Toshiba ML-EC42S(SS) User manual

ML-EC42S(SS)
Microwave Oven
INSTRUCTION MANUAL
Model:
Read these instructions carefully before using your
microwave oven, and keep it carefully.
If you follow the instructions, your oven will provide you
with many years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY
20180116c1_ER-SM20_MY.indd 1 2018/01/16 14:41:25
English

20180116c1_ER-SM20_MY.indd 2 2018/01/16 14:41:25

English
1
CONTENTS
CONTENTS .................................................................................................................................... 1
PRECAUTIONS.............................................................................................................................. 2
SPECIFICATIONS.......................................................................................................................... 2
IMPORTANT SAFETY INSTRUCTIONS............................................................................... 3-4
CLEANING ..................................................................................................................................... 5
UTENSILS ................................................................................................................................... 5-6
SET UP & INSTALLATION...................................................................................................... 7-8
CONTROL PANEL ........................................................................................................................ 9
OPERATION
MICROWAVE COOKING.........................................................................................................................................................10
CLOCK SETTING....................................................................................................................................................................... 10
GRILL & COMBINATION COOKING.....................................................................................................................................11
REHEAT FUNCTION........................................................................................................................................................11-12
CONVECTION COOKING .......................................................................................................................................................12
HOME FRY COOKING .............................................................................................................................................................13
DEFROST BY TIME....................................................................................................................................................................13
DEFROST BY WEIGHT..............................................................................................................................................................13
DEFROST GROUND MEAT.....................................................................................................................................................13
DEFROST SEA FOOD................................................................................................................................................................14
PRE-SET FUNCTION.................................................................................................................................................................14
MEMORY FUNCTION............................................................................................................................................................... 16
MULTI-STAGE COOKING........................................................................................................................................................16
EXPRESS COOKING..................................................................................................................................................................17
TROUBLE SHOOTING................................................................................................................18
LOCK FUNCTION FOR CHILDREN....................................................................................................................................... 17
COOKING END REMINDING FUNCTION........................................................................................................................... 1
INQUIRING FUNCTION..........................................................................................................................................................17
DISPLAY SPECIFICATION....................................................................................................................................................... 1
AUTO MENU COOKING..................................................................................................................................................14-16
.......................................................................................................................... 17 TURNTALE RESET FUNCTION ....................
8
8

C42S(SS)
2
PRECAUTIONS
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY
(a) Do not attempt to operate this oven with the door open since this can result in harmful
exposure to microwave energy. It is important not to break or tamper with the safety
interlocks.
(b)Do not place any object between the oven front face and the door or allow cleaner
residue to accumulate on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the oven must not be operated until it
has been repaired by a competent person.
ADDENDUM
If the apparatus is not maintained in a good state of cleanliness, its surface could be degraded
and affect the life span of the apparatus and lead to a dangerous situation.
SPECIFICATIONS
Model: ML-E
Rated Voltage: 230V~50Hz
Power Consumption (Microwave): 1550W
Rated Output Power (Microwave): 1000W
Rated Input(Grill): 1 00W
Rated Input(Convection): 2 00W
Oven Capacity: 42L
Turntable Diameter: Φ 345mm
Outside Dimensions (W x D x H): 553x470x326 mm
Net Weight: Approx. 21.3kg
3
7
.1

English
3
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electric shock, injury to persons or exposure to excessive microwave oven energy when
using your appliance, follow basic precautions, including the following:
1. Read and follow the specific: “PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY”.
2. This appliance can be used by children and persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user
maintenance shall not be made by children unless they are supervised.
3. Keep the appliance and its cord away from children unless they are continuously supervised.
4. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
5. WARNING: Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of electric
shock.
6. WARNING: It is hazardous for anyone other than a competent person to carry out any service or repair operation
that involves the removal of a cover which gives protection against exposure to microwave energy.
7. WARNING: Liquids and other foods must not be heated in sealed containers since they are liable to explode.
8. When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.
9. Only use utensils that are suitable for use in microwave ovens.
10. If smoke is emitted, switch off or unplug the appliance and keep the door closed in order to stifle any flames.
11. Microwave heating of beverages can result in delayed eruptive boiling, therefore care must be taken when
handling the container.
12. The contents of feeding bottles and baby food jars shall be stirred or shaken and the temperature checked
before consumption, in order to avoid burns.
13. Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they may explode,
even after microwave heating has ended.
14. The oven should be cleaned regularly and any food deposits removed.
15. Failure to maintain the oven in a clean condition could lead to deterioration of the surface that could adversely
affect the life of the appliance and possibly result in a hazardous situation.
16. Only use the temperature probe recommended for this oven.(for ovens provided with a facility to use a
temperature-sensing probe.)
17. The microwave oven shall not be placed in a cabinet unless it has been tested in a cabinet.
18. This appliance is intended to be used in household and similar applications such as:
-staff kitchen areas in shops, offices and other working environments;
-by clients in hotels, motels and other residential type environments;
-farm houses;
-bed and breakfast type environments.
19. The microwave oven is intended for heating food and beverages. Drying of food or clothing and heating of
warming pads, slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or fire.
20. Metallic containers for food and beverages are not allowed during microwave cooking.
21. The appliance shall not be cleaned with a steam cleaner.

4
22. The appliance is intended to be used freestanding.
23. The rear surface of appliances shall be placed against a wall.
24. The appliances are not intended to be operated by means of an external timer or separate remote-control system.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
To Reduce the Risk of Injury to Persons
Grounding Installation
DANGER
Electric Shock Hazard
Touching some of the internal components can cause serious personal injury or death. Do not disassemble this
appliance.
WARNING
Electric Shock Hazard
Improper use of the grounding can result in electric shock.
Do not plug into an outlet until appliance is properly installed and grounded.
This appliance must be grounded. In the event of an electrical short circuit, grounding reduces the risk of electric
shock by providing an escape wire for the electric current.
This appliance is equipped with a cord having a grounding wire with a grounding plug. The plug must be plugged
into an outlet that is properly installed and grounded.
Consult a qualified electrician or serviceman if the grounding instructions are not completely understood or if doubt
exists as to whether the appliance is properly grounded.
If it is necessary to use an extension cord, use only a 3-wire extension cord.
1. A short power-supply cord is provided to reduce the risks resulting from becoming entangled in or tripping over
a longer cord.
2. If a long cord set or extension cord is used:
1) The marked electrical rating of the cord set or extension cord should be at least as great as the electrical rating
of the appliance.
2) The extension cord must be a grounding-type 3-wire cord.
3) The long cord should be arranged so that it will not drape over the counter top or tabletop where it can be
pulled on by children or tripped over unintentionally.

English
5
CLEANING
Be sure to unplug the appliance from the power supply.
1. Clean the cavity of the oven after using with a slightly damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighboring parts must be cleaned carefully with a damp
cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers to clean the oven door glass
since they can scratch the surface, which may result in shattering of the glass.
5. Cleaning Tip---For easier cleaning of the cavity walls that the food cooked can touch:
Place half a lemon in a bowl, add 300ml (1/2 pint) water and heat on 100% microwave
power for 10 minutes. Wipe the oven clean using a soft, dry cloth.
UTENSILS
CAUTION
Personal Injury Hazard
It is hazardous for anyone other than a competent person to carry out any service or repair
operation that involves the removal of a cover which gives protection against exposure to
microwave energy.
See the instructions on “Materials you can use in microwave oven or to be avoided in
microwave oven.” There may be certain non-metallic utensils that are not safe to use for
microwaving. If in doubt, you can test the utensil in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water (250ml) along with the utensil in
question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.

6
Materials you can use in microwave oven
Utensils Remarks
Browning dish Follow manufacturer’s instructions. The bottom of browning dish must be at least 3/16
inch (5mm) above the turntable. Incorrect usage may cause the turntable to break.
Dinnerware Microwave-safe only. Follow manufacturer’s instructions. Do not use cracked or chipped
dishes.
Glass jars Always remove lid. Use only to heat food until just warm. Most glass jars are not heat
resistant and may break.
Glassware Heat-resistant oven glassware only. Make sure there is no metallic trim. Do not use
cracked or chipped dishes.
Oven cooking bags Follow manufacturer’s instructions. Do not close with metal tie. Make slits to allow
steam to escape.
Paper plates and cups Use for short–term cooking/warming only. Do not leave oven unattended while cooking.
Paper towels Use to cover food for reheating and absorbing fat. Use with supervision for a short-term
cooking only.
Parchment paper Use as a cover to prevent splattering or a wrap for steaming.
Plastic Microwave-safe only. Follow the manufacturer’s instructions. Should be labeled
“Microwave Safe”. Some plastic containers soften, as the food inside gets hot. “Boiling
bags” and tightly closed plastic bags should be slit, pierced or vented as directed by
package.
Plastic wrap Microwave-safe only. Use to cover food during cooking to retain moisture. Do not allow
plastic wrap to touch food.
Wax paper Use as a cover to prevent splattering and retain moisture.
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray May cause arcing. Transfer food into microwave-safe dish.
Food carton with metal handle May cause arcing. Transfer food into microwave-safe dish.
Metal or metal-trimmed utensils Metal shields the food from microwave energy. Metal trim may cause arcing.
Metal twist ties May cause arcing and could cause a fire in the oven.
Paper bags May cause a fire in the oven.
Plastic foam Plastic foam may melt or contaminate the liquid inside when exposed to
high temperature.
Wood Wood will dry out when used in the microwave oven and may split or crack.

English
7
SET UP & INSTALLATION
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Turntable Shaft 1
Grill Rack 1
Instruction Manual 1
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
Grill Rack (Can not be used in
microwave function
and must be placed
on the glass tray)
B CD
E
G
F
A
Turntable Installation a. Never place the glass tray upside down.
Follow the instruction to place the glass
tray on the turntable ring with correct
direction. The glass tray should rotate
smoothly.
b. Both glass tray and turntable ring
assembly must always be used during
cooking.
c. All food and containers of food are
always placed on the glass tray for
cooking.
d. If glass tray or turntable ring assembly
cracks or breaks, contact your nearest
authorized service center.
Turntable
shaft
Turntable ring
assembly
Glass tray
Hub (underside)

8
Countertop Installation
Remove all packing material and accessories. Examine the oven for any damage such as
dents or broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface.
Do not remove the light brown Mica cover that is attached to the oven cavity to protect the
magnetron.
Installation
1. Select a level surface that provide enough open space for the intake and/or outlet vents.
20cm
min85cm
20cm
30cm
0cm
(1) The minimum installation height is 85cm.
(2) The rear surface of appliance shall be placed against a wall.
Leave a minimum clearance of 30cm above the oven, a minimum clearance of 20cm
is required between the oven and any adjacent walls.
(3) Do not remove the legs from the bottom of the oven.
(4) Blocking the intake and/ or outlet openings can damage the oven.
(5) Place the oven as far away from radios and TV as possible. Operation of microwave
oven may cause interference to your radio or TV reception.
2. Plug your oven into a standard household outlet. Be sure the voltage and the frequency
is the same as the voltage and the frequency on the rating label.
WARNING: Do not install oven over a range cooktop or other heat-producing appliance.
If installed near or over a heat source, the oven could be damaged and the
warranty would be void.
The accessible surface may be hot during operation.
Side Distance
(cm)
Top 30
Left 20
Right 20
Front Open
Rear 0
Bottom 0

English
9
CONTROL PANEL
1. DIGITAL DISPLAY
2. Micro.
Press to select Microwave power level
3. Grill/Combi
For Grill Cooking & Combination
Cooking
(Microwave+Grill)
4. Conv.
For Convection Cooking
5. Home Fry
For Home Fry Cooking
6. Auto Menu
Vegetable
Fish
Meat
Pasta
Potato
Soup
Roast
Bread
Cake
Pizza
7. START/+30Sec.
For starting cooking or adding cooking
time of 30sec. by every press.
8. STOP/Cancel
9. Reheat
Press to select reheating mode.
10. Clock/Pre-set
Press to set Clock and Pre-set.
11. Memory
Press to set specific cooking mode
memory.
12. Defrost
Press to set defrost mode.
1
3
4
5
6
7
8
11
12
2
6
9
10

10
OPERATION
When the microwave oven is electrified, the oven will display"0:00", buzzer will ring once.
The input time should be within 0:00--23:59(24 Hour) or 0:00--12:59(12 Hour).
(1) Press " Clock/ Pre-set" once, buzzer will ring once and "24H" displays.
(2) Press " Clock/ Pre-set" repeatedly to choose 24H or 12H system.
(3) Press the number buttons to set clock.
(4) Press " Clock/ Pre-set" to finish clock setting. ":" will flash, and the time will light.
Note: 1) If the clock is not set, it would not function when powered.
2) During the process of clock setting, if you press "STOP/Cancel", the oven
will go back to the previous status automatically.
Presses
Instructions Display Microwave
Power
1
2
3
4
5
P100
P80
P50
P30
P10
100%
80%
50%
30%
10%
CLOCK SETTING
MICROWAVE COOKING
Select different microwave power level and set cooking time as you wish. There are five
power levels available for choosing. Keep on pressing "Micro." to choose the power.
Example: If you want to use 80% microwave power to cook for 10 minutes, you can
operate the oven as the following steps.
(1) Press "Micro." once, the oven will display "P100".
(2) Press "Micro." once again to choose 80% power, the oven will display "P80".
(3) Press the number buttons of "1","0","0","0" in order, the oven will display "10:00".
(4) Press "START/+30Sec." to start cooking, ":" will light.
Note: "Micro." Pad presses instructions

English
11
Example: If you want to use grill to cooking for 35 minutes, you can operate
the oven as the following steps.
(1) Press the "Grill/Combi" key once, the oven will display "G-1".
(2) Press the number buttons of "3","5","0","0" in order, the oven will display "35:00"
(3) Press the "START/+30Sec." key to start cooking.
Note: If half the grill time passes, the oven sounds twice, and this is normal. In order
to have a better effect of grilling food, you should trun the food over, close
the door, and then press "START/+30Sec." to continue cooking.
If no operation, the oven will continue working.
Example: If you want to use combination to cook (C-1) for 40 minutes, you can
operate the oven as per the following steps.
(1) Press the "Grill/Combi" key twice, the oven will display "C-1".
(2) Press the number buttons of "4","0","0","0" in order, the oven will display "40:00".
(3) Press the "START/+30Sec." key to start cooking.
Note: "Grill/Combi" Pad presses instructions
Presses
Instructions Display Microwave
Power
Grill
Power
Covenction
Power
1
2
3
4
5
G-1
C-1
C-2
C-3
C-4
GRILL COOKING
COMBINATION COOKING
(1) Press "Reheat" pad once, the "h-1" will display and flash.
(Press the "Reheat" pad several times to select the cooking program you wanted.)
(2) Press "START/+30Sec." key to confirm, the "h-1" will display.
(3) Press "Reheat" pad, the oven will display "150".
(Press the "Reheat" pad several times to selecct the weight of the cooking food.)
(4) Press "START/+30Sec." key to start cooking.
REHEAT FUNCTION
GRILL & COMBINATION COOKING

12
CONVECTION COOKING
Reheat Chart
Menu
h-1
(Auto Reheat)
h-2
(Dinner Plate)
h-3
(Coffee)
h-4
(Roll)
Weight(g) Display
150
250
350
450
600
250
350
450
1 cup(approximately 240g)
2 cups(approximately 480g)
3 cups(approximately 720g)
1 (approximately 70g)
2 (approximately 140g)
3 (approximately 210g)
150
250
350
450
600
250
350
450
1
2
3
1
2
3
With preheating function
The convection cooking can let you to cook the food as a traditional oven. Microwave
is not used. It is recommended that you should preheat the oven to the appropriate
temperature before placing the food in the oven.
(1) Press the "Conv." key once, the oven will display "140".
(Press the "Conv." key several times to select the temperature.)
Convection temperature is from 140 degrees to 230 degrees.
(2) Press the "START/+30Sec." key to start preheating. The temperature figure will flash
when reach to the temperature in advance and buzzer will ring twice to remind you
to put the food into the oven.
(3) Press the number buttons of "4","0","0","0" in order, the oven will display "40:00"
(4) Press the "START/+30Sec." key to start cooking.
Note: a. Cooking time cannot be input until the preheating temperature arrives.
If the temperature arrives, door must be opened to input the cooking time.
b. If the time not input in 5 minutes, the oven will stop preheating. The buzzer
sound five times and turn back to waiting state.
Without preheating function
(1) Press the "Conv." key once, the oven will display "140".
(Press the "Conv." key several times to select the temperature.)
Convection temperature is from 140 degrees to 230 degrees.
(2) Press the number buttons of "4","0","0","0" in order, the oven will display "40:00"
(3) Press the "START/+30Sec." key to start cooking.

English
13
HOME FRY COOKING
(1) Press "Home Fry" pad once, the "F1" will display in oven.
(Press the "Home Fry" pad several times to select the cooking program you wanted.)
(2) Press "START/+30Sec." key to start preheating.
(3) When the preheating temperature arrives, the buzzer will ring twice to remind you to
put the food into the oven.
(4) Press "START/+30Sec." key to start cooking.
Note: When you choose Home Fry function, please do not put the food into the
oven at thebegining. The oven needs to be preheated first. After several minutes,
the buzzer sounds
twice to remind you to put the food into the oven. After putting
the food in the oven, please press "START/+30Sec." again. The timer will count down,
and the food will be cooked
perfectly.
Menu
Display Weight(g)
Frozen French fries
Frozen Potato croquettes
Frozen Squicd
Frozen Onion rings
Frozen Chicken nuggets
Escalope
Shrimps
Vegetable
Spring Rolls
F1
F2
F3
F4
F5
F6
F7
F8
F9
300g
300g
200g
250g
400g
300g
200g
120g
300g
DEFROST BY TIME
(1) Press "Defrost" pad once, the oven will display "d-1".
(2) Input the figure of the time of cooking.
(The maximum cooking time is 99 minutes and 99 seconds.)
(3) Press "START/+30Sec." key to start defrosting.
DEFROST BY WEIGHT
(1) Press "Defrost" pad twice, the oven will display "d-2".
(2) Input the figure of the weight of food.
(The input figure of the weight should be within 100--2000g.)
(3) Press "START/+30Sec." key to start defrosting.
DEFROST GROUND MEAT
(1) Press "Defrost" pad thrice, the oven will display "d-3".
(2) Input the figure of the weight of food.
(The input figure of the weight should be within 100--2000g.)
(3) Press "START/+30Sec." key to start defrosting.

(1) Press "Defrost" pad 4 times, the oven will display "d-4".
(2) Input the figure of the weight of food.
(The input figure of the weight should be within 100--2000g.)
(3) Press "START/+30Sec." key to start defrosting.
PRE-SET FUNCTION
(1) Set the clock first. (Consult the instruction of clock setting.)
(2) Input the cooking program. Two stages can be set at most. Defrosting should
not be set in pre-set function.
After setting cooking program, please do not press "START/+30Sec.". Then do as
following:
(3) Press "Clock/Pre-set". "0:00" will display.
(4) Press the number buttons to set pre-set time.
(5) Press "START/+30Sec." to finish setting. ":" will light, buzzer will ring twice
when the time arrives, then cooking will start automatically.
Note: clock must be set first. Otherwise, pre-set function will not work.
AUTO MENU COOKING
The numeral pads 0--9 are matching with ten different subjects respectively.
Pad
1
2
3
Cook
Vegetable
Fish
Meat
Pad
4
5
6
Cook
Pasta
Potato
Soup
Pad
7
8
9
Cook
Roast
Bread
Cake
Pad
0
Cook
Pizza
Example: Cooking vegetable of 350g:
(1) Press "Vegetable" button.
(2) Press "Vegetable" button again to choose weight, oven will display "350".
(3) Press "START/+30Sec." to start cooking.
DEFROST SEA FOOD
14

English
Meat
Auto Menu Chart
Menu Weight Press Times Display
Vegetable
Fish
Pasta
Potato
Soup
Roast
Bread
Cake
Pizza
150g(with water 30g)
350g(with water 60g)
500g(with water 120g)
150g
250g
350g
450g
650g
150g
300g
450g
600g
50g(with cold water 450g)
100g(with cold water 800g)
150g(with cold water 1200g)
1(approximately 230g)
2(approximately 460g)
3(approximately 690g)
200ml
400ml
600ml
500g
750g
1000g
1200g
50g
100g
150g
475g
200g
300g
400g
Once
Twice
Thrice
Thrice
Thrice
Thrice
Thrice
Thrice
Thrice
Thrice
Thrice
Once
Once
Once
Once
Once
Once
Once
Once
Once
Twice
Twice
Twice
Twice
Twice
Twice
Twice
Twice
4 times
5 times
4 times
4 times
150
350
500
150
250
350
450
650
150
300
450
600
50
100
150
1
2
3
200
400
600
500
750
1000
1200
50
100
150
475
200
300
400 15

Note: When you choose cake, please do not put the cake into the oven at the begining.
The oven needs to be preheated to 180 degree first. After several minutes, the buzzer
sounds twice to remind you to put the cabe into the oven. After putting the cake in the
oven, please press "START/+30Sec." again. The timer will count down, and the cake
If you choose roast, cake or pizza, you should place the food on the grill rack at a
height of 40mm.
If you choose roast, it's only for roasting chicken.
(1) Press "Memory" to choose memory 1-3 procedure. The screen will display 1,2,3.
(2) If the procedure has been set, press " START/+30Sec." to use it. If not, continue to
set the procedure. Only one or two stages can be set.
(3) After finishing the setting, prese "Memory" to save the prcedure and turn back to
the waiting state. If press "START/+30Sec.", the oven will save the procedure and
start it.
Note: 1) If the electricity is cut off, the procedure that has been saved will be cancelled.
2) Defrosting, preheating and auto menu cannot be set as memory procedure.
Two stages of cooking can be maximumly set. If one of the stages is defrosting, it will be
put in the first stage automatically, and auto menu should not be set here. The buzzer
will ring once after each stage and the next stage will begin.
Example: If you want to cook the food with 100% microwave power for 10 minutes +
80% microwave power for 15 minutes. Do it as following:
(1) Press "Micro." once to choose 100% microwave power.
(2) Press number keys "1","0","0","0" in order to adjust the cooking time.
(3) Press "Micro." twice to choose 80% microwave power.
(4) Press number keys "1","5","0","0" in order to adjust the cooking time.
(5) Press "START/+30Sec." to start cooking.
MEMORY FUNCTION
MULTI-STAGE COOKING
6
1
will be cooked perfectly.

English
LOCK FUNCTION FOR CHILDREN
Lock: In waiting state or 10 minutes passes after the end of auto menu cooking,
will light. The oven will display "0:00" or current time.
Lock quitting: In children-lock state, opend the door and a key indicator will go out
INQUIRING FUNCTION
(1) In cooking state, press “Grill/Combi”, "Micro.", or "Conv.", and the current power will
be displayed for 2~3 seconds.
(2) In pre-set state, press "Clock/Pre-set" to inquire the time for delay start cooking.
The pre-set time will flash for 2~3 seconds, then the oven will turn back to the
clock display.
(3) During cooking state, press "Clock/Pre-set" to check the current time. It will be
displayed for 2~3 seconds.
EXPRESS COOKING
When the oven is in the waiting state, press "START/+30Sec." key to start cooking with
When the oven is in the microwave, griill, convection and combination cooking states,
START/+30Sec." key to add 30 seconds cooking time.(in the Weight Defrosting,
Multi-stage Cooking or Auto Menu state is invalid.
Note:
(1) After the door-lock function is activated, pressing any keys the screen will display "door" for 3
seconds. Only the oven quits the door-lock state can the cooking procedure work.
(2) When the oven is electrified with the door is close, the oven will enter the children-lock state
automatically.
if there is no operation within 1 minute, the oven will enter into the children-lock
state and a key indicator
At this time, the lamp, fan and turntable are
reset, the
Note:
1. This function only works for one completed cooking. If pause or open the
2. Under the reset state, opening the door or " " button is
the current cooking cannot enter the turntable reset function.
waiting state.
STOP/CANCEL
oven stops cooking and reminds cooking finished.
table reset function, in waiting state press number key "5" for 3
TURNTABLE RESET FUNCTION
the turntable reset function.
working, " " will dynamic display. After the turntable has
1. When cooking finished, if the turntable is not at the initial position, it will enter
2. In waitng state, press number key "5" for 3 seconds, there will be a long "beep" denoting turntable reset
function is turnned off. To turn on the turn
seconds, there will be a long "beep" denoting that turntable reset function is released.
oven door during cooking,
pressed, the oven will go back to
17
denoting that the lock is released.
press "
time for 30 seconds.(the maximum setting is 99 minutes and 99 seconds.)
full microwave power for 30 seconds. Each press the same key can increase the cooking

TROUBLE SHOOTING
Normal
Microwave oven interfering TV
reception
Radio and TV reception may be interfered when microwave oven operating.
It is similar to the interference of small electrical appliance, like mixer, vacuum
cleaner, and electric fan.
It is normal.
Dim oven light In low power microwave cooking, oven light may become dim. It is normal.
Steam accumulating on door, hot
air out of vents
In cooking, steam may come out of food. Most will get out from vents. But
some may accumulate on cool place like oven door. It is normal.
Oven started accidentally with no
food in.
It is forbidden to run the until without any food inside. It is very dangerous.
Trouble Possible Cause Remedy
Oven can not be started.
(1) Power cord not plugged in
tightly.
Unplug. Then plug again after 10
seconds.
(2) Fuse blowing or circuit breaker
works.
Replace fuse or reset circuit breaker
(repaired by professional personnel
of our company)
(3) Trouble with outlet. Test outlet with other electrical
appliances.
Oven does not heat. (4) Door not closed well. Close door well.
18
COOKING END REMINDING FUNCTION
When the cooking is over, the buzzer will sound 5 “beep” to alert user the
cooking is finished.
DISPLAY SPECIFICATION
(1) In waiting state, the oven will display clock and ":" will flash.
(2) In function setting state, the oven will display the related setting.
(3) In the operation and suspending state, the oven will display the residual cooking time.
(4) Once the cooking programme has been set, "START/+30Sec." is not pressed in
5 minutes. The current time will be displayed. The setting will be cancelled.
PN:16170000A72607
