OWNER’S MANUAL
AIR CONDITIONER (SPLIT TYPE)
For general public use
Indoor unit
RAS-10, 13, 16SKV2 Series
Outdoor unit
RAS-10, 13, 16SAVR Series
1110250162_EN.indd 11110250162_EN.indd 1 5/7/09 3:37:05 PM5/7/09 3:37:05 PM

1
Press
FIX
: Move the louver in
the desired vertical direction.
2
Press
SWING
: Swing the air
automatically and press again to
stop.
3
For horizontal direction, adjust
manually.
DANGER
• Do not install, repair, open or remove the cover. It may expose you to
dangerous voltages. Ask the dealer or the specialist to do this.
• Turning off the power supply will not prevent potential electric shock.
• The appliance shall be installed in accordance with national wiring
regulation.
• Means for disconnection from the supply having a contact separation
of at least 3 mm in all poles must be incorporated in the fixed wiring.
WARNING
• Do not expose your body directly to cool air for a long time.
• Do not insert your finger or any article into the air inlet/outlet.
• When an abnormality (burning smell, etc.) occurs, stop the air
conditioner and disconnect the power supply or turn off the breaker.
• This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a person responsible
for their safety.
• Children should be supervised to ensure that they do not play with the
appliance.
CAUTION
• Do not wash the unit with water. It may cause an electric shock.
• Do not use this air conditioner for other purposes such as preserving
food, breeding animal, etc.
• Do not step or put anything on the indoor/outdoor unit. It may cause
an injury or damage the unit.
• Do not touch aluminium fin because it may cause an injury.
• Before cleaning the unit, turn off the main switch or the circuit breaker.
• When the unit won’t be used for a long time, turn off the main switch
or the circuit breaker.
• It is recommended that maintenance be performed by a specialist
when the unit has been operated for a long time.
PRECAUTIONS FOR SAFETY
INDOOR UNIT DISPLAY
1Hi POWER (Green)
2FILTER (Orange)
3PRE.DEF
(DE-FROST) (Orange)
4TIMER (Yellow)
5OPERATION (Green)
6RESET button
1
Hi POWER FILTER PRE.DEF TIMER OPERATION
RESET
12
3
45
6
PREPARATION BEFORE USE
2
Preparing Filters
1. Open the air inlet grille and remove the air filters.
2. Attach the filters. (see detail in the accessory sheet).
Loading Batteries
1. Remove the battery cover.
2. Insert 2 new batteries (AAA type)
following the (+) and (–) positions.
Clock Setup
1. Push CLOCK
●by tip of the pencil.
2. Press ON or OFF : adjust the time.
3. Press SET : Set the time.
Remote Control Reset
1. Remove the battery.
2. Press .
3. Insert the battery.
AIRFLOW DIRECTION
3
Note:
• Do not move the louver manually by others.
• The louver may automation positioning by come operation mode.
ONE-TOUCH
5
Press the “ONE-TOUCH” button for fully automated operation that is
customised to the typical consumer preferences in your region of the world.
The customised settings control temperature air flow strength, air flow
direction and other settings to provide you alternate contact with “ONE-
TOUCH” of the button. If you prefer other settings you can select from the
many other operating functions of your Toshiba unit.
Press
ONE-TOUCH
: Start the operation.
AUTOMATIC OPERATION
6
To automatically select cooling, heating, or fan only operation
1. Press
MODE
: Select A.
2. Press
TEMP
: Set the desired temperature.
COOLING / HEATING / FAN ONLY OPERATION
7
1. Press
MODE
: Select Cool , Heat , or Fan only .
2. Press
TEMP
: Set the desired temperature.
Cooling: Min. 17oC, Heating: Max. 30oC, Fan Only: No temperature indication
3. Press
FAN
: Select AUTO, LOW , LOW+ , MED , MED+ ,
or HIGH .
DRY OPERATION (COOLING ONLY)
8
For dehumidification, a moderate cooling performance is controlled
automatically.
1. Press
MODE
: Select Dry .
2. Press
TEMP
: Set the desired temperature.
ACL
Hi-POWER OPERATION
9
To automatically control room temperature and airflow for faster cooling or
heating operation (except in DRY and FAN ONLY mode)
Press
Hi-POWER
: Start and stop the operation.
ECO OPERATION
10
To automatically control room to save energy (except in DRY and FAN ONLY
mode)
Press
ECO
: Start and stop the operation.
Note: Cooling operation; the set temperature will increase automatically 1
degree/hour for 2 hours (maximum 2 degrees increase). For heating
operation the set temperature will decrease.
REMOTE CONTROL
4
1Infrared signal emitter
2Start/Stop button
3Mode select button (MODE)
4Temperature button (TEMP)
5Fan speed button (FAN)
6Swing louver button (SWING)
7Set louver button (FIX)
8On timer button (ON)
9Off timer button (OFF)
!Sleep timer button (SLEEP)
"Setup button (SET)
#Clear button (CLR)
$Memory and Preset button (PRESET)
%One Touch button (ONE-TOUCH)
&High power button (Hi-POWER)
(Economy button (ECO)
)Quiet button (QUIET)
~Comfort sleep button (COMFORT SLEEP)
+Filter reset button (FILTER)
,Clock Reset button (CLOCK)
-Check button (CHK)
PRESET
ONE-TOUCH
QUIET
SWING
TIMER
ON
FILTER CHK CLOCK
OFF
CLR
SLEEP SET
FIX Hi-POWER ECO
COMFORT
SLEEP
MODE
TEMP
FAN
5
4
3
~
(
&
9
,
"
#
$
%
)
+
-
8
7
6
1
2
!
1110250162_EN.indd 21110250162_EN.indd 2 5/7/09 3:37:08 PM5/7/09 3:37:08 PM

TEMPORARY OPERATION
11
In case of the misplaced or discharged remote control
•Pressing the RESET button, the unit can start or
stop without using the remote control.
•Operation mode is set on AUTOMATIC operation,
preset temperature is 24°C and fan operation is
automatic speed.
TIMER OPERATION
12
Setting the ON Timer Setting the OFF Timer
1
Press
ON
: Set the desired ON timer.
Press
OFF
: Set the desired OFF timer.
2
Press SET : Set the timer. Press SET : Set the timer.
3
Press
CLR
: Cancel the timer. Press
CLR
: Cancel the timer.
Daily timer allows the user to set both the ON & OFF timers and will be
activated on a daily basis.
Setting Daily Timer
1
Press
ON
: Set the ON timer.
3
Press SET .
2
Press
OFF
: Set the OFF timer.
4
Press SET button during the
( or ) mark flashing.
• During the daily timer is activating, both arrows ( , ) are indicated.
Note:
• Keep the remote control in accessible transmission to the indoor unit;
otherwise, the time lag of up to 15 minutes will occur.
• The setting will be saved for the next same operation.
PRESET OPERATION
13
Set your preferred operation for future use. The setting will be memorized by
the unit for future operation (except airflow direction).
1. Select your preferred operation.
2. Press and hold
PRESET
for 3 seconds to memorize the setting.
The Pmark displays.
3. Press
PRESET
: Operate the preset operation.
AUTO RESTART OPERATION
14
To automatically restart the conditioner after the power failure (Power of the
unit must be on.)
Setting
1. Press and hold the RESET button on the indoor unit for 3 seconds to set
the operation. (3 beep sound and OPERATION lamp blink 5 time/sec for
5 seconds)
• Do not operate ON timer and OFF timer.
2. Press and hold the RESET button on the indoor unit for 3 seconds to
cancel the operation. (3 beep sound but OPERATION lamp does not
blink)
To operate at super low fan speed for quiet operation (except in DRY mode)
Press
QUIET
: Start and stop the operation.
Note: Under certain conditions, QUIET operation may not provide
adequate cooling or heating due to low sound features.
To save energy while sleeping, automatically control air flow and
automatically turn OFF.
Press
COMFORT
SLEEP
: Select 1, 3, 5 or 9 hrs for OFF timer operation.
Note: The cooling operation, the set temperature will increase
automatically 1 degree/hour for 2 hours (maximum 2 degrees
increase). For heating operation, the set temperature will
decrease.
QUIET OPERATION
15
COMFORT SLEEP OPERATION
16
SELF CLEANING OPERATION (COOL AND DRY OPERATION ONLY)
19
OPERATION AND PERFORMANCE
20
1. Three-minute protection feature: To prevent the unit from being activated
for 3 minutes when suddenly restarted or switched to ON.
2. Preheating operation: Warm up the unit for 5 minutes before the heating
operation starts.
3. Warm air control: When the room temperature reaches the set
temperature, the fan speed is automatically reduced and the outdoor
unit will stop.
4. Automatic defrosting: Fans will stop during defrost operation.
5. Heating capacity: Heat is absorbed from outdoors and released into
the room. When the outdoor temperature is too low, use another
recommended heating apparatus in combination with the air conditioner.
6. Consideration for accumulated snow: Select the position for outdoor unit
where it will not be subjected to snow drifts, accumulation of leaves or
other seasonal debris.
7. Some minor cracking sound may occur when unit operating. This is
normal because the cracking sound may be caused by expansion/
contraction of plastic.
Note: Item 2 to 6 for Heating model
Air conditioner operating conditions
Temp.
Operation Outdoor Temperature Room Temperature
Heating –15°C ~ 24°C Less than 28°C
Cooling –10°C ~ 46°C 21°C ~ 32°C
Dry –10°C ~ 46°C 17°C ~ 32°C
The unit does not operate. Cooling or Heating is abnormally low.
• The power main switch is
turned off.
• The circuit breaker is
activated to cut off the power
supply.
• Stoppage of electric current
• ON timer is set.
• The filters are blocked with dust.
•
The temperature has been set improperly.
• The windows or doors are opened.
• The air inlet or outlet of the outdoor
unit is blocked.
• The fan speed is too low.
• The operation mode is FAN or DRY.
TROUBLESHOOTING (CHECK POINT)
21
REMOTE CONTROL A-B SELECTION
22
To separate using of remote control for each indoor unit in case of 2 air
conditioner are installed nearly.
Remote Control B Setup.
1. Press RESET button on the indoor unit to turn the air conditioner ON.
2. Point the remote control at the indoor unit.
3. Push and hold CHK ●button on the Remote Control by the tip of the
pencil. “00” will be shown on the display.
4. Press
MODE
during pushing CHK ●. “B” will show on the display and
“00” will disappear and the air conditioner will turn OFF. The Remote
Control B is memorized.
Note: 1. Repeat above step to reset Remote
Control to be A.
2. Remote Control A has not “A” display.
3. Default setting of Remote Control from
factory is A.
To start the sleep timer (OFF timer) operation
Press
SLEEP
: Select 1, 3, 5 or 9 hrs for OFF timer operation.
SLEEP TIMER OPERATION
17
Firstly, turn off the circuit breaker.
Filter Reset (Some models only)
FILTER lamp lights on; the filter must be cleaned.
To turn off the lamp, push the RESET button on the indoor unit or the FILTER
button on the remote control.
Indoor Unit and Remote Control
• Clean the indoor unit and the remote control with a wet cloth when
needed.
• No benzine, thinner, polishing powder or chemically-treated duster.
MAINTENANCE
18
To protect bad smell caused by the humidity in the indoor unit.
1. If the button is pressed once during “Cool” or “Dry” mode, the fan will
continue to run for other 20 minutes, then it will turn off automatically.
This will reduce the moisture in the indoor unit.
2. To stop the unit immediately, press the 3 times within 30 seconds.
Note:
• SELF CLEANING operation is default setting from factory.
• To cancel this function, press and hold the reset button on the indoor
unit for 20 seconds.
The SELF CLEANING operation will be cancelled. (5 beep sound but
OPERATION lamp does not blink)
• Do the same to set this function again. (5 beep sound and OPERATION
lamp blink 5 time/sec for 5 seconds)
• AUTO RESTART operation will be cancelled by setting or cancellation of
SELF CLEANING operation. Set it again if necessary.
1110250162_EN.indd 31110250162_EN.indd 3 5/7/09 3:37:11 PM5/7/09 3:37:11 PM

1110250162_EN.indd 41110250162_EN.indd 4 5/7/09 3:37:14 PM5/7/09 3:37:14 PM
