Tornado Pro PAC Manual

TORNADO INDUSTRIES
7401 W. LAWRENCE AVENUE
CHICAGO, IL 60706
[phone] FAX [phone]
www.tornadovac.com
Tornado
Operation & Maintenance Manual
For Commercial Use Only
Pro and Super Pro PAC Vacs
MODEL NO.
93020 (6 Quart)
93025 (10 Quart)
L3025A 5/04 2004 Tornado Industries All rights reserved.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

2
This instruction book covers:
CATALOG NO. 93020 93025
CAPACITY 6 QUARTS 10 QUARTS
SERIES A A
VOLTS 120V 120V
WATTS 1100 1100
CERTIFICATION Pending Pending
.
ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE.
TABLE OF CONTENTS:
Safety Instructions ..................................3
Grounding Instructions............................4
Operation and Assembly Instructions .....6
Troubleshooting Guide ........................... 7
Exploded View ....................................... 8
Parts List ................................................ 9
Tornado®Standard Warranty Program*
10 Years:
All plastic tanks and
rotationally-molded bodies 1) 5)
2 Year:
Parts on all Tornado and Tornado/Karcher
cleaning equipment 1) 2) 3) 5)
1 Year:
Labor on all Tornado and Tornado/Karcher
cleaning equipment 2) 5)
Warranties do not cover
components subject to normal
wear or abuse and misuse,
and have other limitations not
specified here. For full details
, contact your Authorized
Tornado Distributor, Service
Center, or the Tornado
Technical Service
Department.
Tornado sales and service
representatives are not
authorized to waive or alter
the terms of this warranty,
or to increase the
obligations of Tornado
under the warranty.
1 Year:
Warranty on batteries and chargers,
one year pro-rated.
* Effective January 1st, 2004. Terms subject to change without notice.
1) Windshear™ Blower-Dryer, Insulation Blowers, T191, T201, CV 30, CV 38, CW 50, CW 100, Pro PAC Vacs, Duo-Upright
Carpetkeepers™, and all chargers are warranted for 1 (one) year for both parts and labor.
2) Warranties on all riding sweepers including the ICC1, KM 100/100 R, KMR 1250, and KMR 1700 are 24 months parts/6
months labor OR 1000 hours of operation, whichever comes first. Warranties on the 75/140 & 90/140 are 24 months
parts/12 months’ labor OR 1,000 hours of operation whichever comes first.
3) All-non wear item parts purchased after warranty expiration are warranted for 90 days.
4) Warranty starts from the date of sale to the consumer or, at Tornado’s discretion, 6 months after dealer purchased the
unit from Tornado, whichever comes first.
See separate limited 2-year pressure washer policy.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

3
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

4
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

5
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

6
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

7
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

8
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

9
Refer to exploded view on opposite page.
ITEM
NO.
PART
NO.
DESCRIPTION QTY
1 31985 VACUUM BODY, 6-QT. 1
1 31878 VACUUM BODY, 10-QT. 1
2 31986 6-QT. LID ASSEMBLY, SCREW-ON 1
2 31879 10-QT. LID ASSEMBLY WITH LATCHES 1
6 90575 6-QT. PAPER BAG FILTER, 10-PACK 1
6 90557 10-QT. PAPER BAG FILTER, 10-PACK 1
7 31864 6-QT. CLOTH FILTER WITH GASKET 1
7 31865 10-QT. CLOTH FILTER WITH GASKET 1
8 31871 DOME FILTER, COMPLETE ASSEMBLY 1
12 31882 MOTOR 1
13 30089 FOAM MOTOR GASKET 1
14 32161 MOTOR SCREWS 4
15 18885 MOTOR WASHERS 4
16 31923 MOTOR DEFLECTOR 1
17 10886 MOTOR DEFLECTOR SCREWS 2
18 31872 SOUND FILTER/BAND 1
19 31873 DUAL-CELL NOISE FILTER 1
20 31874 CUSHION BACK PAD 1
21 31875 SHOULDER & WAIST BAND (NOT SHOWN) 1
22 16142 SHOULDER & BAND SCREWS 4
23 32165 SHOULDER & BAND WASHERS 4
24 31867 VACUUM HOSE SMOOTH CORE 1
25 10670 ON/OFF SWITCH 1
26 31956 PIGTAIL & STRAIN RELIEF ASSEMBLY 1
27 31877 STRAIN RELIEF & NUT ONLY 1
28 31866 CORD – 50’ EXTENSION 1
51 31915 2-PIECE ALUMINUM WAND (Not Shown) 1
53 90004 17” CREVICE TOOL (Not Shown) 1
54 90712 1-1/2” DUST BRUSH (Not Shown) 1
55 90711 1-1/2” UPHOLSTERY TOOL (Not Shown) 1
56 31663 14” SCALLOPED CARPET TOOL (Not Shown) 1
Refer to “Tool Kit” diagram at right.
ITEM
NO.
PART
NO.
DESCRIPTION QTY
51 31915 2-PIECE ALUMINUM WAND 1
52 31867 VACUUM HOSE SMOOTH CORE 1
53 90004 17” CREVICE TOOL 1
54 90712 ROUND DUST BRUSH 1
55 90711 UPHOLSTERY TOOL 1
56 31663 14” SCALLOPED CARPET TOOL 1
* 31972 14” BARE FLOOR TOOL (Not Shown) Opt.
