Toshiba TLP-450 Reference guide

1
2
OPERATIONS
3LCD DATA PROJECTOR
QUICK REFERENCE CARD
Projecting a Picture
• Connect external equipment
such as a computer or
video tape player.
• Connect the power cord to
the projector.
Press ON/STANDBY.
Both the ON and LAMP indications light up
in green.
Turn on the connected equipment
and put it in playback mode.
5
Press INPUT to select the
input source.
Video: VIDEO input picture
RGB: RGB input picture
CAMERA: Camera input picture
Adjust the picture size and
focus.
Zoom ring: Adjust the picture size.
Focus ring: Focus the picture.
4
3
1
2
Turning Off the Power After Use
Put the connected equipment
in the stop mode.
Press ON/STANDBY.
An instruction message appears.
Press ON/STANDBY again.
(Power turns off and then the lamp goes off.)
After confirming the exhaust fan
stops, unplug the power cord.
3
For more informations about usage and operations, see the owner’s manual.
“Camera” function is equipped only with the model which has a document imaging camera model.
4
ON/STANDBY
INPUT
ON/STANDBY
ON/STANDBY
4) Open the camera head.
5) Turn the camera head.
6) Pull up the light.
7) Turn the light.
1
Projecting Images with the Document Imaging Camera
3
4
Press ARM LIGHT.
The light turns on.
Place a document onto or
around the projector, and turn
the camera head to direction
of the document.
Press CAMERA.
The appeared image is a projected one
through the camera.
Move the camera head to
adjust the size of the picture,
and focus on the picture by
turning the focusing ring on
the camera head.
2
5
After using, return the arm to the original position in the
reverse order.
1) Raise up the arm.
2) Stretch the arm.
3) Turn the arm.
ARM LIGHT
CAMERA
Up : to reduce.
Down :To enlarge.
Focusing ring
N: Near
F : Far

Adjustment and Function Setting
1Press MENU.
The menu is displayed.
2Press or to select the item.
(Item not marked with ). Press or to adjust the value or select the setting.
5Press MENU.
The menu disappears.
Note: Pressing RESET of the remote control will return all the adjustments or settings currently displayed to their default.
4(Item marked with ). Press ENTER to execute the item.
Auto set... To correct the keystone
distortion automatically
Adjust...... To make the correction of
keystone distortion
Contrast ..................... Contrast
Brightness .................. Brightness
Color .......................... Colordensity
Tint ............................ Tint
Sharpness .................. Sharpness
R-level ....................... Red level
G-level ....................... Green level
B-level ........................ Blue level
Camera gain .............. Sensitivity
Volume .. Toadjustthesoundvolume
Bass ..... To adjust the bass
Treble ... To adjust the treble
Language ........ To select the lan-
guage
Proj. mode....... To set the projecting
orientation
RGB input ....... Tosetthesignaltype
Video signal ..... Tosetthesignaltype
Scrn display ... Touseofdisableon-
screen displays
Save data ... Tosavethe adjustments
and settings on the
menu.
All preset ....To restore the adjust-
ments and settings on
the menu to the factory
set.
Auto sync. .... Toadjusttheimageau-
tomatically
Phase .......... To reduce flickers
H-Position .... Toshifttheimagehori-
zontally
V-Position ..... To shift the image ver-
tically
Clock ........... To remove vertical
stripes
MENU
MENU
3Press or to select the item.
Auto set
Keystone
Adjust
–+
Auto syn
c.
Phase
–+
H–posi t ion
V–posi t ion
Clock
–+
–+
–+
Con t r as t
–+
Brightness
Color
–+
–+
Tint
Sharpness
–+
–+
R- level
–+
G- level
–+
B- level
–+
Camera gain
–+
Vo l ume
Audio
–+
Bass
Treble
–+
–+
Language
Default
Proj .mode
RGB input
Video signal
yScrn displa
Eng l i sh
Standard
RGB
Auto
On
Save dat
Save
a
Al l preset
ENTER
