EQUIUM 6200D Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1997 TAIS 6200d.doc Rev. 3 04/04/00 nmm. Page 1 of 3
Equium 6200D
2.95 GB: PV1025U-01A
PROCESSOR
Intel PentiumPro 200Mhz (3.3v) w/VRT Yes
Integrated Coprocessor Yes
Processor Cache 32KB: (16KB code; 16KB data)
Socketed Processor Yes
LEVEL 2 (L2) CACHE Yes: 256KB Pipeline Burst Integrated into CPU
Data Bus Width/Address Bus Width 64-bit/32-bit
Local Clock Bus Speed 66 MHz
DATA RAM:
1 Mbit PBS SRAM (3.3V) Yes
Access time 8 nsec
SYSTEM ARCHITECTURE
PCI BUS (V2.1): (32-bit, 33mhz) Yes
MEMORY: 16Mbit EDO DRAM
Standard 32 MB: (2*16 SIMMS)
Maximum 128 MB (96MB without removing memory)
Speed 60ns
Parity No parity
Hyper Page mode memory access Yes
Data Bus Width/Address Bus Width 64-bit/32-bit
Local Clock Bus Speed 66 MHz
Socket type: (4) SIMM sockets: Accepts 16MB or 32MB chips
BIOS (256KB FLASH EPROM, ) Yes
PnP 1.0a SUPPORT Yes
Advanced Power Management 1.2 Support Yes
EPA energy Star Compliant Yes
DMI 2.0 Compliant Yes
DPMS Yes
DDC Yes
NLS Yes
VIDEO
Video Memory: EDO DRAM 2MB expandable to 2MB
Speed 40 ns
PCI Bus Architecture Yes: 33 MHz Bus Clock Speed
Controller Chip Virge DX Controller
Full motion video at 30 fps support Yes
VESA support Yes
YUV to RGB conversion Off-loads conversion from CPU for higher performance full motion video
without compromising picture quality or frame rate.
Graphics Accellerator Support Includes 64-bit BitBLT, Hardware Cursor, DirectDraw, Direct3D
Supported Resolutions Colors/Pallette Refresh Rate (Non-Interlaced)
640 x 480 16.7M colors/16.7M colors 75 Hz
800 x 600 16.7M colors/16.7M colors 75 Hz
1024 x 768 64K colors/64K colors 85 Hz
1280 x 1024 256 colors/256 colors 75 Hz
SOUND SYSTEM
Chipsets: Crystal CS4236
16 bit stereo audio full duplexed Yes
Sound formats supported: SoundBlaster Pro, .WAV, MIDI, CD-ROM audio
ETHERNET SUPPORT IntelEtherExpressPRO/100B LAN Adapter (PCI Card Add-in)
IEEE802, 3µauto-negotiation Yes: provides hardware selection of the highest operating speed

EQUIUM 6200D Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1997 TAIS 6200d.doc Rev. 3 04/04/00 nmm. Page 2 of 3
Equium 6200D
2.95 GB: PV1025U-01A
STORAGE
CONTROLLER TYPE Dual Channel, Bus Mastering PCI-EIDE (supports 4 IDE devices)
PIO Mode 4 (up to 16Mb/sec transfer rate) Yes
HDD ( 3.5”Half-height Enhanced IDE) 3.1 billion bytes (= 2.95 GB)
Access Time <10msec
Burst Data Transfer Rate PIO Mode 4 (16.7MB/sec)
PCI Bus Master support Yes
FDD 3.5” Floppy Disk Drive
CD-ROM: Toshiba XM-5702B 12X- speed
PCI Bus Master support Yes
Interface ATAPI ( Enhanced IDE ) w/256KB Buffer
Random Access Time 115 ms
Sustained Transfer Rate 1.8 MB/sec
Supported Disk Formats Red Book, Yellow Book, CD-ROM XA, CD-Bridge (Photo-CD, Video-CD),
CD-I, CD-I Ready, CD-G, Multisession (Photo-CD, CD-Extra, CD-E)
EXPANSION SLOTS
Number of PCI Slots ( Available/Total ) 1/2
Number of ISA Slots ( Available/Total ) 3/3
EXPANSION BAY
Internal Bay One - occupied with HDD
External 5.25” Bay One open - Two occupied with 3.5”FDD and 12X CD-ROM
EXTERNAL INTERFACES
One RJ-45 port for ethernet card (supplied) Yes
One 9-Pin Serial (16550 UART compliant) Yes
Universal Serial Bus ports Supports 2 USB peripherals without external hub
One 25-Pin Parallel (IEEEP1284 compliant) Yes: Multimode bi-directional (EPP, ECP)
One 15-Pin RGB (SVGA video) Yes
One (PS/2) Mouse Port Yes
One (PS/2) Windows 95 104 Keyboard Yes
Microphone (3.5mm mini jack, monaural) Yes
Headphone (3.5mm mini jack, stereo) Yes
Line-in (3.5mm mini jack, stereo, 2V rms) Yes
Line-out (3.5mm mini jack, stereo, 0.7V rms) Yes
Joystick/MIDI Port (15 pin D-sub) Yes
AC IN (Standard 2 prong ) Yes
KEYBOARD
104-key keyboard with the Windows 95 keys Yes
3.8mm Travel Yes
12 dedicated function keys Yes
Numeric keypad Yes
POINTING DEVICE
PS/2 Mouse Yes
POWER SUPPLY( 200Watts )
Input (Voltage/Frequency) 115-230V; 50-60Hz, Switch Selectable
Supported Safety Standards UL/CSA, NRTL/C, VDE 0805, IEC 950, EN 60950, NEMKO
SECURITY Chasis intrusion alert, Password protection, Cable lock receptacle
DIMENSIONS: (L x W x D) 17.625” x 18.375” x 4.75”
WEIGHT 28 LBS
BUNDLED SOFTWARE: Microsoft Windows NT Workstation v4.x; Intel LanDesk Client Manager, Plug and Play drivers;
PUMA TranXit for IRDA; Ethernet drivers (DOS, Window95, NTW, OS/2, Netware); Disk Creation utility; Mouse drivers
WARRANTY: 3 Yr. Parts & Labor (First Yr. On-site); Dedicated technical support, business hours nationwide
1. Both ports operate from a single controller allowing 128 devices total, not per port. Throughput for the Universal Serial
Bus (UBS) is 12Mbits/sec.

EQUIUM 6200D Product Specifications
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 1997 TAIS 6200d.doc Rev. 3 04/04/00 nmm. Page 3 of 3
PRICING PART # PRICE
6200D 200MHz Pentium Pro, 2.95GB HDD, 12X CD-ROM PV1025U-01A $1,799
EQUIUM MONITORS PART # PRICE
17” (15.8” viewable image)TekBrightMultimedia Monitor (DC786MF) PV2003U-01 $649
Toshiba TekBright



17” (15.8” viewable image) Monitor -- 700P PV2006U-01 $649 NEW!!
Toshiba TekBright



15” (13.7” viewable image) Monitor -- 500V PV2005U-01 $349 NEW!!
17” (16.23”viewable image) Autoscan Monitor DP782M-01 $599
15” (13.78”viewable image) Autoscan Monitor DP566M-01 $299
EQUIUM ACCESSORIES (For 5160D, 5200D, 5230D, 6200D,
6260M) PART # PRICE
8MB Kingston Noteworthy EDO memory upgrade module KTT-INF/8 $40
16MB Kingston Noteworthy EDO memory upgrade module KTT-INF/16 $70
32MB Kingston Noteworthy EDO memory upgrade module KTT-INF/32 $136
64MB Kingston Noteworthy EDO memory upgrade module KTT-INF/64 $263
128MB Kingston Noteworthy EDO memory upgrade module KTT-INF/128 $629
