Tormek T-7 Sharpening System
TORMEK T-7, SE-76, TT-50, SP-650, WM-200, PA-70, HB-10, DVD-1
TNT-708 Woodturner’s Kit
SVD-185, SVS-50, SVD-110, LA-120, MH-380, TTS-100, TNT-300
HTK-705 Hand Tool Kit
SVM-45, SVM-140, SVX-150, SVA-170, SVS-32
Grinding Jigs
SVM-45 Knife Jig ×
SVM-140 Long Knife Jig ×
SVX-150 Scissors Jig ×
SVA-170 Axe Jig ×
SVS-32 Short Tool Jig ×
SVD-185 Gouge Jig ×
SVS-50 Multi Jig ×
SVD-110 Tool Rest ×
SE-76 Square Edge Jig ×
SVH-320 Planer Blade Attachment
SVP-80 Moulding Knife Attachment
DBS-22 Drill Bit Sharpening Attachment
Accessories
TT-50 Truing Tool ×
WM-200 AngleMaster ×
SP-650 Stone Grader ×
LA-120 Profiled Honing Wheel ×
LA-124 Narrow discs for LA-120
PA-70 Honing Compound ×
TTS-100 Turning Tool Setter ×
MH-380 Machine Cover ×
HB-10 Handbook ×
DVD-1 Tormek DVD ×
TNT-300 Woodturner’s Instruction Box ×
Tormek Special Stones
SB-250 Blackstone Silicon
SJ-250 Japanese Waterstone
The key word when sharpening the Tormek way is
repeatability. The tools are guided in jigs – you remove
only a minute fraction of the steel at each sharpening,
which makes it fast. An extra bene t is that your tools
last longer.
You can shape the tool exactly to your needs. Even such
complicated shapes as ngernail turning gouges, spoon
carving gouges and oval skew chisels with a radiused
edge are easily sharpened. Once the shape is created,
you can resharpen the edge in less than a minute.
The water cooled slow speed grindstone is in harmony
with the physical laws governing the steel tool – the
edge does not overheat and lose its hardness.
You nish the sharpening process on the leather honing
wheel, which lets you polish the edge to a razor sharpness.
No grinding dust is produced to pollute the air. The steel
particles are deposited into the water trough.
The Tormek method is safe. At the low speed, you can
fully control the sharpening. Since no sparks are pro-
duced, there is no risk to your eyes and you can safely
use the machine in areas of high re risk.
Since 1973 Tormek has introduced many new techniques
and set the standard in water cooled sharpening. We are
dedicated to sharpening and we are continuously work-
ing on new developments to satisfy all your sharpening
needs.
Buying a Tormek is a safe investment in quality and per-
formance. You are assured that all future developments
will t your machine.
The Ultimate
Sharpening
System
Motor
Industrial single phase
200 W (input) 230 V, 50 Hz or
115 V, 60 Hz, Continuous duty
Maintenance free
Silent running, 52 dB
25,000 hour life
Steel Housing
3 mm (⅛ ")
Weight
Shipping weight 16.8 kg (37 lbs)
Machine only 14.2 kg (31.3 lbs)
Dimensions
Width 270 mm (10⅝ ")
Depth 250 mm (10")
Height 325 mm (12¾")
Grindstone
Aluminium oxide
∅250 × 50 mm (10" × 2")
90 rpm, torque 14.7 Nm
Leather Honing Wheel
∅220 × 31 mm (8⅝ " × 1¼")
Main Shaft and stone hardware
in stainless steel.
9052-1011
Go vertical for the best results. Price often indicates quality, and
we certainly found that to be true in wet sharpeners. Tormek’s
heavy-duty T-7 proved impossible to stall, no matter how hard
we pressed on the tool during sharpening; none of the lower-
priced units even came close. Its tool-holding system (tool
rest and holders) fit together like hand in glove and gave us
dead-on bevels and square ends with little fuss. And the stone
wore much slower than less-expensive models we tried. If you
sharpen hand tools or knives at least once a week, the versatile
T-7 is the sharpener for your shop.
Dave Campbell with John Olson
WOOD Magazine, USA
As a woodworker and woodcarver for 20 years, I’ve been
plagued by multiple bevels on my tools, cutting angles that
were too short or too long. Recently, however, I discovered
Tormek and it’s a dream come true – a machine that sharpens
and hones with the precision of a surgical team.
Roger Schroeder
Wood Carving Illustrated, USA
I have yet to find anything that cannot be sharpened on the
Tormek. The honed edge is incredibly fine, and coupled to this
dramatic improvement in edge quality is the not insignificant
fact that the tools will last far longer, as the sharpening process
is so much less aggressive. I am now a total convert to the wet
grinding system. It really is Touch and Turn, but you touch far
less often and turn far more!
Alan Holtham
The Woodworker, UK
The Tormek TNT-708 Woodturner’s Kit is a superbly made,
comprehensive kit and does speed up the sharpening process.
It is, along with the rest of the Tormek product range, incredibly
well made. I have got the process for sharpening a fingernail
profile gouge down to under a minute so one can no longer say
it is a slow process.
Look at the TTS-100 gouge again (or your own) and compare
the cutting edge to that of a dry bench-ground one. It will
produce a better finish off the tool and I do think the edge lasts
longer as a result. It is well worth the money and as most of us
work in other wood disciplines other than turning, the Tormek
system becomes more and more attractive!
Mark Baker
Woodturning Magazine, UK
BEST BUY
Included with the Tormek T-7Tormek Jig Solutions
Additional Accessories
Square Edge Jig
For plane irons and wood chisels. Max
tool width 76 mm (3"), max tool thickness
9 mm ("). Safety stops prevent the tool
from slipping off the stone.
Truing Tool
Trues the grindstone exactly round and
fl at. Guided by the Universal Support,
which also guides the jigs. Dual knobs
for smooth feed across the stone.
Stone Grader
The fi ne side grades the stone for a 1000
grit fi nish. The coarse side of the grader
reverses the stone to normal fast grinding.
Activates a glazed stone.
AngleMaster
Sets and measures the edge angle. Adjust-
able to any stone diameter from ∅250 mm
(10") down to ∅150 mm (6"). Measures
from 10° to 75°. Magnets keeps it in place.
Honing Compound
For application on the leather honing
wheels. Grain size 3 micron (average).
Removes the burr and polishes the
edge to a mirror fi nish.
Handbook
Explains the basics in sharpening and how
to best work with the Tormek system.
161 pages and 660 line drawings.
Tormek DVD
Brings the Handbook instructions to
life. 24 minute including a 4 minute
introduction to the Tormek way of
sharpening.
Turning Tool Setter
Replicates the geometry on turning
gouges and skews when using the
SVD-185 and SVS-50 jigs. With
built in edge geometries.
Woodturner’s Instruction Box
Contains TNT DVD fi lm and detailed
Handbook. Shows how to shape,
sharpen and hone all your turning tools.
Profiled Honing Wheels
For the inside honing and polishing of
turning/carving gouges and V-tools.
Set of two discs, one with a 3 mm (")
radius and one with a 60º tip.
For narrow tools complement with LA-124
with 2 mm (
") radius and a 45º tip.
Machine Cover
For protecting the machine
from shavings and wood dust.
Short Tool Jig
For straight shanked carving gouges and
V-tools down to 45 mm (1¾") length. Short
wood chisels and tools for power carvers.
Max tool width 32 mm (1¼").
Multi Jig
For turning skew chisels, parting and
beading tools and roughing gouges.
Straight carving gouges up to 50 mm
(2") width.
Tool Rest
For turning scrapers, hollowing tools
and thin parting tools. Also for cabinet
scrapers, screwdrivers and spoke
shave blades.
Axe Jig
For carving and carpenter’s axes.
Max height of axe 170 mm (6½").
Copes with both straight and
curved edges.
Scissors Jig
For scissors of all sizes and shears.
Also suitable for portable electric
hand planer blades.
Knife Jig
For most knives. Width 45 mm (1¾").
Long knives need to be stiff. Min blade
length 60 mm (2"). Also for carver’s
draw knives.
Long Knife Jig
Suitable for long and fl exible knives.
The 140 mm (5½") width of the jig
stabilizes a thin blade. Min blade
length 160 mm (6¼").
The Ultimate Solution for Square Edges
When mounting a wood chisel, conventional jigs need manual alignment
and therefore the grinding can become out of square. The Tormek Square
Edge Jig SE-76 automatically aligns the tool using its upper and at side,
which ensures a 90° edge.
Always a Perfect Grindstone
A grinding stone should run true and have a at surface to give a
good result. The Tormek T-7 therefore comes with a unique Truing
Tool, TT-50 and a Stone Grader, SP-650, so you can keep your
grindstone in perfect condition.
Mounts instantly on the
Universal Support.
Precise setting of cutting
depth with Micro Adjust.
Dual knobs for smooth
feed across the stone.
Unlike conventional
jigs, the upper and
at side of the tool
is always parallel to
the Universal Support.
Tormek Square Edge Jig Conventional Jigs
T-7
Water Cooled Sharpening System
Gouge Jig
For fi ngernail shaped turning gouges
of any geometry. Plus shaft for turning
cutters. Also for bent carving gouges
and V-tools. Max tool width 25 mm (1").
Blackstone Silicon SB-250
Tormek Blackstone delivers
fast steel removal on HSS,
exotic alloys and tools with
large bevel area. It can also
touch up carbide. 220 grit.
Japanese Waterstone SJ-250
This stone provides an extra
fine surface finish on hand
tools where a minimum of
steel removal is needed. Ideal
for carving tools. 4000 grit.
Tormek Special Stones
Design Patents
Sweden 77038
Europe 35092
USA D490,522
Powerful Industrial AC motor
• Minimal RPM loss under load
• Power 200 W (input)
• Maintenance free
• Continuous duty
Universal Support
• For vertical or horizontal mount.
• Micro adjust with scale for each
0.25 mm (0.01").
AngleMaster
Leather Honing Wheel
Tormek Original Grindstone
Developed to combine effi cient
steel removal, smooth surface
fi nish and long life. Can be
graded with the SP-650 for
a 1000 grit surface. 220 grit.
Stainless Steel Shaft
with EzyLock
PAT PEND
Easy and instant locking
and unlocking by hand.
Advanced Water Trough
Built-in magnet for swarf
collection and attachable
chute to catch every drip.
Safety Stop
Square Edge Jig
Safety Stop
Drill Bit Sharpening Attachment
Sharpens drill bits to a 4-facet point.
Can be set at any angle between 90°
and 150°. The optimal clearance angle
can be set for each drilling operation.
Drill size 3–22 mm ("–").
Planer Blade Attachment
For blades of any length. Blades longer
than 270 mm (10½") are relocated in
the blade holder. Min width of blade
13 mm (½").
Moulding Knife Attachment
For all makes and shapes of moulding
knives with 24, 30 or 38 mm distance
between guide hole centres. Max width
of blade 100 mm (4").
Included with the Tormek T-7Tormek Jig Solutions
Additional Accessories
Square Edge Jig
For plane irons and wood chisels. Max
tool width 76 mm (3"), max tool thickness
9 mm ("). Safety stops prevent the tool
from slipping off the stone.
Truing Tool
Trues the grindstone exactly round and
fl at. Guided by the Universal Support,
which also guides the jigs. Dual knobs
for smooth feed across the stone.
Stone Grader
The fi ne side grades the stone for a 1000
grit fi nish. The coarse side of the grader
reverses the stone to normal fast grinding.
Activates a glazed stone.
AngleMaster
Sets and measures the edge angle. Adjust-
able to any stone diameter from ∅250 mm
(10") down to ∅150 mm (6"). Measures
from 10° to 75°. Magnets keeps it in place.
Honing Compound
For application on the leather honing
wheels. Grain size 3 micron (average).
Removes the burr and polishes the
edge to a mirror fi nish.
Handbook
Explains the basics in sharpening and how
to best work with the Tormek system.
161 pages and 660 line drawings.
Tormek DVD
Brings the Handbook instructions to
life. 24 minute including a 4 minute
introduction to the Tormek way of
sharpening.
Turning Tool Setter
Replicates the geometry on turning
gouges and skews when using the
SVD-185 and SVS-50 jigs. With
built in edge geometries.
Woodturner’s Instruction Box
Contains TNT DVD fi lm and detailed
Handbook. Shows how to shape,
sharpen and hone all your turning tools.
Profiled Honing Wheels
For the inside honing and polishing of
turning/carving gouges and V-tools.
Set of two discs, one with a 3 mm (")
radius and one with a 60º tip.
For narrow tools complement with LA-124
with 2 mm (
") radius and a 45º tip.
Machine Cover
For protecting the machine
from shavings and wood dust.
Short Tool Jig
For straight shanked carving gouges and
V-tools down to 45 mm (1¾") length. Short
wood chisels and tools for power carvers.
Max tool width 32 mm (1¼").
Multi Jig
For turning skew chisels, parting and
beading tools and roughing gouges.
Straight carving gouges up to 50 mm
(2") width.
Tool Rest
For turning scrapers, hollowing tools
and thin parting tools. Also for cabinet
scrapers, screwdrivers and spoke
shave blades.
Axe Jig
For carving and carpenter’s axes.
Max height of axe 170 mm (6½").
Copes with both straight and
curved edges.
Scissors Jig
For scissors of all sizes and shears.
Also suitable for portable electric
hand planer blades.
Knife Jig
For most knives. Width 45 mm (1¾").
Long knives need to be stiff. Min blade
length 60 mm (2"). Also for carver’s
draw knives.
Long Knife Jig
Suitable for long and fl exible knives.
The 140 mm (5½") width of the jig
stabilizes a thin blade. Min blade
length 160 mm (6¼").
The Ultimate Solution for Square Edges
When mounting a wood chisel, conventional jigs need manual alignment
and therefore the grinding can become out of square. The Tormek Square
Edge Jig SE-76 automatically aligns the tool using its upper and at side,
which ensures a 90° edge.
Always a Perfect Grindstone
A grinding stone should run true and have a at surface to give a
good result. The Tormek T-7 therefore comes with a unique Truing
Tool, TT-50 and a Stone Grader, SP-650, so you can keep your
grindstone in perfect condition.
Mounts instantly on the
Universal Support.
Precise setting of cutting
depth with Micro Adjust.
Dual knobs for smooth
feed across the stone.
Unlike conventional
jigs, the upper and
at side of the tool
is always parallel to
the Universal Support.
Tormek Square Edge Jig Conventional Jigs
T-7
Water Cooled Sharpening System
Gouge Jig
For fi ngernail shaped turning gouges
of any geometry. Plus shaft for turning
cutters. Also for bent carving gouges
and V-tools. Max tool width 25 mm (1").
Blackstone Silicon SB-250
Tormek Blackstone delivers
fast steel removal on HSS,
exotic alloys and tools with
large bevel area. It can also
touch up carbide. 220 grit.
Japanese Waterstone SJ-250
This stone provides an extra
fine surface finish on hand
tools where a minimum of
steel removal is needed. Ideal
for carving tools. 4000 grit.
Tormek Special Stones
Design Patents
Sweden 77038
Europe 35092
USA D490,522
Powerful Industrial AC motor
• Minimal RPM loss under load
• Power 200 W (input)
• Maintenance free
• Continuous duty
Universal Support
• For vertical or horizontal mount.
• Micro adjust with scale for each
0.25 mm (0.01").
AngleMaster
Leather Honing Wheel
Tormek Original Grindstone
Developed to combine effi cient
steel removal, smooth surface
fi nish and long life. Can be
graded with the SP-650 for
a 1000 grit surface. 220 grit.
Stainless Steel Shaft
with EzyLock
PAT PEND
Easy and instant locking
and unlocking by hand.
Advanced Water Trough
Built-in magnet for swarf
collection and attachable
chute to catch every drip.
Safety Stop
Square Edge Jig
Safety Stop
Drill Bit Sharpening Attachment
Sharpens drill bits to a 4-facet point.
Can be set at any angle between 90°
and 150°. The optimal clearance angle
can be set for each drilling operation.
Drill size 3–22 mm ("–").
Planer Blade Attachment
For blades of any length. Blades longer
than 270 mm (10½") are relocated in
the blade holder. Min width of blade
13 mm (½").
Moulding Knife Attachment
For all makes and shapes of moulding
knives with 24, 30 or 38 mm distance
between guide hole centres. Max width
of blade 100 mm (4").
Included with the Tormek T-7Tormek Jig Solutions
Additional Accessories
Square Edge Jig
For plane irons and wood chisels. Max
tool width 76 mm (3"), max tool thickness
9 mm ("). Safety stops prevent the tool
from slipping off the stone.
Truing Tool
Trues the grindstone exactly round and
fl at. Guided by the Universal Support,
which also guides the jigs. Dual knobs
for smooth feed across the stone.
Stone Grader
The fi ne side grades the stone for a 1000
grit fi nish. The coarse side of the grader
reverses the stone to normal fast grinding.
Activates a glazed stone.
AngleMaster
Sets and measures the edge angle. Adjust-
able to any stone diameter from ∅250 mm
(10") down to ∅150 mm (6"). Measures
from 10° to 75°. Magnets keeps it in place.
Honing Compound
For application on the leather honing
wheels. Grain size 3 micron (average).
Removes the burr and polishes the
edge to a mirror fi nish.
Handbook
Explains the basics in sharpening and how
to best work with the Tormek system.
161 pages and 660 line drawings.
Tormek DVD
Brings the Handbook instructions to
life. 24 minute including a 4 minute
introduction to the Tormek way of
sharpening.
Turning Tool Setter
Replicates the geometry on turning
gouges and skews when using the
SVD-185 and SVS-50 jigs. With
built in edge geometries.
Woodturner’s Instruction Box
Contains TNT DVD fi lm and detailed
Handbook. Shows how to shape,
sharpen and hone all your turning tools.
Profiled Honing Wheels
For the inside honing and polishing of
turning/carving gouges and V-tools.
Set of two discs, one with a 3 mm (")
radius and one with a 60º tip.
For narrow tools complement with LA-124
with 2 mm (
") radius and a 45º tip.
Machine Cover
For protecting the machine
from shavings and wood dust.
Short Tool Jig
For straight shanked carving gouges and
V-tools down to 45 mm (1¾") length. Short
wood chisels and tools for power carvers.
Max tool width 32 mm (1¼").
Multi Jig
For turning skew chisels, parting and
beading tools and roughing gouges.
Straight carving gouges up to 50 mm
(2") width.
Tool Rest
For turning scrapers, hollowing tools
and thin parting tools. Also for cabinet
scrapers, screwdrivers and spoke
shave blades.
Axe Jig
For carving and carpenter’s axes.
Max height of axe 170 mm (6½").
Copes with both straight and
curved edges.
Scissors Jig
For scissors of all sizes and shears.
Also suitable for portable electric
hand planer blades.
Knife Jig
For most knives. Width 45 mm (1¾").
Long knives need to be stiff. Min blade
length 60 mm (2"). Also for carver’s
draw knives.
Long Knife Jig
Suitable for long and fl exible knives.
The 140 mm (5½") width of the jig
stabilizes a thin blade. Min blade
length 160 mm (6¼").
The Ultimate Solution for Square Edges
When mounting a wood chisel, conventional jigs need manual alignment
and therefore the grinding can become out of square. The Tormek Square
Edge Jig SE-76 automatically aligns the tool using its upper and at side,
which ensures a 90° edge.
Always a Perfect Grindstone
A grinding stone should run true and have a at surface to give a
good result. The Tormek T-7 therefore comes with a unique Truing
Tool, TT-50 and a Stone Grader, SP-650, so you can keep your
grindstone in perfect condition.
Mounts instantly on the
Universal Support.
Precise setting of cutting
depth with Micro Adjust.
Dual knobs for smooth
feed across the stone.
Unlike conventional
jigs, the upper and
at side of the tool
is always parallel to
the Universal Support.
Tormek Square Edge Jig Conventional Jigs
T-7
Water Cooled Sharpening System
Gouge Jig
For fi ngernail shaped turning gouges
of any geometry. Plus shaft for turning
cutters. Also for bent carving gouges
and V-tools. Max tool width 25 mm (1").
Blackstone Silicon SB-250
Tormek Blackstone delivers
fast steel removal on HSS,
exotic alloys and tools with
large bevel area. It can also
touch up carbide. 220 grit.
Japanese Waterstone SJ-250
This stone provides an extra
fine surface finish on hand
tools where a minimum of
steel removal is needed. Ideal
for carving tools. 4000 grit.
Tormek Special Stones
Design Patents
Sweden 77038
Europe 35092
USA D490,522
Powerful Industrial AC motor
• Minimal RPM loss under load
• Power 200 W (input)
• Maintenance free
• Continuous duty
Universal Support
• For vertical or horizontal mount.
• Micro adjust with scale for each
0.25 mm (0.01").
AngleMaster
Leather Honing Wheel
Tormek Original Grindstone
Developed to combine effi cient
steel removal, smooth surface
fi nish and long life. Can be
graded with the SP-650 for
a 1000 grit surface. 220 grit.
Stainless Steel Shaft
with EzyLock
PAT PEND
Easy and instant locking
and unlocking by hand.
Advanced Water Trough
Built-in magnet for swarf
collection and attachable
chute to catch every drip.
Safety Stop
Square Edge Jig
Safety Stop
Drill Bit Sharpening Attachment
Sharpens drill bits to a 4-facet point.
Can be set at any angle between 90°
and 150°. The optimal clearance angle
can be set for each drilling operation.
Drill size 3–22 mm ("–").
Planer Blade Attachment
For blades of any length. Blades longer
than 270 mm (10½") are relocated in
the blade holder. Min width of blade
13 mm (½").
Moulding Knife Attachment
For all makes and shapes of moulding
knives with 24, 30 or 38 mm distance
between guide hole centres. Max width
of blade 100 mm (4").
T-7
www.tormek.com
Tormek T-7 Sharpening System
TORMEK T-7, SE-76, TT-50, SP-650, WM-200, PA-70, HB-10, DVD-1
TNT-708 Woodturner’s Kit
SVD-185, SVS-50, SVD-110, LA-120, MH-380, TTS-100, TNT-300
HTK-705 Hand Tool Kit
SVM-45, SVM-140, SVX-150, SVA-170, SVS-32
Grinding Jigs
SVM-45 Knife Jig ×
SVM-140 Long Knife Jig ×
SVX-150 Scissors Jig ×
SVA-170 Axe Jig ×
SVS-32 Short Tool Jig ×
SVD-185 Gouge Jig ×
SVS-50 Multi Jig ×
SVD-110 Tool Rest ×
SE-76 Square Edge Jig ×
SVH-320 Planer Blade Attachment
SVP-80 Moulding Knife Attachment
DBS-22 Drill Bit Sharpening Attachment
Accessories
TT-50 Truing Tool ×
WM-200 AngleMaster ×
SP-650 Stone Grader ×
LA-120 Profiled Honing Wheel ×
LA-124 Narrow discs for LA-120
PA-70 Honing Compound ×
TTS-100 Turning Tool Setter ×
MH-380 Machine Cover ×
HB-10 Handbook ×
DVD-1 Tormek DVD ×
TNT-300 Woodturner’s Instruction Box ×
Tormek Special Stones
SB-250 Blackstone Silicon
SJ-250 Japanese Waterstone
The key word when sharpening the Tormek way is
repeatability. The tools are guided in jigs – you remove
only a minute fraction of the steel at each sharpening,
which makes it fast. An extra bene t is that your tools
last longer.
You can shape the tool exactly to your needs. Even such
complicated shapes as ngernail turning gouges, spoon
carving gouges and oval skew chisels with a radiused
edge are easily sharpened. Once the shape is created,
you can resharpen the edge in less than a minute.
The water cooled slow speed grindstone is in harmony
with the physical laws governing the steel tool – the
edge does not overheat and lose its hardness.
You nish the sharpening process on the leather honing
wheel, which lets you polish the edge to a razor sharpness.
No grinding dust is produced to pollute the air. The steel
particles are deposited into the water trough.
The Tormek method is safe. At the low speed, you can
fully control the sharpening. Since no sparks are pro-
duced, there is no risk to your eyes and you can safely
use the machine in areas of high re risk.
Since 1973 Tormek has introduced many new techniques
and set the standard in water cooled sharpening. We are
dedicated to sharpening and we are continuously work-
ing on new developments to satisfy all your sharpening
needs.
Buying a Tormek is a safe investment in quality and per-
formance. You are assured that all future developments
will t your machine.
The Ultimate
Sharpening
System
Motor
Industrial single phase
200 W (input) 230 V, 50 Hz or
115 V, 60 Hz, Continuous duty
Maintenance free
Silent running, 52 dB
25,000 hour life
Steel Housing
3 mm (⅛ ")
Weight
Shipping weight 16.8 kg (37 lbs)
Machine only 14.2 kg (31.3 lbs)
Dimensions
Width 270 mm (10⅝ ")
Depth 250 mm (10")
Height 325 mm (12¾")
Grindstone
Aluminium oxide
∅250 × 50 mm (10" × 2")
90 rpm, torque 14.7 Nm
Leather Honing Wheel
∅220 × 31 mm (8⅝ " × 1¼")
Main Shaft and stone hardware
in stainless steel.
9052-1011
Go vertical for the best results. Price often indicates quality, and
we certainly found that to be true in wet sharpeners. Tormek’s
heavy-duty T-7 proved impossible to stall, no matter how hard
we pressed on the tool during sharpening; none of the lower-
priced units even came close. Its tool-holding system (tool
rest and holders) fit together like hand in glove and gave us
dead-on bevels and square ends with little fuss. And the stone
wore much slower than less-expensive models we tried. If you
sharpen hand tools or knives at least once a week, the versatile
T-7 is the sharpener for your shop.
Dave Campbell with John Olson
WOOD Magazine, USA
As a woodworker and woodcarver for 20 years, I’ve been
plagued by multiple bevels on my tools, cutting angles that
were too short or too long. Recently, however, I discovered
Tormek and it’s a dream come true – a machine that sharpens
and hones with the precision of a surgical team.
Roger Schroeder
Wood Carving Illustrated, USA
I have yet to find anything that cannot be sharpened on the
Tormek. The honed edge is incredibly fine, and coupled to this
dramatic improvement in edge quality is the not insignificant
fact that the tools will last far longer, as the sharpening process
is so much less aggressive. I am now a total convert to the wet
grinding system. It really is Touch and Turn, but you touch far
less often and turn far more!
Alan Holtham
The Woodworker, UK
The Tormek TNT-708 Woodturner’s Kit is a superbly made,
comprehensive kit and does speed up the sharpening process.
It is, along with the rest of the Tormek product range, incredibly
well made. I have got the process for sharpening a fingernail
profile gouge down to under a minute so one can no longer say
it is a slow process.
Look at the TTS-100 gouge again (or your own) and compare
the cutting edge to that of a dry bench-ground one. It will
produce a better finish off the tool and I do think the edge lasts
longer as a result. It is well worth the money and as most of us
work in other wood disciplines other than turning, the Tormek
system becomes more and more attractive!
Mark Baker
Woodturning Magazine, UK
BEST BUY
Other manuals for T7
1
Other tormek Tools manuals
