Tornado PRO SPOTTER 98636 Manual

TORNADO INDUSTRIES, LLC
3101 WICHITA COURT
FORT WORTH, TX 76140
PHONE 800-VACUUMS
FAX [phone]
WWW.TORNADOVAC.COM
Operations & Maintenance Manual
For Commercial Use Only
Form No. L8636-2 BA 07/20 ©Tornado Industries, LLC. All rights reserved
230V PRO SPOTTER
MODEL NO: 98636
Save These Instructions
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

2
NOTES
For warranty information go to www.tornadovac.com
Within 30 days, to activate the warranty, go to;
https://tornadovac.com/services/warranty-registration-form.aspx
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

3
Your new Tornado unit is a high quality, precision-made product. All parts used in the
manufacturing of this unit have passed rigid quality control standards prior to assembly. Please
safeguard the original receipt / invoice. If you experience any problems with your unit during the
warranty period, the original receipt / invoice will act as proof of purchase. Contact Tornado for
any warranty inquiries.
IMPORTANT SAFETY INSTRUCTIONS
READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING THIS UNIT
Read and understand this owner’s manual and all labels on the unit before operating. Safety is a
combination of common sense,staying alert and knowing how your unit works. Use this unit only
as described in this manual. Use only manufacturer’s recommended attachments. To reduce the
risk of personal injury or damage to your unit use only Tornado recommended accessories.
WARNING To avoid fire, DO NOT use with a flammable or combustible liquid or floor cleaner.
WARNING To avoid electric shock, DO NOT expose to rain. Store Indoors.
• To reduce risk of fire, electric shock, or injury:
• Do not use outdoors or on wet surfaces.
• Do not leave unit unattended when plugged in. Turn off the switch and unplug the
electrical cord when not in use and before servicing.
• Do not allow to be used as a toy. Close attention is necessary when used near children.
• Use only as described in this manual. Use only manufacturer’s recommended attachments.
• Do not use with damaged cord or plug. If unit is not working as it should, has been dropped,
damaged, left outdoors, or dropped into water, return it to a service center before using.
• Do not pull or carry by cord, use cord as a handle, close a door on cord, or pull a cord around
sharp edges or corners. Do not run the unit over cord. Keep cord away from heated surfaces.
• Do not use extension cords or outlets with inadequate current carrying capacity.
• Turn off all controls before unplugging.
• Do not handle plug or unit with wet hands.
• Do not put any objects into openings. Do not use with any opening blocked, keep free of
dust, lint, hair, and anything that may reduce airflow.
• Keep hair, loose clothing, fingers, and all parts of body away from openings and moving
parts.
• Do not pick up anything that is burning or smoking, such as cigarettes, matches or hot ashes.
• Use extra care when cleaning on stairs. Do not use to pick up flammable or combustible
liquids such as gasoline, or use in areas where they may be present.
• Store your unit indoors in a cool, dry area.
• Do not unplug by pulling on cord. To unplug, grasp the plug, NOT THE CORD.
• Follow these guidelines to ensure operator safety and to maintain equipment in running order.
• Make sure the machine is plugged into an electrical outlet with the same voltage rating as
shown on the nameplate of the machine.
• Do not attempt to plug a 115 volt machine into a 230 volt outlet or a 230 volt machine into a
115 outlet.
• Replace a damaged cord immediately.
• If an extension cord is necessary, use a three conductor grounding cord-12 gauge wire or
heavier to prevent motor burnout and over-heating of wires
• Do not expose the machine to freezing temperatures.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

4
GROUNDING INSTRUCTIONS
This appliance must be grounded. If it should malfunction or breakdown, grounding provides
a path of least resistance for electric current to reduce the risk electric shock. This machine is
equipped with a cord having an equipment -grounding conductor and grounding plug. The plug
must be inserted into an appropriate outlet that is properly installed and grounded in accordance
with all local codes and ordinances.
WARNING: Improper connection of the equipment-grounding conductor can result in a risk
of electric shock. Check with a qualified electrician or service person if you are in doubt as to
whether the outlet is properly grounded. Do not modify the plug provided with the appliance - if it
will not fit the outlet, have a proper outlet installed by a qualified electrician.
This appliance is for use on a nominal 230-volt circuit.
• Do not use the machine for totally dry vacuuming. This machine is not fitted with a fine dust
filter.
• Do not use citrus-based cleaners in this machine.
• Do not use cleaning chemicals in this machine except those recommended for commercial
extraction equipment. The use of any chemical with abrasive additives voids the warranty.
• Do not break off or pull out the ground prong on the plug.
• Do not attempt repair on a warranted machine unless instructions to perform it by an
authorized shop are obtained from the factory.
• Do not use any replacement parts except those specified on the parts list. Proper
performance of the machine could be affected if substitutions are made.
• Use defoamer at all times to prevent damaging the vacuum motor.
• Do not use water in excess of 140° F (60° C).
• Failure to comply with the above warning instructions will void the warranty.
Model 98636-AUS 98636-EU
Input Voltage 230 VAC 230 VAC
Plug Type AUS Euro
Solution Tank 3.5 Gal/13.2 l 3.5 Gal/13.2 l
Recovery Tank 2.5 Gal/9.5 l 2.5 Gal/9.5 l
Dimensions 24” x 14” x 23”/61cm x 36 cm
x 58 cm
24” x 14” x 23”/61cm x 36 cm
x 58 cm
Weight 36 lbs./16kg 36 lbs./16kg
Waterlift 89”/226 cm 89”/226 cm
CFM/CMM 104/3 104/3
Solution Pressure 55 p.s.i./3.8 BAR 55 p.s.i./3.8 BAR
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

5
Filling the Pro Spotter
• Unplug the unit.
• Disconnect the solution and recovery tanks.
• Remove the upper recovery tank.
• Add water and/or chemicals to the lower solution tank. Fill only to the fill line indicated on the
label on the inside of the solution tank. The tank will hold up to 3.5 gallons.
Operating the Pro Spotter
• Attach the solution hose to the quick disconnect in the pocket at the front of the machine.
• Attach the vacuum hose to the vacuum inlet (handle) above the recovery tank lid.
• Turn the 3-way switch to use either the pump and vacuum or the vacuum alone. (Allow
approximately 30 seconds for the pump to prime).
• Use the hand tool to spray and recover the solution.
• The float shut-off will disable the suction of the unit when the recovery tank is full. The
operator will notice a distinctive change in the sound of the vacuum motor when the shut-off
is activated. Empty the recovery tank, and then fill the solution tank, to resume cleaning.
Emptying the Recovery Tank
• Unplug the unit.
• Disconnect the solution line and vacuum hose.
• Unlatch the recovery tank from the base of the unit and remove.
• Remove the drain plug.
• Drain the tank over a suitable outlet for wastewater.
• Rinse the tanks after each use.
• Store the unit with the lid off of the recovery and allow it to air dry.
OPERATING INSTRUCTIONS
Vacuum Hose Attachment
Latch Assembly Recovery Tank Drain
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

6
Problem Possible Cause Solution
No Spray Pump is not primed. Depress lever on hand tool to
release pressure.
Low Solution Flow
Solution tank level is low.
Clogged filter.
Clogged Spray jet.
Refill Solution tank.*
Clean the screen filter on the
hose in the solution tank.
Clean the spray jet in the hand
tool.
Low Suction
Recovery tank is full.
Clogged Hand Tool or hose.
Excessive foam.
Empty recovery tank.
Clean Hand Tool and hose.
Add defoamer to recovery
tank.
TROUBLESHOOTING
*Before re-filling the solution tank, always empty the recovery tank.
Solution Hose Connection
3-Way Switch
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

7
3
2
5
1
10
22
60
58
52
56
59
51
15
23
54
14
18
19
47
20
24 41
40
44
39
38
34
31
32
30
33
29
35
28
36
37
27
26
25
46
45
48
21
20
50
12
57
11
53
55
9
8
7
6
4
35
23
16
49
16
53
30
43
42
17
31
13
61
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

8
No. Part No. Qty Description
1 X8295 6 Screw, #8 x 3/4”
2 PX103A 1 Screw-In Lid 6” w/Black Ring
3 X9061 1 Shut Off Disk
4 X9087 1 Washer
5 X9088 1 Screw 8-18 x 1/2”
6 PX103AG 1 Lid Gasket
7 X9518 1 Deflector
8 X9062 1 Float
9 X9082 1 Pipe 1-1/2 x 6-1/2”
10 X9076 1 Bulkhead Fitting 1-1/2” MPT x 1-1/2” Female Slip
11 72821A 1 Detailer Tool 1-1/2”
12 X9058 1 Stretch Hose Assembly 10’
13 72764A 1 Nozzle Adapter
14 PX30 1 Solution Tank Filter
15 PX213 1 Nylon Fitting 1/4” MPT x 1/4” Hose Barb
16 7DL003 6 Hose Clamp
17 71817A 26” Hose, 1/4” 250 PSI
18 PX14A 1 Gasket
19 PX46 1 Lock Nut
20 X9079 2 Gasket
21 X1920BLK 1 Solution Tank
22 PAS36 1 Drain Hose Plug and Strap
23 PC66 2 Hose Barb 1/4”H x 1/8MPT
24 X8237 3 Nyloc Nut
25 X9060 1 Vacuum Motor Screen
26 1989 1 Vacuum Motor 2 Stage 230V
27 X9045 3 Spacer
28 PC10 1 QD Male 1/8” x 1/8” NPT
29 X9412 1 Washer
30 7AT006 2 Brass 90 Deg. Elbow Fitting 1/4” Barb x 1/8” MPT
31 X8212 8 Washer
32 X8291 3 Screw 1/4-20 x 5-1/2”
33 X9047 2 Swivel Caster 45mm 1/4-20 x 3/4”
34 7BS003 2 Screw 1/4-20 x 1/2”
35 00-0600-0503 8 Washer
36 30676 5 Screw 10-24 x 5/8”
37 X9046 1 Base Plate
38 X9048 1 Rocker Switch
39 X8008N 1 Lock Nut 1/2” Steel
40 PD8 1 Strain Relief
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

9
No. Part No. Qty Description
41 M1401-AUS 1 Cord 20M w/Australian Plug (98636-AUS)
41 71912A 1 Cord 14/3 35’ w/ Euro Plug (98636-EU)
42 19565 1 Screw #8 x 3/8”
43 7CZ001 1 Vacuum Hose 2”
44 PX215 2 Hose Clamp
45 FJ5082-2 1 Pump 230V
46 PX204 2 Pump Mount
47 PX214 1 Nylon Fitting 90 Deg. 1/8” MPT x 1/4” Hose Barb
48 X8271 5 Nyloc Nut
49 X9064 1 Gasket
50 PX209 1 Foam Filter
51 7AJ004 1 Brass Anchor Connector 1/8” PFT x MPT
52 72115A 1 Washer
53 X8262 6 Screw 8-32 x 1/4”
54 X9059 2 Latch w/Keeper
55 X8278 2 Screw 8-32 x 1/2”
56 X9106 2 Nut
57 X1921YEL 1 Recovery Tank Yellow
58 X9065 4 Screw 1/4-20 x 1”
59 X8990 1 Handle w/Wheel Assembly
60 72173A 1 Spring Clip
61 7CY001 1 Int. Toothed Lock Washer
Not Shown X2045 1 Fill Line Indicator Label
Not Shown 72697A 1 Wire Reinforced Hose
*Always follow manufacturer instructions*
*AAA Rent-All 225-291-1356*

10
Form No. L8636-2 BA 07/20
