F SERIES
FB-100
SUBWOOFER
THETOA FB-100 SUBWOOFER isthe
idealsolutionforaddingpowerfullowfrequency
enhancementtocommercial,residentialorretail
soundsystems.
TheFB-100featuresahigh-performance
tuned,portedenclosurewithanacoustic
bandpassfilterdesigntoeliminatetheneed
foranexternalcrossover.Anomni-directional
coveragepatternallowsflexibleplacement
—floor,wall,cornerorceiling.
TheFB-100hasaheavy-duty10"wooferfor
highpowerhandlingandextendedlow
frequencyresponse.Thesolidlyconstructed,
paintableenclosurehasaremovableterminal
blockforloop-throughterminationsandsix
riggingpointsforsuspendedmounting.
Optionsincludeamatchingtransformerfor
connectionoftheFB-100todistributed
speakersystemsanda900SeriesLowPass
FilterModuleforconvenientsystem
equalization.TheFB-100alsocarriesafive
yearwarranty.
LowFrequencyEnhancement
for a wide variety of speaker
system applications including
hotels,houses of worship,
museums,offices,residential
spaces,restaurants,and retail
stores.
Tuned,PortedEnclosure
for deep bass and low distortion.
AcousticBandpass FilterDesign
eliminates need for external
crossover.
Floor,Wall,CornerorCeiling-Mount:
omni-directional coverage allows
flexible placement.
HighPowerHandling:
450 W (Continuous Program)
ExtendedLowFrequencyResponse:
35 - 160 Hz (-10 dB,1/2 space)
HighSensitivity:
94 dB SPL (1 W / 1 m,1/2 space)
Heavy-DutyLoudspeakerComponent:
10" woofer with ferrite magnet
and 2" aluminum voice coil for
efficient heat dissipation.
Solid, Vibration-Free Construction,
top-loaded for simplified
maintenance.
PaintableBlackFinish
RemovableTerminalBlockwith
Loop-ThroughTerminations
for convenient connection of
parallel speakers.
SixRiggingPoints
for suspended mounting.
FiveYearWarranty
OPTIONAL ACCESSORIES
E-07S 900 Series Low Pass Filter Module for convenient system
equalization
MT-S0601 Matching Transformer (60W max.) for 70.7 V/100 V distributed
speaker systems,mountable inside enclosure
HIGHLIGHTS

FB-1OO SUBWOOFER
Tel:[phone]
Fax:[phone]
www.toaelectronics.com
SPECIFICATIONS
ModelNo. FB-100
EnclosureType Portradiation,acousticbandpass
SpeakerComponent 10"(25cm)conewooferwithferritemagnet,
2"aluminumvoicecoil,urethanesurround
Impedance 8Ω
Sensitivity 94dBSPL
(1W/1m,1/2space)
PowerHandling(40-200Hz)
ContinuousProgram: 450W
ContinuousPinkNoise: 150W
FrequencyResponse 35-160Hz
(-10dB,1/2space)
Material/Finish Mediumdensityfiber-board,black
urethanepaint
InputConnector Removableterminalblockwithscrewterminals
(AWG#14-#24).Twopairsof(+)/(-)forinput
andloop-throughterminations.
Mounting Sixriggingpoints(3/8")
Dimensions(WxHxD) 13.94"x22.91"x13.39"
(354mmx582mmx340mm)
Weight 35.3lbs.(16kg)
Options E-07S900SeriesLowPassFilterOutputModule
(100Hz,-12dB/oct.)
MT-S0601MatchingTransformer:
70.7VLine:60W,30W,15W,7.5W
100VLine:60W,30W,15W
Thesubwoofershallbeatuned,portedenclosurewithacousticbandpassfilter
design.Theloudspeakercomponentshallhaveadiameterof10"(25cm)with
ferritemagnet,2"aluminumvoicecoil,urethanesurroundandanominal
impedanceof8ohms.Theratedpowerhandlingfrom40to200Hzshallbe
450WContinuousProgramand150WContinuousPinkNoise.Thefrequency
responseshallbe35-160Hz(-10dB,1/2space).Theoutputsoundpressure
levelshallbe94dBSPL(half-space)atadistanceofonemeterwithonewatt
ofinputpowerapplied.Thesubwooferenclosurematerialshallbemedium
densityfiber-boardwithblackpaintfinishandsixriggingpointsforsuspended
mounting.Theinputconnectorshallbearemovableterminalblockwithscrew
terminalsallowingtwopairsofspeakerwireforinputandloop-through
terminations. Anoptionallowpassfiltermoduleshallbeavailableforsystem
equalization. Anoptionalmatchingtransformershallbeavailablefor
connectingthesubwoofertoadistributedspeakersystem.Thetransformer
shallmountinsidethesubwooferenclosurewithselectablewattagetapsof
60W,30W,15Wand7.5Wat70.7Vlineand60W,30Wand15Wat
100Vline.Theenclosuredimensionsshallbe13.94"Wx22.91"Hx13.39"D
(354mmx582mmx340mm)andtheweightshallbe35.3lbs.(16kg).
ThesubwoofershallbetheTOAFB-100.
ARCHITECT’S& ENGINEER’S
SPECIFICATIONS
Bottom View
Front View
Top View
Side View Rear View
1.58
13.39
13.94
22.91
6-Nut ( 3/8 )
18.90 2.01
2.0118.90
FREQUENCY RESPONSE
TOA Electronics, Inc.
601 Gateway Boulevard
Suite 300
South San Francisco,CA 94080
Tel:[phone] Fax:[phone]
www.toaelectronics.com
TOA Canada Corp.
Tel:[phone] Fax:[phone]
LiteratureOrder#:L-FB-100
Specificationssubjecttochangewithoutnotice.
©2004TOAElectronics,Inc. DIMENSIONAL DRAWING
E-07SLPFIn/Out(1/2Space)
