Topcom BUTLER 2562 User manual

Butler 2562
Handleiding
Mode d’emploi
User Guide
Bedienungsanleitung
- v3-
HL_B2562_v3.qxd 24-03-2003 10:01 Page 1

HL_B2562_v3.qxd 24-03-2003 10:01 Page 2

!! Belangrijk !!
Om de ‘Nummerweergave’ te kunnen gebruiken, moet deze dienst geactiveerd zijn
op uw telefoonlijn. Om deze dienst te activeren, hebt U hiervoor meestal een apart
abonnement van uw telefoonmaatschappij nodig.
Indien U geen nummerweergavefunctie hebt op uw telefoonlijn,
zullen de inkomende telefoonnummers NIET op de display van uw
toestel verschijnen.
GB The features described in this manual are published with reservation to modifications.
NL De in deze handleiding beschreven mogelijkheden worden gepubliceerd onder
voorbehoud van wijzigingen.
FLes possibilités décrites dans ce manuel sont publiées sous réserve de modifications.
DDie in dieser Bedienungsanleitung umschriebenen Möglichkeiten, werden vorbehaltlich
Änderungen publiziert.
!! Important !!
Pour utiliser la fonction ‘Caller ID/Clip’ (affichage de l’appelant), ce service doit être
activé sur votre ligne téléphonique. Généralement, vous avez besoin d’un abon-
nement séparé de votre compagnie de téléphone pour activer cette fonction.
Si vous n’avez pas la fonction ‘Caller ID - Affichage Appelant’ sur votre ligne
téléphonique, les numéros de téléphone entrants n’apparaîtront PAS sur
l’écran de votre téléphone.
!! Important !!
To use ‘Caller ID’ (display caller), this service has to be activated on your phone line.
Normally you need a separate subscription from your telephone company to activate
this function.
If you don’t have the Caller ID function on your phone line, the incoming
telephone numbers will NOT be shown on the display of your telephone.
!! Wichtig!!
Zur Verwendung der ‘Rufnummernanzeige’ muss dieser Dienst erst für Ihre
Telefonleitung freigegeben werden. Zur Aktivierung dieser Dienstleistung benöti-
gen Sie meistens ein separates Abonnement Ihrer Telefongesellschaft.
Wenn Sie für Ihre Telefonleitung keine Rufnummernanzeigefunktion
haben, erscheinen die eingehenden Telefonnummern NICHT im Display
Ihres Gerätes.
HL_B2562_v3.qxd 24-03-2003 10:01 Page 3

Safety Instructions
•Only use the charger plug supplied. Do not use other chargers, as this may damage the battery
cells.
•Only insert rechargeable batteries of the same type. Never use ordinary, non-rechargeable
batteries. Insert rechargeable batteries so they connect to the right poles (indicated in the
battery compartment of the handset).
•Do not touch the charger and plug contacts with sharp or metal objects.
•The operation of some medical devices may be affected.
•The handset may cause an unpleasant buzzing sound in hearing aids.
•Do not place the basic unit in a damp room or at a distance of less than 1.5 m away from a
water source. Keep water away from the handset.
•Do not use the telephone in environments where there is a risk of explosions.
•Dispose of the batteries and maintain the telephone in an environment-friendly manner.
•As this telephone cannot be used in case of a power cut, you should use a mains-independent
telephone for emergency calls, e.g. a mobile phone.
Cleaning
Clean the telephone with a slightly damp cloth or with an anti-static cloth. Never use cleaning
agents or abrasive solvents.
4 Topcom Butler 2562
ENGLISH
HL_B2562_v3.qxd 24-03-2003 10:01 Page 4

1. DESCRIPTION OF TELEPHONE 7
1.1 Handset/base Butler 2562 7
1.2 Display 8
2. TELEPHONE INSTALLATION 9
2.1 Connections 9
2.2 Rechargable batteries 9
3. USING THE TELEPHONE 11
3.1 Handset ON/OFF 11
3.2 Choosing menu language 11
3.3 Receiving a call 11
3.4 Making an external call 11
3.5 MakING an internal call 11
3.6 Hands free mode 12
3.7 Internal call transfer 12
3.8 Conference Call 12
3.9 Display of call duration 12
3.10 Microfoon mute 13
3.11 Pause Key 13
3.12 Caller Identification 13
3.13 Redial memory 14
3.14 Calling from the phonebook 14
3.15 Using the alphanumerical keypad 15
3.16 Using the menu 15
4. PERSONALISATION 15
4.1 Adjusting speaker volume 15
4.2 Adjusting the ring volume 16
4.3 Choosing the ring melody 16
4.4 Activation / Deactivation of beeps 17
4.5 Naming handsets 18
4.6 Setting the Date and Time 18
4.7 Changing the PIN code 19
4.8 Setting the dialling MODE 19
4.9 Flash time duration 19
4.10 Automatic answer 20
4.11 Reset 20
Topcom Butler 2562 5
ENGLISH
HL_B2562_v3.qxd 24-03-2003 10:01 Page 5

5. ADVANCED FUNCTIONS 20
5.1 Phonebook 20
5.2 Searching a handset from the base 22
5.3 Choosing priority ringing 22
5.4 Using your telephone with a PABX 23
5.5 Keypad lock 23
5.6 Emergency call (Baby call) 24
5.7 Monitor mode (Baby sit) 24
6. SMS (SHORT MESSAGES SERVICE) 25
6.1. SMS main menu 25
6.2. SMS Setting 26
6.3. Sending SMS Messages 27
6.4. Reading SMS messages 28
6.5. deleting all messages 29
7. MANAGING MULTIPLE HANDSETS 29
7.1 Setting up an ADDITIONAL handset 29
7.2 Removing a handset 30
7.3 Setting up a handset on another base 31
7.4 Selecting a base 31
8. TROUBLE SHOOTING 32
9. GUARANTEE 33
10. TECHNICAL CHARACTERISTICS 33
6 Topcom Butler 2562
ENGLISH
HL_B2562_v3.qxd 24-03-2003 10:01 Page 6

1. DESCRIPTION OF TELEPHONE
1.1 HANDSET/BASE BUTLER 2562
Topcom Butler 2562 7
ENGLISH
Earpiece
Display
SMS
Menu/OK Line-key
Paging Key
Set-up subscription
(press and hold ) Down Key
Call log Key
3 way
Conversation
Internal call
Flash Key
Microphone
Power indicator
Incoming call LED
Handsfree key Charge indicator
Power ON/OFF/
Escape/Mute key
Up arrow/Redial/
Pause key
HL_B2562_v3.qxd 24-03-2003 10:01 Page 7

?New Calls :1
B2562 1
22/04 15h25
?New Calls :1
B2562 1
22/04 15h25
1.2 DISPLAY
Icon line Dot matrix display
Each operation has an associated icon
ICON: MEANING:
You are online
EXT You are in external communication
INT You are in internal communication
Hands free mode activated
rechargeable battery level indicator
The segments scroll during battery recharging
Hand set keypad locked.
The antenna indicates the quality of reception.
The antenna flashes when the handset is not
registered on the base.
or Possible scroll direction in the menu
1.2.1 Standby display
In standby mode, the display shows the:
- Nummers of new calls in the call list, if there are
- Handset name and the handset number
- Date and Time
8 Topcom Butler 2562
ENGLISH
HL_B2562_v3.qxd 24-03-2003 10:01 Page 8

2. TELEPHONE INSTALLATION
2.1 CONNECTIONS
2.2. RECHARGABLE BATTERIES
Before you use your Butler 2562 for the first time, you must first make sure that the batteries are char-
ged for 6-8 hourse. The telephone will not work optimally if not properly charged.
To change or insert a rechargeable battery:
1. Slide the cover towards the bottom and then lift it up.
2. Insert the batteries respecting the (+ and -) polarity.
3. Replace the battery cover
Note: The maximum working time of the batteries is approx. 250h and the maximum talk time is 13 hours! In the
course of time the batteries will start to drain faster. The batteries must be replaced. You can buy new batteries from
any DIY outlet (2 rechargeable batteries, type AAA NiMH)!
Topcom Butler 2562 9
ENGLISH
Telephone cord
bottom view
of base
Power cable
HL_B2562_v3.qxd 24-03-2003 10:01 Page 9

Rechargeable Batteries
back view of hand-set
Cover + -
- +
10 Topcom Butler 2562
ENGLISH
HL_B2562_v3.qxd 24-03-2003 10:01 Page 10

3. USING THE TELEPHONE
3.1 HANDSET ON/OFF
•Turn ON handset: Press shortly (1sec). The handset will search the base.
•Turn OFF handset: Press for 2s. The display will go OFF.
3.2 CHOOSING MENU LANGUAGE
1. Enter the menu by pressing /OK
2. Select HANDSET MENU using the and keys
3. Press OK
4. Select LANGUAGE using the and keys
5. Press OK
6. Select the language of choice by means of the and down keys.
7. Press OK to validate
3.3 RECEIVING A CALL
When the handset rings, press to answer. You are then connected to your correspondent. If the
handset is on the base when the telephone rings, you just need to pick up the handset to answer the
call (if the option autoanswer is set ON: See 4.10. Automatic answer).
If you press when the telephone rings, you pick-up the line and automatically change to handsfree
mode.
3.4 MAKING AN EXTERNAL CALL
Normal numeration:
1. Press
2. Enter telephone number
Block dialling:
1. Dial your correspondents number
2. Press
To correct a number use the key to delete an entered digit
3.5 MAKING AN INTERNAL CALL
Only possible when more than one handsets are registered to the base!!
Topcom Butler 2562 11
ENGLISH
HL_B2562_v3.qxd 24-03-2003 10:01 Page 11

Normal numeration:
1. Press INT for 2 sec.
2. Enter the number of the internal handset (1 to 5)
Prenumération:
1. Enter the number of the internal handset (1 to 5)
2. Press INT for 2 sec.
3.6 HANDS FREE MODE
You can converse with your correspondent without picking up the handset.
To activate or deactivate the hands free mode, press the key during a call.
To adjust the volume, refer to the chapter “ Personalisation “- adjusting speaker volume.
3.7 INTERNAL CALL TRANSFER
Only possible when more than one handset are registered to the base!!
When you want to transfer an external call to another handset:
1. During a conversation press and hold the INT key for 2 s.
2. Select the number of the internal handset, the external caller is put on hold.
3. When the other handset picks up, press to hang up and transfer the call.
If the internal correspondent does not pick-up, press INT for 2 seconds again to reconnect to the
external caller on line.
3.8 CONFERENCE CALL
Only possible when more than one handsets are registered to the base!!
You can converse simultaneously with an internal correspondent and an external correspondent.
When you are on line with an external correspondent:
1. Press and hold the INT key for 2 s.
2. Enter the number of the internal handset that you want to call
3. When the internal correspondent picks- up, press and hold
4. If the internal correspondent does not answer, press INT again for 2 sec. to reconnect to the external
correspondent on-line.
3.9 DISPLAY OF CALL DURATION
The call duration is displayed after 15 seconds, in minutes - seconds,: “00:20”
At the end of each call, the total call duration is displayed for 5 seconds.
12 Topcom Butler 2562
ENGLISH
HL_B2562_v3.qxd 24-03-2003 10:01 Page 12

3.10 MICROFOON MUTE
It is possible to mute the microphone during a conversation.
Press during the conversation, the microphone is then deactivated, you can talk freely without being
heard by the calling party.
“Secrecy On” is displayed.
Press again to return to normal mode.
3.11 PAUSE KEY
When dialling a number you can add a pause between two digits by pressing the redail/pause key
for 3 s.
3.12 CALLER IDENTIFICATION
Caller identification is only available if you have subscribed to this service with your telephone operator.
When you receive an external call, the callers number will appear on the display as the telephone rings.
If the network sends it, or if the name of the caller is in the address book, the caller is identified by his
or her name.
The caller identity is replaced by the call duration after 15 seconds in communication. It is still possible
to display the caller’s identity after this time by pressing OK-key repeatedly for the name and number.
3.12.1 List of calls
Your telephone keeps a list in memory of the last 10 unanswered (missed) calls. This function is only
available if your are subscribed to the caller ID information. The correspondents that have called are
identified by their telephone number or name in the same way as in caller identification. The list also
shows:
-repeat call counter (up till 99): indication of how many times this caller has called
-date and time of this incoming call
Topcom Butler 2562 13
ENGLISH
7 14h35 3O/O4
TOPCOM
O123456789
Time/Date
Repeat call timer
Caller Name
Caller telephonenumber
HL_B2562_v3.qxd 24-03-2003 10:01 Page 13

1. Press . If there are no calls in the list ‘NO ENTRY STORED’ will appear.
2. Scroll through the calls using the up or down arrows. The callers names will be shown if the
name is send by the network or is stored in the phonebook. If you are at the end of the list you will
hear a beep tone.
3. Pressing OK again will give you the option to delete or add this entry in the phonebook if it’s not
already stored:
•Select ‘ADD ENTRY’ and press OK. Enter or modify the name and press OK. The entry will be sto-
red in the phonebook and deleted from the call list!
•Select ‘DELETE ENTRY’ and press OK to delete this entry, or to return to the previous menu.
4. To call back a correspondent, simply press the key when their telephone number or name are
displayed.
If a caller is in the phonebook, they are identified by their name in the list of calls.
Also the date and the time of the call will be shown (if day & time are send together with the caller id
information).
3.12.2. Voice mail indication
This function only works if you have the voice mail or phone mail service and if the network sends this
indication along with the FSK caller ID (CLIP) information!
When you receive a new message in your voice mail system, the icon will appear on the display.
Once you have listened to your message, the icon will disappear.
3.13 REDIAL MEMORY
Your telephone keeps a list of the 10 last calls (of 20digits) you have made in memory; The correspon-
dents called are identified by their telephone number or by their name if they appear in the phonebook.
To consult the redial list:
1. Press
2. Scroll through the calls with the up and down arrows.
3. To call by the selected correspondent, simply press when their telephone number or name is dis-
played.
Note: When name is displayed, you can toggle between name and number by pressing the OK key!
3.14 CALLING FROM THE PHONEBOOK
To call a correspondent whose name you have saved in the phonebook:
1. Enter the menu by pressing /OK.
2. Select ‘PHONEBOOK’ and press ‘OK’.
14 Topcom Butler 2562
ENGLISH
HL_B2562_v3.qxd 24-03-2003 10:01 Page 14

3. Press the first letter of the name. The first name that starts with this letter or the nearest letter in the
alphabet will be displayed.
4. Go through the list of names with the and keys. The list scrolls in an alphabetical order.
5. Press to dial the number of the correspondent whose name is displayed.
To see the number before dialling, carry out steps 1 to 3 from before and press Ok.
3.15 USING THE ALPHANUMERICAL KEYPAD
With your telephone you can also enter alphanumeric characters. This is useful for entering a name into
the phonebook, giving a name to a hand-set, …
To select a letter, press the corresponding key as many times as is necessary. For example to select an
‘A’, press ‘2’ once, to select a ‘B’, press ‘2’ twice and so on. To select ‘A’ and then B consecutively,
select ‘A’, wait until the cursor moves on to the next character, then press ‘2’ twice.
To select a space, press 1.
To select a dash, press ‘1’ twice
The keypad characters under each keys appears on top of the screen whenever a key is pressed!
3.16 USING THE MENU
A wide range of telephone functions are accessible through a user friendly menu.
1. To enter the menu, press /OK
2. Scroll through the selections using the and keys, the selections scroll in a loop ( you return to
the first after the last).
3. To validate a selection, press OK
4. To return to the previous menu, press
4. PERSONALISATION
4.1 ADJUSTING SPEAKER VOLUME
There are two ways to set the speaker volume:
4.1.1 Speaker volume during call
During conversation, press the or key to change the volume accordingly.
4.1.2 Set the default speaker volume
1. Enter the menu by pressing /OK
2. Select HANDSET MENU using the and keys
Topcom Butler 2562 15
ENGLISH
HL_B2562_v3.qxd 24-03-2003 10:01 Page 15

3. Press OK
4. Select EAR VOLUME using the and keys
5. Press OK
6. Select the desired volume (1 to 5 ) by means of the and key.
7. Press OK
A double bleep confirms the validation of your choice
Note: The handsfree volume of the Butler 2562 is also adjust together with the receiver in the handset as above
described!
4.2 ADJUSTING THE RING VOLUME
4.2.1 Handset ring
1. Enter the menu by pressing /OK
2. Select HANDSET MENU using the and keys
3. Press OK
4. Select RING VOLUME using the and keys
5. Press OK
6. Select the desired volume (OFF or 1 to 5 )
7. Press OK to confirm or to return to the previous menu.
Note: Every programmation is confirmed at the end by a double or single long beep. A double bleep confirms the vali-
dation of your choice
A long bleep signifies that the modification has not been taken into account.
4.2.2 Base ring
1. Enter the menu by pressing /OK
2. Select SETUP using the and keys
3. Press OK
4. Select BASE VOLUME using the and keys
5. Press OK
6. Select the desired volume (OFF or 1 to 5 )
7. Press OK to confirm or to return to the previous menu.
4.3 CHOOSING THE RING MELODY
The base and each hand set can ring with a different melody.
The handsets can ring with a different melody according to whether the incoming call is internal or
external.
16 Topcom Butler 2562
ENGLISH
HL_B2562_v3.qxd 24-03-2003 10:01 Page 16

4.3.1 Base melody
1. Enter the menu by pressing /OK
2. Select SETUP using the and keys
3. Press OK
4. Select BASE MELODY using the and keys
5. Press OK
6. Select the melody of your choice ( 1 to 5 ) using the and keys
7. Press OK to confirm or to return to the previous menu.
4.3.2 Handset melody, external call
1. Enter the menu by pressing /OK
2. Select HANDSET MENU using the and keys
3. Press OK
4. Select EXT MELODY using the and keys
5. Press OK
6. Select the melody of your choice ( 1 to 5 ) using the and keys
7. Press OK to confirm or to return to the previous menu.
4.3.3 Handset melody, internal call
1. Enter the menu by pressing /OK
2. Select HANDSET MENU using the and keys
3. Press OK
4. Select INT MELODY using the and keys
5. Press OK
6. Select the melody of your choice ( 1 to 5 ) using the and keys
7. Press OK to confirm or to return to the previous menu.
4.4 ACTIVATION / DEACTIVATION OF BEEPS
The handsets can emit beeptone when a key is pressed, when the batteries are low and when the
handset is out of range.
4.4.1 Key pressed beeptone on/off
1. Enter the menu by pressing /OK
2. Select HANDSET MENU using the and keys
3. Press OK
4. Select WARNING TONES using the and keys
Topcom Butler 2562 17
ENGLISH
HL_B2562_v3.qxd 24-03-2003 10:01 Page 17

5. Press OK
6. Select KEY PRESS using the and keys
7. Press OK
8. Select ON to activate, OFF to deactivate
9. Press OK to confirm.
4.4.2 Low battery
Proceed as before, but select at point 6 "LOW BATTERY" instead of "KEY PRESS".
4.4.3 Handset out of range
Proceed as before, but select at point 6 "OUT OF RANGE" instead of “KEY PRESS".
4.5 HANDSET NAME
This function allows you to personalise each handset.
1. Enter the menu by pressing /OK
2. Select HANDSET MENU using the and keys
3. Press OK
4. Select HANDSET NAME using the and keys
5. Press OK
6. Enter the name
7. Press OK to validate
While entering the name, press to delete a character and press and hold to exit the menu wit-
hout taking any modifications into account.
4.6 SETTING THE DAY AND TIME
1. Enter the menu by pressing /OK
2. Select “SETUP”
3. Press OK
4. Select “TIME SETTING”
5. Press OK
6. Enter day and month and press OK to confirm
7. Enter hours and minutes and press OK to confirm
The new date and time is shown.
Note: The day and time will be automatically set by the network if the network send the date and time together with
the callerID.
18 Topcom Butler 2562
ENGLISH
HL_B2562_v3.qxd 24-03-2003 10:01 Page 18

4.7 CHANGING THE PIN CODE
Certain functions are only available to users who know the PIN code. By default this is PIN code = 0000.
To change the PIN code:
1. Enter the menu by pressing /OK
2. Select SETUP using the and keys
3. Press OK
4. Select PIN CODE using the and keys
5. Press OK
6. Enter the old 4 figure PIN code.
7. Press OK
8. Enter the new 4 figure PIN code
9. Press OK
10. Enter the new PIN code a second time
11. Press OK to validate
4.8 SETTING THE DIALLING MODE
There are two types of dialling mode:
•DTMF/Tone dialling (the most common)
•Pulse dialling ( for older installations )
To change the dialling mode:
1. Enter the menu by pressing /OK
2. Select SETUP using the and keys
3. Press OK
4. Select DIALLING MODE using the and keys
5. Press OK
6. Select the dialling mode using the and keys
7. Press OK to validate
4.9. FLASH TIME DURATION
1. Enter the menu by pressing /OK
2. Select Setup using the and keys
3. Press OK
4. Select RECALL using the and keys
5. Choose RECALL 1 for short flash time (100ms) or RECALL 2 for long flash time (250ms)
Topcom Butler 2562 19
ENGLISH
HL_B2562_v3.qxd 24-03-2003 10:01 Page 19

4.10. AUTOMATIC ANSWER
When there is a incoming call and the handset in on the base, the phone automatically takes the line
when lifted. This is the default setting, but can be set OFF:
1Enter the menu by pressing /OK
2Select HANDSET MENU using the and keys
3Press OK
4Select AUTO ANSWER using the and keys
5Select ON (for automatic answer) or OFF
6Press OK
4.11 RESET
It is possible to return the phone to the original default configuration. This is the configuration which
was installed when you first received the telephone.
To return to default settings:
1. Enter the menu by pressing /OK
2. Select SETUP using the and keys
3. Press OK
4. Select DEFAULT using the and keys
5. Press OK
6. Enter the 4 digit PIN code (default =0000)
7. Press OK to validate
WARNING! Returning to default settings will delete all entries in the phonebook and call log.
The PIN code will also be reset to 0000
5. ADVANCED FUNCTIONS
5.1 PHONEBOOK
The Phonebook allows you to memorise 40 telephone numbers and names. You can enter names of up
to 8 characters length and numbers of up to 20 digits length.
To call a correspondent whose number is stored in the phonebook, refer to the section 3.14
To enter alphanumerical characters, refer to the section 3.15.
20 Topcom Butler 2562
ENGLISH
HL_B2562_v3.qxd 24-03-2003 10:01 Page 20
