Topcon MC-i3 User manual

Hardware Setup, Settings, Pinout, SL-R3 Firmware
Upgrade, GNSS Firmware Upgrade
MC-i3 and SL-100

MC-I3 and SL-100
Topcon Europe Positioning

•Rugged Housing for
Construction Environment
•Ingress Protection:IP-67
•Network RTK Connectivity
•Input Voltage: 9 –32 V DC
•Operating Temp:-30oC to+70oC
Features: SL-100/MC-i3
•New Indicate MC receiver
•Vanguard™ Technology
•Internal SL-R3, Dig UHFII
•Single or Dual GPS configurations
•2 Deutsch connectors serial and
Ethernet to
GX-60 or GX-30
•TNC connectors for radio and GPS
antenna

Dip Switch Settings

Install SIM Card
SL-R3 Antenna
Hardware setup

Hardware

MC-i3 / SL-100 Main B
PC ethernet
connection
Contains:
1001270-01 Ethernet Cable to configure SL-R3
MC-i3 / SL-100 Data cable kit 1001271-01

MC-i3 / SL-100 Data cable kit 1001271-01
Power
Serial 1 –(Main board)
Serial 2 (Aux board)
Contains:
1001269-01 Serial Cable to configure GPS boards
MC-i3 / SL-100 Main A

Connectors pin outs

How to enter the SL-R3 to change settings.
•GX-60 or Computer
•Take 1001269-01 cable to power up the box
only.
•Use 1001270-01 cable for tcp/ip connection to
slr-3

Connect ethernet and powerup the mci3 and follow the steps below.
In “control panel” “network and sharing center” use the “local area connection”
Set Computer Ethernet Port to match with right picture.
Type 192.168.0.1 in your browser( chrome or QT web browser will do)

When prompted for the user name and password,
enter ”admin” for both and click “ok”

Check SL-R3 Firmware

SLR-3 Firmware update:
Select the download of latest firmware release and reboot after loading.
2
3
1
4

Configure SIM Card
Go to settings/ports/gprs
ATD*99***1#
After save all settings Reboot

Check connections and GSM status.

GNNS Firmware update MC-i3 via SLR-3
- Use GX-60 or PC
- Use cable 1001269-01 Power & Serial Cable’s
- Use 1001270-01 cable for tcp/ip connection to slr-3
- Follow procedure described in next slides.

MC-i3 GNNS FW update via GX-60 or PC
Please select serial port 1 and 2 to function with GPS and save

MC-i3 GNNS FW update via GX-60 or PC
Primary GPS
uncheck “Enabled” to disable
gps communication to SLR3.
In case of dual GPS:
Secondary GPS
uncheck “Enabled” to disable
when you update the firmware
for this card too.
Save this and go to
Firmware Upgrade tab.(next slide)
After update and reboot tick “Enabled” in the configuration tab again to
restart using the gps communication to the SLR-3 .(do not forget!)
