Lightolier QVH1GPFOS2FT User manual

Mounting MethodS / Features Dimensions
Job Information Type:
Job Name:
Cat. No.:
Lamp(s):
Volts/Ballast:
Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] • Fax [phone]
631 Airport Road, Fall River, MA 02720 • [phone] • Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902 Section 5 / Folio L85-15
Features
• Efficiency 47.5%.
• Shallow plenum depth.
• Swing down microperforated lamp shields for easy relamping and
maintenance.
• Alter soft white film on inside of mesh conceals lamp image and
provide balance between reflected light and direct light.
• 95% Reflective Alter soft white paint finish.
• One piece body for easy installation.
• Easy access to ballast through lamp compartment.
• Fits standard T-Grid ceilings.
12"
(305mm)
3-9/16"
(90mm)
ACCESS PLATE
(2) 7/8" K.O.'S
5-15/16"
(150mm)
23-15/16"
(608mm)
47-13/16"
(1215mm)
11-13/16"
(300mm)
BALLAST
ALTER SOFT LIGHTS QVH1GPFOS2FT 2X40W
Page 1 of 2 1'x4' SLIM SEMI-RECESSED DIRECT/INDIRECT FLUORESCENT, 2 LAMP, TT5 BI-TUBE
3 9/16’’ RECESSED DEPTH CEILING, MICROPERFORATED MESH LAMP SHIELD, STATIC
Ceiling compatibility
Microperforated mesh
lamp shields
Swing down optical system for
easy relamping and maintenance
Suited to standard exposed
T-grid ceilings
Suited to standard exposed
Slot T-grid ceilings

Lightolier a Genlyte Thomas Company www.lightolier.com
Technical Information: [phone] •Fax [phone]
631 Airport Road, Fall River, MA 02720 •[phone] •Fax [phone]
We reserve the right to change details of design, materials and finish.
© 2002 Genlyte Thomas Group LLC (Lightolier Division)
A0902 Section 5 / Folio L85-15
Job Information Type:
Specifications
MATERIALS: One piece chassis constructed from die formed 20 gauge cold
rolled steel. Reflectors - 95% reflectance baked white acrylic matte paint finish.
Soft white acrylic film on inside of lamp shield conceals lamp image.
FINISH: Chassis exterior - phosphate undercoating, baked white acrylic matte
high reflectance paint finish.
ELECTRICAL: Rapid start HPF, thermally protected class “P”ballast (Bi-tube
type). If K.Os are within 3”of ballast use wire suitable for at least 90C.
LABELS: Listed by
Photometry
Ordering Information
Explanation of Catalog Number. Example: QVH1GPFOS2FT120SB
ALTER SOFT LIGHTS QVH1GPFOS2FT 2X40W
Page 2 of 2 1'x4' SLIM SEMI-RECESSED DIRECT/INDIRECT FLUORESCENT, 2 LAMP, TT5 BI-TUBE
3 9/16’’ RECESSED DEPTH CEILING, MICROPERFORATED MESH LAMP SHIELD, STATIC
QUALITY
VISUAL
STATIC
QVH- Slim Semi-Recessed
FIXTURE
WIDTH:
1’
CEILING TYPE:
G=Standard exposed
T-grid ceilings
LAMP SHIELD:
PF = Microperforated
LAMP
QUANTITY
LAMP/FIXTURE
LENGTH:
(NOMINAL 24”)
FT = TT5
Bi-Tube
VOLTAGE:
120V
277V
347V
BALLAST:
BE = 50W Electronic TT5 RS
BR = 40W Electronic TT5 RS
BX = 40W Magnetic TT5 RS
PB = 40W TT5 PowerSpec Dimming*
PC = 50/55W TT5 PowerSpec Dimming*
SB = 40W Generic Electronic TT5
*Not available in 347V.
OPTIONS:
F = Internal Fusing (consult
factory)
N = Emergency lighting
System (for U.S.)
O = Emergency Lighting System
(for Canada)
R = Radio Interference Flter
QVH 1 G PF OS 2FT
SHIELD DETAILING:
OS = Open slot (no acrylic)
