Toshiba BU406M User manual

D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
BU Series
CMOS Camera
Instruction Manual
Model
BU406M
Information contained in this document is subject to change without prior notice.
Thank you for purchasing our product.
Before using this CMOS camera, please read through this instruction manual
carefully in order to use this product correctly and safely.
After reading, keep this instruction manual handy so that you can refer to,
whenever you need it.

1 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
Contents
Contents........................................................................................................................1
General Handing ..........................................................................................................................3
CASES FOR INDEMNITY (LIMITED WARRANTY) ....................................................................5
RESTRICTION FOR USE............................................................................................................6
Notes on using this product..........................................................................................................7
Installation ...................................................................................................................11
Specifications...............................................................................................................12
Overview.......................................................................................................................................12
Features........................................................................................................................................12
Configuration ................................................................................................................................14
Connection....................................................................................................................................15
Connector PinAssignment...........................................................................................................16
Outline Drawing............................................................................................................................17
General Specifications..................................................................................................................18
LED status....................................................................................................................................20
I/O Specification............................................................................................................................21
Timing Specification......................................................................................................................22
Typical Spectral Response...........................................................................................................24
Operating Ambient Conditions......................................................................................................25
Functions.....................................................................................................................27
Bootstrap Registers......................................................................................................................28
DeviceControl...............................................................................................................................29
ImageFormatControl.....................................................................................................................30
Scalable........................................................................................................................................31
PixelFormat...................................................................................................................................33
AcquisitionControl.........................................................................................................................34
ImageBuffer..................................................................................................................................36
ExposureTime...............................................................................................................................38
BlackLevel ....................................................................................................................................39
Gain ..............................................................................................................................................40
Gamma.........................................................................................................................................41
TriggerControl...............................................................................................................................42
UserSetControl.............................................................................................................................46
DigitalIOControl ............................................................................................................................48
TimerControl.................................................................................................................................51
LEDIndicatorLuminance...............................................................................................................53
TestPattern....................................................................................................................................54
Decimation....................................................................................................................................56
Reverse ........................................................................................................................................58
EventNotification...........................................................................................................................59
Appendix......................................................................................................................61
MultiFrame and Bulk function difference......................................................................................61
Warranty rules .............................................................................................................64
Repair..........................................................................................................................65

2 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
Safety Precautions
Before using this product, read these safety precautions carefully. Important information is shown in this
Instruction Manual to protect users from bodily injuries and property damages, and to enable them to use the
product safely and correctly.
Please be sure to thoroughly understand the meanings of the following signs and symbols before reading
the main text that follow, and observe the instructions given herein.
[Definition of Safety Signs]
Notes *1:“Serious injury” refers to cases of loss of eyesight, wounds, burns (high or low temperature),
electric shock, broken bones, poisoning, etc., which leave after-effects or which require
hospitalization or a long period of outpatient treatment of cure.
*2: "Light to moderate injuries" refers to injuries, burns, electric shock etc. that do not require
hospitalization or long-term treatment.
*3: "Property damage" refers to cases of extensive damage involving damage to buildings,
equipment, farm animals, pet animals and other belongings.
[Explanation of Safety Symbols]
Safety Signs Description
WARNING
Indicates a potentially hazardous situation that may result in death or serious
injury (*1) in the event of improper handling.
CAUTION Indicates a potentially hazardous situation that may result in light to moderate
injuries (*2) or only in property damage (*3)in the event of improper handling.
Safety Symbols Description
PROHIBITED
This sign indicates PROHIBITION (Do not).
The content of prohibition is shown by a picture or words beside the symbol.
MANDATORY This sign indicates MANDATORY ACTION (You are required to do).
The content of action is shown by a picture or words beside the symbol.

3 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
General Handing
WARNING



Stop operation immediately when any
abnormality or defect occurs.
If abnormal conditions are present, such as smoke, a burning smell, ingress of water or
foreign matter, or if the equipment is dropped or malfunctions, fire or electric shock may
result.
Be always sure to disconnect the power cable from the wall socket at once and contact
your dealer.
Unplug


Do not use the equipment in locations subject to water splashes.
Otherwise, fire or electric shock may result.
Do not get wet


Do not disassemble, repair, or modify the equipment.
Otherwise, fire or electric shock may result.
For internal repair, inspection, or cleaning, contact your sales representative.
Never pull apart


Do not place anything on the equipment.
If metallic objects, liquid, or other foreign matter enters the equipment, fire or electric
shock may result.
Avoid


Do not install the equipment in an unstable or inclined location or locations
subject to vibration or impact.
Otherwise, the equipment may topple over and cause personal injury.
Avoid


During an electrical storm, do not touch the power cable and the connection
cable.
Otherwise, an electric shock may result.
Do not touch
Instruction


Use the specified voltage.
Use of an unspecified voltage may result in fire or electric shock.


Do not be handled roughly, damaged, fabricated, bent forcefully, pulled, twisted,
bundled, placed under heavy objects or heated the power cable and the
connection cable.
Otherwise, fire or electric shock may result.
Avoid

4 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
CAUTION


Observe the following when installing the equipment:
·Do not cover the equipment with a cloth, etc.
·Do not place the equipment in a narrow location where heat is likely to accumulate.
Otherwise, heat will accumulate inside the equipment, possibly resulting in a fire.
Instruction


Do not place the equipment in locations subject to high moisture, oil fumes,
steam, or dust.
Otherwise, fire or electric shock may result.
Avoid


Do not install the equipment in locations exposed to direct sunlight or humidity.
Otherwise, the internal temperature of the equipment will rise, which may cause a fire.
Avoid


Use only specified the power cable and the connection cables.
Otherwise, fire or electric shock may result.
Instruction


Do not give strong impact against the equipment.
It may cause the trouble.
Avoid


When performing connection, turn off power.
When connecting the power cable and the connection cable, turn off the equipment
power.
Otherwise, fire or electric shock may result.
Instruction


Do not expose its camera head to any intensive light (such as direct sunlight).
Otherwise, its inner image pickup device might get damaged.
Avoid


Avoid short-circuiting signal output.
Otherwise, a malfunction may occur.
Avoid


Avoid giving a strong shock against the camera body.
It might cause a breakdown or damage. If your camera is used in a system where its
camera connector is subjected to strong repetitive shocks, its camera connector is
possible to break down. If you intend to use your camera in such a situation, if possible,
bundle and fix a camera cable in the place near the camera, and do not transmit a
shock to the camera connector.
Avoid


Contact your sales representative to request periodic inspection and cleaning
(every approx five years).
Accumulation of dust inside the equipment may result in fire or electric shock.
For inspection and cleaning costs, contact your sales representative.
Instruction

5 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
CASES FOR INDEMNITY (LIMITED WARRANTY)
We shall be exempted from taking responsibility and held harmless for damage or losses incurred by the
user in the following cases.
●In the case damage or losses are caused by natural disasters, such as an earthquake and thunder, fire, or
other acts of God, acts by a third party, deliberate or accidental misuse by the user, or use under extreme
operating conditions.
●In the case of indirect, additional, consequential damages (loss of business interests, suspension of
business activities) are incurred as result of malfunction or non-function of the equipment, we shall be
exempted from responsibility for such damages.
●In the case damage or losses are caused by failure to observe the information contained in the
instructions in this instruction manual and specifications.
●In the case damage or losses are caused by use contrary to the instructions in this instruction manual and
specifications.
●In the case damage or losses are caused by malfunction or other problems resulting from unintended use
of equipment or software etc. that are not specified.
●In the case damage or losses are caused by repair or modification conducted by the customer or any
unauthorized third party (such as an unauthorized service representative).
●Expenses we bear on this product shall be limited to the individual price of the product.
●The item that is not described in specifications of this product is out of the guarantee.
●The case of damages or losses which are caused by incorrect connection of the cable is out of the
guarantee.

6 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
RESTRICTION FOR USE
●Should the equipment be used in the following conditions or environments, give consideration to safety
measures and inform us of such usage:
1. Use of the equipment in the conditions or environment contrary to those specified, or use outdoors.
2. Use of the equipment in applications expected to cause potential hazard to people or property, which
require special safety measures to be adopted.
●This product can be used under diverse operating conditions. Determination of applicability of equipment or
devices concerned shall be determined after analysis or testing as necessary by the designer of such
equipment or devices, or personnel related to the specifications. Such designer or personnel shall assure
the performance and safety of the equipment or devices.
●This product is not designed or manufactured to be used for control of equipment directly concerned with
human life (*1) or equipment relating to maintenance of public services/functions involving factors of safety
(*2). Therefore, the product shall not be used for such applications.
(*1): Equipment directly concerned with human life refers to.
- Medical equipment such as life-support systems, equipment for operating theaters.
- Exhaust control equipment for exhaust gases such as toxic fumes or smoke.
- Equipment mandatory to be installed by various laws and regulations such as the Fire Act or Building
Standard Law
- Equipment related to the above
(*2): Equipment relating to maintenance of public services/functions involving factors of safety refers to.
- Traffic control systems for air transportation, railways, roads, or marine transportation
- Equipment for nuclear power generation
- Equipment related to the above

7 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
Notes on using this product
●Handle carefully
Do not drop the equipment or allow it to be subject to strong impact or vibration, as such action may cause
malfunctions. Further, do not damage the connection cable, since this may cause wire breakage.
●Environmental operating conditions
Do not use the product in locations where the ambient temperature or humidity exceeds the specifications.
Otherwise, image quality may be degraded or internal components may be adversely affected. In particular,
do not use the product in areas exposed to direct sunlight. Moreover, during shooting under high
temperatures, vertical stripes or white spots (noise) may be produced, depending on the subject or camera
conditions (such as increased gain). However, such phenomena are not malfunctions.
●Check a combination with the lens
Depending on the lens and lighting you use, an image is reflected as a ghost in the imaging area. However,
this is not because of a fault of the camera.
In addition, depending on the lens you use, the performance of the camera may not be brought out fully due
to deterioration in resolution and brightness in the peripheral area, aberration and others.
Be sure to check a combination with the camera by using the lens and lightning you actually use.
When installing a lens in the camera, make sure carefully that it is not tilted.
In addition, use a mounting screw free from defects and dirt. Otherwise, the camera may be unable to be
removed.
Install a next lens; its dimension of protrusion from bottom of the screw is equal to or less than 10 mm. If a
lens does not stand to this condition, it might not be installed to this camera.
●Mounting to pedestal
When mounting this product to a pedestal, make sure carefully that lens doesn’t touch with the pedestal.
●Do not shoot under intense light
Avoid intense light such as spot lights on part of the screen because it may cause blooming or smears. If
intense light falls on the screen, vertical stripes may appear on the screen, but this is not a malfunction.

8 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
●Do not expose the camera's image-pickup-plane to sunlight or other intense light directly
Its inner CMOS sensor might be damaged.
●Occurrence of moiré
If you shoot thin stripe patterns, moiré patterns (interference fringes) may appear. This is not a malfunction.
●Occurrence of noise on the screen
If an intense magnetic or electromagnetic field is generated near the camera or connection cable, noise may
be generated on the screen. If this occurs, move the camera or the cable.
●Handling of the protective cap
If the camera is not in use, attach the lens cap to the camera to protect the image pickup surface.
●If the equipment is not to be used for a long duration
Turn off power to the camera for safety.
●Maintenance
Turn off power to the equipment and wipe it with a dry cloth.
If it becomes severely contaminated, gently wipe the affected areas with a soft cloth dampened with diluted
neutral detergent. Never use alcohol, benzene, thinner, or other chemicals because such chemicals may
damage or discolor the paint and indications.
If the image pickup surface becomes dusty, contaminated, or scratched, consult your sales representative.

9 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
●Disposal
When disposing of the camera, it may be necessary to disassemble it into separate parts, in accordance with
the laws and regulations of your country and/or municipality concerning environmental contamination.
Following information is only for EU-member states:
The use of the symbol indicates that this product may not be treated as household
waste. By ensuring this product is disposed of correctly, you will help prevent
potential negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. For more
detailed information about the take-back and recycling of this product, please contact
your supplier where you purchased the product.
“This symbol is applicable for EU member states only”
This equipment has been tested and found to comply with the limits for a class A digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instruction manual, may cause harmful interference to radio
communication.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
[Phenomena specific to CMOS sensor]
Defective pixels
A CMOS image sensor is composed of photo sensor pixels in a square grid array. Due to
the characteristics of CMOS image sensors, over- or under-driving of the pixels results in
temporary white or black areas (as if these are noises) appearing on the screen. This
phenomenon, which is not a defect is exacerbated under higher temperatures and long
exposure time.
 Image shading
The brightness of the upper part of the screen may be different from that of the lower part. Note
that this is a characteristic of a CMOS image sensor and is not a fault.

10 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
环保使用期限标识，是根据电子信息产品污染控制管理办法以及，电子
信息产品污染控制标识要求(SJ/T11364-2006)、电子信息产品环保使用
期限通则，制定的适用于中国境内销售的电子信息产品的标识。
电子信息产品只要按照安全及使用说明内容，正常使用情况下，从生产
月期算起，在此期限内，产品中含有的有毒有害物质不致发生外泄或突
变，不致对环境造成严重污染或对其人身、财产造成严重损害。
产品正常使用后，要废弃在环保使用年限内或者刚到年限的产品时，请
根据国家标准采取适当的方法进行处置。
另外，此期限不同于质量/功能的保证期限。
The Mark and Information are
applicable for People's Republic of
China only.
＜
＜＜
＜产
产产
产品中有毒有害物
品中有毒有害物品中有毒有害物
品中有毒有害物质
质质
质或元素的名称及含量
或元素的名称及含量或元素的名称及含量
或元素的名称及含量＞
＞＞
＞
部件名称
有毒有害物质或元素
铅（Pb） 汞（Hg） 镉（Cd） 六价铬
（Cr(VI)）
多溴联苯
（PBB）
多溴二苯醚
(PBDE）
相机本体
× ○ ○ ○ ○ ○
○：表示该有毒有害物质在该部件所有均质材料中的含量均在电子信息产品中有毒有害物质的
限量要求标准规定的限量要求(SJ/T11363-2006)以下
×：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出电子信息产品中有毒有害
物质的限量要求标准规定的限量要求(SJ/T11363-2006)
This information is applicable for People's Republic of China only.
リサイクルに
リサイクルにリサイクルに
リサイクルに関
関関
関する
するする
する情報
情報情報
情報（
（（
（包装物
包装物包装物
包装物）
））
）
有关再利用的信息
有关再利用的信息有关再利用的信息
有关再利用的信息(
((
(包装物
包装物包装物
包装物)
))
)
Information on recycling of wrapping composition
Information on recycling of wrapping compositionInformation on recycling of wrapping composition
Information on recycling of wrapping composition
中华人民共和国
环保使用期限
10
ペーパーボード
ペーパーボードペーパーボード
ペーパーボード
纸板
纸板纸板
纸板
Paper board
Paper boardPaper board
Paper board
箱
箱箱
箱／
／／
／箱子
箱子箱子
箱子／
／／
／Box
BoxBox
Box
内部緩衝材料
内部緩衝材料内部緩衝材料
内部緩衝材料・
・・
・袋
袋袋
袋
内部
内部内部
内部缓冲材料
缓冲材料缓冲材料
缓冲材料·
··
·袋
袋袋
袋
Internal buffer
Internal bufferInternal buffer
Internal buffer materials
materialsmaterials
materials・
・・
・Bag
BagBag
Bag

11 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
Installation
Before using this product, you shall install application software to display image and control registers of
camera, and IP configuration tool for network setting.
You can download the SDK for our USB camera products (TeliU3vSDK) from the Service & Support section
of our website.
User registration is necessary to use downloading service. Please make a user registration, or contact your
sales representative.
●TOSHIBATELI CORPORATION Top Page
http://www.toshiba-teli.co.jp/index.htm
●Service & Support
https://www.toshiba-teli.co.jp/cgi/ss/en/service.cgi
Please refer to the TeliU3vSDK startup guide, about Operation environment, Installation, and Setup.

12 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
Specifications
Overview
This BU406M is an integrated-(one-body)-type monochrome camera that adopts 1/1 type 4M pixel CMOS
sensor. For video output and camera control, the USB 3.0 interface standard is adopted for high transfer rate,
and it is easy to integrate into industrial equipment.
Features
●High frame rate
Supported frame rate is up to 90fps (BU406M/4M pixel).
●Global shutter
As it employs a global electronic shutter similar to a CCD image sensor, clear images of even fast-moving
object are obtainable with less blur.
●USB*3.0 interface
Video output and camera control are performed via the USB 3.0 standard interface. Data transfer is up to
5Gbps (Maximum) that enables to output uncompressed video data at high frame rate.
●USB3 Vision* conformity
This product is based on USB3 Vision Ver.1.0.
●GenICam* Ver 2.3 conformity
This product is based on GenICam Generic Interface for Cameras Ver 2.3.
●IIDC2 Digital Camera Control Specification Ver.1.0.0 conformity
This product is based on IIDC2 Digital Camera Control Specification Ver.1.0.0.

13 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
●e-CON* Connector adoption
The e-CON connector adoption enables to assemble the cable easily without using special tools.
●Decimation mode
Camera reads all effective areas at high speed by skipping lines.
●Random Trigger Shutter
The Random Trigger Shutter function provides images in any timing by input of an external trigger signal.
Trigger control from PC is available as well.
●Scalable
Selectable video output area. This mode achieves higher frame rate by reducing vertical output area. And
reduces occupied data rate of USB bus by reducing horizontal output area.
●Compact and lightweight
This camera is compact and lightweight; it is easy to integrate into industrial equipment.
●EU RoHS & Chinese ROHS
* USB is a unified standard established by USB-IF(USB Implementers Forum).
* USB3 Vision is a unified standard established byAIA(Automated ImagingAssociation).
*GenICam is a registered trademark of EMVA (European Machine Vision Association).
* IIDC2 is a unified standard established by JIIA (Japan IndustrialAssociation).
*e-CON (Easy & Economy connector) is a sensor connector that is normalized by the manufacturer of the
sensor, FA equipment and connector.

14 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
Configuration
The system configuration of this camera series is as follows;
This camera has no accessories, please prepare other equipments separately.
●Camera: This product. (BU)
●Camera mounting kit CPTBU (*1): To fix a camera to a tripod; attach this to the bottom of the camera.
●USB3.0 Cable (*2): This cable is used to connect the camera to host PC. Please use
a USB3.0 cable of Standard A - Micro B. This product is able to
connect a USB cable equipped with screw lock mechanism.
Please use it as needed.
●USB3.0 Interface Card (*2): This is the interface card to connect to the camera. Usually this
card is installed to expansion slot of PC etc.
●e-CON Cable. (*2): This cable is used to input external trigger signal and output GPIO
signal.
We recommend using shielded cable, because there is likely to be
affected by the noise depending on the operating environment of
the camera.
*1: Optional part. Contact your sales representative for details of option units.
*2: Commercial items.

15 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
Connection
Notes on Connection:
- Please confirm the power supply of the camera off when plugging in or pulling out the I/O Connector. It causes the
breakdown.
- If your camera is used in a system where its connectors are subjected to strong repetitive shocks, its connectors are
possible to break down. If you use your camera in such a situation, use an USB3.0 cable with a lock screw, and secure
the camera cable as close as possible to the camera body for avoid physical shock to the camera connector.
- About e-CON cable: In the case that electric-wire is long or thin, input and output voltage may not satisfy specifications
of the camera or your system by voltage drop. Please confirm wires’ specifications before use them.
- Lost packets may occur by an electrical characteristic of the transmission line of USB3.0. (USB3.0 Interface Card,
USB3.0 Cable, and USB3.0 HUB).

16 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
Connector Pin Assignment
Rear View
1. USB3.0 Interface Connector
Connector model: WMUR-10F6L1PH5N (WIN WIN PRECISION INDUSTRIAL)
Pin No. I/O Signal Function
1 - VBUS Power
2 I/O D- USB2.0 differential pair
3 I/O D+
4 - NC Not connected
5 - GND Ground for power return
6 O SSTX- SuperSpeed transmitter differential pair
7 O SSTX+
8 - GND_DRAN Ground for SuperSpeed signal return
9 I SSRX- SuperSpeed receiver differential pair
10 I SSRX+
2. I/O Connector
Connector (Camera side) 37204-62B3-004PL (Sumitomo 3M) or equivalent
Matching connector (Cable side) Connectors which conformed to e-CON
e.g. 37104 series (Sumitomo 3M), RITS 4P series (Tyco)
* Matching connector is not an accessory of this product.
Pin assignment
↑TOP
*Above figure is connector view from insert side.
Pin No. I/O Signal Function
1 O GPIO(Line2) GPIO Output
2 O GPIO(Line1) GPIO Output
3 - GND Ground
6 I TRIG_IN(Line0) Trigger Input

17 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
Outline Drawing

18 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
General Specifications
Model Name BU406M
Imager CMOS image sensor
Number of effective pixels (H) × (V) 2048 x 2048
Optical Size 1/1 type
Scanning area (H) × (V)[mm] 11.26 × 11.26
Pixel size (H) × (V)[µm] 5.5 × 5.5
Scan method Progressive
Electronic shutter method Global shutter
Aspect ratio 1: 1
Standard subject illuminance 3500lx, F11, 1/90s
Minimum subject illuminance (*1) 7lx
Power supply DC +5V±5% (from USB connector)
Power consumption (*2) 2.6W (maximum)
Base clock frequency 48.000MHz±100ppm
Interface USB 3.0 (Only SuperSpeed is supported)
Transmission speed 5Gbps (maximum)
Protocol USB3 Vision
Cable length Up to 3.0 m
Image format Mono 8 bit
Number of Video out pixels (H) × (V)
2048 × 2048
Maximum Frame rate (*2) 90 fps
Dimensions 29 mm(W) x 29 mm (H) x 13 mm (D) (Not including protrusion)
Mass Approximately 32g
Lens mount C-mount
Flange back 17.526mm
Camera body grounding:
insulation status No conductive between circuit GND and camera body
*1 F1.4, Gain: Maximum (x8), video level: 50%
*2 at the all pixel readout

19 / 65 D4223121B
Copyright © 2013 TOSHIBA TELI CORPORATION, All rights reserved. www.toshiba-teli.co.jp
Notes on combination of C-mount lens:
- Depending on the lens you use, the performance of the camera may not be brought out fully due to the deterioration in
resolution and brightness in the peripheral area, occurrence of a ghost, aberration and others. When you check the
combination between the lens and camera, be sure to use the lens you actually use.
- In addition, use a mounting screw free from defects and dirt. Otherwise, the camera may be unable to be removed.
- As for the C-mount lens used combining this camera, the projection distance from bottom of the screw should use
10mm or less.
Notes on Dropping Frames:
Depends on your PC and USB3.0 interface card configurations, images may not be captured properly (e.g. dropping
frames). In this case, change frame rate setting lower.
