Toshiba Data Projector
TLP 260/261
DATA PROJECTOR
TLP260/TLP261
High brightness 1500 ANSI lumens
Crisp 60-inch screen from a distance of only 3.94ft.
1500 ANSI lumens
TLP261
TLP260
• Equipped with 60-inch/3.94ft (100-inch/6.56ft) short focal point lens
• 1500 ANSI lumens for projection of vivid images
• Lineup of reasonable prices and models to match your budget

TOSHIBA DATA PROJECTOR
TLP260/261
Capable of easily realizing large-screen projection in
classrooms and small rooms by being equipped with
60-inch/3.94 ft short focal point lens
Lens shift function enables vertical adjustment of the
projection position with a touch of the finger
Icon menu makes the projector easier to use even for
first time users
Equipped with 3D real-time gamma tracking correction
circuit
The providing of a short focal point lens allows large-
screen projection simply by placing the projector near the
teacher’s desk without having to set up in the back of the
classroom as was the case with conventional projectors.
The lens shift dial results in compatibility with stacked or
rear projection since it enables the vertical projection
position to be adjusted easily.
These data projectors feature an icon menu that allows
them to be used intuitively along with a guide menu that
displays adjustments relating to the task that is desired to
be performed.The result is outstanding ease of operation
even for first time users.
Color unevenness can be corrected efficiently as a result
of performing correction for each signal level in addition
to correcting color unevenness in the horizontal and ver-
tical directions. Moreover, the use of a digital drive circuit
makes it possible to provide sharp, high-definition images
with minimal noise.
■1500 ANSI lumens despite its compact design and
light weight of only 7.1 lbs
■Equipped with digital keystone correction function
■Y/PB/PR video input compatible with HDTV
■Quiet operating design employing a heat-compatible
mechanism that reduces noise levels of the fan and
other components
■Loaded with unique digital features, including 10X
zoom and picture-in-picture
■Comes with a mouse controlled remote control that
allows hand-held operation of both the PC and projec-
tor. PowerPoint page changing can be performed with
the remote control
■Comes with its own carrying case that allows it to be
taken practically anywhere
■Projector distance and Screen size
Features
30 36 50 60 80 100 120 150 180 inches
11.91 ft
9.91~11.91 ft
7.90~9.48 tf
6.56~7.91 ft
5.21~6.30 ft
3.90~4.69 ft
3.21~3.90 ft
2.30~2.79 ft
2.30 ft
Model TLP260 TLP261
Liquid crystal panel No. of pixels 786,432 (1,024 x 768) 0.7" x 3
Drive method Polysilicon TFT active matrix method
Projection lens Manual zoom/manual focus lens F2.0~2.4, f=14.5~17.4mm
Light source 160 W high-pressure mercury lamp
Brightness 1500 ANSI lumens
Contrast 400:1
Resolution 800 x 600 dots (SVGA)
Colour reproduction Full-colour (16,770,000 colours)
Screen size 30 to 180 inches
Projection distance 2.29 ft~11.91 ft
Compatible scanning Horizontal (kHz) 15~93
frequency Vertical (Hz) 50~85
Video input Video signals 2 channels (RCA pin x 1/S terminal x 1) Colour difference
terminals signal 1 channel, shared with RGB signal
RGB input terminals RGB signals 1 channel (D-sub 15-pin x 1) (analog signal)
Audio/video input signals 1 channel (stereo mini-jack)
Input signal formats Video signals NTSC, PAL, SECAM
Colour difference Y/P
B /P R , (525i/525p/750p/1125i)
signals Y/C B
/C R (DVD)
RGB signals VGA, SVGA, XGA,
XGA (compressed), SXGA (compressed)
RGB output 1 channel Dsub 15 pin x 1
Internal speaker 1 W, monaural speaker
PC interface RS232C (mini- DIN, 8 pins)
External dimensions (W x D x H) inch 10.23 x 3.75 x 11.61 10.23 x 3.75 x 13.86
Weight (lbs) 7.1 8.6
Power consumption (W) 225 240
Power source AC100-240V, 50/60HZ
Replacement lamp type TLPL55
Accessories
•User’s manual (abridged version)
•User’s manual (CD-ROM version)
•Remote control unit •Batteries
•RGB cable (3m) •Video cable (2m)
•Audio cable (for VIDEO) (3m)
•Audio cable (for PC) (3m)
•Control cable (1.8m)
•USB cable (2m) •Power cable
•Carrying case
Equipped with 810k Pixel CCD Document Camera
(TLP261)
Equipped with a CCD
camera that allows
projection of printouts,
three-dimensional objects,
watches and other moving
objects on a real-time
basis.The easy-to-use
short focal point design in
able to handle typical size
business documents at a
distance of 7.94 inch.
Distributed by:
TOSHIBA OF CANADA LIMITED
Office Products Group
191 McNabb Street, Markham, Ontario, Canada L3R 8H2
Tel: [phone] Fax: [phone]
www.toshiba.ca Printed in Canada
May 2002
■ Specification details are subject to change without notice.
Specifications (Projector)
Device 1/3-inch CCD, 810k pixels
Resolution 500 TV lines or more (horizontal resolution
Lens F 2.8, f=6.2 mm, manual focusing
Specifications (Document Camera) TLP261
