TDP-P9
DATA PROJECTOR
OWNER’S MANUAL

2
Before using
SAFETY PRECAUTIONS
MODEL NAME: TDP-P9!
FCC NOTICE:This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful interference to radio
communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence of uninsulated "dangerous voltage"
within the product's enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH
VOLTAGES ARE PRESENT INSIDE THE ENCLOSURE. DO NOT OPEN THE
CABINET. REFER SERVICING TO QUALIFIED PERSONNEL ONLY.
WARNING: Handling the cord on this product or cords associated with accessories sold
with this product, will expose you to lead, a chemical known to the State of
California to cause birth defects or other reproductive harm. Wash hands
after handling.
WARNING: Lamp contains mercury. Disposal of this product may be regulated due to
environmental considerations. For disposal, reuse or recycling information, please
contact your local government or the Electronic Industries Alliance at www.eiae.org.
TRADE NAME: DATA PROJECTOR MODEL NAME: TDP-P9
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
USA ONLY
USA ONLY
USA ONLY

3
Before Using
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
RESPONSIBLE PARTY: TOSHIBA AMERICA INFORMATION SYSTEMS, INC.
9740 Irvine Blvd., Irvine, CA 92618-1697 U.S.A
Phone: [phone]
WARNING: Changes or modifications made to this equipment, not expressly approved by
Toshiba, or parties authorized by Toshiba, could void the user’s authority to
operate the equipment.
Notice: This Class B digital apparatus complies with Canadian ICES-003. Cet appareil
numérique de la classe B est conforme à la norme NMB-003 du Canada.
USA ONLY
CANADA ONLY

4
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUCTIONS
GIVEN IN THIS OWNER'S MANUAL AND THOSE MARKED ON THE UNIT.
RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
This unit is fully transistorized and does not contain any parts that can be repaired by the
user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO DANGER-
OUS VOLTAGE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL ONLY.
1. Read Owner's Manual
After unpacking this product, read the
owner's manual carefully, and follow all
the operating and other instructions.
3. Source of Light
Do not look into the lens while the lamp is
on. The strong light from the lamp may
cause damage to your eyesight.
2. Power Sources
This product should be operated only
from the type of power source which
does not exceed the voltage range
specified on the rating label and the
power cord. If you are not sure of the
type of power supply to your home,
consult your product dealer or local
power company.
4. Ventilation
Openings in the cabinet are provided for
ventilation and to ensure reliable operation
of the product and to protect it from
overheating, and these openings must not
be blocked or covered. The openings
should never be blocked by placing the
product on a bed, sofa, rug or other similar
surface. This product should not be placed
in a built-in installation such as a
bookcase or rack unless proper ventilation
is provided.

5
Before Using
5. Heat
The product should be situated away
from heat sources such as radiators,
heat registers, stoves, or other
products (including amplifiers) that
produce heat.
8. Be sure that you firmly insert
the plug into the wall outlet.
Incorrect or faulty connections may result
in fire or electric shock. Avoid using an
unsound or loose outlet.
9. Power-Cord Protection
Power-supply cords should be routed so
that they are not likely to be walked on or
pinched by items placed upon or against
them, paying particular attention to cords
at plugs, convenience receptacles, and
the point where they exit from the product.
10.Overloading
Do not overload wall outlets; to reduce
the risk of electric shock, do not use the
polarized plug with an extension cord ,
receptacle, or other outlet unless the
blades can be inserted completely with
three-wire grounding type to prevent
blade exposure. As this can result in a
risk of fire or electric shock.
6. Water and Moisture
Do not use this product near water.
- for example, near a bath tub, wash
bowl, kitchen sink, or laundry tub; in a
wet basement; or near a swimming
pool and the like.
7. Cleaning
Unplug this product from the wall outlet
before cleaning. Do not use liquid
cleaners or aerosol cleaners.
Use a soft cloth for cleaning.

6
IMPORTANT SAFETY INSTRUCTIONS (Continued)
11.Lightning storms
For added protection for this product
during storm, or when it is left
unattended and unused for long
periods of time, unplug it from the wall
outlet. This will prevent damage to the
product due to lightning and power-
line surges.
However, while it is thundering or
lightning, do not touch the apparatus
and any connected cable and/or
equipment.
This will prevent you from receiving
the electric shock by an electric surge.
14.Do not place the product
vertically
Do not use the product in the upright
position to project the pictures, or any
other vertical positions. It may fall down
and dangerous.
15.Stack Inhibited
Do not stack other equipment on this
product or do not place this product on
the other equipment. Top and bottom
plates of this product develops heat and
may give some undesirable damage to
other unit.
16.Attachments
Do not use attachments not recommended
by the product manufacturer as they may
cause hazards.
12.Object and Liquid Entry
Never push objects of any kind into
this product through openings as they
may touch dangerous voltage points
or short-out parts that could result in a
fire or electric shock. Never spill liquid
of any kind on the product.
13.Do not place or keep the
projector within the reach
of the children.
It may fall down or tip over, which
could result in severe injury.

7
Before Using
17.Accessories
Do not place this product on an
unstable cart, stand, tripod, bracket, or
table. The product may fall, causing
serious injury to a child or adult, and
serious damage to the product. A
product and cart combination should
be moved with care. Quick stops,
excessive force, and uneven surfaces
may cause the product and cart
combination to overturn.
e) If the product has been dropped or dam-
aged in any way (If the cabinet should
break, please handle with care to avoid
injury) .
f) When the product exhibits a distinct
change in performance - this indicates a
need for service.
19.If glass components, including
lens and lamp, should break,
contact your dealer for repair
service.
This product incorporates glass
components, including a lens and a lamp.
If such parts should break, please handle
with care to avoid injury and contact your
dealer for repair service. The broken
pieces of glass may cause to injury. In the
unlikely event of the lamp rupturing,
thoroughly clean the area around the
projector and discard any edible items
placed in that area.
20.Servicing
Do not attempt to service this product
yourself as opening or removing covers
may expose you to dangerous voltage or
other hazards. Refer all servicing to
qualified service personnel.
18.Damage Requiring Service
Unplug this product from the wall
outlet and refer servicing to qualified
service personnel under the following
conditions:
a) When the power-supply cord or plug is
damaged.
b) If liquid has been spilled, or objects
have fallen into the product.
c) If the product has been exposed to
rain or water.
d) If the product does not operate nor-
mally by following the operating
instructions. Adjust only those controls
that are covered by the operating
instructions as an improper adjust-
ment of other controls may result in
damage and will often require exten-
sive work by a qualified technician to
restore the product to its normal oper-
ation.
S3125A

8
IMPORTANT SAFETY INSTRUCTIONS (Continued)
21.Replacement Parts
When replacement parts are required,
be sure the service technician has
used replacement parts specified by
the manufacturer or have the same
characteristics as the original part.
Unauthorized substitutions may result
in fire, electric shock, or other hazards.
(Replacement of the lamp only should
be made by users.)
22.Safety Check
Upon completion of any service or
repairs to this product, ask the service
technician to perform safety checks to
determine that the product is in proper
operating condition.
23.Do not leave thermal-paper
documents or easily deformed
items on top of the unit or
near the air exhaust for long
periods of time.
The heat from the unit could erase the
information on the thermal paper, or
cause deformation or warping.
24.Do not use the product in a
closed installation state.
Do not place the product in a box or in
any other closed installation state.
Otherwise it may overheat. This could
result in a risk of fire.
25.Do not look into the laser
light source of the remote
control or direct the laser
pointer toward a person or a
mirror.
The laser beam may cause damage to
your eyesight.

9
Before Using
IMPORTANT PRECAUTIONS
Moisture Condensation
Never operate this unit immediately after moving it from a cold location to a warm location.
When the unit is exposed to such a change in temperature, moisture may condense on the
lens and the crucial internal parts. To prevent the unit from possible damage, do not use the
unit for at least 2 hours when there is an extreme or sudden change in temperature.
Place and Manner of Installation
• Do not place in hot locations, such as near heating equipment. Doing so could cause
malfunction, and shorten the life of the projector.
• Avoid locations with oil or cigarette smoke. Doing so will dirty the optical parts,
shortening their lives, and darkening the screen.
• Do not use this product in the upright position or tilt it up or down by more than 20° from
level. Doing so may cause a failure or shorten the life of the product.
• Using this instrument near a TV or radio may cause interference to the images or audio
sound. If this happens, move it away from the TV or radio.
• Moving the projector from a low-temperature room to a high-temperature room may
cause condensation on the lens or internal parts in the instrument. If you continue to use
it in that situation, the malfunction may result. Ensure to wait until the condensation
naturally disappears.
• In a high altitude location where air is thin, cooling efficiency is reduced so use the
projector with [Fan mode] set to [High].
• Only plug the power cord into outlets rated for use with the power cord's specified
voltage range. Do not overload extension cords or table taps as this can result in fire or
electric shock.
• Route the power cable or the connecting cable away from where people could trip over
it. The projector may fall down, which could result in severe injury.
• Be sure the power cord is easily reached for unplugging in case of emergency. Do not
place any obstacles near a wall outlet in which the cord is plugged.
Avoid Volatile Liquid
Do not use volatile liquids, such as an insect spray, near the unit. Do not leave rubber or
plastic products touching the unit for a long time. They will leave marks on the finish. Do not
use a chemically saturated cloth.
p.36

10
EXEMPTION CLAUSES
• Toshiba Corporation bears no responsibility in the case of damages arising from natural
disaster such as earthquakes, lightning, etc., fire not liable to Toshiba Corporation, acts
by third parties, other accidents, or use under abnormal conditions including erroneous
or improper operation and other problems.
• Toshiba Corporation bears no responsibility for incidental damages (lost profit, work
interruption, corruption or loss of the memory contents, etc.) arising from the use of or
the inability to use this unit.
• Toshiba Corporation accepts no liability whatsoever for any damages arising from not
having followed the descriptions in this Instruction Manual.
• Toshiba Corporation accepts no liability whatsoever for any damages arising from
malfunctions arising from combination with equipment or software that is not related to
Toshiba Corporation.
In the spaces provided below, record the Model and Serial No. located at the bottom of your
projector.
Model No.!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!Serial No.!!!!!!!!!!
Retain this information for future reference.

11
Before Using
OTHER INFORMATION
Copyrights
Showing or transmitting commercial imaging software or broadcast or cable-broad casting
programs with the purpose of other than the personal and private viewing, including
modifying images using the freeze function, or displaying with the varying aspect ratio of the
images, could violate the direct or indirect copyrights of the imaging software or broadcast
program, etc., if done without first consulting with the copyright holder. For this reason,
please take appropriate measures before performing one of the actions listed above,
including obtaining a license from the copyright holder.
Disposal
This product contains substances which are harmful to humans and the environment.
• The lamp contains mercury.
Please dispose of this product or used lamps in accordance with local regulations.
Following information is only for EU-member states:
The use of the symbol indicates that this product may not be treated as
household waste. By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the environment and
human health, which could otherwise be caused by inappropriate waste
handling of this product. For more detailed information about recycling of this
product, please contact your local city office, your household waste disposal
service or the shop where you purchased the product.
Trademarks
• VGA, SVGA, XGA, SXGA, UXGA are trademarks or registered trademarks of
International Business Machines Corporation.
•DLP
®(Digital Light Processing) is a registered trademark of Texas Instruments, Inc.
• Macintosh is a registered trademark of Apple Computer, Inc.
• Windows is a registered trademark of Microsoft Corporation in the U.S. and other
countries.
• Adobe is a registered trademark and Acrobat Reader is a trademark of Adobe Systems
Incorporated.
• All other brand and product names are trademarks or registered trademarks of their
respective companies.
Notational Conventions Used in This Manual
• References to pages with related information are annotated as follows. For example, if
making a reference to page 36:
• The illustrations in this document are for reference purposes only and may not reflect
your package exactly.
p.36

12
REMOTE CONTROL BATTERIES
Caution
• Never throw batteries into a fire.
Using the batteries improperly may cause them to explode or leak and lead to burn or injury.
If battery-leaking fluid contacts skin, wash the fluid off immediately with clean water and
consult a doctor. If the fluid is spilt on an instrument, avoid contact and wipe it off using tissue
paper. (Dispose of the used tissue paper as flammable garbage after moistening with water.)
Notes
• Be sure to use AAA (LR03) size batteries.
• Dispose of batteries in a designated disposal area.
• Attention should be drawn to the environmental aspects of battery disposal.
• Do not mix different battery types or combine used batteries with new ones.
• If the remote control does not operate correctly, or if the operating range becomes
reduced, replace both batteries with new ones.
• If the batteries are dead or if you will not be using the remote control for a long time,
remove the batteries to prevent battery acid from leaking into the battery compartment.

13
Before Using

14
CONTENTS
Before using
SAFETY PRECAUTIONS ............................................................................. 2
IMPORTANT SAFETY INSTRUCTIONS ...................................................... 4
IMPORTANT PRECAUTIONS ...................................................................... 9
EXEMPTION CLAUSES ............................................................................. 10
OTHER INFORMATION ............................................................................. 11
REMOTE CONTROL BATTERIES ............................................................. 12
CONTENTS ................................................................................................ 14
Preparations
Checking the package contents .................................................................. 16
Names of each part on the main unit .......................................................... 17
Names of each part on the control panel and remote control ..................... 18
Label locations ............................................................................................ 20
Parts on the rear panel ................................................................................ 20
Preparing and using the remote control ...................................................... 21
Operating a computer using the remote control .......................................... 23
Placement ................................................................................................... 24
Connection .................................................................................................. 26
Operations
Turning the power on and off ...................................................................... 28
Basic operations .......................................................................................... 30
Using handy features .................................................................................. 31
Using auto setting (Only for computer input) .......................................................31
Correcting the keystone distortion .......................................................................31
Cutting off the picture and sound temporarily (Mute) ...........................................31
Freezing the image (Freeze) ...............................................................................32
Using the menus ......................................................................................... 33
How to use the menus .........................................................................................33
Image adjustment menu ......................................................................................34
Display setting menu ...........................................................................................35
Default setting menu ............................................................................................36
Displaying Information (Status display) ...............................................................37
Using USB Memory ..................................................................................... 38
Maintenance
About lamp .................................................................................................. 42
Lamp replacement ...................................................................................... 42
Lens and main unit cleaning ....................................................................... 45

15
Before Using
Others
Indicators ..................................................................................................... 46
Before calling service personnel ................................................................. 47
Specifications .............................................................................................. 48
List of general specifications................................................................................ 48
Separately sold product ....................................................................................... 48
List of supported signals (RGB signals)............................................................... 49
List of supported signals (Video, S-Video signals) .............................................. 50
Pin assignment of COMPUTER IN terminals ...................................................... 51
Pin assignment of S-VIDEO terminals................................................................. 51

16
Preparations
Checking the package contents
Please make sure that the following items are included in the box, along with the main unit.If
any item is missing, please contact the store immediately where you purchased theproduct.
Note
• The shape and number of supplied power cords vary depending on the product
destination.
• To maintain original performance, make sure to use supplied cables.
Save Original Packing Materials
The original shipping carton and packing materials will come in handy if you ever have to
ship your projector. For maximum protection, repack the set as it was originally packed at
the factory.
The supplied CD-ROM contains an owner’s manual, including information not available for
the printed Owner’s manual (Getting Started) in PDF format. (PDF: Portable Document
Format) Please use Acrobat Reader 5 or more to view the manual.

Adobe®Acrobat®Reader®or Adobe®Reader®
The supplied CD-ROM does not contain Acrobat®Reader®. If you can not read PDF
files, please install Adobe Reader software in your computer by downloading it from the
Adobe Systems website.

Viewing the manual
Run the CD-ROM and double-click on Start.pdf. Acrobat®Reader®launches, and the
menu screen of the Owner’s manual appears. Click on your language. The Owner's
Manual cover and list of bookmarks appear. Click on a bookmark title to view that
section of the manual. Click on to view a reference page with related information.
See the Help menu for more information about Acrobat®Reader®.
(1) (4) (7)
(2)
(5)
(8)
(3) (6)
(1) Remote control
(2) LR03 (SIZE AAA) batteries for remote control (2)
(3) CD-ROM
(4) Owner’s Manual
(5) RGB cable (3m) (See note)
(6) Power cord (See note)
(7) Carrying bag
(8) Mouse remote control receiver

The Supplied CD-ROM

17
Preparations
Names of each part on the main unit
Name :Function
(1) Infrared remote sensor :Senses commands from the remote control.
(2) Lens :Projects expanded image.
(3) Focus ring :Adjusts the screen focus.
(4) Foot adjuster release button :Press to set up or stow the foot adjuster.
(5) Air exhaust :Expels air that has grown hot inside the projector.
(6) Air intake :Draws in air from outside the projector for internal
cool down.
(7) Control panel :Operates the projector.
(8) Speaker :Outputs audio sound.
(9) Zoom ring :Adjusts the screen size.
(10)Antitheft lock hole :Attach a safety cable or any other antitheft device.
(11) Rear panel :Connects external devices.
(12) Lamp cover :Remove to replace lamp.
(13)Tilt adjuster :Adjusts the projector’s horizontal tilt.
(14)Foot adjuster :Adjusts the vertical projection angle.
(1)
(6)
(2)(3)(4)(6) (5)(7)(8)(9)(1)
(10) (11) (6) (12) (14)(13)
Back Front
p.18
p.30
p.18
p.20
p.42
p.30
p.30

18
Names of each part on the control panel and remote control
Control panel Remote Control
CAUTION
• Do not look into the laser
light source of the remote
control or direct the laser
pointer toward a person
or a mirror.
• Handling and adjusting
other than described
here may lead to
dangerous exposure to
laser.
Name :Main Function
Control panel
(1) ON/STANDBY button :Turns the power on/off (standby).
(2) Selection buttons :Menu selections and adjustments, volume control, etc.
(3) INPUT button :Selects input.
(4) ENTER button :Accepts the selected mode.
(5) MENU button :Displays menus.
(6) LAMP indicator :Displays lamp mode.
(7) ON/STANDBY indicator :Displays whether power is on or off.
(8) TEMP indicator :Lights when internal temperature is too high.
Remote control
(1) ON/STANDBY button :Turns the power on/off (standby).
(2) Selection buttons :Menu selections and adjustments, volume control, etc.
(3) INPUT button :Selects input.
(4) ENTER button :Accepts the selected mode.
(5) MENU button :Displays menus.
(4) (5)
(6)(7)(8)
(1)
(2)
(3)
(1)
(3)
(7)
(5)
(4)
(6)
(8)
(14)
(15)
(16)
(11)
(18)
(2)
(9)
(12)
(13)
(10) (17)
Remote control transmitter
Laser light source
Battery
cover
Warning
label
p.28
p.33
p.30
p.33
p.29
p.29
p.28
p.28
p.33
p.30
p.33

19
Preparations
Note
• For the remainder of this manual, buttons are referred to as follows:
Selection buttons   ; ENTER button 
Name :Main Function
(6) LASER button :Shows a laser pointer.
(7) AUTO SET button :Sets up analog input from computer.
(8) R-CLICK button :Functions as right-click of a mouse.
(9) PAGE- button :Goes back PowerPoint®slides.
(10) KEYSTONE + / - button :Adjusts keystone distortion.
(11) Remote control ON/OFF switch :Switches on/off the remote control.
(12)Laser indicator :Lights when laser is on.
(13) Mouse control button :Controls a mouse pointer.
(14)PAGE+ button :Proceeds PowerPoint®slides.
(15)MUTE button :Cuts off the picture and sound temporarily.
(16)FREEZE button :Pauses image.
(17)VOLUME + / - button :Adjusts the volume level.
(18)L-CLICK button :Functions as left-click of a mouse.
p.31
p.23
p.23
p.31
p.21
p.23
p.23
p.31
p.32
p.23

20
Label locations
Parts on the rear panel
Caution
.
use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
Name :Main Function
(1) Infrared remote sensor :Senses commands from the remote control.
(2) SERVICE :Firmware update.
(3) COMPUTER IN terminal :Input analog RGB signal from a computer or other
source, or a component video signal (Y/PB/PR) from
video equipment.
(4) S-VIDEO terminal :Input S video signals from video equipment.
(5) VIDEO terminal :Input video signals from video equipment.
(6) AUDIO IN terminal :Input audio signals.
(7) USB terminal :Connects a commercial USB memory.
(1) (2) (3) (4) (5) (6) (7)
p.38
