Tornado ExSELLerate Series Setup guide

At a Glance
Specifications Page2
Introduction Page3
Overview Page4
Installing the Lint Screen Page 5
DualPurpose Page6
Features and Benefits Page 7
KeyFeatures Page8
Operational Tips Page 10
Narrative Bid Specifications Page 16
Recommended Stocking Parts List Page 17
GreenCleaning Page18
SWB 26/8
ExSELLerate™ Series Dealer Training Guide
Demo Sales Training Guide - For Internal Use Only

2
ExSELLerate® Sales Training Series │SWB 26/8
Machine Dimensions SWB 26/8
Model Number 96210
L X W X H 32 in X 28 in X 24 in
80 cm X 70 cm X 60 cm
Weight (w/o batteries) 93 lbs. (42 kg)
Weight (with batteries) 124 lbs. (56 kg)
Capacity 8 gal. (40 liters)
Design Characteristics
Batteries 24 V
Drive Mechanism Brush Propelled
Tank Construction Rotomold Plastic
Dust Control Filter
Wheel Dimensions 9 in (23 cm) Non-marking
Cleaning System
Main Brush Width 16 in (41 cm)
Main Brush Diameter 7 in (19 cm)
Main Brush RPM 750
Side Brush RPM 90
Cleaning Path 26 in (66 cm)
Filtration Level 3 Micron @ 99.7%
Sound Level 67 dB (A)
Productivity
Cleaning Rate 26,000 ft2per hour (2,400 m2per hour)
Motors
Brush Motor 24V
Warranty
Parts 1 year
Labor 2 years
Tanks 10 years
Side Brush Width 10 in (25 cm)
Specifications

3
ExSELLerate® Sales Training Series │SWB 26/8
Introduction
Product Mission
Tornado’s SWB 26/8 was developed to be an industry leading battery powered, walk-behind sweeper,
designed for use on carpeting, as well as hard floor surfaces.
In carpet applications, when cleaning an airport terminal, dining hall, or any other large area, the SWB
26/8 offers more than double the productivity of a traditional, corded, wide area vacuum. The versatility
of the unit allows for cleaning hard floor surfaces as well, and with an operating decibel level below 70
dB, cleaning during the day or in noise sensitive areas is no longer an issue.
The SWB 26/8 operates in an “overthrow” fashion, allowing for maximum use of the debris
bin. “Overthrow” operation lifts the debris up and over the brush and “throws” it into in the debris bin.
This fills the debris bin to its maximum capacity, unlike a “dustpan” design which only partially fills the
debris bin making dumps and refills more frequent. Incorporating sealed, maintenance free, AGM
(Absorbed Glass Mat) batteries, which meet LEED and CIMS-GB standards, the SWB 26/8 maximizes
performance from the 24volt system.
While the type of floor surface will impact run time, the SWB 26/8 operates for approximately two (2)
hours on a single charge. With the on-board charger and the AGM batteries, the unit can be charged
any time it’s sitting idle (opportunity charged). Unlike traditional lead acid batteries, there is no need to
wait for AGM batteries to completely discharge before recharging them. The SWB 26/8 can be re-
charged after ten (10) minutes of use or anytime the unit is sitting idle!
Many of the distinctive features of the SWB 26/8 give your customers options and flexibility to use the
machine for multiple cleaning applications, saving them time and money. And remember, this dual-
purpose machine is effective for cleaning carpets as well as hard floor applications, both indoors and
outdoors.
Target Market
Carpet technicians, janitors, in-house facility managers, and building service contractors will appreciate
the features of Tornado’s SWB 26/8 designed for use on large carpeted areas and hard surfaces. This
unit is perfect for the following environments:
 Convention halls, banquet centers, meeting rooms or anywhere hallways and main areas have to be
kept clean around the clock;
 Schools and universities where clean environments mean improved test scores;
 Retail or hotel settings where round-the-clock clean floors, aisles and hallways signify safety and
continued business success;
 And for BSCs who must deliver maximum cleaning performance and speed, while reducing the total
cost of cleaning.
The Tornado Commitment
Tornado Industries is a leading manufacturer of commercial cleaning solutions offering the most
comprehensive and innovative line of cleaning equipment in the industry. With over 85 years of industry
experience, Tornado manufactures a complete line of upright vacuums, floor machines, automatic
scrubbers, sweepers, wet dry vacuums, industrial vacuums and more. Selling through a strong network
of national Tornado® dealers, we are committed to supporting the profitable growth of our dealer
partners by delivering innovative and durable equipment that provides high profit margins for increased
business growth.

4
ExSELLerate® Sales Training Series │SWB 26/8
Overview
1 2 4 6 7
3
10
9
8
12
13
11
1. Main Power Button (activates main and side brush)
2. Side Brush Power Button
3. Charging Indicator
4. Battery Power Level Indicator
5. Debris Tank Lock Lever
6. Filter Shake Lever
7. Debris Tank
8. On-Board Charger
9. Side Brush Lock
10.Side Brush
11.Main Housing
12.Handle Height Adjustment Knobs
13.Brush Activation Lever
5

5
ExSELLerate® Sales Training Series │SWB 26/8
Installing the Lint Screen
When the SWB 26/8 arrives you will notice a metal lint screen packed inside the debris bin. The lint
screen is to be installed and used when you are operating the SWB 26/8 on carpeting. The lint screen
keeps carpet fibers and lint from clogging the filter.
To install the lint screen:
 Open the debris bin by lifting the debris bin lock and pull back. Remove the lint screen that
was stored inside the debris bin during shipment.
2. Loosen the two wing nuts holding the filter mount in place and remove the filter assembly.
3. Remove the pleated filter from the mounting bracket and place the lint screen in the filter
mount
4. Place the pleated filter back into the filter mount (place it on top of the lint screen so that when
the assembly is reinstalled, the lint screen is the first filter facing down into the collection
hopper).
5. Put the filter assembly back into the unit. Be sure to hand tighten the two wing nuts that hold
the filter assembly in place.
Once the lint screen is installed you do not have to uninstall it when sweeping both carpet and hard floor
surfaces. The lint screen will not reduce the effectiveness of the SWB 26/8 when operating on hard floor
surfaces.
If your customer is not operating the SWB 26/8 on carpeting, they do not need to install the lint screen.
Tornado recommends, however, that your customer retain the lint screen in the event they need to
operate the SWB 26/8 on carpet at a later date.

6
ExSELLerate® Sales Training Series │SWB 26/8
Dual Purpose
10,000
26,000
Sweeper Productivity (Sq. Ft. Per Hour)
Tornado SWB 26/8
The SWB 26/8 is a dual-purpose machine that can be used on both hard floors and
carpet.
The biggest market or opportunity for Janitorial Supply Dealers on the SWB 26/8 is
carpet applications. The SWB 26/8 provides double the performance / productivity of a
traditional, corded, wide area vacuum. Since it’s battery powered, customers also
avoid the need to unplug and plug in a power cord. In addition, the SWB’s side broom
eliminates the need for edge cleaning after sweeping. Unlike a wide area vacuum, the
SWB 26/8 operates at a whisper quite 67 dB, which not only meets LEED standards
for noise levels, it also allows the unit to be used during business hours without inter-
rupting building occupants.
Industrial Sweeper Dealers will find their biggest market for the SWB 26/8 to be hard
floor applications, both indoor and outdoor. Moving from sidewalks and policing of
parking lots, directly into warehouses is effortless for the SWB 26/8. The rugged con-
struction of the unit makes it appropriate for even the toughest applications. Featuring
an impeller fan and filter system, the unit offers superior dust control compared to most
competitive models. Featuring “overthrow” design, the unit maximizes debris bin ca-
pacity and easily picks up all types of debris.
The SWB 26/8 is at home in schools, hospitals, airports, commercial office buildings,
theaters, retail, stores, casinos, sports facilities, and arenas.
30” Wide Area Vacuum

7
ExSELLerate® Sales Training Series │SWB 26/8
Features & Benefits
Productivity
 Maximize sweeping speed up to 26,000 sq. ft. per hour—more than
two-and-a-half times faster than wide-area vacuums and ten times
faster than a manual broom!
Overthrow System
 All debris passing over the core of the roller brushes is collected
 The flexibility of the brushes easily picks up objects large and small
 With no front end direct collector, the debris is never pushed along in
front of the sweeper
 The top loading design allows the collection bin to be filled to more
than 75%, unlike front load or dustpan style units that have much
less operating fill ratios
High Filtration  Dust-control filter system for improved air quality
 Filtration level of 3 Micron @ 99.7%
Service-friendly  The main housing is easily removed, allowing for quick and easy
access for service.
9” wheels  Large, non-marking rear wheels and front castor for enhanced
mobility
AGM Batteries  Sealed maintenance free batteries, that meet LEED standards
 Offers up to two (2) hours of runtime per charge
On-Board Charger  A built-in charger lets you quickly plug in and charge the SWB after
every use
Adjustable Handle  Handle adjusts allowing for a comfortable operating position.
 Collapses for storage in small areas
Compact Design  Compact design goes through standard size doors, and in areas
where larger walk-behind or ride-on units cannot
Side Brush
 The side brush increases the width of your edge-cleaning path,
reaching along the edge of hard floors and carpets, pulling material
into the cleaning path of the main broom.
Low Decibel Level  Whisper-quiet at 67 dB for noise sensitive environments

Key Features
Operating in a “overthrow” fashion lifts debris up and over the
main broom and drops it into the debris bin.
This method maximizes the amount of debris that can be put
into the debris bin.
4. Overthrow Operation
The SWB 26/8 has more than double the productivity of a
traditional wide area vacuum, saving time and money.
The unit also will work on both carpet and hard floor surfaces.
One machine will cover multiple floor types.
1. Productivity
The SWB 26/8 incorporates a blower fan that draws light
material up through the pleated filter, ensuring less dust and
particulate escape into the air.
The system ensures improved indoor air quality.
2. Filtration System
The unit operates below 70 dB.
This meets LEED standards on sound levels and will allow it
to be used in noise sensitive environments.
3. Whisper Quiet Operation
Sweeper Productivity
(Sq. Ft. Per Hour)
10,000
26,000
8
ExSELLerate® Sales Training Series │SWB 26/8

A dead man operating lever ensures safe operation.
When the operating lever is released the unit will stop operating
and does not activate again until the lever is pulled up.
6. Safety Handle
The side broom extends from the right side of the machine,
increasing the cleaning width by 10 inches. This allows for
cleaning right along the edges of walls and other surfaces.
This is especially useful when sweeping carpets, eliminating
the need for edge cleaning.
5. Edge Cleaning With Side Broom
Key Features
The SWB 26/8 incorporates sealed, maintenance free,
Absorbed Glass Mat (AGM) batteries.
These batteries not only meet LEED standards, they re-
quire no maintenance. This eliminates any safety issue that
come with maintaining traditional wet-acid batteries.
7. Sealed Batteries
The unit comes with an on-board charger.
Allow for convenient “opportunity charging” anywhere
there is an electrical outlet.
8. On-Board Charger
9
ExSELLerate® Sales Training Series │SWB 26/8

Operation Tips
10
ExSELLerate® Sales Training Series │SWB 26/8
The side brush power button turns the
side brush only off and on.
Main power button activates both the
main brush and the side brush.

Operation Tips
11
ExSELLerate® Sales Training Series │SWB 26/8
Change the pressure
of the side brush
Once the main housing has been lifted you can:
Change the pressure
of the main brush
A safety bolt is located directly in front of the caster. The bolt
securely fastens the lid / cover ensuring safety. Qualified
maintenance technicians can easily access the mechanicals by
removing the bolt.

Operation Tips
12
ExSELLerate® Sales Training Series │SWB 26/8
Pull back on the brush lock to set the
side brush in place. If you want the
brush floating simply pull forward.
Pull up on the brush
activation lever to engage
the brushes and release
the lever to disengage
them.

Operation Tips
13
ExSELLerate® Sales Training Series │SWB 26/8
Move the Filter Shake lever left and right to knock
away loose debris from the filter. Perform this
procedure periodically while sweeping in order to
keep the filter system efficient.
Pull up on debris bin lock and pull back to empty the bin
in an approved location.

Operation Tips
14
ExSELLerate® Sales Training Series │SWB 26/8
The Pleated Filter
First, remove the debris tank
The filter is located directly above the debris tank. To access the filter:
Second, loosen the two wing nuts
You now have access to:
Lint Screen Filter Mount

Operation Tips
15
ExSELLerate® Sales Training Series │SWB 26/8
In order to charge your SWB 26/8, simply plug the on-board charger into a wall outlet.

16
ExSELLerate® Sales Training Series │SWB 26/8
Narrative Bid Specifications
Summary
The specified unit shall be battery operated, employing four (4) sealed, 6 volt, mainte-
nance free batteries (24-volt system). The unit shall have an 8 gallon debris bin, with a
total cleaning path of 26 inches. The unit shall also have a side broom for edge cleaning.
The machine should have a compact design to increase operator maneuverability when
cleaning. The unit shall be able to sweep carpets as well as hard floor surfaces. The unit
shall incorporate a filter, lint screen and blower fan to contain dust. The unit will have a
battery level indicator, allowing the operator to know how much charge is left in the bat-
tery.
The unit shall incorporate both a main brush and a side brush. The main brush shall
move the debris off the floor surface and into the debris tank. The side brush shall
provide edge cleaning, moving debris into the path of the main brush.
Access to the electrical / machine components will require the use of a tool for safety.
The handle will be adjustable for comfortable operation as well as easy of storage.
The warranty shall be as follows: 2 years parts, 1 year labor and 10 years on tanks.
Sweeping Operation The unit shall operate in an over-throw fashion, bring debris up and over the brushes and
dropping it into the debris tank.
Brush Design
The main brush shall be of chevron design, situated directly in front of the debris bin. It
will be 17 inches in length and a diameter of 7 inches.
The side brush shall be situated to the right of the unit, extended outward for edge
cleaning. The side brush shall be 10 inches.
Debris Bin The debris bin shall be constructed of rotationally molded plastic with a safety lock. This
lock shall be of lever design for easy access in order to dump the debris.
Sound Level The unit shall operate at 67 dB.
Filtration The unit shall incorporate a two-part filter system, consisting of both a filter and lint
screen. The filter shall rest in a housing located directly above the debris bin. The filter
shall capture 3 Micron @ 99.7%.
On-Board Charger The unit will have a built in, on-board charger that will plug into a standard 110 volt wall
outlet. There shall be a charging indicator, allowing the operator to know that the unit is
charging.
Batteries The batteries shall be sealed and maintenance free, meeting LEED standards. The
batteries shall allow for “opportunity charging”.
Wheels Non-marking 9” wheels.
Brush Motor The brush motor shall be 24 volt.
Specified Unit Tornado SWB 26/8, Model: 96210

17
ExSELLerate® Sales Training Series │SWB 26/8
Recommended Stocking Parts List
Part Number Description Qty
90100 Filter 3
39026 Lint Screen 2
39122 Main Broom 1
39167 Side Broom 1

18
ExSELLerate® Sales Training Series │SWB 26/8
Tornado Industries, Inc. is committed to creating a clean, safe and healthy workplace environment
through the use of innovative cleaning technology developed to minimize the impact of cleaning on in-
door and outdoor environments. At Tornado, we care deeply about our planet and realize the cleaning
industry is in a position to make positive and profound contributions to the environment, ensuring that
our children and our children’s children inherit a sustainable and healthy planet. That’s why we carefully
design our machines to deliver not only the latest innovation, but also green features to enhance indoor
air quality (IAQ), use less water and chemicals, create less noise, and produce less moisture. Tornado
embraces the following ecological and corporate values through green and healthy practices:
1. Water conservation: Our products, such as our carpet extractors, deliver adjustable solution control
for safe, healthy and fast-drying floors that eliminate mold and mildew. Our cylindrical brush floor ma-
chines use 30% less water. The design of cylindrical brush machines minimizes splashing and over
spray by containing water within the machine housing. Cylindrical brush machines have six times the
contact pressure of a conventional rotary brush machine, which not only helps reduce water usage, but
also improves worker productivity and reduces labor costs.
2. Less chemicals: Due to recent green legislation and the development of new cleaning standards, all
of our cylindrical brush machines and carpet extractors are designed to use less chemicals as well as
provide increased rotations per minute (RPMs). The adjustable head pressure helps to minimize the
need for powerful and potentially harmful chemicals. Our carpet extractors have enhanced vacuum sys-
tems that limit the possibility of mold and mildew from developing and speed carpet-drying time. The
result? Areas cleaned are ready for use faster and are safer for building occupants.
3. IAQ Enhancement: Vacuum cleaners including uprights, backpacks and canisters can release dust
and debris into the air if they are not designed with advanced infiltration systems. That’s why Tornado
has developed a comprehensive product family of high-filtration vacuums with true HEPA filtration to
minimize dust and exhaust from escaping the vacuum. All of our carpet care cleaning equipment has
been Carpet & Rug Institute (CRI) and Tandus Industries tested and approved for green cleaning.
What’s more, many of our UHS Ultra High Speed machines have passive vacuum systems to trap con-
taminants before they become airborne.
4. Reusable and Recyclable: Our machines are designed with durable polypropylene tanks, housings
and other components that are recyclable after the machine is no longer in use. All Tornado machines
proudly display the recyclable logo. Our long lasting, deep cycle, rechargeable batteries increase run
time and minimize down time and time spent on battery maintenance. Our cylindrical brush technology
creates less environmental waste by utilizing one cylindrical pad to every 100 rotary brush pads, in-
creases the productivity of your maintenance staff with less time spent on pad maintenance and
replacement.
5. U.S. Green Building Council Member: We support standards and the criteria established by
certification bodies such as the U.S. Green Building Council, The Carpet and Rug Institute’s (CRI)
Green Label Certification program, the Green Seal GS-37 standards, and more.
Tornado’s Commitment to
Environmental Sustainability

ExSELLerate® Sales Training Series │SWB 26/8
Notes

Copyright © 2012. Tornado Industries. ALL RIGHTS RESERVED. Use of text, copy, or distribution of this document is protected by law.
1.800.VACUUMS www.tornadovac.com
