Toshiba PA3897U-1CAS Camileo BW10 - S User manual

GMAA00268010
02/11
English/Español
CAMILEO®BW10
User’s Manual

2
Regulatory Information
TOSHIBA declares that this product conforms to the following Standards:
CE compliance
This product is CE marked in accordance with the requirements of the applicable
EU Directives. Responsible for CE marking is Toshiba Europe GmbH,
Hammfelddamm 8, 41460 Neuss, Germany. A copy of the official Declaration of
Conformity can be obtained from following website:
http://epps.toshiba-teg.com.
Model number: CAMILEO®BW10
Working Environment
The Electromagnetic Compliance (EMC) of this product has been verified
typically for this product category for a so called Residential, Commercial &
Light Industry Environment. Any other working environment has not been
verified by Toshiba and the use of this product in these working environments is
maybe restricted or cannot be recommended. Possible consequences of the use of
this product in non verified working environments can be: Disturbances of other
products or of this product in the nearby surrounding area with temporarily
malfunction or data loss/corruption as result. Example of non verified working
environments and related advices: Industrial environment (e.g. where 3-phase
380V mains is being used mainly): Danger of disturbances of this product due to
possible strong electromagnetic fields especially near to big machinery or power
units.
Medical environment: The compliance to the Medical Product Directive has not
been verified by Toshiba, therefore this product cannot be used as a medical
product without further verification. The use in usual office environments e.g. in
hospitals should be no problem if there is no restriction by the responsible
administration.
Automotive environment: Please search the owner instructions of the related
vehicle for advices regarding the use of this product (category).
FCC Conditions
This equipment has been tested and found to comply with Part
15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received.
Including interference that may cause undesired operation.

3
Aviation environment: Please follow the instructions of the flight personnel
regarding restrictions of use.
Additional Environment not related to EMC
Outdoor use: As a typical home/office equipment this product has no special
resistance against ingress of moisture and is not strong shock proofed.
Explosive atmosphere: The use of this product in such special working
environment (Ex) is not allowed.
REACH
Following information is only valid for EU-member States:
REACH - Compliance Statement
The new European Union (EU) chemical regulation, REACH (Registration,
Evaluation, Authorization and Restriction of Chemicals), entered into force on 1
June 2007.
Toshiba will meet all REACH requirements and is committed to provide our
customers with information about the chemical substances in our products
according to REACH regulation.
Please consult the following website
http://www.toshiba-europe.com/ computers/info/reach for information about the
presence in our articles of substances included on the candidate list according to
article 59(1) of Regulation (EC) No 1907/2006 (“REACH”) in a concentration
above 0.1% weight by weight.
WEEE
Following information is only valid for EU-member
States: Disposal of products
The crossed out wheeled dust bin symbol indicates that products must be
collected and disposed of separately from household waste. Integrated batteries
and accumulators can be disposed of with the product. They will be separated at
the recycling centers.
The black bar indicates that the product was placed on the market after August
13, 2005.

4
By participating in separate collection of products and batteries, you will help to
assure the proper disposal of products and batteries and thus help to prevent
potential negative consequences for the environment and human health.
For more detailed information about the collection and recycling programs
available in your country, please visit our website (http:// eu.computers.toshiba-
europe.com) or contact your local city office or the shop where you purchased the
product.
Disposal of batteries and /or accumulators
The crossed out wheeled dust bin symbol indicates that batteries and/or
accumulators must be collected and disposed of separately from household
waste.
If the battery or accumulator contains more than the specified values of lead (Pb),
mercury (Hg), and/or cadmium (Cd) defined in the Battery Directive
(2006/66/EC), then the chemical symbols for lead (Pb), mercury (Hg) and/or
cadmium (Cd) will appear below the crossed out wheeled dust bin symbol. By
participating in separate collection of batteries, you will help to assure the proper
disposal of products and batteries and thus help to prevent potential negative
consequences for the environment and human health.
For more detailed information about the collection and recycling programs
available in your country, please visit our website (http:// eu.computers.toshiba-
europe.com) or contact your local city office or the shop where you purchased the
product.
Contact
Address: TOSHIBA America Information Systems, Inc.
9740 Irvine Boulevard
Irvine, California 92618-1697
Telephone: [phone]
Pb, Hg, Cd

5
Safety Instructions
Safety Instructions
1Do not drop, puncture or disassemble the camcorder; otherwise
the warranty will be voided.
2Do not expose the camcorder to high temperature or leave it in
direct sunlight. Doing so may damage the camcorder.
3Use the camcorder with care. Avoid pressing hard on the
camcorder body.
4For your own safety, avoid using the camcorder when there is a
storm or lightning.
5Do not use batteries of different specifications. Doing so may
lead to the potential for serious damage.
6Remove the battery during long periods between usage, as a
deteriorated battery may affect the functionality of the
camcorder.
7Remove the battery if it shows signs of leaking or distortion.
8Use only the accessories supplied by the manufacturer.
9Keep the camcorder out of the reach of infants.
10 Risk of explosion if battery is replaced by an incorrect type.
11 Dispose of used batteries according to the instructions.
About the battery
❖Only use batteries recommended by TOSHIBA as replacements. The
battery is a lithium ion battery, which can explode if not replaced, used,
handled or disposed of properly. Dispose of the battery as required by local
ordinances or regulations.
❖Only charge the battery in ambient temperatures between 41 and 95 degrees
Fahrenheit (5 and 35 and degrees Celsius). Otherwise, the electrolyte
solution might leak, battery performance might deteriorate and the battery
life might be shortened.
❖Never install or remove the battery without first turning off the power and
disconnecting the USB cable.
❖Only use the supplied USB cable or a generic standard USB AC adaptor
(not supplied by Toshiba). Never attempt to charge the battery with
anything other than the above chargers specified.

6Safety icons
Safety icons
This manual contains safety instructions that must be observed to
avoid potential hazards that could result in personal injuries,
damage to your equipment, or loss of data. These safety cautions
have been classified according to the seriousness of the risk, and
icons highlight these instructions as follows:
Indicates an imminently hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, may
result in minor or moderate injury.
Indicates a potentially hazardous situation which, if not avoided, may
result in property damage.
Provides important information.
NOTE

7
Safety icons
Waterproof* feature
This camcorder complies with Japanese Industrial Standards (JIS)
IPX8 (formerly JIS protection grade 8) waterproof standard and can
be used in water. Note, however, that failing to heed the following
precautions may result in damage or injury that is not covered by
the warranty. Please take the time to carefully read and heed the
following cautions.
*Can be submerged up to a maximum depth of 6.56 ft. (2.0m), for up to
60 minutes.
Before using the camcorder
❖When closing the slot cover and port cover, make sure that no
foreign objects such as sand, hair, dust, etc. are caught in the
rubber seal.
❖Make sure that the slot cover and port cover are completely and
securely closed to prevent water from getting inside the
camcorder and damaging it.
❖Please note that the camcorder accessories are not waterproof.
Cautions concerning use in water
❖The waterproof properties of the camcorder apply to fresh water
and saltwater only; they do not apply to cleaning substances,
chemicals or water from spas, etc. In case of a splash,
immediately wipe off any moisture.
❖Do not immerse in water at a depth greater than 6.56 ft. (2.0m).
❖Do not subject the camcorder to high-pressure water.
❖Do not immerse in water for longer than 60 minutes. After 60
minutes of use in water, allow it to dry for at least 10 minutes.
❖Do not immerse in water that is warmer that 104 °F (40 °C).
❖Do not open and close the slot cover or port cover when the
camcorder is wet or while it is immersed in water.
❖Do not open and close the slot cover or port cover with wet
hands.
❖Do not open the slot cover or port cover on the beach or at the
pool side.
❖Do not jolt the camcorder while it is immersed in water. Doing so
may cause the slot cover or port cover to open.

8Safety icons
Storing and maintaining your camcorder
❖Do not leave the camcorder unwashed after it has been
immersed in salt water or if salt water is adhering to it. Doing so
may cause corrosion and discoloration of the plating, as well as
deterioration of the camcorder’s waterproof capability.
❖After the camcorder has been used in water, use fresh water to
wash it. Never use soap or detergent to clean the camcorder, as
doing so will cause deterioration of the camcorder’s waterproof
capability.
❖After washing the camcorder, take care to completely drain it,
and use a dry cloth to wipe off any drops of water adhering to it.
❖Do not leave the camcorder in an environment colder than 32 °F
(0 °C) or warmer than 104 °F (40 °C), as doing so may cause
deterioration of the camcorder’s waterproof capability.
Other cautions
❖Do not subject the camcorder to severe jolts, as doing so may
deform the slot cover, port cover or the camcorder body, thus
compromising its waterproof capability.
What is “JIS IPX8” (formerly “JIS protection grade8”)?
❖“JIS IPX8” specifies that a device is protected against the effects
of continuous immersion in water for a limited period of time.
Before recording in water
Make sure that the slot cover and the port cover are closed. If a
cover is open, water will get inside the camcorder and damage it.
When closing the slot cover and port cover, make sure that no
foreign object such as sand, hair, dust, etc. is caught in the rubber
seal.
NOTE

9
Safety icons
There are places in the camcorder where water might accumulate,
but this will not affect its waterproof properties. To care for your
camcorder after using it in water, see “Waterproof* feature” on
page 7.
Additional Information
© Copyright 2011 TOSHIBA CORPORATION. All rights
reserved. TOSHIBA reserves the right to make technical changes.
TOSHIBA assumes no liability for damages incurred directly or
indirectly from errors, omissions or discrepancies between this
product and the documentation.
Trademarks
CAMILEO is a registered trademark of Toshiba America
Information Systems, Inc. and/or Toshiba Corporation.
Adobe and Photoshop are either registered trademarks or
trademarks of Adobe Systems Incorporated in the United States
and/or other countries.
HDMI, the HDMI Logo and High-Definition Multimedia Interface
are trademarks or registered trademarks of HDMI Licensing, LLC.
Intel, Intel Core, Celeron, Centrino and Pentium are trademarks or
registered trademarks of Intel Corporation or its subsidiaries in the
United States and other countries.
Mac OS is a trademark of Apple Inc., registered in the U.S. and
other countries.
Microsoft, Windows, and Windows Vista are either registered
trademarks or trademarks of Microsoft Corporation in the United
States and/or other countries.
Secure Digital and SD are trademarks of SD Card Association.
YouTube and the YouTube logo are registered trademarks of
Google, Inc.
All other brand and product names are trademarks or registered
trademarks of their respective companies.

10
5.375 x 8.375 ver 2.3
Contents
Safety Instructions....................................................5
About the battery ......................................................5
Safety icons ..............................................................6
Chapter 1: Getting to Know Your Camcorder.......................... 13
Overview ................................................................13
Check the Components.....................................14
System Requirements.......................................14
Front view .........................................................15
Rear view..........................................................16
Chapter 2: Getting Started......................................................... 17
Loading the battery.................................................17
Inserting the battery..........................................18
Removing the battery........................................19
Charging the battery .........................................20
Remove moisture from all camcorder
surfaces ......................................................22
Temperature alert icon............................................27

11
Contents
5.375 x 8.375 ver 2.3
Inserting and removing a media card......................27
Taking photos without a media card
installed ......................................................29
To format a media card.....................................29
Turning the camcorder on and getting started........29
Accessing the MENU screen .............................30
Setting the date and time ........................................32
Resetting the date and time ..............................33
Starting again from the power save mode ..............33
Chapter 3: Recording................................................................. 35
Recording a video clip ............................................35
Changing the video settings..............................36
Taking still photos...................................................37
Zooming in or out on a subject.........................38
Changing the photo settings .............................39
Capturing a still photo while recording a
video clip ..........................................................39
Saving one frame from a video clip as a
still image ...................................................40
Chapter 4: Playback................................................................... 41
Playing back video clips and still images ................41
Deleting files .....................................................42
Video clip playback operation .................................42
Chapter 5: Connecting to a TV.................................................. 44
Connecting the HDMI™ cable .................................44
Chapter 6: Connecting to a Computer ..................................... 46
Copying files to a computer ....................................46
Application software .........................................48
Disconnecting the camcorder from the
computer ....................................................48

12 Contents
5.375 x 8.375 ver 2.3
Chapter 7: Uploading Video Files to YouTube®....................... 49
Chapter 8: Specifications........................................................... 50
Multi-indicator ........................................................51
Operating Environment Conditions .........................51
Chapter 9: Troubleshooting....................................................... 52
Chapter 10: Other Information.................................................. 56
Toshiba Support .....................................................56
Before you call ..................................................56
Contacting Toshiba .................................................57
Toshiba’s technical support Web site................57
Toshiba voice contact .......................................57
Warranty.................................................................58
Online Warranty Information.............................58
Warranty Service ..............................................58

13
Chapter 1
Getting to Know Your
Camcorder
Overview
Your Toshiba camcorder comes equipped with a 5 Megapixel
sensor that can record H.264 format videos. This format allows for
extended video recording with less memory.
Other features of your CAMILEO®BW10 camcorder are:
❖6.5 ft. (2 m.) waterproof
❖Quality images up to 5 Megapixels
❖Color LCD screen for easy viewing of video and photos
❖Video recording at full HD resolution of 1920 x1080
❖HDTV connectivity via an HDMI™ cable (HDMI™ cable sold
separately)
❖Built-in YouTube®Direct application, allowing you to upload
videos captured by the camcorder to YouTube®more
effortlessly
❖10x digital zoom
❖Built-in memory allowing you to take a few photos and to
record videos without a memory card

14 Getting to Know Your Camcorder
Overview
❖Memory card slot allowing users to increase storage capacity
A portion of the built-in memory is used for Firmware to operate the
camcorder.
Check the Components
Unpack the box and make sure all the listed items below are
included:
(Sample Illustration) Components
Be sure to remove the protective film on the lens before use.
System Requirements
❖Microsoft®Windows®XP SP3/Windows Vista®/Windows®7
❖Intel®Core™ Duo E4400 2.0 GHz or above
❖1 GB RAM
❖1 GB free hard disk space
NOTE
containing product software,
User’s Manual (this document),
Installation DVD-ROM Li-ion battery USB cable
Hand strap
Soft case Quick Start Guide
and Warranty information
NOTE

15
Getting to Know Your Camcorder
Overview
❖DVD-ROM
❖1x USB port
The LCD screen is manufactured using extremely high-precision
technology. However, some tiny black and/or bright dots (white, red,
blue or green) may appear on the LCD screen. These dots are a
normal result of the manufacturing process, and do not affect the
recording.
Front view
(Sample Illustration) Front view
NOTE
Video button
Multi-indicator light
OK button
Arrow buttons
Screen
Power button
Playback
MENU button
button
button

16 Getting to Know Your Camcorder
Overview
Rear view
(Sample Illustration) Rear view
LED light
Microphone
Lens
Port cover
Battery/Media card
slot cover

17
Chapter 2
Getting Started
Loading the battery
Before using the camcorder, remove the protective film from the
battery as shown below.
(Sample Illustration) Removing the protective film from the battery

18 Getting Started
Loading the battery
Inserting the battery
To install the supplied battery:
1While pressing down on the slot cover release latch, slide the
slot cover out and open.
(Sample Illustration) Opening the battery/media card slot cover
2Insert the battery until it locks into place.
(Sample Illustration) Inserting the battery
3Close the battery/media card slot cover. Secure it by sliding it
back into place.
(Sample Illustration) Closing the battery/media card slot cover

19
Getting Started
Loading the battery
Close the slot cover and port cover securely.
If any cover is not closed or is not closed completely, the camcorder
will no longer be waterproof. When closing a cover, make sure that
no foreign object such as sand, hair, dust, etc. is caught in the rubber
seal.
Removing the battery
To remove the battery:
1While pressing down on the slot cover release latch, slide the
slot cover out and open.
(Sample Illustration) Opening the battery/media card slot cover
2Slide the battery clip down.
The battery pops out slightly from the slot.
3Pull the battery straight out.
(Sample Illustration) Removing the battery
4Close the battery/media card slot cover. Secure the cover by
sliding it back into place.

20 Getting Started
Loading the battery
Close the slot cover and port cover securely.
If any cover is not closed or is not closed completely, the camcorder
will no longer be waterproof. When closing a cover, make sure that
no foreign object such as sand, hair, dust, etc. is caught in the rubber
seal.
Charging the battery
❖Do not turn on the camcorder while the battery is charging. It is
not possible to charge the battery while the camcorder is on.
❖Do not turn off the computer while the battery is charging. It is
not possible to charge the battery while the computer is off.
❖With certain computers, it may be possible to charge the battery
even when the computer is turned off.
You must use the supplied USB cable or a generic standard USB AC
adaptor (not supplied by Toshiba) to charge your camcorder before
use.
Recharging takes place only when the camcorder is turned off, or
when the power save function or the sleep function has been
activated. Recharging does not take place when the camcorder is in
record mode or playback mode.
1To charge the battery, the camcorder must be OFF. If the
camcorder is ON, press the Power button for at least one
second to turn it off.
(Sample Illustration) The Power button
NOTE
NOTE
Power button
