Apex Shed Assembly Manual
Pressure Treated Tanalised Timber for Longer Lasting Life!
Version 1.4
Thank you for purchasing your Total Shed.
All of our sheds are made from only the nest selected timber which are
(Tanalised), specially pressure treated for a longer and lasting durable life
span to the elements.
Each shed is carefully packed and delivered on a pallet
ready to be assembled.
FEATURES NEW FLEXIBLE,
INTER-CHANGEABLE DESIGN
FORYOUR INDIVIDUAL STYLE.
DELIVERED FLAT PACKED IN
EASY TO INSTALL SECTIONS
2 Persons Recommended for Assembling Shed
PLEASE NOTE: Use extreme caution when using any tools. Always wear safety gear where
necessary. It is advisable that at least 2 or more persons assemble the shed for health and safety
purposes. We are not responsible for any injuries caused whilst assembling this shed.
Ready to Build Shed
Includes 5x4ft to 5x20ft Instructions
Featured Build of the Apex 5ft x 7ft Shed
DRILL DRIVER HAMMER HAND SAW STANLEY KNIFE
Tools Required:
www.totalsheds.co.uk
© Sheds (Midlands) Limited 2021
Total Sheds
Unit 1 Park Lane,
West Bromwich, B21 8LE
Tel: [phone]
Email: [e-mail]

+


4x5ft 4x5ft
4x5ft
4x5ft 4x5ft 4x5ft
4x5ft
4x5ft
2x5ft
3x5ft
















2x5ft
3x5ft
+
+
4x5ft
+
+
2x5ft
3x5ft
4x5ft
+
2x5ft
+
+
+
4x5ft
3x5ft
+
+
4x5ft
+
4x5ft
PRE-ASSEMBLY STEP • 1
01
Unpack all of the components and check that
you have all the parts required. Please use the
checklist on previous page.
Carefully dispose of the delivery pallet and
any excess timber.
Advisable: The underside of the oor must be
treated with a quality wood preserver.
Recommended: Paint shed
in an oil based treatment to
prevent water ingress into
the timber. Also silicon your
windows (Must silicon inside &
outside) to prevent rain water
seeping through the gaps
between glass and the timber.
SHED FLOOR: Setting Shed Base
Unpacking your Parts
SET THE SHED FOUNDATION
This Manuals Diagrams are based on the
5ft x 7ft Apex Shed
= Drill Points using
screws provided as shown
x3
x2
4.0 x 70mm
Per Floor Section
3ft Floor 5ft Floor
4ft Floor
PLEASE NOTE: All Shed Floors have the 4ft x 4ft Floor on the Left.
1a. Place the Floor panels with the Frame work pointing forwards (as shown in below)
then screw together using screws provided at the end of the bearer points.
1b. Check that all oor sections are securely attached and in a straight line to avoid any problems
later on the build stage.
Use a Spirit Level for accuracy
1c. Secure the oor sections together by
screwing the oor bearers at each end where
they meet as shown in diagram 1c.
© Sheds (Midlands) Limited 2021 www.totalsheds.co.uk

STEP • 2 STEP • 3
02
IMPORTANT
All Sheds With 4 or More
Floor Pannels have the
smallest Floor Panel
located at the back.
As shown on this diagram.
FLOOR & BLOCK ENDS
Add the Floor Block Ends
(Heavy Duty Posts)
= Drill Points using
screws provided as shown
= Drill Points using
screws provided as shown
x3
x3
4.0 x 70mm
Per Floor Block
FLOOR BLOCKS
2b
2a
2FT BACK SIDE PANEL
2ft RIGHT SIDE PANEL
Place rst panel againts
far right of shed oor
as shown.
(2ft wide blank panel)
2a. In your kit you should nd 2x 5ft blocks.
These will act as your oor block.
2b. Fix together by screwing the Floor.
Blocks at each end as shown. Use the screws
provided and make sure the ends are xed
securely. 2 screws on each Floor Block will
suce. (Repeat for other side)
3a. Place the 2ft Blank Panel against the far side of the
Shed oor. Make sure the panel stands rmly on the
Heavy Duty Post (Floor Block).
3b. Now prepare the 3ft Blank Panel in order to create an
‘L’ shape in the corner with the two panels.
3c. DO NOT x the panels at this stage to the oor. This is
because you need to leave room for adjustements in the
nal stages of the shed build.
© Sheds (Midlands) Limited 2021 www.totalsheds.co.uk

INFORMATION
Not all Sheds will have the same panel
arrangment. Please Ensure that the 3ft
Panels are placed onto 3ft oors.
STEP • 4 STEP • 5
03
= Drill Points using
screws provided as shown
= Drill Points using
screws provided as shown
3ft BACK PANEL
3FT BLANK
PANEL
3ft SIDE PANEL
Place second panel againts
far right of back of the shed
oor as shown. (3ft wide
blank panel)
4b
5a
SIDE & REAR PANELS
SIDE & REAR PANELS
Fix 3ft Wide Blank
Sections. Create a Corner
for Balance.
4a. Place a 3ft Blank Panel side as shown below. Repeat this step for all larger sheds. Please use
reference on left for additional sections required according to your shed size.
4b. Screw the panels alongside the framework as shown in Diagram 4b.
5a. Place the 3ft Blank Panel side against the corner of the back oor as shown making sure the
panel is sitting rmly on the Shed oor and the side meeting the framework of the back Blank
Panel.
5b. Fix the panels together with
screws as shown in diagram. You
may require some supports to
keep the frame upright whilst
building longer sheds.
x3
x3
4.0 x 70mm
Per Panel Edge
x3
x3
4.0 x 70mm
Per Panel Edge
© Sheds (Midlands) Limited 2021 www.totalsheds.co.uk

STEP • 6 STEP • 7
04
4ft LEFT PANEL
= Drill Points using
screws provided as shown
= Drill Points using
screws provided as shown
x3 x3
x3 x3
4.0 x 70mm 4.0 x 70mm
Per Panel Edge Per Panel Edge
3ft RIGHT PANEL
4FT BLANK
PANEL
4ft LEFT PANEL
Fix 4ft Wide Blank Section
Left Panel 4ft Section
(This panel might be 3ft depending on the
shed )
3ft RIGHT SIDE PANEL
Fix 3ft Wide Blank Section
Side Panel 3ft (Right)
7a. Place the 3ft Blank Panel side against the corner of the back right of the 3ft Floor as shown
making sure the panel is sitting rmly on the Shed oor and the side meeting the framework of
the back 3ft Blank Panel.
7b. Fix the panels together with screws as shown in diagram. You may require some supports to
keep the frame upright whilst building longer sheds.
6a. Place the 4ft Blank Panel at the far Left of the Shed, connecting it with the other sections.
DO NOT screw the standing panels down to the oor just yet. Leave room for adjustments
when the nal frame is tted.
© Sheds (Midlands) Limited 2021 www.totalsheds.co.uk

x3
STEP • 8 STEP • 9
05
4ft RIGHT WINDOW PANEL
RIGHT WINDOW
PANEL
Attach
Window Panel
(4ft Window Panel)
8a.
= Drill Points using
screws provided as shown
2ft FRONT PANEL
x3
4.0 x 70mm
FRONT 2ft PANEL
Attach 2ft Front Panel
9a. Now place the 2ft Blank Panel as shown. Fix together with screws to the left side panel
framework.
= Drill Points using
screws provided as shown
x3
x3
4.0 x 70mm
Per Window Panel Per Panel Edge
DO NOT screw the standing panels
down to the oor just yet. Leave room for
adjustments when the nal frame is tted.
8a. Start back from the Right side placing the 4ft
Window Panel as shown. Fix together with screws
to the right side panel framework.
© Sheds (Midlands) Limited 2021 www.totalsheds.co.uk

STEP • 10 STEP •11
06
= Drill Points using
screws provided as shown
x3
x6
4.0 x 70mm
Per Door Panel Per Angel Top
3ft DOOR PANEL
FRONT 3ft DOOR
PANEL
Attach Door Panel
(The 3ft Door panel can be placed
where ever a 3ft blank panel is
located)
= Drill Points using
screws provided as shown
x2
4.0 x 70mm
5ft APEX ROOF GABLE ENDS
APEX ROOF GABLE ENDS
(Set Frame for roof sections)
Now attach all the 5ft Apex
Gable Ends Tand the 5ft
Apex Truss
DID YOU KNOW?
Door panels can be
placed anywhere a 3ft
panel is. The 3ft Door
must be placed opposite
the 3ft back panel and
on top of a 3ft oor.
10a. Place the 3ft Front Door Panel as shown and x in place at the meeting points to nish the
outer Shed framework as shown below.
10b. Secure the
framework to the side
of 2ft section and use
additional screws where
needed to make the
frame strong.
11a. Place the the Roof Gable Ends as shown below. The 2 outer
sections will be fully framed as below and any centre trusses will t
in between all panel meeting points.
11b. Truss must sit in
between panel sections
where two panels meet.
Ensure the Gable Ends
slot neatly in to the
current Tongue & Groove
over lower section, then
screw down using the
framework behind.
5ft GABLE END
5ft TRUSS
© Sheds (Midlands) Limited 2021 www.totalsheds.co.uk

STEP • 12 STEP •13
07
= Drill Points using
screws provided as shown
x3
x3
4.0 x 70mm
PENT FRONT TOPS
= Drill Points using
screws provided as shown
x3
x4
4.0 x 70mm
Per Roof PanelPer Corner Strip
APEX ROOF PANELS
APEX ROOF PANELS
Place 4ft Roof section.
Repeat for all Roof Panels
(2ft, 3ft and 4ft)
13a. Place the 4ft Roof Panel
in place. Repeat this stage
for models as shown below.
Repeat placing the roof panels
corresponding to the panel size
for the Floor Front an Rear.
13b
13b. Screw the roof panel
down as shown in
diagram 13b.
Repeat this for all roof
panels, making sure each
panel is sitting on its
corresponding sized
front/back panel.
SIDE & CORNER STRIPS
Hide the panel edges.
Cover the framework &
seams.
12a. Use all the Side/Corner Strips to
nish o the shed, by covering any
exposed framework and the panel
joining seams.
INFORMATION
The Corner Strips cover all panel edges.
Remember to attach these to the exterior back
panels too.
© Sheds (Midlands) Limited 2021 www.totalsheds.co.uk

STEP • 14 STEP • 15
08
TACKS PROVIDED
ATTACH THE ROOF FELT
Use the felt lengths
provided.
15a. Apply the roof felt as shown. Apply lower levels rst to create
correct rain run o positions.
15b. Using a hammer, tack down the felt with the tacks provided in a
neat fashion.
15c. Trim down excess felt with a stanley knife. Remember to
overlay the 1st felt to avoid rain leaks.
15d. Tuck and fold edges neatly and tack in place to hide any
loose edges. Check that all areas are covered and there are no
holes to avoid any rain water getting through your felt roof.
ROOF FELT
CUTTING THE ROOF
FELT
Use the felt table to cut
your felt to the correct
size
14a. Use the Stanley knife to cut your felt into the correct size. Using the table below, nd the shed
size that you have and cut your felt down to achieve the size that you will need.
Example:
Apex Shed 5ft x 7ft
The 5 by 7 Shed needs 3 sheets of felt. All at 8ft each.
CUTTING THE ROOF FELT
4ft (x3) 5ft (x3) 6ft (x5) 7ft (x5) 8ft (x5)
4ft 5ft 5ft 5ft 5ft 5ft
5ft 6ft 6ft 6ft 6ft 6ft
6ft 7ft 7ft 7ft 7ft 7ft
7ft 8ft 8ft 8ft 8ft 8ft
8ft 9ft 9ft 9ft 9ft 9ft
9ft 10ft 10ft 10ft 10ft 10ft
10 ft 11ft 11ft 11ft 11ft 11ft
11 ft 12ft 12ft 12ft 12ft 12ft
12 ft 13ft 13ft 13ft 13ft 13ft
13 ft 14ft 14ft 14ft 14ft 14ft
14 ft 15ft 15ft 15ft 15ft 15ft
15 ft 16ft 16ft 16ft 16ft 16ft
16 ft 17ft 17ft 17ft 17ft 17ft
17 ft 18ft 18ft 18ft 18ft 18ft
18 ft 19ft 19ft 19ft 19ft 19ft
19 ft 20ft 20ft 20ft 20ft 20ft
20 ft 21ft 21ft 21ft 21ft 21ft
Build Length
Build Depth
© Sheds (Midlands) Limited 2021 www.totalsheds.co.uk

STEP • 16 STEP • 17
09
= Drill Points using
screws provided as shown
x3
x2
4.0 x 38mm
FELT STRIPS
ATTACH FELT STRIPS
Create the Final Roof
Edges. Final steps
nishing o the roof.
NOTE:
Location of the Felt Strips
16c. Felt Strips must be same height as roong
felt to allow rain water to run o. See Diagram on
the right.
x3
x2
4.0 x 38mm
DIAMOND CAPS
DIAMOND CAPS
Add the Finishing
Touch. (Optional)
Timber is a naturally grown product and may shrink and warp when dried out, timber is a porous
material which can absorb water. Although all of our buildings come pressure treated we strongly
advise the building is re-treated with an oil/spirit based treatment inside and out to make the timber
water repellent and to preserve the quality and life of the product.
Congratulations
17a. Using the provided
Diamond Caps you can
create a nice nishing
touch to the Apex Shed.
This also covers the
seam bewteen the arch
of the Felt Strips and
hides any joins showing.
16a. Using the Felt Strips provided cover the edges of the roofs and ends of the roof felt. You
will need to measure these and saw to t to your requirements and create the perfect roof nish
as shown below.
16b. Drill in the felt strips as shown on front and back of the shed to nish the roof o. Use the
framework of the roof blocks to screw the felt strips down to. The Felt Strips will give your shed
a neat nish for the roof and hide any overhang areas of the roof felt.
Per Felt Strip
© Sheds (Midlands) Limited 2021 www.totalsheds.co.uk
Total Sheds
Unit 1 Park Lane,
West Bromwich, B21 8LE
Tel: [phone]
Email: [e-mail]
