Tornado Windshear 98782 Manual

TORNADO INDUSTRIES
7401 W. LAWRENCE AVENUE
CHICAGO, IL 60706
[phone] FAX [phone]
www.tornadovac.com
Operations & Maintenance Manual
For Commercial Use Only
Model WindshearTM Sidedraft
MODEL NO.
98782 (115v) & 98783 (230v)
Form No. L 9700
©2007 Tacony Inc. All rights reserved.
OPERATING INSTRUCTIONS
MAINTENANCE/TROUBLE SHOOTING
1. Plug in to a standard outlet with the correct voltage and amperage for the unit.
2. Place the dryer in the desired operating position.
3. Set the switch at the desired speed: low or high.
4. Check for proper operation before leaving the unit unattended.
Do not move or carry the dryer when it is running.
Daisy-chained: Up to 6 units may be plugged into on a single 15 amp circuit and
up to 9 on a 20 amp circuit. The axial fan is equipped with dual power outlets that
will allow you to “daisy chain” up to 5 units units. Do not “daisy chain” more than 5
units. The axial fan system has a 12 amp circuit breaker built in that will trip if more
than 5 units are “daisy chained” from a single machine.
12 AMP Resettable Circuit Breaker
The axial fan features a 12 amp circuit breaker that will “trip” if more than 12 amps of
electrical current is drawn through the cord.
GFCI Protection and Outlet
The axial fan provides a standard duplex GFCI outlet for daisy-chaining multiple
units together. The GFCI protection promotes operator safety and will “trip” is an
electrical ground fault is sensed. To test the GFCI protection, press the TEST button.
If operating properly, the RESET button on the GFCI outlet will pop out.
Operating Positions
The axial fan is designed to operate in multiple positions for any type of drying.
1. Tilt Back – Tilt the axial fan backward on the four curved molded legs at an
angle to direct air for elevated drying.
2. Upright – Set the axial fan square with the handle on the top to direct air across
a room.
3. Tilt Forward – Tilt the axial fan forward on the “standing legs at an angle to
direct airflow along the flow in front of the dryer.
4. Face Down – Set the axial fan on the four curved molded legs with the
“standing legs” facing up to direct air straight down.
5. Powr Pitch – Model PDaxial fan is equipped with a 3º down angle leg.
6. Stack for Storage – the axial fan interlock and stack for easy
storage and transport.
Periodic Maintenance
1. Check power cord for any breaks, seperations or cuts.
2. Make sure the ground pin or grounding prong is intact or
the machine will be unsafe to operate.
Trouble Shooting (if the dryer will not run)
1. Check electrical cord; is it firmly seated in wall outlet
2. Check GFCI and reset if tripped
3. Check if dryer circuit breaker is tripped, reset if necessary.
4. Check to see if building circuit breaker is tripped. If circuit
is overloaded, move cord to different GFCI outlet.
5. If using an extension cord, make sure it is in good
condition, proper gauge and firmly connected.
2 postion switch and daisy-chained outlets
Cord wrap

This appliance must be grounded. If it should malfunction or break down, grounding
provides a path of least resistance for electric current to reduce the risk of electric
shock. This appliance is equipped with a cord having an equipment-grounding con-
ductor and grounding plug. The plug must be plugged into an appropriate outlet that
is properly installed and grounded in accordance with all local codes and ordi-
nances.
This appliance is for use on a nominal 120 volt circuit and has a ground plug (see
illustration, right). Make sure that the appliance is connected to an outlet having the
same configuration as the plug. No adaptor should be used with this appliance.
WARNING - Improper connection of the equipment-grounding conductor can result
in a risk of electric shock. Check with a qualified electrician or service person if you
are in doubt as to whether the outlet is properly grounded. Do not modify the plug
provided with the appliance – if it will not fit the outlet, have a proper outlet installed
by a qualified electrician.
GROUNDING INSTRUCTIONS
Prong or
Grounding pin
Grounded
Outlet
Grounded
Outlet Box
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE
USING THIS APPLIANCE
When using an electrical appliance, basic pre-
cautions should always be followed.
WARNING- To reduce the risk of fire, electric
shock or injury:
Use only as described in this manual. Use
only manufacturer’s recommended compo-
nents and attachments.
Use only indoors. Do not use outdoors or
expose to rain.
Do not use with damaged cord or plug. If
appliance is not working as it should, has
been dropped, damaged, left outdoors, or
dropped into water, return it to your Authorized
dealer.
Do no pull or carry by cord, use cord as a
handle, close door on cord, or pull cord
around sharp edges or corners. Keep cord
away from heated surfaces.
Do not unplug by pulling on cord. To unplug,
grasp the plug, not the cord.
Do not handle plug or appliance with wet
hands.
Do not put any object into openings. Do not
use with any opening blocked; keep free of
dust, hair and anything that may reduce air
flow.
Turn off all controls before unplugging.
Do not attempt to service the unit while appli-
ance is plugged in.
Appliance may cause a fire when operating
near flammable vapors or materials. Do not
operate this machine near flammable fluids,
dust or vapors.
Connect to a properly grounded outlet.
Do not use with any solid state speed control
device.
This unit is thermally protected.
FOR BEST PERFORMANCE
• Keep machine clean and in good operating condition.
• Have machine checked periodically by your Authorized
Dealer.
• Use only authorized service centers for parts or service.
• Store machine carefully in dry area.
• For optimum drying performance and safety, study and
follow your operators manual.
SAVE THESE INSTRUCTIONS
WARNING
Do not stack dryers more than
4 (four) units high for transport,
5 (five) units high for storage.
NOTES
Write your machine serial number here:________________________________
ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
This instruction book covers:
MODEL NO. 98782 98783
VOLTS 115 230
SERIES F F
*This applies only to North America. The 230v model is designed to operate on a 230/50 Hz electrical connection.
Make sure the electrical outlet is grounded and all safety precautions are taken
.
