUX).
BatteryCheck: flashestoindicatelowbattery
status.
Finish Body,microphone: ABSresin,off-white
Shoulderpad,belt: Black
Dimensions(WxHxD) 4.08"x10.32"x8.64"
(102x258x216mm)
Weight(withoutbatteries) 3.5lbs.(1.6kg)
Accessories(included) 3.5mm(0.14”)miniplug: 1
Externalpowersupplycord: 1
Options WH-4000HHeadsetMicrophone
WH-4000AHeadsetMicrophone,Moisture-
Resistant
DM-1200HandheldMicrophonew/25ft.
Cable
