total sheds Pent Shed User manual

Pent Shed Assembly Manual
Total Sheds
28 Charles Street,
Willenhall, WV13 1HG
Tel: [phone]
Email: [e-mail]
Version 1.1
Ready to Build - 6ft Range
Includes 4x6ft to 20x6ft Instructions
SHEDS • SUMMER HOUSES • KENNELS
© Sheds (Midlands) Limited 2021
www.totalsheds.co.uk
Featured Build of the Pent 10x6ft Shed
Pressure Treated Tanalised Timber for Longer Lasting Life!
PRESSURE TREATED TIMBER
TOTAL SHEDS
Thank you for purchasing your Total Shed.
All of our sheds are made from only the nest selected
timber which are (Tanalised), specially pressure treated
for a longer and lasting durable life span to the elements.
Each shed is carefully packed and delivered
on a pallet ready to be assembled.
Tools Required to Build:
2 Persons Recommended for Assembling Shed
STANLEY
KNIFE
HAMMER DRILL
DRIVER
PLEASE NOTE: Use extreme caution when using any tools. Always wear safety gear where necessary. It is advisable
that at least 2 or more persons assemble the shed for health and safety purposes. We are not responsible for any
injuries caused whilst assembling this shed.
FEATURES NEW FLEXIBLE,
INTER-CHANGEABLE DESIGN
FOR YOUR INDIVIDUAL STYLE.
Ready to Build Shed
DELIVERED FLAT PACKED IN EASY
TO INSTALL SECTIONS...

20x6ft Pent Range
© Sheds (Midlands) Limited 2021
Check List: See your shed size for details.
Your delivery should contain the following:
If your thinking of mixing it up then just a
few key points to bare in mind.
All 4ft panels can be tted in any order but 2ft panels
must always be tted on far left of shed build.
Take a few moments to study the manual and get an idea
of how your shed should look after each step.
4x6ft Pack
x1 Floor (4x6ft)
x1 Pent Roof Section (4x6ft)
x2 Pent Angle Tops (6ft)
x1 Pent Roof Top (4ft)
x2 Blank Panels (4ft Wide)
x2 Blank Panels (2ft Wide)
x1 Door Panel
x1 Window Panel
x2 Heavy Duty Posts (6ft)
x4 Felt Strips (4ft x2) (6ft x2)
x6 Corner Strips
x2 Diamond Caps
x1 Fixing Kit
Single Double
Single Double
4x6ft PENT SHED
10x6ft PENT SHED 12x6ft PENT SHED
(found in the polytube pack)
Instruction Manual
Checked & Signed by:
(found in the polytube pack)
Instruction Manual
Checked & Signed by:
(found in the polytube pack)
Instruction Manual
Checked & Signed by:
(found in the polytube pack)
Instruction Manual
Checked & Signed by:
(found in the polytube pack)
Instruction Manual
Checked & Signed by:
8x6ft Pack
x2 Floors (4x6ft)
x2 Pent Roof Section (4x6ft)
x2 Pent Angle Tops (6ft)
x2 Pent Roof Tops (4ft)
x8 Felt Strips (4ft x6) (6ft x2)
x1 Door Panel
x4 Blank Panels (4ft Wide)
x2 Blank Panels (2ft Wide)
x2 Heavy Duty Posts (6ft)
x1 Window Panel
x8 Corner Strips
x2 Diamond Caps
x3 Roof Felt (9ft Lengths)
x1 Fixing Kit
12x6ft Pack
x3 Floors (4x6ft)
x2 Heavy Duty Posts (6ft)
x3 Pent Roof Section (4x6ft)
x2 Pent Angle Tops (6ft)
x3 Pent Roof Tops (4ft)
x5 Blank Panels (4ft Wide)
x2 Blank Panels (2ft Wide)
x2 Window Panels
x1 Door Panel
x4 Diamond Caps
x3 Felt (13ft Length)
x1 Fixing Kit
x8 Felt Strips
(4ft x6) (6ft x2)
x10 Corner Strips
6x6ft Pack
Floors 1x (4x6ft) 1x (2x6ft)
Pent Roof Sections 1x (4x6ft) 1x (2x6ft)
Pent Roof Tops 1x (4ft) 1x (2ft)
x2 Blank Panels (4ft Wide) x4 Panels (2ft Wide)
x2 Pent Angle Tops (6ft)
x1 Door Panel
x6 Felt Strips (2x 6ft) (2x 4ft) (2x 2ft)
x1 Window Panel
x2 Heavy Duty Posts (6ft)
x8 Corner Strips
x2 Diamond Caps
x3 Roof Felt (7ft Lengths)
x1 Fixing Kit
Single Double
10x6ft Pack
Floors 2x (4x6ft) 1x (2x6ft)
Pent Roof Sections 2x (4x6ft) 1x (2x6ft)
Pent Roof Tops 2x (4ft) 1x (2ft)
x4 Blank Panels (4ft Wide) x4 Panels (2ft Wide)
x2 Pent Angle Tops (6ft)
x1 Door Panel
x8 Felt Strips (4ft x4) (6ft x2) (2ft x2)
x2 Heavy Duty Posts (6ft)
x1 Window Panel
x10 Corner Strips
x4 Diamond Caps
x3 Roof Felt (11ft)
x1 Fixing Kit
Single Double
Single
Double
6x6ft PENT SHED
8x6ft PENT SHED
FLEXIBLE, INTER-CHANGEABLE
PANELS FOR YOUR INDIVIDUAL
STYLE & PREFERENCE...

(found in the polytube pack)
Instruction Manual
Checked & Signed by:
x1 Fixing Kit
(found in the polytube pack)
Instruction Manual
x2 Heavy Duty Posts (6ft)
x1 Fixing Kit
(found in the polytube pack)
Instruction Manual
x1 Fixing Kit
(found in the polytube pack)
Instruction Manual
14x6ft Pack
Floors 3x (4x6ft) 1x (2x6ft)
Pent Roof Sections 3x (4x6ft) 1x (2x6ft)
Pent Roof Tops 3x (4ft) 1x (2ft)
x5 Blank Panels (4ft Wide) x4 Panels (2ft Wide)
x2 Pent Angle Tops (6ft)
x10 Felt Strips (6x 4ft) (2x 6ft) (2x 2ft)
x1 Door Panel
x2 Heavy Duty Posts (6ft)
x2 Window Panels
x12 Corner Strips
x6 Diamond Caps
x3 Roof Felt (15ft Lengths)
x1 Fixing Kit
Single Double
Single Double
18x6ft Pack
Floors 4x (4x6ft) 1x (2x6ft)
Pent Roof Sections 4x (4x6ft) 1x (2x6ft)
Pent Roof Tops 4x (4ft) 1x (2ft)
x6 Blank Panels (4ft Wide) x4 Panels (2ft Wide)
x2 Pent Angle Tops (6ft)
x1 Door Panel
x2 Heavy Duty Posts (6ft)
x3 Window Panels
x10 Felt Strips (4ft x8)
(6ft x2) (2ft x2)
x12 Corner Strips
x8 Diamond Caps
x3 Roof Felt
(19ft Lengths)
Single Double Single Double
Checked & Signed by: Checked & Signed by:
© Sheds (Midlands) Limited 2021
14x6ft PENT SHED 16x6ft PENT SHED
18x6ft PENT SHED 20x6ft PENT SHED
16x6ft Pack
x4 Floors (4x6ft)
x4 Pent Roof Section (4x6ft)
x2 Pent Angle Tops (6ft)
x4 Pent Roof Tops (4ft)
x1 Door Panel
x6 Blank Panels (4ft Wide)
x2 Blank Panels (2ft Wide)
x2 Heavy Duty Posts (6ft)
x3 Window Panels
x10 Felt Strips
(8x4ft) 2x 6ft)
x12 Corner Strips
x6 Diamond Caps
x3 Roof Felt
(17ft Lengths)
Checked & Signed by:
20x6ft Pack
x5 Floors (4x6ft)
x5 Pent Roof Section (4x6ft)
x2 Pent Angle Tops (6ft)
x5 Pent Roof Tops (4ft)
x1 Door Panel
x7 Blank Panels (4ft Wide)
x2 Blank Panels (2ft Wide)
x4 Window Panels
x12 Felt Strips
(4ft x10) (6ft x2)
x14 Corner Strips
x8 Diamond Caps
x3 Roof Felt (21ft)

www.totalsheds.co.uk
STEP • 1
Unpack all of the components and check that you
have all the parts required. Please use the checklist on
previous page.
Carefully dispose of the delivery pallet and any
excess timber.
Advisable: The underside of the oor must be
treated with a quality wood preserver.
1a. Place the 6ft side ends of the oors to match as below, then
screw together using screws provided at the end of the bearer
points. Use RED areas as joining points.
1b. Repeat this process for larger sheds in similar fashion.
1c. Check that all oor sections are securely attached and in a
straight line to avoid any problems later on the build stage.
Use a Spirit Level if need be to get accurate results.
Recommended: Paint shed in an oil based treatment to
prevent water ingress into the timber. Also silicon your
windows (Must silicon inside & outside) to prevent rain water
seeping through the gaps between glass and the timber.
PRE ASSEMBLY
SHED FLOOR: Set your shed base.
Page 4
Unpacking your parts:
SET THE SHED FOUNDATION
= Drill Points using
screws provided as shown
4x6FT SHED FLOOR
4x6FT SHED FLOOR
8x6FT SHED FLOOR LAYOUT
2x6FT SHED FLOOR
x2
4.0 x 70mm
Per Floor Section
Diagrams based on
10x6ft Pent Shed
This Manuals Diagrams are based on the
10x6ft Pent Shed
NOTE: 4x6ft Sheds Please Skip to STEP 2
6x6ft Sheds: Add 2ft oor
Repeat Steps with 4x6ft
Floors as shown below:
8x6ft
10x6ft
12x6ft
14x6ft
16x6ft
18x6ft
20x6ft
Repeat x1
Repeat x1
Repeat x2
Repeat x3
Repeat x3
Repeat
Repeat
x3
x4
1d.
1d. Secure the oor sections together
by screwing the oor bearers at each
end where they meet as shown
in diagram 1d.
8x6ft
Shed 10x6ft Shed 12x6ft Shed 14x6ft Shed 18x6ft Shed 20x6ft Shed
16x6ft
Shed
6x6ft
Shed
PRESSURE TREATED TIMBER
TOTAL SHEDS
Shed Floor Build Guide
Follow the above layout according
to your shed size.
Shed Floors indicated
in Green will have 2ft Floor
Section included.
4x6ft
6ft
4ft
6ft
8ft
10ft
12ft
14ft
16ft
18ft
20ft
6x6ft
8x6ft
10x6ft
12x6ft
14x6ft
16x6ft
18x6ft
20x6ft
DRILL
DRIVER
+
6x4ft
6x2ft
4x6ft
Shed
6x4ft
6x4ft
+
6x4ft
+
6x4ft
6x4ft
+
6x2ft
+
6x4ft
6x4ft
+
6x4ft
+
6x2ft
6x2ft
+
6x4ft
+
+
6x4ft
+
+
6x4ft
6x4ft
+
6x4ft
6x4ft
+
6x4ft
6x4ft
+
6x4ft
6x4ft
6x4ft
+
6x4ft
+
6x4ft
+
6x4ft
+
6x4ft
+
6x4ft
PLEASE NOTE: 6ft • 10ft •
14ft & 18ft Sheds always
start with laying
2x6ft Floor First! then...

FLOOR & BLOCK ENDS
Add the Floor Block Ends.
(Heavy Duty Posts 6ft)
www.totalsheds.co.uk
© Sheds (Midlands) Limited 2021
STEP • 3STEP • 2 Page 5
IMPORTANT
6ft, 10ft, 14ft & 18ft
Sheds must add
2ft oor on left end.
As shown on this diagram.
Begin with right side of shed
oor with a blank 2ft panel.
Next step will be the back 4ft
panel to create an‘L’ Frame
= Drill Points using
screws provided as shown
2b.
2a.
HEAVY DUTY POSTS
10x6FT SHED FLOOR LAYOUT
DRILL
DRIVER
2a. Place the 6ft long Floor Block Ends
provided on both ends of the oor alongside
existing oor bearers as shown below.
2b. Fix together by screwing the Floor
Blocks at each end as shown. Use the
screws provided and make sure the ends
are xed securely. 3 screws on each
end will suce.
x3
4.0 x 70mm
Per Gable Section
PLEASE NOTE: Larger sheds will have extra oor sections
so please ensure all sections are connected correctly then
the Floor Blocks are added only after the oor is complete.
2ft RIGHT SIDE PANEL
Attach 2ft Wide Section
Side Wall 2ft Blank Section
3a. Place the 2ft panel side against the far right side of
shed oor shown making sure the panel is sitting rmly on
6ft Heavy Duty Bearer (Floor Block).
3b. Now prepare a 4ft blank panel to make an ‘L’ shape with
the 2 frames (2ft & 4ft Blank Panels)
See Step 4
3c. DO NOT x the panels at this stage to the oor
to leave room for adjustments in the nal stages.
Next Step will create a corner frame balance with 4ft panel.
= Drill Points using
screws provided as shown
DRILL
DRIVER

© Sheds (Midlands) Limited 2021
STEP • 5
SIDE & REAR PANELS
Fix 4ft Wide Blank Sections
Create Corner for Balance.
4a. Now place a blank 4ft panel side as shown. Create an ‘L’ Shape.
Repeat this step for all larger sheds. Please use reference on left for
additional sections required according to your shed size.
4b. Screw the panels at the framework as shown in Diagram 5b.
5b.
4b.
= Drill Points using
screws provided as shown
x3
4.0 x 70mm
Per Panel Edge
x3
4.0 x 70mm
Per Panel Edge
4FT BLANK PANEL
2FT BLANK PANEL
NOTE: Place panel to sit rmly
on the side Floor Block.
5a. Place the 4ft blank panel as shown along the
right end of the shed aligning with the edge of the
2ft panel and Floor Block. See Diagram 5a.
Use RED highlighted area as guide.
5b. It is advisable to have a
second person holding the
panel in place while the next
section is attached. You may
notice that the panels will have
nothing to balance on or againts
at this stage. It is advisable to use
supports if required at this stage
till the corner frames are
attached for balance.
5c. Screw the panels together as
shown on diagram 5c.
4ft RIGHT SIDE PANEL
Place blank 4ft panel against
right of shed oor as shown.
(4ft wide blank panel)
SHED FLOOR
5a.
IMPORTANT
Start Build point from Left to Right.
As shown on the diagram. NOTE: First 4ft Panel must sit rmly on oor block
4FT BLANK PANEL
Repeat Steps with 4ft Blank
Panels as shown below:
4c. DO NOT x
the panels at this
stage to the oor
to leave room for
adjustments in
the nal stages.
www.totalsheds.co.uk
STEP • 4 Page 6
8x6ft
10x6ft
12x6ft
14x6ft
16x6ft
18x6ft
20x6ft
Repeat x1
Repeat x1
Repeat x2
Repeat x3
Repeat x3
Repeat
Repeat
x3
x4
4a.
5c.
DRILL
DRIVER
DRILL
DRIVER

STEP • 6
2ft REAR PANELS
Fix 2ft Wide Blank Section
Last Back Panel 2ft Section
6a. Place the 2ft panel side against the reamining 4ft back
panels as shown making sure the panel is sitting rmly on
the shed oor and the side meeting the framework of the
back 4ft blank panel.
6b. Fix the panels together with screws as shown in diagram.
You may require some supports to keep frames
upright whilst building longer sheds.
Use RED Area as
placement guide.
= Drill Points using
screws provided as shown
x3
4.0 x 70mm
Per Panel Edge
Page 7
6b.
© Sheds (Midlands) Limited 2021
STEP • 7
2ft LEFT SIDE PANEL
Attach Left 2ft Section
Side Wall 2ft Blank Section
7a. Place the 2ft panel side against the corner of the back
2ft oor as shown making sure the panel is sitting rmly on
the shed oor and the side meeting the framework of the
back 2ft blank panel.
7b. Fix the panels together with screws as shown in diagram
7b. You may require some supports to keep the frame upright
whilst building longer sheds.
Use RED Area as
placement guide.
= Drill Points using
screws provided as shown
x3
4.0 x 70mm
Per Panel Edge
7b.
DRILL
DRIVER
DRILL
DRIVER
SKIP Step
Jump to Step 7
NOTICE:
8x6ft
12x6ft
16x6ft
20x6ft
SKIP Step
SKIP Step
SKIP Step

www.totalsheds.co.uk
© Sheds (Midlands) Limited 2021
FRONT DOOR PANEL
Attach nal Front Panel
(4ft Panel: Single or Double Door)
DID YOU KNOW?
Door panels can be placed
anywhere a 4ft panel is, this
counts for window panels too.
STEP • 8 Page 8
LEFT SIDE PANEL
Now attach Left Side Panel
(4ft wide left blank section)
8a. Place the 4ft left side panel as shown below.
Screw sections together as shown in diagram 8a.
8b. Check that all the frames are correctly xed and
screwed together from the sides. Use more screws to
strengthen if necessary.
= Drill Points using
screws provided as shown x3
4.0 x 70mm
Per Panel Edge
Use Red Area as placement guide.
Use Red Area as placement guide.
STEP • 9
9a. Now start back from the Right side placing the 4ft
Door Panel as shown. Fix together with screws to the
right side panel framework as shown in diagram 9a.
DO NOT screw the standing
panels down to the oor just yet.
Leave room for adjustments when the nal frame is tted.
DO NOT screw the standing
panels down to the oor just yet.
Leave room for adjustments when the nal frame is tted.
= Drill Points using
screws provided as shown
x3
4.0 x 70mm
Per Panel Edge
8a.
9a.
DRILL
DRIVER
DRILL
DRIVER

STEP • 10
© Sheds (Midlands) Limited 2021
WINDOW PANELS
Attach Window Panels
(4ft Window Panels)
10a. Place 4ft front window panel as shown and x in place at the
meeting points with screws. Fix the panel sides with 3 screws.
10b. Repeat this step for larger models as
shown on the diagram to the left.
DID YOU KNOW?
Window panels can be placed anywhere a
4ft panel is, this counts for door panel too.
Use the RED Area as placement guide.
= Drill Points using
screws provided as shown
x3
4.0 x 70mm
Per Window Panel
DO NOT screw the standing
panels down to the oor just yet.
Leave room for adjustments when the nal frame is tted.
Repeat Steps with 4ft
Window Panels as below:
x2
x3
x3
x3
x4
www.totalsheds.co.uk
Page 9
2ft FRONT PANEL
Place the Final 2ft Panel
For 6ft, 10ft, 14ft & 18ft Sheds
11a. Place the nal front panel as shown below to complete
the outer framework. Then adjust and screw down the
panels to the shed oor to make the build secure.
11b. Use the RED areas below as reference to the joining
points of the nal panel. Note the 2ft section should t
perfectly to complete the front section.
11c. Make sure all panels are straight and screwed down
rmly to each other to strengthen the outer framework
before continuing.
= Drill Points using
screws provided as shown
x6
4.0 x 70mm
Final 2ft Panel
9b.
9c.
STEP • 11
12x6ft
14x6ft
16x6ft
18x6ft
20x6ft
Repeat x1
Repeat x1
Repeat x2
Repeat
Repeat
x2
x3
DRILL
DRIVER
DRILL
DRIVER
SKIP Step
Jump to Step 12
NOTICE:
8x6ft
12x6ft
16x6ft
20x6ft
SKIP Step
SKIP Step
SKIP Step

www.totalsheds.co.uk
© Sheds (Midlands) Limited 2021
STEP • 13STEP • 12 Page 10
x2
4.0 x 70mm
Per Front Tops
SIDE PENT ANGLETOPS
Now attach all the SideTops
of Pent Shed End Panels.
PENT FRONTTOPS
Place the front tops of shed.
Use 2ft Section for below models.
6x6ft • 6x10ft • 6x14ft • 6x18ft
12a. Place the right and left Pent Angle Tops as shown below.
Make sure the higher ends are at the front of the shed as shown in the diagram below.
12b. Adjust the panels so that the tounge & groove are xed together in place correctly.
Use a hammer to lightly tap in to the grooves to create a perfect t.
13a. Place the 4ft Pent Front Top sections in place. Use any 2ft sections if your shed size is
one of the above. Make sure the 2ft section is placed on top of the 2ft front panel only as
shown in the diagram.
13b. Adjust the panels so that the tounge & groove are
xed together in place correctly. Use a hammer to lightly
tap in to the grooves to create a perfect t.
13c. Attach the sections down by screwing through
the inner frameworks of both panels.
12c. Attach the sections down by screwing through
the inner frameworks of both panels.
= Drill Points using
screws provided as shown
= Drill Points using
screws provided as shown
x4
4.0 x 70mm
DRILL
DRIVER
DRILL
DRIVER

www.totalsheds.co.uk
© Sheds (Midlands) Limited 2021
STEP • 15STEP • 14 Page 11
SIDE & CORNER STRIPS
Hide the panel edges.
Cover the framework & seams.
14a. Use all the side/corner strips to nish off the shed,
by covering any exposed framework and the panel
joining seams.
14b. Fix the strips down by using 3 screws to
secure them to the shed. This will create a nice
nish and hide any gaps on the outer walls of
framework, front, back and sides.
14c. Continue this process along the sides and
rear of the shed till you have covered all
exposed panel edges and seams.
PENT ROOF PANELS
Place 4x6ft roof section.
Repeat for larger models as shown.
15a. Place the 4x6ft roof section in
place. Repeat this stage for models
as shown below. 2ft roof section will
follow last. Shown in Step 16.
15b. Screw the roof panel down as
shown in Diagram 15b.
= Drill Points using
screws provided as shown = Drill Points using
screws provided as shown
x6
4.0 x 70mm
x24
4.0 x 70mm
15b.
14b.
Repeat Steps for 4x6ft Roof
Panels as shown below:
8x6ft
10x6ft
12x6ft
14x6ft
16x6ft
18x6ft
20x6ft
Repeat x1
Repeat x1
Repeat x2
Repeat x3
Repeat x3
Repeat
Repeat
x3
x4
DRILL
DRIVER
DRILL
DRIVER

Make nal adjustments
if required. NOW DRILL SHED TO THE FLOOR
www.totalsheds.co.uk
© Sheds (Midlands) Limited 2021
STEP • 17
STEP • 16
Page 12
2ft ROOF SECTION
Place 2x6ft roof section last. ATTACH THE ROOF FELT
Use the felt lengths provided.
16a. Place the 2ft roof section at the far
left end of roof if your shed size is a 6ft, 10ft, 14ft & 18ft.
16b. Please note that the roof sections should sit rmly on
the top of the front and rear panels and have the same
height as the side Pent Angle Tops.
16c. You will notice the gaps in
the roof as above. This is normal
and will be covered by the roof
felt material once applied.
17a. Apply the roof felt as shown. Apply lower levels
rst to create correct rain run off positions.
17b. Using a hammer, tack down the felt
with the tacks provided in a neat fashion.
17c. Trim down excess felt with a stanley knife.
Remember to overlay the 1st felt to avoid rain leaks.
• 1st Section Lower Back
•2nd Section Middle of roof overlaying section 1
17d. Tuck and fold edges neatly and tack in place
to hide any loose edges. Check that all areas are
covered and there are no holes to avoid any rain
water getting through your felt roof.
= Drill Points using
screws provided as shown
x4
4.0 x 70mm
STANLEY
KNIFE
HAMMER
1st Sheet at lower of roof
2nd Sheet in midde
3rd sheet on top front
Trim edges with 3” over
Fold & tack edges neatly
A
B
C
D
E
TACKS PROVIDED
16b. • 3rd and last section on top front of roof overlaying section 2
DRILL
DRIVER
6x6ft • 6x10ft • 6x14ft • 6x18ft
SKIP Step
Jump to Step 17
NOTICE:
8x6ft
12x6ft
16x6ft
20x6ft
SKIP Step
SKIP Step
SKIP Step

www.totalsheds.co.uk
© Sheds (Midlands) Limited 2021
STEP • 19
STEP • 18 Page 13
ATTACH FELT STRIPS
Create the Final Roof Edges.
Final steps nishing off the roof.
DIAMOND CAPS
Add the FinishingTouch.
18a. Using the felt strips provided cover the edges of the roofs
and ends of the roof felt. You will need to measure these to t
to your requirements and create the perfect roof nish as
shown below.
18b. Drill in the felt strips as shown on front and back of the
shed to nish the roof off. Use the framework of the roof blocks
to screw the felt strips down to. The felt strips will give your
shed a neat nish for the roof and hide any overhang areas of
the roof felt.
18c. Felt Strips must be same height as roong felt to allow
rain water to run off. See Diagram on the right.
19a. Using the provided Diamond Caps you can
create a nice nishing touch to the Pent Shed.
This also covers the seam bewteen the Felt Strips and
hides any visible joints.
19b. Double check your shed for any loose bits or
areas that need further strengthening
or additional screws to secure further.
= Drill Points using
screws provided as shown
= Drill Points using
screws provided as shown
x18
4.0 x 70mm
x2
4.0 x 70mm
YOUR FINISHED!
YOUR ALMOST DONE BUILDING YOUR SHED...
Total Sheds
28 Charles Street,
Willenhall, WV13 1HG
Tel: [phone]
Email: [email protected].uk
18b.
19a.
DRILL
DRIVER
DRILL
DRIVER
18c.
Note: Felt Strip Positions
Enjoy Your New Shed.
T
Pressure Treated
Tanalised Timber for Longer
Lasting Life!
