Topgreener TGWFRSM1 User manual

Wi-Fi Single Relay Smart Switch Module
Model: TGWFRSM1
INSTALLATION INSTRUCTIONS

Features:
2
•Control lights, fans, humidifiers, and other
small appliances with your smart devices
without the need of any hubs
•Easy to configure, easy to use Smart App
•Save energy by automating the ON/OFF times
or using the timer.
• Compatible with Amazon Alexa, Google
Assistant, and IFTTT

Requirements:
Specifications:
3
•Wi-Fi Internet connection of 2.4GHz. Smart
phone or tablet must be on same network only
for the initial pairing.
•Smart device such as a smart phone or
tablet with an operating system of Android
ver. 4.1 or higher or iOS 8 of higher.
•Installation of the TOPGREENER Smart
App on the smart device.
Rating.......................... 120-240VAC, 50/60Hz
Maximum Load requirement .................... 10A
Wireless Type .................................... 2.4GHz
Protocol .............................. IEEE 802.11b/g/n
Operating Temp...........32°F~104°F(0°C~40°C)
Type 1.B action, operating control

4
FCC Compliance Statement
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions: 1. This device may not cause
interference, and 2. This device must accept
any interference received, including
interference that may cause undesired
operation.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation
exposure limits set forth for an uncontrolled
environment. This equipment should be installed
and operated with a minimum distance of 8in
(20cm) between the radiator & your body.

5
RF Exposure
A distance of 8in (20cm) shall be maintained
between the antenna and users, and the transmitter
module may not be co-located with any other
transmitter or antenna.
WIRING DIRECTIONS
1. Remove the wall plate.
2. Remove receptacle from wall box and prior to
disconnecting wires, identify the wires and
label as needed.
3. Remove wires from existing receptacle.
4. Follow the diagram below to reconnect the
receptacle.

6
WIRING DIRECTIONS
Neutral
91150
Switch
Ground
Load Hot Neutral
Aux
Hot
Neutral Auxiliary
Ground
If Hot and Neutral are located in the wall box,
then wire the TGWFRSM1 this way
Wall box
Power/ Program
Button
Reversible

7
91150
Switch
Ground
Ceiling box
Wall box
If Hot and Neutral are located in the ceiling box,
then wire the TGWFRSM1 this way
Reversible
Neutral Auxiliary

8
Hot
Load
Hot
Neutral
Aux
Power
Neutral
Ground
Neutral

9
2. Connect your Smart Device (phone or tablet)
to the same 2.4GHz Wi-Fi network that your
TGWFRSM1 outlet will be connecting to.
INITIAL SET UP FOR Wi-Fi CONTROL
1. Single Relay Smart Switch Module.

10
3. Use your mobile device and search
“TOPGREENER” from the App Store or
Google Play, then download and install it.
4. Once installed, open the App and follow the
on-screen instructions to register and log-in.
Follow the instructions in the App to connect
the Smart Plug to your network. Over time,
the App may be updated for a better
experience or added features, so be sure to
follow the in-App instructions closely:

11
a. Login tothe App.

12
b.Navigate tothe Devices tab and click “Add
Device” or the “+”button.

13
c. Select the device type “Smart Switch Module”.
Smart Switch Module
In-Wall Outlet and USB

14
d. When prompted to
“Power On the device
and Confirm”, push
and hold the button
on the TGWFRSM1
for 5 secs and the
LED indicator on the
device will start
blinking rapidly.
When LED starts
blinking, press
“Confirm indicator
rapidly blinks”.
Confirm indicator rapidly blinks
Back Add Device
09:40
93%
AP Mode
How to make the indicator rapidly blink
Discovering Device:
Power On the device and click on
Confirm when LED indicator rapidly
blinks

15
e. Enter your Wi-Fi password when prompted
and click confirm.

16
f. After successfully adding the device, you can
change the name of the device if desired.
Smart Switch Module

17
CONFIGURE DEVICE IN AP MODE
AP mode is a secondary
way to configure your
device to work on your
network. Configuration in
this mode requires a
connection from your smart
device to the smart outlet.
To do so, go to the "Add
Device" screen and click
on "AP Mode" at the top
of the screen and follow
the on-screen instructions.
Confirm indicator rapidly blinks
Back Add Device
09:40
93%
AP Mode
How to make the indicator rapidly blink
Discovering Device:
Power On the device and click on
Confirm when LED indicator rapidly
blinks

18
AP mode is a secondary
way to configure your
device to work on your
network. Configuration in
this mode requires a
connection from your smart
device to the smart outlet.
To do so, go to the "Add
Device" screen and click
on "AP Mode" at the top
of the screen and follow
the on-screen instructions.
NOTE:
By default, the app will only allow one user to control the
outlet. To add users, go to your Profile on the app and click
on “Device Sharing” and follow the on-screen instructions.
