Toshiba LEV112320W827TE Manual

E-core LED Light Engine
Technical Information
Toshiba Lighting & Technology Corporation

1. Introduction
Toshiba terminated the production of general incandescent lamps in March, 2010. Our long history of
the incandescent lamp production started in 1890 ended. There was the background of the
innovational development of LED lighting as the 4th new light source. Energy-saving focused on the
LED lighting is highly expected as one of the effectiveness on reducing global warming.
LED lighting is greatly expected since it has more possibilities for free luminaires design and better
functions. LED is not solely high efficient, but also its electrical control is easier and glass covering is
no longer needed, compared with conventional lamps such as incandescent and fluorescent.
We have been working on the LED product development such as general LED lamps, exchangeable
LED light engines, lighting luminaires for indoor and outdoor.
The LED Light Engine (hereinafter called LLE) we are going to release has a totally different
structure, compared with conventional lamps and luminaires. Its biggest characteristics is that the
luminous output performance of the LLE is greatly improved by the heat release cycle from the
LLE to the luminaire. Plus, it is also advantage that we can choose variable light engines to
exchange. LLE development contributes to both new lighting development and more energy-saving.

2. Specifications
(1) 1100 lumens type
LEV112320W827TE
(1100 / 85D / 2700K)
LEV112320M827TE
(1100 / 45D / 2700K)
Lumen Output
1050 lm
Color Temperature
2700 K
CRI
80
Beam Angle
85 degrees
45 degrees
Input Voltage
220-240 V
Frequency
50-60 Hz
Power Factor
0.92
Dimming
Dimmable (Trailing edge)
Wattage
20 W
Life Time
40,000 hours
Efficacy
52.5 lm/W
Dimensions
90 - 42 mm
LEV112320W830TE
(1100 / 85D / 3000K)
LEV112320M830TE
(1100 / 45D / 3000K)
Lumen Output
1100 lm
Color Temperature
3000 K
CRI
80
Beam Angle
85 degrees
45 degrees
Input Voltage
220-240 V
Frequency
50-60 Hz
Power Factor
0.92
Dimming
Dimmable (Trailing edge)
Wattage
20 W
Life Time
40,000 hours
Efficacy
55.0 lm/W
Dimensions
90 - 42 mm

LEV112318W840TE
(1100 / 85D / 4000K)
LEV112318M840TE
(1100 / 45D / 4000K)
Lumen Output
1100 lm
Color Temperature
4000 K
CRI
80
Beam Angle
85 degrees
45 degrees
Input Voltage
220-240 V
Frequency
50-60 Hz
Power Factor
0.92
Dimming
Dimmable (Trailing edge)
Wattage
18 W
Life Time
40,000 hours
Efficacy
61.1 lm/W
Dimensions
90 - 42 mm
Note:
The specifications above are the values where the product is turned on the following conditions: the
input voltage:230V, base-up positioned, the ambient temperature:25 ℃, using the TLT standard
heat sink(Tcase:50℃), and at the initial (0 hour lighting time).

(2) 1600 lumens type
LEV162323W840TE
(1600 / 85D / 4000K)
LEV162323M840TE
(1600 / 45D / 4000K)
Lumen Output
1600 lm
Color Temperature
4000 K
CRI
80
Beam Angle
85 degrees
45 degrees
Input Voltage
220-240 V
Frequency
50-60 Hz
Power Factor
0.71
Dimming
Dimmable (Trailing edge)
Wattage
23 W
Life Time
40,000 hours
Efficacy
69.6 lm/W
Dimensions
90 - 42 mm
Note:
The specifications above are the values where the product is turned on the following conditions: the
input voltage:230V, base-up positioned, the ambient temperature:25 ℃, using the TLT standard
heat sink(Tcase:60℃), and at the initial (0 hour lighting time).

3. Dimensions
LED Light Engine LLE with Socket
Socket

4. Installation Manual
We show a procedure to install LED Light Engine in Socket.
(i)Make a direction △mark of LLE even with Mechanical Key (which there is between earthing
contact and no.4 contact)of the socket.
(ii)Fit LLE in the socket.
(iii)Turn it 15° in clockwise direction.
△mark
Contact 1
Contact 2
Contact 3
Contact 4
Earthing Contact
Mechanical Key

Socket moves about 0.5mm to the bottom of the figure. LLE is strongly attached to the heat sink by
the spring built-in the socket.
△mark
Mechanical Key
Earthling Contact
LLE is strongly attached to the heat sink
by the spring built-in the socket.
15°turn
Socket moves 0.5mm down.
To make the installation easier, we suggest to put a mark (like the △mark above) on the fixture
side.
△mark

5. Heat release design
(1)Case Temperature (Tcase) measurement method
We define Case Temperature (Tcase) that is the temperature of φ30mm of the cap center of LLE.
Some characteristics of LLE depend on Tcase.
And, tc defined by EN 62031 (rated maximum temperature) is evaluated the temperature at the
measurement area. In the LLE,
1100 lm type tc=65℃,
1600 lm type tc=75℃,
Tcase shall be measured with a thermocouple. By making a hole etc., avoid the attachment part with
a thermocouple being apart from heat sink.
Tcase measurement point(φ30)

(2)Heat release design for fixtures
To use the LED light engine safely and to exploit the product specification such as luminous output
and life time, heat release design for fixtures is very important. That is why heat sink shall be
attached to the socket side of the LED light engine.
The heat sink design in this case can be reduced as long as the Tc remains under 65 ℃(1100 lm type),
75℃(1600 lm type).
This LED light engine has been designed to meet the rated luminous output and light maintenance
at the Tcase=50℃(1100 lm type),Tcase=60℃(1600 lm type). In normal operating (for instance,
ambient temperature 25℃, rated voltage input), we recommend to use a heat sink which Tcase
become 50℃or 60℃.
(3)TLT standard heat sink
Here, we show TLT standard heat sink. TLT standard heat sink has a hole(φ15) in the center for
temperature measurement use.
Material ADC12
Surface Treatment: Black alumite treated
LLE installation side
15(hole for Tcase
measurement)
Socket installation
hole(P.C.D. 80)

(4)Heat releases silicon sheet
The attached sheet on the base cap is heat release silicon sheet. This sheet has appropriate
elasticity(thickness:0.5mm), which fill in the space between the light engine and heat sink, and
greatly help heat release cycle from the light engine to heat sink.
The heat release silicon sheet never shall be taken off.
Heat release silicon sheet

6. Characteristics
(1)Use condition
Power supply
220-240V (±6%)
Ambient temperature for fixture
5～35℃
Case temperature (Tcase)
65℃or less (1100 lm Type)
75℃or less (1600 lm Type)
Relative humidity
85% or less
(2)Temperature characteristics
The values above are the relation of case temperature (Tcase) and engine’s specification where the
product is turned on the following conditions: the input voltage is 230V , base-up positioned.
90%
95%
100%
105%
110%
30 35 40 45 50 55 60 65
Relative Data
Case Temperature [℃]
Lumen
Current
Wattage
(3)Optical characteristics
The optical curve is the one where the input voltage is 230V, base-up positioned, ambient
temperature is 25℃, and TLT standard heat sink is used (Tcase=50℃).

Wide beam angle type
Middle beam angle type
Luminous Intensity (cd/1000 lm)
Luminous Intensity (cd/1000 lm)
Luminous Intensity (cd/1000 lm)
Luminous Intensity (cd/1000 lm)

(4)Dimming characteristics
By applying trailing edge dimmer, 10-100% dimming is possible.
Leading-edge dimmer cannot be used.

7. Wiring diagram
L
N
Terminal 1 2
3
4
Earthing
Terminal
Pin 1 Pin 2
Terminal
Pin
Use
1
1
N - Power Line
2
2
L- Power Line
3
---
Dimming Line (no connection)
4
---
Dimming Line (no connection)
5
---
Earthing (no connection)

8. Applicable standards/regulations
(1)Safety
EN 62031 :2008
Classification Built-in module
Glow-wire test 850℃pass
EN 62471 :2008
Exempt Group
LEV112320W827TE
LEV112320M827TE
LEV112320W830TE
LEV112320M830TE
Risk Group 1 (Low-Risk)
LEV112318W840TE
LEV112318M840TE
LEV162323W840TE
LEV162323M840TE
Others
Non-waterproof structure
Overvoltage category II, Pollution level 2
(2)EMC
EN 55015 :2006 + A1 :2007 + A2 :2009
EN 61000-3-2 :2006 + A1 :2009 + A2 :2009
EN 61000-3-3 :2008
EN 61547 :2009
(3)Environment
2002/96/EC (WEEE)
2002/95/EC (RoHS)
(EC) No 1907/2006(REACH)
2006/122/EC (PFOS)

(Appendix) Socket specification
(1)Dimensions
(2)Part number and name on BJB
BJB part no.
Part name
28.301.1001
GH76p-1 Socket (100VAC-120VAC)
28.301.1002
GH76p-2 Socket (220VAC-277VAC)
(3)Certification
Safety Test* :Already applied
(*Equivalent test level with Japanese Electrical Appliances and Material Safety Act)
VDE :Planned to apply
cURus :Planned to apply

(4)Ratings
BJB part no.
Rated voltage
Rated current
Rated temp
28.301.1001
120VAC
2A
100℃
28.301.1002
250VAC
2A
100℃
(5)Applicable wires
Single wire :0.8 mm - 1.0 mm in diameter
Bonded wire :0.5 mm2 - 0.75 mm2
Stranded wire :0.5 mm2 - 0.75 mm2(Solder finish)
Strip line :8-9 mm
(6)注意事項
a) 3 pieces of M3 screw are attached with the socket. Please do not use any other screw, other
than the attached M3 screw.
b) Tighten the screw till the screw head reaches the installation side.
c) Regarding the pitch of the screws, please refer to the attached drawing.
d) Screw holes for the M3 screws shall be not sharp and shall have no burr.
e) When installing LLE, turn it 15°in clockwise direction. When removing LLE, turn it 15°in
anticlockwise direction.
f) Please follow the specification for LED chips manufacturer as well.
g) After stripping a wire, insert it straight, being careful at not hurting the wire covering.
h) Part selection and fixture design shall be implemented and the final product quality shall be
managed in charge of your company.
