Toshiba TDP-FF1A User manual

OWNER'S MANUAL
LED PROJECTOR
TDP-FF1A
Before Using
Preparations
Operations
Others

2
SAFETY PRECAUTIONS
The lightning flash with arrowhead symbol, within an equilateral triangle, is in-
tended to alert the user to the presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS AP-
PLIANCE TO RAIN OR MOISTURE. DANGEROUS HIGH VOLT AGES ARE PRESENT IN-
SIDE THE ENCLOSURE. DO NOT OPEN THE CABINET. REFER SERVICING TO QUALI-
FIED PERSONNEL ONLY.
WARNING: Handling the cord on this product or cords associated with accessories sold
with this product, will expose you to lead, a chemical known to the State of
California to cause birth defects or other reproductive harm. Wash hands af-
ter handling.
MODEL NAME: TDP-FF1 USA only
TRADE NAME: LED PROJECTOR MODEL NAME: TDP-FF1
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
FCC NOTICE: This device complies with part 15 of the FCC Rules. Operation is subject to
the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. This
equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment gener-
ates, uses and can radiate radio frequency energy and, if not installed and used in ac-
cordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
USA only

3
Before Using
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
RESPONSIBLE PARTY: TOSHIBA AMERICA INFORMATION SYSTEMS, INC.
9740 Irvine Blvd., Irvine, CA 92618-1697 U.S.A
Phone: [phone]
WARNING: Changes or modifications made to this equipment, not expressly approved by
Toshiba, or parties authorized by Toshiba, could void the user’s authority to
operate the equipment.
WARNING: This Class B digital apparatus complies with Canadian ICES-003. Cet appareil
numérique de la classe B est conforme à la norme NMB-003 du Canada.
USA only
CANADA only
CAUTION
LED RADIATION DO NOT STARE INTO BEAM OR VIEW DIRECTLY WITH OPTICAL
INSTRUMENTS. CLASS 2M LED PRODUCT.
MANUF ACTURED
SERIAL NO.

4
IMPORTANT SAFETY INSTRUCTIONS
CAUTION: PLEASE READ AND OBSERVE ALL WARNINGS AND INSTRUC-
TIONS GIVEN IN THIS OWNER’S MANUAL AND THOSE MARKED
ON THE UNIT. RETAIN THIS BOOKLET FOR FUTURE REFER-
ENCE.
This set has been designed and manufactured to assure personal safety. Improper use can
result in electric shock or fire hazard. The safeguards incorporated in this unit will protect
you if you observe the following procedures for installation, use and servicing. This unit is
fully transistorized and does not contain any parts that can be repaired by the user.
DO NOT REMOVE THE CABINET COVER, OR YOU MAY BE EXPOSED TO
DANGEROUS VOLTAGE. REFER SERVICING TO QUALIFIED SERVICE PER-
SONNEL ONLY.
1. Read Owner’s Manual
After unpacking this product, read
the owner’s manual carefully, and
follow all the operating and other
instructions.
3. Source of Light
Do not look into the lens while the
machine is on. The strong light
from the len may cause damage to
your eyes or sight.
2. Power Sources
This product should be operated
only from the power source indi-
cated on the marking label.
If you are not sure of the type of
power supply to your home, con-
sult your product dealer or local
power company.
For products intended to oper-
ate from battery power, or other
sources, refer to the operating
instructions.
4. Ventilation
Openings in the cabinet are pro-
vided for ventilation and to ensure
reliable operation of the product
and to protect it from overheating,
and these openings must not be
blocked or covered. The openings
should never be blocked by placing
the product on a bed, sofa, rug or
other similar surface. This product
should not be placed in a built-in
installation such as a bookcase
or rack unless proper ventilation
is provided or the manufacturer’s
instructions have been adhered to.

5
Before Using
5. Heat
The product should be situated
away from heat sources such as
radiators, heat registers, stoves,
or other products (including ampli-
fiers) that produce heat.
6. Water and Moisture
Do not use this product near water.
For example, near a bath tub, wash
bowl, kitchen sink, or laundry tub;
in a wet basement; or near a swim-
ming pool and the like.
7. Cleaning
Unplug this product from the outlet
before cleaning. Use a soft cloth in-
stead of liquid cleaners or aerosol
cleaners for cleaning.
8. Power-Cord Protection
Power-supply cords should be
routed so that they are not likely to
be walked on or pinched by items
placed upon or against them, pay-
ing particular attention to cords at
plugs, convenience receptacles,
and the point where they exit from
the product.
9. Overloading
Do not overload outlets; extension
cords, or integral convenience
receptacles as this can result in a
risk of fire or electric shock.

6
IMPORTANT SAFETY INSTRUCTIONS (continued)
10. Lightning storms
For added protection for this prod-
uct during storm, or when it is left
unattended and unused for long
periods of time, unplug it from the
outlet. This will prevent damage to
the product due to lightning and
power-line surges. However, while
it is thundering or lightning, do
not touch the apparatus and any
connected cable and/or equip-
ment. This will prevent you from
receiving the electric shock by an
electric surge.
11. Object and Liquid Entry
Never push objects of any kind
into this product through open-
ings as they may touch dangerous
voltage points or short-out parts
that could result in a fire or elec-
tric shock. Never spill liquid of any
kind on the product.
12. Do not place the product
vertically
Do not use the product in the
upright position to project the pic-
tures at the ceiling, or any other
vertical positions. It may fall down
and be dangerous.
13. Stack Inhibited
Do not stack other equipment on
this product or do not place this
product on the other equipment.
Top and bottom plates of this
product develops heat and may
give some undesirable damage to
other unit.
14. Attachments
Do not use attachments not
recommended by the product
manufacturer as they may cause
hazards.

7
Before Using
15. Accessories
Do not place this product on an
unstable cart, stand, tripod, brack-
et, or table. The product may fall,
causing serious injury to a child
or adult, and serious damage to
the product. A product and cart
combination should be moved with
care. Quick stops, excessive force,
and uneven surfaces may cause
the product and cart combination
to overturn.
S3125A
16. Damage Requiring Service
Unplug this product from the out-
let and refer servicing to qualified
service personnel under the fol-
lowing conditions:
a) When the power-supply cord or
plug is damaged.
b) If liquid has been spilled, or ob-
jects have fallen into the product.
c) If the product has been exposed to
rain or water.
d) If the product does not operate
normally by following the operat-
ing instructions. Adjust only those
controls that are covered by the
operating instructions as an im-
proper adjustment of other con-
trols may result in damage and will
often require extensive work by a
qualified technician to restore the
product to its normal operation.
e) If the product has been dropped
or damaged in any way.
f) When the product exhibits a dis-
tinct change in performance - this
indicates a need for service.
17. If glass components, in-
cluding lens, should break,
contact your dealer for
repair service.
This product incorporates glass
components, including a lens. If
such parts break, please handle
with care to avoid injury and con-
tact your dealer for repair service.
The broken pieces of glass may
cause to injury.
18. Servicing
Do not attempt to service this
product yourself as opening or
removing covers may expose you
to dangerous voltage or other haz-
ards. Refer all servicing to quali-
fied service personnel.

8
IMPORTANT SAFETY INSTRUCTIONS (continued)
19. Replacement Parts
When replacement parts are re-
quired, be sure the service techni-
cian has used replacement parts
specified by the manufacturer or
have the same characteristics as
the original part.
Unauthorized substitutions may
result in fire, electric shock, or
other hazards.
20. Safety Check
Upon completion of any service
or repairs to this product, ask
the service technician to perform
safety checks to determine that
the product is in proper operating
condition.
21. Do not leave thermalpaper
documents or easily de-
formed items on top of the
unit or near the air exhaust
for long periods of time.
The heat from the unit could erase
the information on the thermal
paper, or cause deformation or
warping.
22. Do not use the product in
a closed installation state.
Do not place the product in a box
or in any other closed installation
state. Otherwise it may overheat.
This could result in a risk of fire.

9
Before Using
Save Original Packing Materials
The original shipping carton and packing materials will come in handy if you ever have to
ship your projector. For maximum protection, repack the set as it was originally packed at
the factory.
Moisture Condensation
Never operate this unit immediately after moving it from a cold location to a warm location.
When the unit is exposed to such a change in temperature, moisture may condense on the
lens and the crucial internal parts. To prevent the unit from possible damage, do not use
the unit for at least 2 hours when there is an extreme or sudden change in temperature.
Place and Manner of Installation
• Do not place in hot locations, such as near heating equipment. Doing so could cause
malfunction, and shorten the life of the projector.
• Avoid locations with oil or cigarette smoke. Doing so will dirty the optical parts, shortening
their lives, and darkening the screen.
• Using this instrument near a TV or radio may cause interference to the images or audio
sound. If this happens, move it away from the TV or radio.
• Moving the projector from a low-temperature room to a high-temperature room may cause
condensation on the lens or internal parts in the instrument. If you continue to use it in
that situation, the malfunction may result. Ensure to wait until the condensation naturally
disappears.
• Do not use the projector while holding it in your hands or lap.
• Do not use the projector near a power source and the like, or in locations like a ship
or vehicle that are subject to vibration or shock. Doing so may lead to a malfunction or
shorten service life.
Avoid Volatile Liquid
Do not use volatile liquids, such as an insect spray, near the unit. Do not leave rubber or
plastic products touching the unit for a long time. They will leave marks on the finish.
If cleaning with a chemically saturated cloth, be sure to follow the product’s precautions.
IMPORTANT PRECAUTIONS

10
EXEMPTION CLAUSES
In the spaces provided below, record the Model and Serial No. located at the bottom of your
projector.
Model No. Serial No.
Retain this information for future reference.
• Toshiba Corporation bears no responsibility in the case of damages arising from natural
disaster such as earthquakes, lightning, etc., fire not liable to Toshiba Corporation, acts
by third parties, other accidents, or use under abnormal conditions including erroneous or
improper operation and other problems.
• Toshiba Corporation bears no responsibility for incidental damages (lost profit, work inter-
ruption, corruption or loss of the memory contents, etc.) arising from the use of or the
inability to use this unit.
• Toshiba Corporation accepts no liability whatsoever for any damages arising from not hav-
ing followed the descriptions in this Instruction Manual.
• Toshiba Corporation accepts no liability whatsoever for any damages arising from mal-
functions arising from combination with equipment or software that is not related to
Toshiba Corporation.

11
Before Using
OTHER CAUTIONS AND INFORMATIONS
Copyrights
Showing or transmitting commercial imaging software or broadcast or cable-broad cast-
ing programs with the purpose of other than the personal and private viewing, including
modifying images using the freeze functions, or displaying with the varying aspect ratio
of the images, could violate the direct or indirect copyrights of the imaging software or
broadcast program, etc., if done without fi rst consulting with the copyright holder. For this
reason, please take appropriate measures before performing one of the actions listed
above, including obtaining a license from the copyright holder.
Disposal
Following information is only for EU-member states:
The use of the symbol indicates that this product may not be treated as
household waste. By ensuring this product is disposed of correctly, you will
help prevent potential negative consequences for the environment and human
health, which could otherwise be caused by inappropriate waste handling of
this product. For more detailed information about recycling of this product,
please contact your local city offi ce, your household waste disposal service or
the shop where you purchased the product.
This product contains substances which are harmful to humans and the environment.
Trademarks
• VGA, SVGA, XGA, SXGA, UXGA are trademarks or registered trademarks of Internation-
al Business Machines Corporation.
• Digital Light Processing, Digital Micromirror Device and DMD are trademarks of Texas
Instruments.
• Macintosh is a registered trademark of Apple Computer, Inc.
• Windows is a registered trademark of Microsoft Corporation in the U.S. and other coun-
tries.
• Adobe is a registered trademark and Acrobat Reader is a trademark of Adobe Systems
Incorporated.
Notational Conventions Used in This Manual
• References to pages with related information are annotated as follows.
For example, if making a reference to :
• The illustrations in this document are for reference purposes only and may not refl ect your
package exactly.

12
BATTERIES
The Battery Type
For remote control: Be sure to use the lithium CR2025 battery.
For Projector: Be sure to use TLPBP1 battery pack.
Caution
• Never shock the battery pack by dropping or throwing it.
• Never throw the battery pack into a fire, as this could cause the battery pack to explode.
• Never disassemble the battery pack, as this could cause leakage of alkaline solution or
other electrolytic substance.
• Never short-circuit the battery pack by either accidentally or intentionally bringing the
terminals in contact with another metal object. Never carry the battery pack or store it to-
gether with any other metal object such as necklace or hairpin. This could cause personal
serious injury or a fire, and could also damage the battery pack. Never expose the termi-
nals of the battery pack to any other metal object. Wrap the battery pack or place it in a
protective plastic bag, whenever transporting it.
• Never drive a nail into the battery pack.
• Never strike the battery pack with a hummer.
• Never step or tread on the battery pack.
• Never immerse or expose the battery pack to any liquid.
• If you ever detect the emission of an extraordinary odor, excessive heat, discoloration, or
deformation of the battery pack, remove it from the projector after confirming safety and
discontinue use of it.
• Keep the battery pack away from heat or fire, if you detect an odor emission or leakage of
alkaline solution or other electrolytic substance.
• Always keep the battery pack out of reach of infants or small children.
• Never expose the battery pack to direct sunlight. Never store or use the battery pack in a
locked and unventilated vehicle, where excessive internal temperatures may be encoun-
tered.
• If the liquid contained within the battery pack leaks, use a large amount of water with a
soap and immediately wash off any liquid which may have contacted any part of the body.
Notes
• Dispose of battery in a designated disposal area.
• Attention should be drawn to the environmental aspects of battery disposal.
• If the remote control does not operate correctly, or if the operating range becomes re-
duced, replace the battery with new one.
• If the battery is dead or if you will not be using the remote control for a long time, remove
the battery to prevent battery acid from leaking into the battery compartment.

13
Before Using
TABLE OF CONTENTS
SAFETY PRECAUTIONS 2
IMPORTANT SAFETY INSTRUCTIONS 4
OTHER CAUTIONS AND INFORMATIONS 11
BATTERIES 12
Checking the package contents 15
Main unit components 16
Control keypad and functions 18
Remote control keypad and functions 19
Using the battery pack with the projector 20
Using the remote control 22
Changing the new lithium battery 22
Operating the remote control 22
Placement 23
Connection 24
Turning the power on and off 25
Basic operations 26
Using handy features 27
Using auto setting (Only for computer input) 27
Correcting the keystone distortion 27
Freezing the image (Freeze) 28
Using USB Memory 29
Placement of the projection screen 34
Using the screen 34
Using the menus 35

14
How to use the menus 35
Image adjustment menu 36
Display setting menu 37
Default setting menu 38
Displaying Information (Status display) 39
Lens and main unit cleaning 40
Lens cleaning 40
Main unit cleaning 40
Before calling service personnel 41
Indicators 42
Specifications 43
List of general specifications 43
List of supported signals (RGB signals) 44
List of supported signals (Y/PB/PR signals) 45
List of supported signals (Video signals) 45
List of USB function limitations 45
Pin assignment of COMPUTER IN terminals 46
TABLE OF CONTENTS (continued)

15
Preparations
Checking the package contents
The Supplied CD-ROM
The supplied CD-ROM contains an owner’s manual and Acrobat® Reader™ to view the
manual.
Installing Acrobat® Reader™
Windows®: Run the CD-ROM, select the Reader/English folder, and run ar500enu.exe.
Follow the on-screen instructions.
Macintosh: Run the CD-ROM, select the Reader/English folder, and run Reader In-
staller. Follow the on-screen instructions to install the software.
Viewing the manual
Run the CD-ROM and double-click on Start.pdf. Acrobat® Reader™ launches, and
the menu screen of the Owner’s manual appears. Click on your language. The Owner’s
Manual cover and list of bookmarks appear. Click on a bookmark title to view that
section of the manual. Click on
p.
to view a reference page with related information.
See the Help menu for more information about Acrobat® Reader™.
Please make sure that the following items are included in the box, along with the main unit.
If any item is missing, please contact the store immediately where you purchased the prod-
uct.
(1) (4) (7)
(2) (5) (8)
(3) (6) (9)
(1) Remote control
(2) Battery pack
(3) CD-ROM
(4) Owner’s Manual
(5) RGB cable (1.5m)
(6) Power cord (See note)
(7) Adaptor
(8) Carrying bag
(9) Screen
Note
The shape and number of supplied power cords vary depending on the product destination.

16
Main unit components
Top
Left
1. Focus Ring Adjusts the focus
2. Control Panel Operates the projector
3. LED indicators Indicates projector
status
TEMP Lights when temperature
too high
BATT. Display battery condition
POWER Lights when power on
6. USB port Plug in USB memory
7. Headphone Outputs audio signals
8. Audio in Inputs audio signals
9. Video in Inputs video signals from
video equipment
10. Antitheft lock
hole
For security lock
11. Computer in Inputs analog RGB
signal from computer, or
component video signal
from video equipment.
1
2
3
6
7
8
9
10
11
Bottom
4. Battery
connector cover
Protect battery connector
5. Foot adjuster Adjust the vertical
projection angle
4
5

17
Preparations
Right
12. DC input Connect the AC adaptor
13. Power switch Turn on/off the projector
14. Ventilator Air ventilator for cooling
inside
15. Speaker Ouputs sounds from audio
in terminals
16. Battery pack Li-ion battery TLPBP1
12
13
14
15
16
17
18
Rear
17. Service port For service only
18. Battery
power in
connector
For battery connection
Front
19. Lens Projects expanded
20. Infrared remote
sensor
Sense commands from
the remote control
2019

18
Control keypad and functions
1. Input/Menu Normal mode:
• Change input source when pressing for less than 1 seconds.
• Display menu system when pressing for longer than 1 seconds.
• Move to upper level in menu system.
File view mode:
• Same as Normal mode.
Slideshow mode:
• Changes input source when pushing shorter than 1 seconds.
• Exits slideshow and go to file view mode (pressing for longer
than 1 seconds.)
Sub-menu “Stop slideshow?” is shown
 Select Yes: go to file view mode.
 Select No: display screen menu system.
2.
<, >
+Normal mode:
• When OSD is not displayed:
 Volume control (Computer, Video input)
• When OSD is displayed:
 Choose menu item
File view mode:
• When OSD is not displayed:
 Choose file or directory
• When OSD is displayed:
 Choose menu item
Slideshow mode:
• Show previous/next slide
3. AUTOSET / Normal mode:
• When OSD is not displayed:
 AUTOSET (RGB signal)
• When OSD is displayed:
 Confirm screen menu selections
File view mode:
• When OSD is not displayed:
 Highlight on a file: Start the slideshow
 Highlight on a directory: Change the directory
• When OSD is displayed:
 Confirm screen menu selections
Slideshow mode:
• To pause or re-start the slide show
Normal mode: with COMPUTER or VIDEO INPUTS
File view mode: with USB INPUT for file/directory selection.
Slideshow mode: with USB INPUT.
2
13

19
Preparations
1. AUTOSET Auto set
2. Normal mode:
• When OSD is not displayed: No action
• When OSD is displayed: Confirm screen menu
selections
File view mode:
• When OSD is not displayed:
 Highlight on a file: Start the slideshow
 Highlight on a directory: Change the directory
• When OSD is displayed:
 Confirm screen menu selections
Slideshow mode:
• To pause or re-start the slide show
3. Volume +/- Adjust volume
4. Keystone Correct image distortion
5. Freeze Pause image (Computer, Video input only)
6. Menu Display menu system/move to upper level in menu system
7. /
Normal mode:
• When OSD is not displayed: No action
• When OSD is displayed: Choose menu item
File view mode:
• When OSD is not displayed:
 Choose file or directory
• When OSD is displayed:
 Select screen menu items
Slideshow mode:
• Show previous/next slide
8. Input Select input sources
Remote Control
Remote control keypad and functions
1
2
3
4
5
6
7
8

20
Using the battery pack with the projector
The following procedures are for the installation of the battery pack with the projector.
Installing the battery
 Turn off the power switch and disconnect the AC adaptor.
 Open the battery connector cover.
 Plug in the battery pack.
 Press down the battery pack firmly until it clicks into place.
 Switch the power button to turn on the projector.
Remove the battery
 Turn off the power switch and disconnect the AC adaptor.
 Move the button to “unlock” and keep it.
 Lift the battery pack.
 Remove the battery pack.
 Close the battery connector cover.
1
2
3
Charge the battery
The battery pack can be charged with the projector when the AC adaptor is connected. It
can be also charged when the projector is turned on. It takes 3 to 4 hours to charge the
battery completely.
