PROFESSIONAL SOUND SYSTEM
Mini Subwoofer System
Model FB-10
General Description
The FB-10 is designed as a subwoofer system for the *F-
series speaker system.
*F-series Speaker System
F-10W, F-10B
F-150W, F-150G, F-150R
F-300W, F-300G, F-300R
Specifications
Enclosure: Port radiation type
Speaker: 16 cm cone speaker
Impedance:
Power Handling Capacity
Continuous Pink Noise: 60W (40-20,000Hz) 20W (40-100Hz)
Continuous Program: 180W (40-20,000Hz) 60W (40-100Hz)
Sensitivity: 83dB (1W/1m)
Frequency Response: 40Hz - 100Hz
Finish (Enclosure): Urethane coated (Black)
Dimensions: 700(W) x 212(H) x 212(D) mm
27.6(W) x 8.3(H) x 8.3(D) inches
Weight: Approx. 9 kgs (20 Ibs.)
Specifications are subject to change without notice for
improvements.
Features
1. The FB-10 is a high input capacitance, mini subwoofer
system using a 16 cm woofer.
2. By adopting a port radiation type enclosure, the FB-10
can reproduce super low frequency sound with less
distortion despite its compact size.
3. The FB-10 can be installed on the wall or the ceiling
with the optionally available BY-10 fitting.
Instruction Manual
TOA Corporation
KOBE, JAPAN

Wherever you install the system, the FB-10's exclusive capability of reproducing a low frequency
range of 100Hz or less substantially lowers directional sensitivity; therefore, you are not able to
detect from which direction the sound is coming. As such a low frequency sound with long
wavelength is easy to diffracted, satisfactorily heavy and low frequency sounds can be obtained
even if the system is installed in a location where it cannot be seen.
Accordingly, you are free to set the system anywhere you like: for example, under the table or
sofa, behind a counter, or on the side of a ceiling beam.
Since FB-10 reproduces non directional heavy and low frequency sounds, loudness can be
enhanced if the system is installed in an appropriate location.
There are generally four patterns of installation as illustrated below. In the room where the system
is installed as shown in illustration (A), there are no obstacles around the system and the room
condition is similar to that of an anechoic room. Comparing the room condition shown in (B) with
the above condition (A), the radiation space is half as wide and the sound pressure is about 3 dB
higher. Under the condition illustrated in (C), the radiation space is a quarter of that in (A) and the
sound pressure level is about 6 dB better. And in (D), the radiation space is one eighth of that in
(A) and the sound pressure level is about 9 dB better. Since the installation method affects
loudness as described above, it is strongly recommended to install the system along a wall or in
the corner of a room.
Before you install the system on the floor or along the wall, make sure those structures are
sufficiently stable so as not to cause resonation.
Use an optionally available fitting BY-10 to install the system on the wall or ceiling.
(Note: One BY-10 is available to install only one FB-10.)
Set the crossover frequency to 100 Hz when applying the input by shutting the high frequency
components with a channel divider, a graphic equalizer, or the like. Since the allowable input
capacity lowers if you input the band limited signals, pay special attention to the setting of input
level. (Refer to the specification.)
If an abnormal noise arises, immediately lower the input level to control the excessive input.
Install FB-10 so as not to block the duct part of the system. Further, make a clearance of at least
10 cm in front of the duct.
1.
2.
3.
4.
1 .
2.
3.
Installation
Cautions

1. System using one stereo power amplifier (4 drive)
Mixer or
Preamplifier
Power Amplifier
F-series
Speaker
System
FB-10
2. System using two stereo power amplifiers (8 drive)
Mixer or
Preamplifier
Power Amplifier
F-series
Speaker
System
FB-10
3. 3-D (three dimension stereo reproducing) system
Mixer or
Preamplifier
Power Amplifier
F-series
Speaker
System
In this system only the subwoofer FB-10 is driven by monoral signals.
s
FB-10
MONO
Connection Diagram

TOACorporation
KOBE, JAPAN
Printed in Japan
133-01-235-20
