User’s Manual
Pop-up Gazebo 3×3 m with Carrying Bag
63418, 63419
Illustration similar, may vary depending on model
Please read and follow the operating instructions and safety information prior to initial operation.
Technical changes reserved!
Illustrations, functional steps, and technical data may deviate insignificantly due to continuous further
developments.

© by WilTec Wildanger Technik GmbH Item 63418, 63419 Page 2
http://www.toboli.com 12 2022-1
The information contained in this document may alter at any time without prior notice. No part of this
document may be copied or otherwise duplicated without prior written consent. All rights reserved.
WilTec Wildanger Technik GmbH cannot be held liable for any possible mistakes in this operating man-
ual, nor in the diagrams and illustrations shown.
Although WilTec Wildanger Technik GmbH has made every possible effort to ensure that this operating
manual is complete, accurate, and up-to-date, errors cannot be ruled out entirely.
If you have found an error or wish to suggest an improvement, we look forward to hearing from you.
Send us an e-mail to:
[email protected]
or use our contact form:
https://www.wiltec.de/contacts/
The most recent version of this manual in several languages can be found in our online shop:
https://www.wiltec.de/docsearch
Our postal address is:
WilTec Wildanger Technik GmbH
Königsbenden 12
52249 Eschweiler – Germany
To return your goods for exchange, repair, or other purposes, please use the following address. Atten-
tion! To allow for a trouble-free complaint or return, it is important to contact our customer service team
before returning your goods.
Retourenabteilung
WilTec Wildanger Technik GmbH
Königsbenden 28
52249 Eschweiler – Germany
E-mail: [e-mail]
Tel: [phone]
Fax: [phone]

© by WilTec Wildanger Technik GmbH Item 63418, 63419 Page 3
http://www.toboli.com 12 2022-1
Introduction
Thank you for choosing to purchase this quality product. To minimise the risk of injury, we ask you to
always take some basic safety precautions when using this product. Please read this operating manual
carefully and make sure that you understand it.
Keep these operation instructions in a safe place.
Safety instructions
•The assembly of the gazebo requires two persons. It is not meant to be assembled permanently,
but to be used temporarily for corresponding occasions.
•Make sure that the klick-locks serving for stabilising the bars are always snapped correctly into
place.
•When opening and closing the gazebo, do not apply excessive force. Opening and closing must
be done with the required caution lest the tarpaulin and bars be not damaged.
•During snowfall, you must make sure to remove the charge from the gazebo to avoid damages.
During heavy winds, gusts might get under the gazebo and lift it up. Therefore, as a precaution,
the gazebo should be disassembled when foul weather is expected (heavy rainfall, hail, storm,
heavy snowfall, etc.). It is not suitable for such weather conditions.
•Always fix the tent with the help of the guy ropes and tent pegs included.
Mounting and unmounting
Attention: Follow the instructions carefully to avoid any pinching of your fingers in the moving
parts. The assembly and disassembly of the gazebo requires two persons. Do not open the gazebo
during strong wind; otherwise, material damage and injuries might follow.
Assembly
1. Place the folded-up gazebo in the centre of the area that it should shelter afterwards. Remove
the carrying bag and stand the tent on its feet as shown. The two persons that mount the tent
should be at opposite sides. Grasp two outer legs, slightly lift the frame, and step backwards so
that your arms are fully outstretched.
2. Now grasp your corner above and beneath the tarpaulin. Push your hands together up- and
downwards and take another step backwards until the roof is fully opened. Make sure not to
pinch your fingers and do not pull the bars backwards too hard, as this would result in the sup-
ports bending.
3. Now first engage the slider of one side up using one hand while holding down the top of the leg
with the other hand until the snap button engages in its hole. Repeat this on the three other
corners.
4. Place a foot onto the small plate at the lower end of your support and pull the inner out of the
outer leg bar until the snap button engages in its hole. Repeat this on the three other supports.
5. Square up the tent and attach the hook-and-loop fastener located on the underside of the cover
around the upper part of the supports.
6. To fasten the tent, you can attach the guy ropes at the corner rings and, using the pegs, into
the ground. You may as well engage the pegs through the holes of the lower end of the supports
to fix the gazebo.
Disassembly
1. Remove the tent pegs and guy ropes and open the hook-and-loop fasteners.
2. The two persons that unmount the tent should be at opposite sides. Grasp your support leg,
slightly lift the tent, and loosen the snap buttons of the bars. Slide the inner support leg into the
outer. Repeat this on the three other supports.
3. Untighten the slider underneath the roof on all four corners by exerting a slight upward pressure
with one hand and loosening the snap knob with the other hand. Pull down the slider over the
snap knob.

© by WilTec Wildanger Technik GmbH Item 63418, 63419 Page 4
http://www.toboli.com 12 2022-1
4. Now slightly lift the tent on two opposite sides. Slightly shake the tarpaulin. Pull your hands apart
while stepping towards each other until the tent is about three-quarters closed.
5. Grasp the two outer legs, slightly lift the tent, and close it completely.
6. Before stowing away the gazebo in its carrying bag, make sure that it is entirely dry.
Figures for assembly and disassembly
Assembly

© by WilTec Wildanger Technik GmbH Item 63418, 63419 Page 5
http://www.toboli.com 12 2022-1
Disassembly
Technical specifications
Ground surface (㎝)
300 × 300
Height (㎝)
250
Material
220D Oxford polyester, steel
Colour
63418: grey; 63419: white
