CAMILEO®P100
Quick Start Guide

Introduction
2
Introduction
For more detailed information please refer to the User's Manual on the
included CD.
Safety instructions
1Do not drop, puncture or disassemble the camcorder; otherwise the
warranty will be voided.
2Avoid all contact with water, and dry hands before using.
3Do not expose the camcorder to high temperature or leave it in direct
sunlight. Doing so may damage the camcorder.
4Use the camcorder with care. Avoid pressing hard on the camcorder
body.
5For your own safety, avoid using the camcorder when there is a storm
or lightning.
6Do not use batteries of different specifications. Doing so may lead to
the potential for serious damage.
7Remove the battery during long periods between usages, as a
deteriorated battery may affect the functionality of the camcorder.
8Remove the battery if it shows signs of leaking or distortion.
9Use only the accessories supplied by the manufacturer.
10 Keep the camcorder out of the reach of infants.
11 There is risk of explosion if battery is replaced by an incorrect type.
12 Dispose of used batteries according to the instructions.
About the battery
❖Use only batteries recommended by TOSHIBA as replacements. The
battery is a lithium ion battery, which can explode if not replaced,
used, handled or disposed of properly. Dispose of the battery as
required by local ordinances or regulations.
❖Charge the battery only in an ambient temperature between 41 and 95
degrees Fahrenheit (5 and 35 degrees Celsius). Otherwise, the
electrolyte solution might leak, battery performance might
deteriorate and the battery life might be shortened.

Safety instructions 3
❖Never install or remove the battery without first turning off the power
and disconnecting the USB cable and AC adaptor.
❖Only use the USB cable or AC adaptor to charge the battery. Never
attempt to charge the battery with any other charger.
Handling the cord on this product will expose you to lead, a chemical
known to the State of California to cause birth defects or other
reproductive harm. Wash hands after handling.
Regulatory Information
TOSHIBA declares that this product conforms to the following Standards:
Following information is only valid for EU-member States:
Contact
FCC Conditions
This equipment has been tested and found to comply with Part
15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received.
Including interference that may cause undesired operation.
Disposal of products
This symbol indicates that this product must not be disposed of
with normal household waste. The product must be disposed
of separately.
Address: TOSHIBA America Information Systems, Inc.
9740 Irvine Boulevard
Irvine, California 92618-1697
Telephone: [phone]

Safety instructions
4
Additional Information
© Copyright 2011 TOSHIBA CORPORATION. All rights reserved.
TOSHIBA reserves the right to make technical changes. TOSHIBA
assumes no liability for damages incurred directly or indirectly from
errors, omissions or discrepancies between this product and the
documentation.
Trademarks
CAMILEO is a registered trademark of Toshiba America Information
Systems, Inc. and/or Toshiba Corporation.
Adobe and Photoshop are either registered trademarks or trademarks of
Adobe Systems Incorporated in the United States and/or other countries.
ArcSoft, MediaImpression, and MediaConverter are registered trademarks
of ArcSoft, Inc.
HDMI, the HDMI Logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing, LLC.
Secure Digital and SD are trademarks of SD Card Association.
All other brand and product names are trademarks or registered
trademarks of their respective companies.

Getting Started 5
Getting Started
The battery comes pre-installed in the camcorder, however you must
remove the protective film on the battery before use.
To properly connect the battery:
1Slide the back battery cover down and remove.
2Remove the battery.
3Pull the film off.
4Reinsert the battery, making sure it is lined-up with the correct
polarity marks.
5Reinstall the battery cover.
To insert the SD™ Card (optional):
1Flip open the SD™ Card cover.
2Insert the SD™ Card into the slot until it locks in place.
REMOVE
Li-ion battery

Getting Started
6
3Once inserted, close the SD™ Card cover.
Charge your battery
You must use the supplied USB cable or AC adaptor to charge your
camcorder before use. Turn off the camcorder. A blinking light will
indicate active charging and a solid light will indicate that charging is
complete. In AC charging mode, the light will turn off automatically after
5 minutes.
To remove the
SD™ Card, press
inward to release
it. When the card
pops out, grasp
it and pull it
straight out.

Quick Tour 7
Quick Tour
3
2
7
4
1
1 To power on
Press and hold the Power (......)
button for one second.
To conserve battery power, the
camcorder will turn off automatically
after 3 minutes of non-operation.
2 To start or stop recording
Press the Video (........) button.
4 To take a photo
Press the Photo (.......) button.
5 To zoom in and out
Press the T/W (Tele/Wide) buttons.
6 To review videos/photos
Press the Playback (..........) button or
7 For menu options
Press the on-screen (.....,..) icon to access
the options menu.
For more detailed operational instructions,
please refer to the User’s Manual on the.
supplied CD.
touch the on-screen (......) icon to access
the Playback mode.
3 To pause recording
Press the Pause (.....) button.
5
LCD touch screen
6

Quick Tour
8
Front/Sides
Lens
NOTE: Remove the
Light
Power button
Speaker
Battery cover
protective film from
the lens before use.
Internet upload button
(In Playback mode)
Press to select the file to
upload to a Web site.
When the camcorder is
connected to a computer,
press to launch the
CAMILEO®Uploader
Playback button
Press to switch to Playback
mode.
application (for Windows®
based systems only).

Quick Tour 9
Microphone
Photo button
Press to take a photo.
Press to begin recording.
Video button
Rear/Underside
Wide (W) button
Zoom out
Press to pause recording.
Pause button
Mini USB 2.0 port
Strap hook
Tele (T) button
Mini HDMI™ port
Press it again to stop recording.
Zoom in
Press it again to continue
Tripod socket
Multi-indicator light
recording.
SD™ Card cover

Quick Tour
10
On-screen touch options
Touch the screen to display the options bar at the bottom of the screen.
Video Record mode (the Video ( ) icon is highlighted)
Touch to switch between Stabilization ON and OFF.
Touch to open the video resolution menu. Four resolution
settings are available.
Touch to switch between Advanced Zoom ON/OFF.
Touch to open the light settings menu.
ON:The light turns ON, providing illumination when
recording.
OFF: The light turns OFF.
DigitalLight:Extends the dynamic range for backlight and
high contrast, so that objects are brighter and clearer.
Photo Record mode (the Photo ( ) icon is highlighted)
Touch to switch between Self-Timer ON and OFF.
Touch to open the photo resolution menu. Three resolution
settings are available.
Touch to open the light settings menu.
ON:The light turns ON, providing illumination when
recording.
OFF: The light turns OFF.
DigitalLight:Extends the dynamic range for backlight and
high contrast, so that objects are brighter and clearer.
Video/Photo Playback mode (touch the Playback ( ) icon while in Preview mode)
Touch to display the options menu.
Touch to display the Select & Play thumbnail screen.
Touch to turn Continuous Play ON and OFF.
(In Video Playback mode only.)
Touch to turn Slideshow ON and OFF.
(In Photo Playback mode only.)

Quick Tour 11
Menu options
Touch the on-screen ()icon to display the options menu.
Video Settings
Light
ON The light turns ON, providing illumination when
recording.
OFF The light turns OFF.
Digital Light Extends the dynamic range for backlight and high
contrast, so that objects are brighter and clearer.
Resolution
Full HD 1080/30 1920 x 1080p (30fps)
HD 720/60 1280 x 720p (60fps)
HD 720/30 1280 x 720p (30fps)
VGA 480/30 640 x 480 (30fps)
Stabilization ON Enables digital image stabilization, providing
smooth and stable recording.
OFF Disables digital image stabilization.
Motion Detect ON Initiates video recording when motion is detected.
OFF Disables Motion Detection.
Slow Motion
ON Record videos with Slow Motion effect. When the video is played, the playback time will be longer than
the actual recording time.
NOTE: While using the Slow Motion setting, audio is not
recorded and zoom is disabled.
OFF Disables Slow Motion.
Pre-Record ON Enables pre-recording. The camcorder records one
second before the Record button is pressed.
OFF Disables pre-recording.
Time Lapse
OFF Disables time lapse.
1 Sec Records one frame per second.
3 Sec Records one frame every three seconds.
5 Sec Records one frame every five seconds.
Continuos Play ON Playback a video file continuously.
OFF Disables continuous play.

Quick Tour
12
Photos Settings
Light
ON The light turns ON, providing illumination when
recording.
OFF The light turns OFF.
Digital light Extends the dynamic range for backlight and high
contrast, so that objects are brighter and clearer.
Resolution
High-16MP 4608 x 3456 (16MP)
Standard-8MP 3264 x 2448 (8MP)
Low-3MP 2048 x 1536 (3MP)
Self-Timer ON Activates 10-second delayed self-timer.
OFF Disables self-timer.
Face Tracking ON Detects and focuses on human face(s) automatically.
This function is available in Photo mode to capture
portraits in backlit scenes.
OFF Disables face tracking.
Date Printing ON Imprints the date and time on each photo.
OFF Disables date printing.
ISO
Auto The camcorder adjusts the ISO sensitivity of the
image automatically.
800 The larger the number, the higher the ISO sensitivity.
Select a lower number to shoot a smoother image.
Select a higher number to shoot an image in the dark
or a subject moving at high speed.
NOTE: The image may appear grainy, while using a
higher number.
1600
Slideshow
2 sec Displays one photo every 2 seconds.
5 sec Displays one photo every 5 seconds.
10 sec Displays one photo every 10 seconds.
OFF Disables Slideshow.

Quick Tour 13
Effects
Macro Mode ON Change the focus range to be about 0.39 - 3.94 in.
(0.99 - 10cm).
OFF Disables Macro mode.
Scene
Auto Automatically adjusts to the current conditions.
Skin Adjusts skin tones to appear more natural.
Night Use in low light conditions or at night.
Backlight Use when the subject is brightly lit from behind.
Filter
Auto Automatically adjusts to the current conditions.
Black & White The image is converted to black and white.
Classic The image is converted to sepia.
Negative The image is converted to a negative of the original image.
White Balance
Auto Automatically adjusts to the current conditions.
Daylight Use while taking photos outside.
Fluorescent Use in fluorescent lighting.
Tungsten Use in tungsten lighting.
Setup
Menu Sound ON Enables camcorder operation sounds.
OFF Disables camcorder operation sounds.
TV NTSC (60Hz) TV output setting is NTSC standard.
PAL (50Hz) TV output setting is PAL standard.
Language Czech, Danish, Dutch, English, Finnish, French, German, Greek, Italian,
Norwegian, Polish, Portuguese, Russian, Swedish, Spanish, Turkish.
Time Setting Set up Date and Time.
Format
YES Formats the internal memory or the media card.
NO Do not format the internal memory or the media
card.
Default Setting YES Restores to the default factory settings.
NO Does not restore the default factory settings.
Delete
Delete Video Selects video files to be deleted.
Delete Photo Selects photo files to be deleted.
Select & Delete Selects video and photo files to be deleted.
Delete All Deletes all video and photo files.

Plug and share
14
Plug and share
Install the bundled software application, ArcSoft MediaImpression®, for
optimal video playback on your computer.
Connect the computer and camcorder with the supplied mini USB 2.0
cable as shown.
Videos and photos recorded on your SD™ Card can be found on your
computer at My Computer\SD\DCIM\100MEDIA (path will vary
depending on name of SD™ Card). In this folder, you can view, delete,
move, or copy the desired recorded movies and pictures.
Uploading files to a Web site
You can also share recorded movies on the Internet via the built-in
CAMILEO®Uploader application (for Windows®based systems only),
which offers you an easy way to upload your video clips and photos to a
Web site instantly. For more detailed instructions, refer to the User’s
Manual, on the supplied CD.
The social Web site must first be configured with your user profile in
the CAMILEO®Uploader application before file transfer can begin.
Webcam mode
Connect the camcorder to your computer with the supplied mini USB 2.0
cable. Press the Playback button to switch to Webcam mode. The
Multi-indicator light glows blue. You can also implement live video
conference meetings and multimedia communications.
For additional information, refer to the User’s Manual.

Toshiba Support 15
Toshiba Support
If you require help or are having problems operating your product, you
may need to contact Toshiba for additional technical assistance.
Before you call
Since some problems may be related to software, it is important that you
investigate other sources of assistance first. Try the following before
contacting Toshiba:
❖Review the User’s Manual supplied with your product.
❖If a problem occurs when you are running software applications,
consult the software documentation for troubleshooting suggestions.
Contact the software company’s technical support department for
assistance.
❖Consult the reseller or dealer from whom you purchased your
product. They are your best resource for current information and
support.
Contacting Toshiba
Toshiba’s technical support Web site
For technical support, or to stay current on the most recent software
options for your CAMILEO®product and for other product information,
be sure to regularly check the Toshiba Web site at
www.support.toshiba.com.
Toshiba voice contact
For technical support, call the Toshiba Customer Support Center:
Within the United States at [phone]
Outside the United States at [phone]

Toshiba Support
16
Toshiba Phone Service Center for Latin America Specialized technical
service in Spanish.
Hours:
Monday through Friday from 8:00 a.m. to 9:00 p.m. EST
Argentina: 0-800-666-3701
Bolivia: 800-100-684
Chile: 800-64-6526
Colombia: 01-800-912-0539
Costa Rica: 0-800-011-1123
Ecuador: 949-587-6834*
El Salvador: 800-6601
Guatemala: 949-587-6835*
Honduras: 949-587-6836*
Nicaragua: 949-587-6843
Panama: 00-8000-44-7813
Paraguay: 009-800-441-0059
Peru: 0-800-5-3817
Dominican Republic: 1-888-862-3225
Uruguay: 000-411-002-2297
Venezuela: 0-800-100-8819
*Phone charges apply
This product comes with a One (1) Year Standard Limited Warranty.
The One (1) Year Standard Limited Warranty for Toshiba Computer
Accessories can be found online at
http://pcsupport.toshiba.com/accessories1yr.

CAMILEO®P100
Guía de inicio rápido

Introducción
2
Introducción
Para obtener información detallada consulte el Manual del usuario en el
CD que se incluye.
Instrucciones de seguridad
1No deje caer la videocámara ni la perfore o desarme, de lo contrario
se anula la garantía.
2Evite el contacto con el agua y séquese las manos antes de usar la
videocámara.
3No exponga la videocámara a temperaturas elevadas ni la deje en
contacto directo con la luz del sol ya que la videocámara podría
averiarse.
4Use la videocámara con cuidado. No presione el cuerpo de la
videocámara con fuerza.
5Para su seguridad personal, no utilice la videocámara durante una
tormenta ni cuando relampaguea.
6No utilice baterías de especificaciones diferentes, ya que se podrían
causar daños graves.
7Extraiga la batería cuando no esté utilizando la videocámara durante
un período prolongado, ya que una batería deteriorada puede afectar
el funcionamiento de la videocámara.
8Extraiga la batería si da muestras de que tiene una fuga o una
deformación.
9Utilice solamente los accesorios suministrados por el fabricante.
10 Mantenga la videocámara fuera del alcance de los niños.
11 Se corre el riesgo de una explosión cuando se reemplaza la batería
con una de tipo incorrecto.
12 Elimine las baterías usadas de acuerdo con las instrucciones.
Información sobre la batería
❖Use solamente las baterías recomendadas por TOSHIBA como
repuestos. La batería es de iones de litio y puede explotar si no se
reemplaza, utiliza, manipula o elimina en forma correcta. Deseche la
batería de acuerdo con la legislación y los reglamentos locales.

Instrucciones de seguridad 3
❖Cargue la batería solamente a temperatura ambiente entre 5 y 35
grados centígrados (41 y 95 grados Fahrenheit). De lo contrario, es
posible que se fugue la solución electrolítica, que se deteriore el
rendimiento de la batería y que se acorte su duración.
❖Nunca instale o extraiga la batería sin antes apagar la alimentación y
desconectar el cable USB y el adaptador de CA.
❖Para cargar la batería utilice solamente el cable USB o el adaptador
de CA. Nunca trate de cargar la batería con cualquier otro tipo de
cargador.
Al tocar el cable de este producto las personas se exponen al plomo,
una sustancia química que el estado de California sabe que ocasiona
anomalías congénitas u otros daños a la reproducción. Lávese las
manos después de tocar el cable.
Información reglamentaria
TOSHIBA declara que este producto cumple con las siguientes normas:
La siguiente información es sólo para estados miembros de la
Unión Europea:
Requisitos de la FCC
Este equipo se probó y se comprobó que cumple con la Parte
15 de las normativas de la FCC.
Su funcionamiento está sujeto a las siguientes dos condiciones:
(1) Este dispositivo no debe causar interferencias perjudiciales.
(2) Este dispositivo debe aceptar cualquier interferencia,
incluidas aquellas que puedan comprometer su funcionamiento.
Desecho de productos
Este símbolo indica que este producto no se debe desechar con
los desechos domésticos normales. El producto debe ser
desechado por separado.
A D V E R T E N C I A

Instrucciones de seguridad
4
Contacto
Información adicional
© Copyright 2011 TOSHIBA CORPORATION. Todos los derechos
reservados. TOSHIBA se reserva el derecho de efectuar cambios técnicos.
TOSHIBA no asume ninguna responsabilidad por daños directos o
indirectos incurridos por errores, omisiones o discrepancias entre este
producto y la documentación.
Marcas comerciales
CAMILEO es una marca registrada de Toshiba America Information
Systems, Inc. y/o Toshiba Corporation.
Adobe y Photoshop son marcas registradas o marcas comerciales de
Adobe Systems Incorporated en Estados Unidos y/u otros países.
ArcSoft, MediaImpression, y MediaConverter son marcas registradas de
ArcSoft, Inc.
HDMI, el logotipo de HDMI y High-Definition Multimedia Interface son
marcas comerciales o marcas registradas de HDMI Licensing, LLC.
Secure Digital y SD son marcas comerciales de la SD Card Association.
Todos los demás nombres de marcas y productos son marcas comerciales
o marcas registradas de sus respectivas compañías.
Dirección: TOSHIBA America Information Systems, Inc.
9740 Irvine Boulevard
Irvine, California 92618-1697
Teléfono: [phone]
