TDP-TW100U
Sleek.
Toshiba’s TDP-TW100U features extraordinary performance and wireless networking capabilities
in a lightweight DLP®projector. With its 2700 ANSI lumens, the projector offers impressive dis-
plays even in challenging ambient light settings. The wireless1functionality delivers fast set-up
time and presentation flexibility. The Toshiba TDP-TW100U is suitable for mobile presenters,
small-to-medium businesses and for video gamers, weekend sports enthusiast and DVD
movie watchers.
Outstanding Image Quality and
Performance
The Toshiba TDP-TW100U offers incredible
power and flexibility from a lightweight
projector. A full-featured performer, it also
offers digital zoom, a password-protected
security feature to prevent unauthorized
usage, and instant shut down feature,
eliminating the wait for the projector to turn
off and cool down. The projector offers
superior image quality and performance for
presentations, video gaming, weekend sports
and DVD movies in virtually any setting.
Wireless Networking for Added
Flexibility
With wireless1functionality, the Toshiba
TDP-TW100U delivers fast set-up time
and presentation flexibility. Without the
hassle of additional cables, a presenter can
simply turn the unit on and begin without
worrying about extra time needed to connect
to a notebook or fumble with set up. The
TDP-TW100U also offers on-the-go profes-
sionals the option to deliver a “PCfree”
presentation with a USB thumb nail drive.
Simply store the presentation in JPEG format
and plug into the USB port.
A Quiet Presentation Tool
Designed for premium presentations to vast
conference room audiences, the Toshiba
TDP-TW100U projector ensures the presen-
tation is the center of attention with whisper-
quiet operation of only 33dB (in low mode) -
quieter than a soft conversation.
Easy Setup and Operation
Ready to go out of the box, the feature-
packed TDP-TW100U is easy to setup and
operate. The TDP-TW100U makes present-
ing easy with its built-in "blackboard" function
with wall color adjustment when projecting on
a non-screen surface. Simply select a wall
color in accordance with the projecting
surface, such as green, black, brown, blue or
beige, to display properly on a non-screen
surface. A fully-loaded presentation remote
control with laser pointer and auto set button
that sets up the projector to the optimum
settings, such as frequency and screen
position, ensures worry-free, professional
presentations even in the most unforgiving
environments.

TDP-TW100U1Detailed Product Specifications
Internal Speaker
• 1.0W Monaural
External Dimensions
• 11.8" (W) x 8.6" (D) x 3.9" (H)
Weight3
• 6.8 lbs.
Power Consumption
• 385W
Power Source
• 100-240V, 50/60Hz
Replacement Lamp
• TLP-LW10
Box Contents
• Mouse remote control with laser pointer
• Mouse remote control receiver
• Two size AAA batteries for remote control
• Power cord
• RGB cable
• CD-ROM
• User's Manual
• Soft Carrying Bag
Input Terminals
• Video: 1x S-video; 1x RCA for Composite Video
• RGB: 2 x D-sub 15-pin terminal
• RGB Audio: 1x stereo mini-jack
• Video/S-Video Audio: 2 x RCA (L/R)
Input Signal Format
• Video: NTSC, PAL, SECAM
• Color Difference: HDTV/DTV (1080i/720p/576p/576i/480p/480i)
• RGB: VGA, SVGA, XGA (true), SXGA (compressed), UXGA
(compressed)
Output Terminals
• Audio: 1x stereo mini-jack (variable output)
• RGB: 1x D-sub 15-pin outupt terminal
Other Terminals
• RS-232: 1x mini DIN 8-pin
• USB: 1x type A USB 2.0 high-speed enabled port
Digital Keystone Correction
• Automatic vertical +/- 30°
Auto Set
• Yes
Noise Level
• 36dB (33dB in low mode)
Product Specifications
Display Technology
• Shape: 0.55" DMD DLP®
• Number of Pixels: 786,432 (1024 x 768)
Projection Lens
• Standard Lens: 1.6x power zoom/auto focus
• F/f (mm): F = 2.23 - 2.82, f = 20.5 - 32.8mm
Throw Ratio
• 1.8 - 2.9:1
Lamp
• 275W
Brightness
• 2700 ANSI lumens
Native Resolution
• XGA 1024 x 768
Wireless Technology2
• IEEE 802.11b/g
Color Reproduction
• Full 16.7 Million Colors
Contrast Ratio
• 2000:1
Projection Screen Size (Diagonal)
• 30" - 300"
Projection Distance
• 3.5 ft - 36.4 ft
Compatible Scanning Frequency
• Horizontal (kHz): 15 - 120kHz
• Vertical (Hz): 50 - 150Hz
© Copyright 2006 All rights reserved. Toshiba is a registered trademark or trademark of Toshiba America Information Systems, Inc. and/or Toshiba Corporation. DLP®and the DLP logo are registered trademarks of Texas Instruments. All other products and names mentioned are the property of their respective owners. Product specifications, configurations, prices, system/component/options availability are all subject to change without notice.
1 This projector is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous Substances in electrical and electronic equipment (RoHS), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its projector component suppliers to meet RoHS requirements and verifi es its suppliers’ commitment to meeting RoHS requirements by conducting component
sampling inspections during the product design approval process. 2May require purchase of additional software, external hardware, or services. Transmission speeds may vary. See Wireless Legal Footnote at www.info.toshiba.com. 3Weight may vary. See Weight Legal Footnote at www.info.toshiba.com.
