Tornado EZ Installation guide

TORNADO INDUSTRIES
7401 W. LAWRENCE AVENUE
CHICAGO, IL 60706
[phone] FAX [phone]
www.tornadovac.com
Tornado
Operation & Maintenance Manual
For Commercial Use Only
20” & 24” Floorkeeper “EZ”
MODEL NOS.
99125A, 99125B
99126 & 99130
L2552NL 02/04 2004 Tornado Industries All rights reserved.

2
NOTES

3
This illustrated parts book covers:
MODEL 20" 20" 20" 20" 24"
CAT. NO. 99125** 99125A** 99125B** * 99126 99130**
VOLTS 36VDC 36VDC 36VDC 36VDC 36VDC
SERIESLLLLL
* 32” Squeegee **
All specifications are subject to change without notice.
TABLE OF CONTENTS
Safety Instructions……………………… 4
Safety Information……………………….6
Machine Set –Up……………………… ..8
How to Operate the Machine…………12
Maintenance…………………………… 16
Troubleshooting Chart……………… ...17
Traction Drive Assembly………………18
Brush Motor & Cover Assembly………20
Brush Lift Assembly……………………22
Solution Tank Assembly..................... 24
Recovery Tank Assembly................... 26
Squeegee Assembly .......................... 28
Control/Instrument System................. 30
Rear Access Panel w/Relays ............. 32
Control Wiring .................................... 34
Maintenance Parts……………………. 36
Tornado®Standard Warranty Program*
10 Years:
All plastic tanks and
rotationally-molded bodies 1) 5)
2 Years:
Parts on all Tornado and Tornado/Karcher
cleaning equipment 1) 2) 3) 5)
1 Year:
Labor on all Tornado and
Tornado/Karcher cleaning equipment 2) 5)
Warranties do not cover components
subject to normal wear or abuse and
misuse, and have other limitations
not specified here. For full details ,
contact your Authorized Tornado
Distributor, Service Center, or the
Tornado Technical Service
Department.
Tornado sales and services
representatives are not auhorized
to waive or alter the terms of this
warranty, or to increase the
obligations of Tornado under the
warranty. 1 Year:
Warranty on batteries and chargers,
One year pro-rated.
* Effective January 1st, 2001. Terms subject to change without notice.
1) Windshear™ Blower-Dryer, Insulation Blowers, T191, T201, CV 30, CV 38, CW 50, CW 100, Pro PAC Vacs, Duo-Upright
Carpetkeepers™, and all chargers are warranted for 1 (one) year for both parts and labor.
2) Warranties on all riding sweepers including the ICC1, KM 100/100 R, KMR 1250, and KMR 1700 are 24 months parts/6 months
labor OR 1000 hours of operation, whichever comes first. Warranties on the 75/140 & 90/140 are 24 months parts/12 months’
labor OR 1000 hours of operation, whichever comes first.
3) All non-wear item parts purchased after warranty expiration are warranted for 90 days.
4) Warranty starts from date of sale to the consumer or, at Tornado’s discretion, 6 months after dealer purchased the unit from
Tornado, whichever comes first.
5) See limited 2-year pressure washer warranty.

4

5

6

7

8

9

10

11

12

13

14

15

16

17

18

19
TRACTION DRIVE ASSEMBLY
1 1 19283 Weldment, Chassis Frame
2 2 18079 Caster
3 8 03301 Washer, Plain 5/l6"
4 8 01577 Lockwasher 5/16"
5 8 18111 Screw
7 2 03536 Lock washer 3/8"
8 2 18104 Screw
9 2 03321 Washer, Plain 3/8"
10 2 18509 Wheel w/Set Screw
11 1 19258 Transaxle
14 2 18115 Key
15 4 16031 SCREW-HEX HD CAP 5/16-18 X 1-1/2 (ZP)
16 4 01574 Lock washer, ¼” (H/S)
17 4 05427 Screw, Rd. Hd. ¼” 20 x 5/8”
18 2 19294 Retainer, EZ Transaxle
20 4 02956 #8 - 32 Lock Nut
21 4 10892 #8 - 1/2" Lock Screw
22 4 18309 5/8" Dia. Cable Clamp
23 2 03960 Washer-Plain 25/32 ID (ZP)
*
*
2
2
24422
24423
Brush, Carbon (Transaxle)
Cap, Brush (Transaxle)
* Not Shown (Service Only Items)
Item No. Qty. Part No. Description

20
