Toshiba Ravage User manual

Device Label "Ravage"/"Tigatron"
Operating USB Flash Drive
User’s Manual
English

Contents
2
Contents
Safety Icons .................................................................................... 3
Safety Instructions .......................................................................... 4
Regulatory statements .................................................................... 4
FCC Information .............................................................. 4
Industry Canada Requirement ......................................... 5
CE Compliance ................................................................. 6
CE mark............................................................................ 6
Following Information is Only for EU-Member States ..................... 6
Copyright Statement ........................................................................7
Disclaimer ....................................................................................... 7
Trademarks ...................................................................................... 7
Introduction ..................................................................................... 8
Package Contents ............................................................................ 8
Computer Requirements ................................................................. 9
Installing the Software ..................................................................... 9
Using the USB Flash Drive on your Computer ............................... 12
Basic Operation ............................................................................. 15
Changing Settings ......................................................... 15
Remove the USB Flash Drive ......................................... 18
Others ........................................................................... 19
Troubleshooting ............................................................................ 20
Specifications* .............................................................................. 20

Safety Icons 3
Safety Icons
This manual contains safety instructions that must be observed
to avoid potential hazards that could result in personal injuries,
damage to your equipment, or loss of data. These safety
cautions have been classified according to the seriousness of the
risk, and icons highlight these instructions as follows:
Indicates an imminently hazardous situation which, if not
avoided, will result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, could result in death or serious injury.
Indicates a potentially hazardous situation which, if not
avoided, may result in minor or moderate injury.
Indicates a potentially hazardous situation which, if not
avoided, may result in property damage.
Provides important information.

Safety Instructions
4
Safety Instructions
To protect against risk of fire, bodily injury, electric shock or
damage to the equipment:
❖Do not immerse any part of this product in water or other
liquid.
❖Do not spray liquid on this product or allow excess liquid
to drip inside.
❖Do not use this product if it has sustained any type
of damage.
❖Disconnect this product before cleaning.
Regulatory statements
FCC Information
FCC notice "Declaration of Conformity Information"
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the
FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
❖Reorient or relocate the receiving antenna.
❖Increase the separation between the equipment and
receiver.

Regulatory statements 5
❖Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
❖Consult the dealer or an experienced radio/TV technician
for help.
Only peripherals complying with the FCC class B limits
may be attached to this equipment. Operation with
noncompliant peripherals or peripherals not
recommended by TOSHIBA is likely to result in
interference to radio and TV reception. Shielded cables
must be used between the external devices and the
replicator's ports.
Changes or modifications made to this equipment, not
expressly approved by TOSHIBA or parties authorized by
TOSHIBA, could void the user’s authority to operate the
equipment.
FCC Conditions
This equipment has been tested and found to comply with Part
15 of the FCC Rules. Operation is subject to the following two
conditions:
❖This device may not cause harmful interference.
❖This device must accept any interference received,
including interference that may cause undesired operation.
Contact
Industry Canada Requirement
This Class B digital apparatus complies with Canadian ICES-
003.
Address:TOSHIBA America Information Systems, Inc.
9740 Irvine Boulevard
Irvine, California 92618-1697
Telephone:[phone]

Following Information is Only for EU-Member States
6
Cet appareil numérique de la classe B est conformé à la norme
NMB-003 du Canada.
CE Compliance
This product is CE marked in accordance with the
requirements of the applicable EU Directives.
Responsible for CE-marking is Toshiba Europe
GmbH, Hammfelddamm 8, 41460 Neuss,
Germany. A copy of the official Declaration of
Conformity can be obtained from following
website: http://epps.toshiba-teg.com/
CE mark
The product is not CE marked itself because of the total size
but the product is fully compliant to the relevant EMC
requirements for CE marking.
Following Information is Only for EU-Member States
Disposal of Products
The crossed out wheeled dust bin symbol indicates that products
must be collected and disposed of separately from household
waste. Integrated batteries and accumulators can be disposed of
with the product. They will be separated at the recycling centres.
The black bar indicates that the product was placed on the
market after August 13, 2005.
By participating in separate collection of products and batteries,
you will help to assure the proper disposal of products and
batteries and thus help to prevent potential negative
consequences for the environment and human health.
For more detailed information about the collection and
recycling programmes available in your country, please visit our
website (http://eu.computers.toshiba-europe.com) or contact
your local city office or the shop where you purchased the
product.

Copyright Statement 7
Copyright Statement
This guide is copyrighted by Toshiba Corporation with all
rights reserved. Under the copyright laws, this guide
cannot be reproduced in any form without the prior written
permission of Toshiba. No patent liability is assumed,
however, with respect to the use of the information
contained herein.
©2009 by TOSHIBA Corporation. All rights reserved.
©2009 Hasbro. All rights reserved.
©TOMY
Disclaimer
Information in this document is subject to change without
notice. The manufacturer does not make any representations or
warranties (implied or otherwise) regarding the accuracy and
completeness of this document and shall in no event be liable
for any loss of profit or any commercial damage, including but
not limited to special, incidental, consequential, or other
damage.
September 2009, Rev1.0
Trademarks
Microsoft, Windows, Windows XP, and Windows Vista are
either registered trademarks or trademarks of Microsoft
Corporation in the United States and/or other countries.
Macintosh and Mac OS are registered trademarks of Apple Inc.
Other trademarks or brand names mentioned herein are
trademarks or registered trademarks of their respective
companies.

Introduction
8
Introduction
Thank you for purchasing the Device Label "Ravage"/
"Tigatron" operating USB Flash Drive!
This USB Flash Drive is actually a transformers-like toy which
can be transformed into the shape of a Ravage/Tigatron. What’s
more, with the fun application, you can enjoy its animations on
your computer. The cool on-screen appearance and vivid
actions will give you with a wonderful experience!
There are two types of USB Flash Drive---- the black-colored
Ravage and the white-colored Tigatron, which have the same
features. This manual is based on the Ravage. To find out how
to transform between the USB Flash Drive and the Ravage,
please refer to the Quick Start Guide provided with your
product.
Package Contents
Check to make sure you have all of the following items:
❖Quick Start Guide
❖Device Label "Ravage" or "Tigatron" operating USB
Flash Drive (contains User's manual [this documentation]
and driver)

Computer Requirements 9
Computer Requirements
This system requirements are only for the software application.
To operate the USB Flash Drive, you need a computer with the
following specifications:
Installing the Software
Component Requirement
Operating System Microsoft®Windows®XP
Windows Vista®
CPU 1.6 GHz or higher processor. Intel®
Pentium®/Celeron®family, or AMD K6®/
AMD Athlon™/AMD Duron™family, or
compatible processor recommended
(Intel®Core™2 Duo 2.0 GB or higher
processor recommended for
performance)
Available Disk Space 150M
Memory (RAM) 512 MB or more (Windows®XP)
1GB or more (Windows Vista®)
USB Interface USB 2.0 or USB 1.1 supported

Installing the Software
10
1Plug the USB Flash Drive's connector into an available
USB port on your computer.
2The Transformers Install Menu will be displayed on
your computer screen.
If the Transformers Install Menu is not displayed, follow
these steps:
In Windows®XP:
1) Double-click the My Computer icon on your desktop.
2) Double-click “CD Drive PA3772” and then double-click
AutoRun.exe.
In Windows Vista®:
1) Click Start->Computer.
2) Double-click “CD Drive PA3772” and then double-click
AutoRun.exe.
USB port

Installing the Software 11
3Click Install Transformers Utility.
4Follow the on-screen instructions to complete installation.
If you do not want to show this screen anymore, you can
select the “Do not show this screen again.” box.
5A shortcut icon will be placed on the desktop.
6Unplug the USB Flash Drive from your computer.
To disconnect the USB Flash Drive, double-click the
Unplug/Safely Remove/or Eject Hardware icon in the
system tray in the lower right of your screen. When the
window appears, select the name of the device that you
want to remove and then click Stop. A “This device can
now be safely removed from the computer” message will
be dispalyed. Click OK and then remove it from the USB
port.

Using the USB Flash Drive on your Computer
12
Using the USB Flash Drive on your Computer
1Launch the "Transformers Desktop Defender" application.
You may need to manually start the application in one of
the following ways:
❖ double-click the shortcut icon on the desktop;
❖ select Start->All Programs->TOSHIBA
->Transformers Desktop Defender.
The application icon ( ) will then appear in the system
tray.
The first time you use the USB Flash Drive on your
computer, the application must be started manually.
However, if you have already enabled the "Auto Start"
function ( see page 19), the application will start
automatically when you start the computer.
2Make sure the application has been started, then plug the
USB Flash Drive's connector into an available USB port
on your computer.
3The Ravage animation will appear on the screen.

Using the USB Flash Drive on your Computer 13
a The device will appear in the shape of a normal USB
Flash Drive.
b The USB Flash Drive on the screen will then begin to
transform into the shape of the Ravage.
c The Ravage will then perform a series of movements
randomly.
- walk, jump, run, creep, kick, pause, sleep
- shock, roar
- eat icon
- transform
Among the above, roar, eat icon, jump, and transform
movement can be started immediately by right-clicking
the Ravage on the screen and selecting Demo->Roar/
Eat Icon/Jump/Transform.
For optimal visual effect, it is recommended you set the
background color to one that contrasts with the Ravage.

Using the USB Flash Drive on your Computer
14
For the detailed explanation and of the four demo movements,
please refer to the table as below.
Movement Appearance Description
roar The Ravage roars on the screen, raising its
head to the sky but there is no sound
associated with this movement.
eat The Ravage will eat the desktop icons
displayed on your screen. You can restore
these icons by:
-selecting Resume Icons after right-clicking
the Ravage on the screen or the application
icon in the system tray
-un-plugging the USB Flash Drive from your
computer
-clicking the Ravage and pressing the F5 or
Q key of your computer
Please note that the eat function won’t work
on the external display.
jump The Ravage will jump on or off the screen.
When the Ravage jumps to the edge of the
screen, it will go off the screen and turn
around. If you are using an external monitor,
the Ravage will also jump onto the screen of
the external monitor.
transform - The Ravage will transform from a USB Flash
Drive into the shape of the Ravage. Refer to
Page 13 for the detailed information.

Basic Operations 15
When dragging the Ravage using the mouse, the Ravage will
shake, then run or jump away.
Once the Ravage goes sleeping, it will lasts for about 2 minutes.
After sleeping, the Ravage will stand up and perform other
actions. You can also wake up the Ravage by dragging and
dropping it.
When you un-plug the Ravage, the Ravage will disappear
from the screen and all the changes made by this Ravage
will be undone.
Basic Operations
Changing Settings
To configure the settings of the Ravage, please follow one of the
methods as below.
❖Click or right-click the application icon ( ) in the
system tray of your Windows®desktop, point to the name
of the desired USB Flash Drive and select Setup from the
shortcut menu.

Basic Operations
16
❖Right-click the animated Ravage on the screen and select
Setup from the shortcut menu.
In the “Setup” window, you can view and modify the
information for your target Ravage:

Basic Operations 17
Field Name Description Default Setting
Ravage/
Tigatron
Switch between the Ravage and Tigatron
animations.
If you change the character, the basic
information will change immediately, and the
character on the screen will change after you
clicking OK.
Displays according to
the physical shape of
your USB Flash Drive.
Name Name of the Ravage.
You can change this name (e.g. change to “My
Device”), which will be applied to the shortcut
menu immediately.
The name could be a string of up to 50
characters and it should not be blank.
Ravage1, Ravage2,
Ravage3...etc
Character
Movement
Speed of the Ravage. Set to midium speed.
Character
Nature
Ranging between lazy and active, this setting
will determine the actions of the animation.
If the slider is moved to the leftmost, the
Ravage will sleep for most of time;if the slider
is moved to the rightmost, the Ravage will run
or jump for most of time. Besides this, it will
do the walking, turning around, roaring,
pausing, creeping, eating and kicking.
Set to medium range of
activity.

Basic Operations
18
Follow the steps below to modify settings.
1(Optional) You can switch between Ravage and Tigatron,
or modify the Ravage's name in the "name" text box.
2(Optional) You can change some settings in the “Setting”
area, including “Character Movement”, “Character
Nature”, whether the animation will eat icons, etc.
3Click OK to confirm the changes. To cancel changes, click
Cancel.
After clicking OK, all settings will be written on to the USB
Flash Drive. When you use the Ravage on another
computer, all the settings stored to this Ravage will be
preserved.
Remove the USB Flash Drive
Remove one USB Flash Drive
You can remove one USB Flash Drive using one of the
following methods.
❖Click or right-click the application icon ( ) in the
system tray of your Windows®desktop, point to the name
of the desired USB Flash Drive and select Remove USB
Drive from the shortcut menu.
Do not eat icon If this check box is selected, the Ravage will
not eat desktop icons.
If this check box is not selected, the Ravage
will randomly eat desktop icons.
Not selected
Hide Character If this check box is selected, the animated
Ravage will not appear on the desktop.
You can also enable this function by clicking
or right- clicking the system tray icon and
selecting Hide Character in the shortcut menu.
Not selected

Basic Operations 19
❖Right-click the Ravage on the screen and select Remove
USB Drive from the shortcut menu.
Remove all the USB Flash Drive
❖Click or right-click the application icon ( ) in the
system tray of your Windows®desktop and select
Remove all Drives from the shortcut menu.
Even though your USB Flash Drive has been removed, the
application will not be closed automatically. You can
activate the Ravage on the screen by removing and re-
inserting it.
Others
You can select the options below by clicking or right-clicking
the application icon ( ) in the system tray of your
Windows®desktop.
Auto Start
❖If this item is selected, the application will start up
automatically every time you start your computer.
Demo
❖Start the Roar/Eat Icon/Jump/Transform movement
immediately.
Help
❖The User’s Manual will be displayed on the screen.
About
❖The copyright and version information will be displayed
on the screen.
Exit
❖The application will close.

Troubleshooting
20
Troubleshooting
Specifications*
There is another partition named “CD Drive PA3772”
which stores the drivers and the User’s Manual in the USB
Flash Drive. If you format the USB Flash Drive, this “CD
drive” will be preserved. You cannot delete the content in
this “CD drive”.
*Specifications are subject to change without further notice.
Problem Solution(s)
The USB Flash
Drive does not
work on your
computer.
Make sure you have installed the application correctly.
Make sure the application has already been started before you insert
the USB Flash Drive into your computer. Please see “Using the USB
Flash Drive on your Computer” on Page 12.
Make sure the USB Flash Drive is plugged into an available USB port
on your computer.
Make sure the USB Flash Drive has been properly detected by the
operating system. Refer to your computer documentation for correct
port configuration.
Operating System Windows®XP / Windows Vista®/
Windows®7
Mac OS®X 10.3 or later
*Software application does not support Mac
OS and Windows 7.
Memory Size 2GB or 4GB (including drivers and User’s
Manual)
Power Consumption 110mA
Dimensions(W x H x D) Approximately 28(W) x 10(H) x 65(D)
mm
Weight Approximately 17 grams
Operating humidity 20%~80% (non-condensing)
Operating temperature 5°C to 35°C (41°F to 95°F)
