Toshiba RAV-SM182CTP-UL User manual

For commercial use
Pour usage commercial
Para uso comercial
AIR CONDITIONER (SPLIT TYPE)
Owner’s Manual
Indoor Unit
Model name:
Ceiling type
RAV-SM182CTP-UL
RAV-SM242CTP-UL
RAV-SM302CTP-UL
RAV-SM362CTP-UL
RAV-SM422CTP-UL
RAV-SM482CTP-UL
Owner’s Manual 1 English
Manuel d’installation 18 Français
Manual de instalación 35 Español
1115653833
01_OM_1115653833_EN.indd 101_OM_1115653833_EN.indd 1 4/4/2565 BE 11:104/4/2565 BE 11:10

Original instruction
Thank you very much for purchasing TOSHIBA Air Conditioner.
Please read this owner’s manual carefully before using your Air Conditioner.
• Be sure to obtain the “Owner’s manual” and “Installation manual” from constructor (or dealer).
Request to constructor or dealer.
• Please clearly explain the contents of the Owner’s manual and hand over it.
NOTE
This manual describes operations of the indoor unit and the wireless remote controller.
For details of the wired remote controller and the outdoor unit, refer to the operation manual supplied with the
outdoor unit. (Keep these manuals carefully.)
ADOPTION OF NEW REFRIGERANT
This Air Conditioner uses R410A an environmentally friendly
refrigerant.
According to UL 60335-1
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play
with the appliance.
Auto-restart
This air conditioner is equipped with an Automatic restarting facility which allows the air conditioner to resume
the set operating conditions in the event of a supply power shutdown without the use of the remote controller.
Contents
1 Precautions for safety.....................................................................................3
2 Part names.......................................................................................................6
3 Wired remote controller..................................................................................7
4 Operation .........................................................................................................8
5 Off reminder timer.........................................................................................10
6 Adjustment of wind direction....................................................................... 11
7 Energy saving................................................................................................13
8 Maintenance...................................................................................................14
9 Troubleshooting ............................................................................................15
10 Operations and performance .......................................................................16
11 Installation .....................................................................................................17
– 1 –
1-EN 2-EN
01_OM_1115653833_EN.indd 101_OM_1115653833_EN.indd 1 4/4/2565 BE 11:104/4/2565 BE 11:10

EN
Generic Denomination: Air Conditioner
Definition of Qualified Installer or Qualified Service Person
The air conditioner must be installed, maintained, repaired and removed by a qualified installer or qualified service
person. When any of these jobs is to be done, ask a qualified installer or qualified service person to do them for
you. A qualified installer or qualified service person is an agent who has the qualifications and knowledge described
in the table below.
Agent Qualifications and knowledge which the agent must have
Qualified installer • The qualified installer is a person who installs, maintains, relocates and removes the air conditioners
made by Toshiba Carrier Corporation. He or she has been trained to install, maintain, relocate and
remove the air conditioners made by Toshiba Carrier Corporation or, alternatively, he or she has
been instructed in such operations by an individual or individuals who have been trained and is
thus thoroughly acquainted with the knowledge related to these operations.
• The qualified installer who is allowed to do the electrical work involved in installation, relocation
and removal has the qualifications pertaining to this electrical work as stipulated by the local laws
and regulations, and he or she is a person who has been trained in matters relating to electrical
work on the air conditioners made by Toshiba Carrier Corporation or, alternatively, he or she has
been instructed in such matters by an individual or individuals who have been trained and is thus
thoroughly acquainted with the knowledge related to this work.
• The qualified installer who is allowed to do the refrigerant handling and piping work involved in
installation, relocation and removal has the qualifications pertaining to this refrigerant handling and
piping work as stipulated by the local laws and regulations, and he or she is a person who has
been trained in matters relating to refrigerant handling and piping work on the air conditioners made
by Toshiba Carrier Corporation or, alternatively, he or she has been instructed in such matters
by an individual or individuals who have been trained and is thus thoroughly acquainted with the
knowledge related to this work.
• The qualified installer who is allowed to work at heights has been trained in matters relating to
working at heights with the air conditioners made by Toshiba Carrier Corporation or, alternatively,
he or she has been instructed in such matters by an individual or individuals who have been trained
and is thus thoroughly acquainted with the knowledge related to this work.
Qualified service
person
• The qualified service person is a person who installs, repairs, maintains, relocates and removes
the air conditioners made by Toshiba Carrier Corporation. He or she has been trained to install,
repair, maintain, relocate and remove the air conditioners made by Toshiba Carrier Corporation
or, alternatively, he or she has been instructed in such operations by an individual or individuals
who have been trained and is thus thoroughly acquainted with the knowledge related to these
operations.
• The qualified service person who is allowed to do the electrical work involved in installation, repair,
relocation and removal has the qualifications pertaining to this electrical work as stipulated by the
local laws and regulations, and he or she is a person who has been trained in matters relating to
electrical work on the air conditioners made by Toshiba Carrier Corporation or, alternatively, he or
she has been instructed in such matters by an individual or individuals who have been trained and
is thus thoroughly acquainted with the knowledge related to this work.
• The qualified service person who is allowed to do the refrigerant handling and piping work involved
in installation, repair, relocation and removal has the qualifications pertaining to this refrigerant
handling and piping work as stipulated by the local laws and regulations, and he or she is a person
who has been trained in matters relating to refrigerant handling and piping work on the
air conditioners made by Toshiba Carrier Corporation or, alternatively, he or she has been
instructed in such matters by an individual or individuals who have been trained and is thus
thoroughly acquainted with the knowledge related to this work.
• The qualified service person who is allowed to work at heights has been trained in matters relating
to working at heights with the air conditioners made by Toshiba Carrier Corporation or, alternatively,
he or she has been instructed in such matters by an individual or individuals who have been trained
and is thus thoroughly acquainted with the knowledge related to this work.
■Warning indications on the air conditioner unit
Warning indication Description
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect all remote
electric power supplies
before servicing.
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect all remote electric power supplies before servicing.
WARNING
Moving parts.
Do not operate unit with grille
removed.
Stop the unit before the servicing.
WARNING
Moving parts.
Do not operate unit with grille removed.
Stop the unit before the servicing.
CAUTION
High temperature parts.
You might get burned
when removing this panel.
CAUTION
High temperature parts.
You might get burned when removing this panel.
CAUTION
Do not touch the aluminum
fins of the unit.
Doing so may result in injury.
CAUTION
Do not touch the aluminium fins of the unit.
Doing so may result in injury.
CAUTION
BURST HAZARD
Open the service valves before
the operation, otherwise there
might be the burst.
CAUTION
BURST HAZARD
Open the service valves before the operation, to avoid
unnecessary pressure built up which could lead to explosion.
– 2 – 4-EN3-EN
01_OM_1115653833_EN.indd 201_OM_1115653833_EN.indd 2 4/4/2565 BE 11:104/4/2565 BE 11:10

1Precautions for safety
The manufacturer shall not assume any liability for the damage
caused by not observing the description of this manual.
WARNING
General
•Carefully read Owner’s Manual before starting the air conditioner.
There are many important things to keep in mind for daily
operation.
•Ask for installation to be performed by the dealer or a professional.
Only a qualified installer is able to install an air conditioner.
If a non-qualified person installs an air conditioner, it may result in
problems such as fire, electric shock, injury, water leakage, noise
and vibration.
•Do not use any refrigerant different from the one specified for
complement or replacement. Otherwise, abnormally high pressure
may be generated in the refrigeration cycle, which may result in a
failure or explosion of the product or an injury to your body.
•Places where the operation sound of the outdoor unit may cause
a disturbance. (Especially at the boundary line with a neighbour,
install the air conditioner while considering the noise.)
•This appliance is intended to be used by expert or trained users in
shops, in light industry, or for commercial use by lay persons.
Transportation and storage
•To transport the air conditioner, wear shoes with protective toe
caps, protective gloves, and other protective clothing.
•To transport the air conditioner, do not take hold of the bands
around the packing carton. You may injure yourself if the bands
should break.
•Before stacking the packing cartons for storage or transportation,
heed the precautions written on the packing cartons. Failure to
heed the precautions may cause the stack to collapse.
•The air conditioner must be transported in stable condition. If any
part of the product broken, contact your dealer.
•When the air conditioner must be transported by hand, carry it by
two or more people.
Installation
•Only a qualified installer or qualified service person is allowed
to carry out the electrical work of the air conditioner. Under no
circumstances must this work be done by an unqualified individual
since failure to carry out the work properly may result in electric
shocks and/or electrical leaks.
•After the installation work has been completed, have the installer
explain about the circuit breaker positions. In the event that
trouble has occurred in the air conditioner, set the circuit breaker
to the OFF position, and contact a service person.
•If the unit is installed in a small room, take appropriate measures
to prevent the refrigerant from exceeding the limit concentration
even if it leaks. Consult the dealer from whom you purchased the
air conditioner when you implement the measures. Accumulation
of highly concentrated refrigerant may cause an oxygen deficiency
accident.
•Do not install the air conditioner in a location that may be subject
to a risk of exposure to a combustible gas. If a combustible gas
leaks and becomes concentrated around the unit, a fire may
occur.
•Use the company-specified products for the separately purchased
parts. Use of non-specified products may result in fire, electric
shock, water leakage or other trouble. Have the installation
performed by a professional.
•Confirm that grounding is performed correctly.
Operation
•Before opening the intake grille of the indoor unit or service panel
of the outdoor unit, set the circuit breaker to the OFF position.
Failure to set the circuit breaker to the OFF position may result
in electric shocks through contact with the interior parts. Only a
qualified installer or qualified service person is allowed to remove
the intake grille of the indoor unit or service panel of the outdoor
unit and do the work required.
•Inside the air conditioner are high-voltage areas and rotating
parts. Due to the danger of electric shocks or of your fingers or
physical objects becoming trapped in the rotating parts, do not
remove service panel of the outdoor unit.
– 3 –
5-EN 6-EN
01_OM_1115653833_EN.indd 301_OM_1115653833_EN.indd 3 4/4/2565 BE 11:104/4/2565 BE 11:10

EN
When work involving the removal of these parts is required,
contact a qualified installer or a qualified service person.
•Do not move or repair any unit by yourself. Since there is high
voltage inside the unit, you may get electric shock when removing
the cover and main unit.
•Use of a stand more than 19.7" (50 cmhigh to clean the filter of
the indoor unit or to carry out other such jobs constitutes working
at heights. Due to the danger of falling off the stand and injuring
yourself while working at heights, this kind of work should not be
done by unqualified individuals. When this kind of work must be
carried out, do not do it yourself but ask a qualified installer or a
qualified service person to do it for you.
•Do not touch the aluminum fin of the outdoor unit. You may injure
yourself if you do so. If the fin must be touched, do not touch
it yourself but contact a qualified installer or a qualified service
person.
•Do not climb onto or place objects on top of the outdoor unit.
You may fall or the objects may fall off of the outdoor unit and
result in injury.
•Do not place any combustion appliance in a place where it is
directly exposed to the wind of air conditioner, otherwise it may
cause imperfect combustion.
•When the air conditioner is operated with a combustion appliance
in the same place, ventilate the room sufficiently. Poor ventilation
causes oxygen shortage.
•When the air conditioner is used in a closed room, sufficiently
ventilate the room. Poor ventilation causes oxygen shortage.
•Do not expose your body to cool air directly for a long time and do
not cool yourself excessively.
Doing so may result in deteriorated physical condition and ill
health.
•Do not insert your finger or a stick into the air intake or discharge.
Doing so may result injury as the fan is rotating at high speed
inside the unit.
•Consult the shop where you purchased the air conditioner if
air conditioning (cooling and heating) is not performed properly as
a refrigerant leakage may be the cause. Confirm the repair details
with a qualified service person when the repair includes additional
charging of the refrigerant.
•Stop running the air conditioner and turn off the breaker before
cleaning.
Otherwise, injury may result as the fan is rotating at high speed
inside the unit.
Repairs
•If there is any kind of trouble (such as when an error display has
appeared, there is a smell of burning, abnormal sounds are heard,
the air conditioner fails to cool or heat or water is leaking) has
occurred in the air conditioner, do not touch the air conditioner
yourself but set the circuit breaker to the OFF position, and
contact a qualified service person. Take steps to ensure that the
power will not be turned on (by marking “out of service” near the
circuit breaker, for instance) until qualified service person arrives.
Continuing to use the air conditioner in the trouble status may
cause mechanical problems to escalate or result in electric shocks
or other trouble.
•If the fan grille is damaged, do not approach the outdoor unit but
set the circuit breaker to the OFF position, and contact a qualified
service person to have the repairs done. Do not set the circuit
breaker to the ON position until the repairs are completed.
•If there is a danger of the indoor unit’s falling, do not approach
the indoor unit but set the circuit breaker to the OFF position, and
contact a qualified installer or a qualified service person to refit the
unit. Do not set the circuit breaker to the ON position until the unit
has been refitted.
•If there is a danger of the outdoor unit’s toppling over, do not
approach the outdoor unit but set the circuit breaker to the OFF
position, and contact a qualified installer or a qualified service
person to have the improvements or refitting done. Do not set
the circuit breaker to the ON position until the improvements or
refitting is completed.
•Do not customize the unit. Doing so may result in fire, electric
shock or other trouble.
– 4 – 8-EN7-EN
01_OM_1115653833_EN.indd 401_OM_1115653833_EN.indd 4 4/4/2565 BE 11:104/4/2565 BE 11:10

Relocation
•When the air conditioner is to be relocated, do not relocate it
yourself but contact a qualified installer or a qualified service
person. Failure to relocate the air conditioner properly may result
in electric shocks and/or a fire.
CAUTION
Installation
•Certainly lay the drain hose for perfect draining. Improper
drainage may cause flooding in the house and getting furniture
wet.
•Connect the air conditioner to an exclusive power supply of the
rated voltage, otherwise the unit may break down or cause a fire.
•Confirm that the outdoor unit are fixed on the base. Otherwise,
falling down of the units or other accidents may occur.
Operation
•Do not use this air conditioner for special purpose such as
preserving food, precision instruments, art objects, breeding
animals, car, vessel.
•Do not touch any switches with wet finger, otherwise you may get
an electric shock.
•If the air conditioner will not be used for a considerably long time,
turn off the main switch or the circuit breaker, for safety.
•To make the air conditioner operate in its original performance,
operate it within the range of the operating temperature specified
in the instructions. Otherwise it may cause a malfunction, or water
leak from the unit.
•Prevent any liquid from falling into the remote controller.
Do not spill juice, water or any kind of liquid.
•Do not wash the air conditioner. Doing so may result in electric
shock.
•Check whether the installation base and other equipment have
become deteriorated after being used for a long time.
Leaving them such condition may result in the unit’s falling down
and causing injury.
•Do not leave flammable sprays or other flammable materials near
the air conditioner, and do not spray flammable aerosol directly to
the air conditioner. They may catch fire.
•Stop running the air conditioner and turn off the breaker before
cleaning.
Otherwise, injury may result as the fan is rotating at high speed
inside the unit.
•Ask for cleaning of the air conditioner to be performed by the
dealer.
Cleaning the air conditioner in an improper manner may cause
damage to plastic parts, insulation failure of electric parts or other
parts, and result in a malfunction. In the worst case, it may result
in water leakage, electric shock, smoke emission or fire.
•Do not put a water container such as a vase on the unit.
Water intrusion into the unit may occur and it may cause
deterioration of electric insulation and result in electric shock.
•Do not wash air conditioners with pressure washers.
Electric leaks may cause electric shocks or fires.
– 5 –
9-EN 10-EN
01_OM_1115653833_EN.indd 501_OM_1115653833_EN.indd 5 4/4/2565 BE 11:104/4/2565 BE 11:10

EN
■Information on the transportation, handling and storage of the
carton
◆Examples of indication on the carton
Symbol Description Symbol Description
Keep dry Do not drop
Fragile Do not lay down
Stacking height
(12 cartons can be
stacked in this case)
Do not walk on this carton
This side up Do not step
Handle with care
Other cautions Description
CAUTION
Injury possibility.
Don’t handle with packing band, or may get injured in case of
broken band.
Stacking notice.
In case that cardboard boxes protrude out of pallet when stacking.
Lay a 0.4" (10 mm) thick plywood over the pallet.
2Part names
■Indoor unit
Horizontal louver / Vertical grille /
Air discharge
The air discharge direction can be
changed.
Air intake grille
Air is taken in through here.
Ground screw
Inside the electrical box.
Air filter
Filters out dust.
(Behind the air intake grille)
■Outdoor unit (The design varies depending on the outdoor unit.
The following illustration shows an example.)
Panel
There is an ground screw,
valves, and electric parts inside.
Air intake
(Side and rear)
Fixing leg
Air discharge
Piping panel
Wiring hole
Refrigerant pipe discharge
– 6 – 12-EN11-EN
01_OM_1115653833_EN.indd 601_OM_1115653833_EN.indd 6 4/4/2565 BE 11:104/4/2565 BE 11:10

3Wired remote controller
This remote controller can control the operation of up to 8 indoor units.
■Before Use
Operate the remote control according to the following procedure
when it is used for the first time or when the settings are
changed. Pushing the [ ON/OFF] button starts running the
air conditioning unit with the settings made on the remote
control from the next time.
Preparation
Turn on the circuit breaker.
• “ Setting” appears on the display of the remote control when
the power is turned on.
* When the power is turned on, it takes about 5 minutes
before the remote control becomes operable. This is not a
malfunction.
12:00
Mode Fan Speed
Cool
75 F
1
2
3
7
8
4,5
6
75
12:00
Mode Fan Speed
Cool
F
1[ MONITOR] button
Displays the monitoring screen.
2[ MENU] button
Displays the menu screen.
3[ CANCEL] button
Functions as indicated on the screen, such as
returning to the previous menu screen.
4[
∧ ] button
During normal operation: adjusts the temperature.
On the menu screen: selects a menu item.
5[
∨ ] button
During normal operation: adjusts the temperature.
On the menu screen: selects a menu item.
6[ F1 ] button
Varies its function according to the setting screen.
7[ F2 ] button
Varies its function according to the setting screen.
8[ ON/OFF] button
Switching between the normal display and detailed display
Push and hold the [ CANCEL] button and [ MONITOR] button at the same time for more than 4 seconds to
switch the display mode.
The normal display mode is selected as a factory default setting.
Normal display mode (factory default)
82
12:00
Mode Fan Speed
Cool
F
Energy saving icon
• Displayed when performing the power saving operation of the
air conditioner.
Soft cooling icon
• Shows the air conditioner is performing the soft cooling
operation.
Saving icon
• Displayed when performing operation by suppressing
excessive heating or excessive cooling through automatic
correction of the temperature set point.
(*1)
Detailed display mode
75
Room A
12:00
Mode Fan Speed
Cool
F
Icons appear on the screen when the detailed display mode is
selected.
*1 • The “ Preparing to heat” icon appears when the heating
operation starts or when defrosting operation.
The indoor fan stops or the operation becomes the blowing
operation when it is displayed.
• It may be displayed depending on the model when
“ Preparing to operate” is displayed.
(*1)
– 7 –
13-EN 14-EN
01_OM_1115653833_EN.indd 701_OM_1115653833_EN.indd 7 4/4/2565 BE 11:104/4/2565 BE 11:10

EN
▼Icon list
Shows the Energy saving operation is
activated. Shows a timer function is activated.
Shows the remote control sensor is
activated.
(*2)
Shows the Louver lock is activated.
Shows the Night operation is activated. Shows the setting of the louver.
Shows the central control device prohibits
the use of the remote control. !Shows the filter needs to be cleaned.
Shows the saving operation is activated. Shows soft cooling is activated.
Shows operation switching control is in
progress.
*2 Normally the temperature sensor of the indoor unit senses the temperature. The temperature around the remote
control can also be sensed. For details, contact the dealer where you purchased the air conditioner. * Do not use
the function when the air conditioner is controlled in a group.
▼Ventilation icon list
Ventilation icons appear on the display only when a ventilation unit is connected.
Automatic mode 24-hour ventilation mode
Bypass mode Nighttime heat purge mode
Total heat exchange mode
■Running operation
* Some operation modes are not available depending on the type of indoor unit.
12:00
Mode Fan Speed
Cool
75 F
1Push the [ ON/OFF] button to start running.
2Push the “ Mode Mode” [ F1 ] button to
select the operation mode.
ÆThe operation mode changes as follows each time
the button is pushed.
Auto Heat Dry Cool Fan
3Push the [ ON/OFF] button to stop running.
■Changing the fan speed
* The available fan speeds vary depending on the indoor unit connected.
1Push the “ Fan speed Fan speed” [ F2 ] button
to select the fan speed.
ÆThe fan speed changes as follows each time the
button is pushed.
Auto High LowMed
When the remote control is used in combination with
an indoor unit that supports 5 speeds, each
push of the “ Fan speed Fan speed” [ F2 ] button
changes the fan speed display.
Auto
Low+ Low
Med+
Med
High
Æ“ ” appears on the display when the connected
indoor unit is not equipped with the fan speed.
Æ“ ” is not available when “Fan” is selected as
the operation mode.
4Operation
– 8 – 16-EN15-EN
01_OM_1115653833_EN.indd 801_OM_1115653833_EN.indd 8 4/4/2565 BE 11:104/4/2565 BE 11:10

■Changing the temperature
1Push the [
∧ ] / [ ∨ ] button to adjust the
temperature.
ÆPush the [
∧ ] button to raise the temperature
setting, push the [
∨ ] button to lower it.
• Refer to “Set temp. range limit” for the temperature
range available.
• The temperature cannot be adjusted when “Fan” is
selected as the operation mode.
▼When dual automatic mode
In dual set point setting, the temperature set point of individual cooling and heating can be set to adjust the
indoor temperature.
Thermo.OFF for temperature range between the temperature set points for cooling and heating.
If you wish to use the dual automatic mode, ask your dealer to set the setting.
75
68
F
F
Mode Fan Speed
Auto
Room A
12:00
82
72
F
F
Return Fix
Cool Heat
Cool
Heat
Room A
12:00
82
72
F
F
Return Fix
Cool Heat
Cool
Heat
Room A
12:00
1Push the [
∧ ] / [ ∨ ] button to switch to
the display shown on the left.
2To set the cooling temperature set point, push
[Cool] and adjust the setting with [
∧ ] /
[
∨ ].
A box will surround [ Cool] and [Temperature set
point]. To set the heating temperature set point,
push [ Heat] and adjust the setting with
[
∧ ] / [ ∨ ].
A box will surround [ Heat] and [Temperature set
point].
ÆPush [ MENU] to confirm the settings and return
to the normal display.
ÆPush [ CANCEL] to cancel the settings and
return to the normal display.
NOTE
When connecting to an air conditioning control system which does not support dual set point
• The temperature set point, a value half the heating temperature and Cooling temperature set point will be
displayed.
• When temperature setting has been changed by the unsupported controller, the cooling temperature set point and
heating temperature set point displayed on the dual set point screen will be set automatically.
• For details, contact the dealer where you purchased the air conditioner.
■46°F (8°C) operation (For object pre-heating)
The air conditioner can control the heating temperature to about 8°C in the heating mode.
The 8°C heating operation requires settings with the wired remote controller. Ask the installer or dealer for
the settings according to the installation manual of the indoor unit.
Start
1. Set the displayed temperature to 64°F in the heating mode by pushing TEMP. button.
2. Set the displayed temperature to 46°F by pushing TEMP. button for at least 4 seconds
Stop
1. Set the displayed temperature to 64°F by pushing TEMP. button.
• The air conditioner returns to the normal HEAT mode. Select a desired temperature and operation mode.
NOTE
• The discharged air temperature is lower than that in the normal heating operation.
• The room temperature may not be heated evenly depending on the remote controller installation location.
• The room temperature may not reach 86°F depending on the room size or the installation conditions.
• Setting for fan speed is available during the 46°F heating operation.
The 46°F heating operation is cancelled in the following cases.
• When operation is stopped with button
• When another operation mode is selected with button
• When temperature setting or operation mode is changed or operation is started / stopped by the wireless
remote controller or the central control remote controller.
• When this operation mode is used, observe proper operating hours and periodic maintenance by service staff is
recommended.
– 9 –
17-EN 18-EN
01_OM_1115653833_EN.indd 901_OM_1115653833_EN.indd 9 4/4/2565 BE 11:104/4/2565 BE 11:10

EN
■Off reminder timer
Before setting
Off reminder timer
1.Off reminder timer
ON / OFF
2.Timer setting
Set OFF
90 min.
Return Fix
1Push the [
∧ ] / [ ∨ ] button to select
“4. Off reminder timer” on the menu screen, then
push the “ Set Set” [ F2 ] button.
Off reminder timer
Set the length of time until the air conditioner stops automatically.
Off reminder timer
1.Off reminder timer
ON / OFF
2.Timer setting
Set OFF
90 min.
Return Fix
Off reminder timer
1.Off reminder timer
ON / OFF
2.Timer setting
90 min.
Return Fix
+–
Set OFF
1Push the [
∧ ] / [ ∨ ] button to select
“1. Off reminder timer”.
2Push the “ ” [ F1 ] button.
ÆPush the “ ” [ F2 ] button to turn off
the Off reminder timer.
3Push the [
∧ ] / [ ∨ ] button to select
“2. Timer setting”.
4Push the “ ++” [ F1 ] / “ –-”
[ F2 ] button to set the time.
ÆThe time can be set at 10 minutes intervals.
5Push the [ MENU] button.
ÆThe screen returns to the menu screen.
5Off reminder timer NOTE
• The air conditioner stops running after the specified time has elapsed.
Start
Elapsed time of the Off reminder timer
Off reminder timer
No remaining time
Running Stop
• “ ” appears on the detailed display when the Off reminder timer is used.
• The Off reminder timer does not work in the following cases:
When the Off reminder timer is deactivated
When an error has occurred
While the test operation is in progress
While setting the functions
When the central control is used (when the run and stop operation is prohibited)
• The Off reminder timer cannot be set on the Follower remote control when the dual remote control system is used.
• The time of Off reminder timer can be set within the range from 30 minutes to 240 minutes.
• Push the [ CANCEL] button to stop the setting procedure. No setting has been made and the screen returns
to the menu screen.
– 10 – 20-EN19-EN
01_OM_1115653833_EN.indd 1001_OM_1115653833_EN.indd 10 4/4/2565 BE 11:104/4/2565 BE 11:10

6Adjustment of wind direction
For best cooling and heating performance, adjust the
louvers (adjustment plates of up / down wind direction)
appropriately. Cold air descends and warm air rises, so
to heat a room tilt the louvers downward, and to cool a
room tilt them horizontally.
CAUTION
Direct the louvers horizontally for cooling.
If the louvers stay pointed downward during cooling,
condensation may form on the discharge port and /
then drops from the louvers.
• When operation is stopped, the horizontal louver
(plate for adjusting the vertical air flow) automatically
closes.
• In heating preparation mode, the horizontal louver
(plate for adjusting the vertical air flow) points
upward. The louver starts swinging when the heating
preparation mode has finished, but the swing
indicator appears on the remote controller even in
heating preparation mode.
As characteristics of air, cold air
accumulates lower area and warm
air accumulates upper area.
Return
Wind direction
Swing ON
Louver
◆How to set up the wind direction
1Push the [
∧ ] / [ ∨ ] button to
select “1. Wind direction” on the menu
screen, then push the “ Set Set”
[ F2 ] button.
2Push the [
∧ ] / [ ∨ ] button to
select the wind direction.
(1) (2) (3) (4) (5)
Operation mode Available directions
Heat, Fan, Auto
(heating)
(1) Ù(2) Ù(3) Ù(4) Ù(5)
Cool, Dry, Auto
(cooling) (1) Ù(2) Ù(3)
3Push the [ CANCEL] button to return.
ÆThe screen returns to the menu screen.
In Heat operation
Direct the louver (adjustment plate of up / down wind
direction) downward. If directing at horizontally, hot
air may not come to the foot.
Initial setup
In Cool / Dry operation
Direct the louver (adjustment plate of up / down wind
direction) horizontally. If directing it downward, the dew
may form on the surface of the air discharge port and
may drop down.
Initial setup
In Fan operation
Select a desired wind direction.
Initial setup
◆Turning on/off the louver swing
Wind direction
Return
Swing OFF
Louver
* When the louver is stopped,
“ Swing ON Swing ON” is displayed.
1Push the “ Swing ON Swing ON” [ F2 ]
button on the “Wind direction” screen.
ÆPushing the [
∧ ] / [ ∨ ] button on
the “Wind direction” screen while the louver
swing is on stops swinging and sets the wind
direction to (1).
2Push the [ CANCEL] button.
ÆThe screen returns to the menu screen.
◆To stop the louver swing
Wind direction
Return
Swing ON
Louver
* When the louver is swinging,
“ Swing OFF Swing OFF” is displayed.
1Push the “ Swing OFF Swing OFF” [ F2 ]
button on the “Wind direction” screen.
ÆPush the “ Swing OFF Swing OFF Swing
OFF” [ F2 ] button to stop swinging. The
louver stops in the position where the button is
pushed.
• The louver does not stop in the position (4) or
(5) when the operation mode is “Cool” or “Dry”.
The louver stops in the position (3) even if
the button is pushed when the louver is in the
position (4) or (5)
Display when the louver swing is stopped
Fan, Heat Cool, Dry
• Pushing [ ∧ ] / [ ∨ ] while the
display when the louver swing is stopped
appears on the screen sets the louver in the
position (1).
2Push the [ CANCEL] button.
ÆThe screen returns to the menu screen.
– 11 –
21-EN 22-EN
01_OM_1115653833_EN.indd 1101_OM_1115653833_EN.indd 11 4/4/2565 BE 11:104/4/2565 BE 11:10

EN
Return
Unit Set
Wind direction
1–1
1–2
1–– 3
1
–4
1–
––
–5
ALL
–
–
Return
Unit Set
Wind direction
1–1
1–2
1–3
1
–4
1–
–
–5
ALL
–
–
–
–
Return
Wind direction
Swing ON
Louver
1–1
1Select the group-controlled function on the menu
screen, then push the “ Set Set” [ F2 ]
button.
2Push the “ Unit unit” [ F1 ] button to
select the unit to set.
ÆThe selected unit changes as follows each time the
button is pushed:
1-1 1-2 1-8
3Push the “ Set Set” [ F2 ] button.
ÆThe setting display for the selected unit appears.
4Push the [ CANCEL] button.
ÆPushing the [ CANCEL] button returns to the
previous screen.
ÆPushing the [ CANCEL] button when setting
“Swing type” or “Louver lock” shows “ Setting”
on the screen.
• The number (address) of the selected unit appears
on the upper left of the screen, unless “All” is
selected for the unit selection.
• “All” is not available for some settings.
◆Unit select button
• When multiple indoor units are controlled with one
remote controller, wind direction can be set for each
indoor unit by selecting individually.
Horizontal air flow adjustment
To change the horizontal air flow direction, point the
vertical louvers inside the horizontal louver in your
preferred direction.
NOTE
• When the horizontal louver is pointing downward in
COOL mode, water droplets may form on the surface
of the cabinet or louver and drop down.
• When the horizontal louver is pointing horizontally
in HEAT mode, the air may not warm up the room
evenly.
– 12 – 24-EN23-EN
01_OM_1115653833_EN.indd 1201_OM_1115653833_EN.indd 12 4/4/2565 BE 11:104/4/2565 BE 11:10

7Energy saving
Set for the energy saving operation: Energy saving operation, Set temp. range limit, Return back and Saving
operation.
Energy saving(1/2)
1.Energy saving operation
2.Set temp. range limit
3.Return back
<ON>
<OFF>
Set
Return
1Push the [
∧ ] / [ ∨ ] button to select
“9. Energy saving” on the menu screen, then push
the “ Set Set” [ F2 ] button.
2Push the [
∧ ] / [ ∨ ] button to select
3Push the “ Set Set” [ F2 ] button.
Item Function
1. Energy saving operation Perform the power saving operation of the air conditioner.
2. Set temp. range limit Set the temperature range limit of the remote control operation.
3. Return back
Set the function that changes the temperature back to the specified
temperature automatically if the temperature has been changed on
the remote control.
4. Saving operation
Performs operation by suppressing excessive heating or excessive
cooling through automatic correction of the temperature set point.
* “No function” is displayed in the case of a model for which the
saving operation cannot be set.
CAUTION
Refer to the Owner’s Manual supplied with the air conditioner about “Energy saving operation”, “Saving operation”.
■Energy saving operation
Set for the power saving operation of the air conditioner.
Energy saving operation
1.Energy saving operation
2.Energy saving ratio
3.Energy saving schedule
ON / OFF
Return Fix
1Push the [
∧ ] / [ ∨ ] button to select
“1. Energy saving operation” on the “Energy
saving” screen.
2To start the Energy saving operation:
After setting “2. Energy saving ratio” and
“3. Energy saving schedule”, push the
“ ” [ F1 ] button to select “ON”,
then push the [ MENU] button. To stop the
Energy saving operation: Push the
“ ” [ F2 ] button to select
“OFF”, then push the [ MENU] button.
Energy saving ratio
Carry out the setting operation while the indoor unit is stopped. (Turn off the air conditioning unit before starting the
setting operation.)
Energy saving operation
1.Energy saving operation
2.Energy saving ratio
3.Energy saving schedule
ON / OFF
Return Fix
Energy saving ratio
Energy saving ratio
75%
%+%–
Return Fix
Set
1Push the [
∧ ] / [ ∨ ] button to select
“2. Energy saving ratio” on the “Energy saving
operation” screen, then push the “ Set Set”
[ F2 ] button.
2
Push the “
%+
%+” [ F1 ] / “
%–
%-”
[ F2 ] button to set the button to set the value.
ÆThe Energy saving ratio can be set within the range
from 50% to 100% by 1%. The lower the value is
set, the higher the power saving effect becomes.
3Push the [ MENU] button.
Æ“ Setting” appears on the screen, then the screen
returns to the “Energy saving operation” screen.
NOTE
• Cooling / heating performance may be reduced a little because its power is saved during the Energy saving
operation.
• “ ” appears on the display when the Energy saving operation is activated.
• The Energy saving operation cannot be set on the Follower remote control when the dual remote control system
is used.
• The remote control may not be used for setting the Energy saving operation depending on the settings of the
central control remote control or the outdoor unit.
• The Energy saving schedule operation is not available when the clock display is blinking (the clock has not been
adjusted).
– 13 –
25-EN 26-EN
01_OM_1115653833_EN.indd 1301_OM_1115653833_EN.indd 13 4/4/2565 BE 11:104/4/2565 BE 11:10

EN
8Maintenance
Turn off the power before maintenance.
CAUTION
Do not operate the unit with wet hands.
Doing so may result in electric shocks.
■Daily maintenance
Wipe the remote control with a dry, soft cloth. Using water to clean the remote control may result in a malfunction.
■Cleaning the air filter
Cool
75
Room A 12:00
Mode Fan Speed
Clean the air filter when “ ” (filter sign) appears on
the detailed display.
(“ ” is not displayed in the normal display mode.)
• Clogged air filter reduces the cooling or heating
performance.
◆Check periodically
• If the unit is used for a long time, parts may deteriorate and cause malfunction or bad drainage of dehumidified
water depending on the heat, humidity, or dust.
• In addition to the usual maintenance, it is recommended that you have the unit checked and maintained by the
dealer where you purchased it.
NOTE
For environmental conservation, it is strongly recommended that the indoor and outdoor units of the air conditioner
in use be cleaned and maintained regularly to ensure efficient operation of the air conditioner.
When the air conditioner is operated for a long time, periodic maintenance (once a year) is recommended.
Furthermore, regularly check the outdoor unit for rust and scratches, and remove them or apply rustproof treatment,
if necessary.
As a general rule, when an indoor unit is operated for 8 hours or more daily, clean the indoor unit and outdoor unit
at least once every 3 months. Ask a professional for this cleaning / maintenance work.
Such maintenance can extend the life of the product though it involves the owner’s expense.
Failure to clean the indoor and outdoor units regularly will result in poor performance, freezing, water leakage, and
even compressor failure.
Maintenance List
Part Unit Check (visual / auditory) Maintenance
Heat exchanger Indoor / outdoor Dust / dirt clogging, scratches Wash the heat exchanger when it is
clogged.
Fan motor Indoor / outdoor Sound Take appropriate measures when
abnormal sound is generated.
Filter Indoor Dust / dirt, breakage
• Wash the filter with water when it is
contaminated.
• Replace it when it is damaged.
Fan Indoor • Vibration, balance
• Dust / dirt, appearance
• Replace the fan when vibration or
balance is terrible.
• Brush or wash the fan when it is
contaminated.
Air intake /
discharge grilles Indoor / outdoor Dust / dirt, scratches Fix or replace them when they are deformed or damaged.
Drain pan Indoor Dust / dirt clogging, drain
contamination
Clean the drain pan and check the
downward slope for smooth drainage.
Ornamental panel,
louvers Indoor Dust / dirt, scratches Wash them when they are contaminated or apply repair coating.
Exterior Outdoor • Rust, peeling of insulator
• Peeling / lift of coat Apply repair coating.
– 14 – 28-EN27-EN
01_OM_1115653833_EN.indd 1401_OM_1115653833_EN.indd 14 4/4/2565 BE 11:104/4/2565 BE 11:10

9Troubleshooting
Check the points described below before requesting repair.
Symptom Cause
Outdoor unit
• White, misty, cold air or water
comes out.
• Sometimes the noise of air leaking
is heard.
• A noise is heard when the power
is turned on.
• The fan of the outdoor unit is automatically
stopped and defrosting is performed.
• The solenoid valve works when defrosting starts
or stops.
• The outdoor unit is preparing for running.
It is not a malfunction.
Indoor unit
• Sometimes a swishing is heard. • When the unit starts running, during operation,
or immediately after the unit stops running, a
sound such as water flowing may be heard, or
the operation sound may become louder for a
couple of minutes immediately after the unit starts
running. This is the sound of the refrigerant flowing
or the dehumidifier draining.
• A clacking sound is heard. • This is a sound generated when the heat
exchanger, etc. expands and contracts slightly due
to temperature change.
• Discharged air smells unusual. • Various smells from the walls, carpet, clothes,
cigarette, cosmetics, etc. adhere to the
air conditioner.
The unit does not run.
• Has a blackout occurred?
• Has the circuit breaker blown?
• Has the protective device been activated?
(The operation indicator and on the remote
controller are blinking.)
Check again.
The room does not cool down or warm up.
• Is the air intake or discharge of the outdoor unit
clogged?
• Is a door or window open?
• Is the air filter clogged with dust?
• Is the air volume set to “Low”? or is the operation
mode set to “Fan”?
• Is the setup temperature appropriate?
If you find something unusual even after checking the above, stop running the unit, turn off the circuit breaker, and
inform the dealer where you purchased the product of the product number and symptom. Do not attempt to repair
the unit by yourself as doing so is dangerous. If the check indicator ( , , etc.) is displayed on the remote
controller LCD, inform the dealer of its content as well.
If any of the following occur, stop running the unit immediately, turn off the circuit breaker, and contact the dealer
where you purchased the product.
• The switch does not work properly.
• The circuit breaker often blows out.
• You unintentionally put a foreign object or water inside.
• The unit cannot be run even after the cause of the protective device activation is removed.
• Other unusual conditions are found.
Cool
75
Mode Fan Speed
Code : P10 Unit : 2–2
Check code
Unit number of
the malfunctioning
indoor unit
Check
Contact Information
Return
Check
Code:P10
Unit:2–2
When an error has occurred in the air conditioner, the
check code and the unit number of the indoor unit
appear on the display of the remote control.
* The check code appears only while the unit is
running.
Push the [ MONITOR] button or [ CANCEL]
button to display the check information screen.
While the check information screen appears:
Push the “ Contact Contact” [ F1 ] button to
display the contact number for service.
Push the “ Information Information” [ F2 ] button to
display the model name and serial number of the unit.
– 15 –
29-EN 30-EN
01_OM_1115653833_EN.indd 1501_OM_1115653833_EN.indd 15 4/4/2565 BE 11:104/4/2565 BE 11:10

EN
10 Operations and performance
▼Check before running
• Check whether the ground wire is cut or disconnected.
• Check whether the air filter is installed.
• Turn on the circuit breaker 12 hours or more before
starting operation.
▼3 minutes protection function
3-minutes protection function prevents the
air conditioner from starting for initial 3 minutes after
the main power switch / circuit breaker is turned on for
restarting the air conditioner.
▼Power failure
Power failure during operation will stop the unit
completely.
• To restart the operation, push the ON / OFF button
on the remote controller.
• Lightning or a wireless car telephone operating
nearby may cause the unit to malfunction. Turn off
the main power switch or circuit breaker and then
turn them on again. Push the ON / OFF button on the
remote controller to restart.
▼Defrosting operation
If the outdoor unit is frosted during the heating
operation, defrosting starts automatically (for
approximately 2 to 10 minutes) to maintain the heating
capacity.
• The fans in both indoor and outdoor units will stop
during the defrosting operation.
• During the defrosting operation, the defrosted water
will be drained from the bottom plate of the
outdoor unit.
▼Heating capacity
In the heating operation, the heat is absorbed from
the outside and brought into the room. This way of
heating is called heat pump system. When the outside
temperature is too low, it is recommended to use
another heating apparatus in combination with the
air conditioner.
▼Protective device
• Stops operation when the air-conditioner is
overloaded.
• If the protective device is activated, the unit stops
running, and the operation indicator and check
indicator on the remote controller blink.
▼If the protective device is activated
• Turn off the circuit breaker and perform a checkup.
Continued running may cause a malfunction.
• Check whether the air filter is installed. If not, the
heat exchanger may be clogged with dust and water
leakage may occur.
▼During cooling
• The air intake or discharge of the outdoor unit is
clogged.
• Strong wind continuously blows against the
discharge of the outdoor unit.
▼During heating
• The air filter is clogged with a large amount of dust.
• The air intake or discharge of the indoor unit is
clogged.
▼Do not turn off the circuit breaker
• During the air-conditioning season, leave the circuit
breaker turned on, and use the ON / OFF key on the
remote controller.
▼Attention to snowfall and freeze on the outdoor unit
• In snowy areas, the air intake and air discharge of the outdoor unit are often covered with snow or frozen up.
If snow or freeze on the outdoor unit is left as it is, it may cause machine failure or poor warming.
• In cold areas, pay attention to the drain hose so that it perfectly drains water without water remaining inside for
freeze prevention. If water freezes in the drain hose or inside the outdoor unit, it may cause machine failure or
poor warming.
▼Air conditioner operating conditions
For proper performance, operate the air conditioner under the following temperature conditions
Cooling operation
Outdoor temperature : 5°F to 115°F (Dry bulb temp.)
Room temperature : 70°F to 89°F (Dry bulb temp.), 59°F to 75°F (Wet bulb temp.)
[CAUTION] Room relative humidity – less than 80%. If the air conditioner operates in
excess of this figure, the surface of the air conditioner may cause dewing.
Heating operation Outdoor temperature : –13°F to 59°F (Wet bulb temp.)
Room temperature : 59°F to 86°F (Dry bulb temp.)
If air conditioner is used outside of the above conditions, safety protection may work.
– 16 – 32-EN31-EN
01_OM_1115653833_EN.indd 1601_OM_1115653833_EN.indd 16 4/4/2565 BE 11:104/4/2565 BE 11:10

11 Installation
Do not install the air conditioner in the following places
• Do not install the air conditioner in any place within 39.4" (1 m) from a TV, stereo, or radio set. If the unit is
installed in such place, noise transmitted from the air conditioner affects the operation of these appliances.
• Do not install the air conditioner near a high frequency appliance (sewing machine or massager for business use,
etc.), otherwise the air conditioner may malfunction.
• Do not install the air conditioner in locations where iron or other metal dust is present. If iron or other metal dust
adheres to or collects on the interior of the air conditioner, it may spontaneously combust and start a fire.
• Do not install the air conditioner in a humid or oily place, or in a place where steam, soot, or corrosive gas is
generated.
• Do not install the air conditioner in a salty place such as seaside area.
• Do not install the air conditioner in a place where a great deal of machine oil is used.
• Do not install the air conditioner in a place where it is usually exposed to strong wind such as in seaside area.
• Do not install the air conditioner in a place where sulfureous gas generated such as in a spa.
• Do not install the air conditioner in a vessel or mobile crane.
• Do not install the air conditioner in an acidic or alkaline atmosphere (in a hot-spring area or near a chemicals
factory, or in a place subject to combustion emissions). Corrosion may be generated on the aluminum fin and
copper pipe of the heat exchanger.
• Do not install the air conditioner near an obstacle (air vent, lighting equipment, etc.) that disturbs discharge air.
• (Turbulent airflow may reduce the performance or disable devices.)
• Do not use the air conditioner for special purposes such as preserving food, precision instruments, or art objects,
or where breeding animals or growing plants are kept.
(This may degrade the quality of preserved materials.)
• Do not install the air conditioner over an object that must not get wet. (Condensation may drop from the indoor unit
at a humidity of 80% or more or when the drain port is clogged.)
• Do not install the air conditioner in a place where an organic solvent is used.
• Do not install the air conditioner near a door or window subject to humid outside air.
Condensation may form on the air conditioner.
• Do not install the air conditioner in a place where special spray is used frequently.
Be careful with noise or vibrations
• Do not install the air conditioner in a place where noise by outdoor unit or hot air from its air discharge annoys
your neighbors.
• Install the air conditioner on a solid and stable foundation so that it prevents transmission of resonating, operation
noise and vibration.
• If one indoor unit is operating, some sound may be audible from other indoor units that are not operating.
– 17 –
33-EN 34-EN
01_OM_1115653833_EN.indd 1701_OM_1115653833_EN.indd 17 4/4/2565 BE 11:104/4/2565 BE 11:10

FR
Instruction d’origine
Merci beaucoup d’avoir choisi le climatiseur TOSHIBA.
Veuillez lire attentivement ce manuel du propriétaire avant d’utiliser votre climatiseur.
• Veillez à vous faire remettre le « Manuel du propriétaire » et le « Manuel d’installation » par le constructeur
(ou le revendeur).
Consigne à l’attention du constructeur ou du revendeur.
• Veuillez expliquer clairement le contenu du manuel du propriétaire avant de le transmettre.
REMARQUE
Ce manuel décrit le fonctionnement de l’unité intérieure et de la télécommande sans fil.
Pour plus de renseignements sur la télécommande sans fil et l’unité intérieure, veuillez consulter le manuel
d’utilisation fourni avec l’unité extérieure. (Gardez ces manuels en lieu sûr.)
ADOPTION DU NOUVEAU REFRIGERANT
Ce climatiseur utilise le R410A qui est un réfrigérant écologique
Conforme UL 60335-1
Cet appareil n’est pas conçu pour être utilisé par des personnes
(y compris les enfants) aux capacités physiques, sensorielles
ou mentales diminuées, ou manquant d’expérience ou de
connaissances, sauf si une personne responsable de leur
sécurité leur a expliqué le fonctionnement de l’appareil et les
garde sous surveillance.
Les enfants doivent être surveillés afin de garantir qu’ils ne
jouent pas avec l’appareil.
Redémarrage automatique
Ce climatiseur est équipé d’une fonction de redémarrage automatique qui lui permet de reprendre les conditions
de fonctionnement définies en cas de coupure de l’alimentation électrique sans l’utilisation de la télécommande.
Sommaire
1 Précautions relatives à la sécurité ..............................................................20
2 Noms des pièces ..........................................................................................23
3 Télécommande avec fil.................................................................................24
4 Fonctionnement ............................................................................................25
5 Minuterie de rappel d’arrêt ...........................................................................27
6 Réglage de l’orientation soufflage...............................................................28
7 Économie d’énergie ......................................................................................30
8 Entretien.........................................................................................................31
9 Dépannage.....................................................................................................32
10 Fonctionnement et performance .................................................................33
11 Installation .....................................................................................................34
– 18 –
1-FR 2-FR
02_OM_1115653833_FR.indd 1802_OM_1115653833_FR.indd 18 4/4/2565 BE 11:114/4/2565 BE 11:11

Dénomination générale : Climatiseur
Définition d’installateur qualifié ou de personne d’entretien qualifiée
Le climatiseur doit être installé, entretenu, réparé ou enlevé par un installateur qualifié ou une personne d’entretien
qualifiée. Lorsqu’un de ces travaux doit être réalisé, demandez à un installateur qualifié ou à une personne
d’entretien qualifiée de le faire pour vous. Un installateur qualifié ou une personne d’entretien qualifiée est un agent
qui possède les qualifications et les connaissances décrites dans le tableau ci-dessous.
Agent Qualifications et connaissances que l’agent doit avoir
Installateur
qualifié
• L’installateur qualifié est une personne qui installe, entretient, déplace et enlève les climatiseurs
fabriqués par Toshiba Carrier Corporation. Il ou elle a été formé(e) pout installer, entretenir,
déplacer et enlever les climatiseurs fabriqués par Toshiba Carrier Corporation ou, alternativement,
il ou elle a été formé(e) pour de telles opérations par un individu ou des individus qui a été formé et
est, par conséquent, informé des connaissances relatives à ces opérations.
• L’installateur qualifié qui est autorisé à effectuer les tâches électriques incluses dans l’installation,
le déplacement et l’enlèvement possède les qualifications relatives à ce travail électrique
conformément aux réglementations et à la législation locales, et il ou elle est une personne qui
a été formée dans des matières relatives au travail électrique sur les climatiseurs fabriqués par
Toshiba Carrier Corporation ou, alternativement, il ou elle a été formé dans de telles matières par
un ou des individus qui ont été entraînés et sont, par conséquent, totalement informées avec la
connaissance relative à ce travail.
• L’installateur qualifié qui est autorisé à manipuler le réfrigérant et à effectuer des travaux de
plomberie inclus dans l’installation, le déplacement et l’enlèvement possède les qualifications
relatives à cette manipulation de réfrigérant et à cette réalisation de travaux de plomberie
conformément aux réglementations et à la législation locales, et il ou elle est une personne
qui a été formée dans des matières relatives à la manipulation du réfrigérant et à la réalisation
des travaux de plomberie sur les climatiseurs fabriqués par Toshiba Carrier Corporation ou,
alternativement, il ou elle a été formé dans de telles matières par un ou des individus qui ont été
entraînés et sont, par conséquent, totalement informées avec la connaissance relative à ce travail.
• L’installateur qualifié qui est autorisé à travailler en hauteur a été formé dans des matières relatives
à des travaux en hauteur avec les climatiseurs fabriqués avec Toshiba Carrier Corporation ou,
alternativement, il ou elle a été formé dans de telles matières par un ou des individus qui ont été
formés et, sont, par conséquent, totalement informés des connaissances relatives à ce travail.
Personne
d’entretien
qualifiée
• La personne d’entretien qualifiée est une personne qui installe, répare, entretient, déplace et
enlève les climatiseurs fabriqués par Toshiba Carrier Corporation. Il ou elle a été formé(e) pout
installer, réparer, entretenir, déplacer et enlever les climatiseurs fabriqués par Toshiba Carrier
Corporation ou, alternativement, il ou elle a été formé(e) pour de telles opérations par un individu
ou des individus qui a été frmé et est, par conséquent, informé des connaissances relatives à ces
opérations.
• La personne d’entretien qualifiée qui est autorisé à effectuer les tâches électriques incluses dans
l’installation, la réparation, le déplacement et l’enlèvement possède les qualifications relatives à
ce travail électrique conformément aux réglementations et à la législation locales, et il ou elle est
une personne qui a été formée dans des matières relatives au travail électrique sur les climatiseurs
fabriqués par Toshiba Carrier Corporation ou, alternativement, il ou elle a été formé dans de
telles matières par un ou des individus qui ont été entraînés et sont, par conséquent, totalement
informées avec la connaissance relative à ce travail.
• La personne d’entretien qualifiée qui est autorisée à manipuler le réfrigérant et à effectuer des
travaux de plomberie inclus dans l’installation, la réparation, le déplacement et l’enlèvement
possède les qualifications relatives à cette manipulation de réfrigérant et à cette réalisation de
travaux de plomberie conformément aux réglementations et à la législation locales, et il ou elle
est une personne qui a été formée dans des matières relatives à la manipulation du réfrigérant
et à la réalisation des travaux de plomberie sur les climatiseurs fabriqués par Toshiba Carrier ou,
alternativement, il ou elle a été formé dans de telles matières par un ou des individus qui ont été
entraînés et sont, par conséquent, totalement informées avec la connaissance relative à ce travail.
• La personne d’entretien qualifiée qui est autorisée à travailler en hauteur a été formé dans des
matières relatives à des travaux en hauteur avec les climatiseurs fabriqués avec Toshiba Carrier
Corporation ou, alternativement, il ou elle a été formé dans de telles matières par un ou des
individus qui ont été formés et, sont, par conséquent, totalement informés des connaissances
relatives à ce travail.
■Indications d’avertissement concernant le climatiseur
Indication d’avertissement Description
WARNING
ELECTRICAL SHOCK HAZARD
Disconnect all remote
electric power supplies
before servicing.
AVERTISSEMENT
DANGER DE CHOC ELECTRIQUE
Débranchez toutes les alimentations en électricité à distance
avant l’entretien.
WARNING
Moving parts.
Do not operate unit with grille
removed.
Stop the unit before the servicing.
AVERTISSEMENT
Pièces mobiles.
Ne faites pas fonctionner l’unité en l’absence de grille.
Arrêtez l’unité avant l’entretien.
CAUTION
High temperature parts.
You might get burned
when removing this panel.
ATTENTION
Pièces à haute température.
Un risque de brûlure est possible lors de la dépose de ce
panneau.
CAUTION
Do not touch the aluminum
fins of the unit.
Doing so may result in injury.
ATTENTION
Ne touchez pas les palmes en aluminium de l’unité.
De le faire, vous risqueriez de vous blesser.
CAUTION
BURST HAZARD
Open the service valves before
the operation, otherwise there
might be the burst.
ATTENTION
DANGER D’EXPLOSION
Ouvrez les soupapes de service avant l’opération, afin d’éviter
toute accumulation de pression inutile qui pourrait entraîner
une explosion.
– 19 –
4-FR3-FR
02_OM_1115653833_FR.indd 1902_OM_1115653833_FR.indd 19 4/4/2565 BE 11:114/4/2565 BE 11:11
