Total TCBNLI2001 User manual

1
v
BATTERY NAILER

2
Security instructions
Caution
Read all safety warnings and all instructions. Failure to follow the warnings and
instructions may result in electric shock, fire, and/or serious injury.
Note: Save all warnings and instructions for future reference. Due to our ongoing I+D+I
program, the specifications in this document are subject to change without notice.
1) Work area safety
a. Keep the work area clean and well lit to prevent accidents.
b. Do not use power tools in explosive atmospheres, such as in the presence
of flammable liquids, gases, or dust that can cause fires.
c. Keep children and other unauthorized persons away while using a power
tool. Distractions can cause you to lose control of the tool.
2) electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way.
Using a suitable plug reduces the risk of electric shock.
b. Avoid bodily contact with grounded surfaces such as pipes, radiators,
ranges, and refrigerators. There is an increased risk of electric shock if
your body is grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a
power tool will increase the risk of electrical shock.
d. Never use the cord to carry, pull or unplug the power tool. Keep the cable
away from heat or oil.
e. When using a power tool outdoors, use an extension cord suitable for
outdoor use.
f. If using the tool in a damp location is unavoidable, use a Residual Current
Device (RCD) protected supply to reduce the risk of electric shock.
g. Make sure the mains voltage is the same as the voltage on the tool's
nameplate. Remove plug from outlet before making any adjustments or
servicing.
3) Personal security
a. Always stay alert, watch what you are doing and use common sense
when using the tool.
b. Do not use a power tool if you are tired or under the influence of
medication or other substances.
c. Wear personal protective equipment. Always wear eye protection.
Protective equipment such as a dust mask, non-slip safety shoes, hard
hat, or hearing protection used in the proper conditions will reduce
personal injury. Also don't wear loose clothing or jewelry.
d. Prevent the tool from turning on unintentionally. Make sure the switch is
in the off position before connecting to power source and moving.
e. Remove any adjusting wrenches or wrenches before turning on the power
tool. An adjustable wrench or wrench placed in a rotating part of the power
tool can cause serious injury.

3
f. If devices are used for dust extraction and collection, make sure they are
properly connected. Properly use these devices and you will reduce dust-
related hazards.
4) Use and care of power tools
a. Do not force the tool. Use the correct power tool for each use.
b. Do not use the power tool if its power switch does not work. Any power
tool that cannot be controlled with the switch is dangerous and must be
repaired.
c. Disconnect the plug from the power source before making any
adjustments, changing accessories, or storing the tool to avoid accidental
starting of the tool.
d. Use the power tool, accessories and bits etc. in accordance with these
instructions, taking into account the working conditions and the work to
be carried out. Using the power tool for operations other than those
intended could result in a hazardous situation.
e. Store power tools out of the reach of children and do not allow people
unfamiliar with the tool to use it.
f. Keep power tools in good condition. Check for misalignment or binding of
moving parts, breakage of parts, and any other conditions that may affect
the operation of power tools. If it is damaged, have the power tool repaired
before using it. Many accidents are caused by poorly maintained power
tools.
g. Keep cutting tools sharp and clean. Properly maintained cutting tools with
sharp cutting edges are less likely to bind and are easier to control.
5) Battery use and care
a) Recharge the battery only with the charger specified by the manufacturer.
An unsuitable charger can create a fire hazard.
b) Use specifically designated batteries. Use of other batteries may create a
risk of injury or fire.
c) When the batteries are not in use, keep it away from other metal objects,
such as paper clips, coins, keys, nails, screws, or other small metal
objects, that can make a connection from one terminal to another.
Shorting the battery terminals can cause burns or fire.
d) Abusive conditions can cause expulsion of liquid from the battery; avoid
contact. If accidentally contacted, rinse immediately with water. If the
liquid comes into contact with the eyes, also seek medical help. Liquid
expelled from the battery can cause irritation or burns.
e) Do not use a battery or tool that is damaged or modified. They may exhibit
unpredictable behavior resulting in fire, explosion, or risk of injury.
f) Do not expose a battery or tool to fire or excessive heat. Exposure to fire
or temperature above 130°C may cause an explosion.
g) Follow all charging instructions. Do not charge the battery or tool outside
the temperature range specified in the instructions. Improper charging or
charging at temperatures outside the specified range may damage the
battery or increase the risk of fire.
6) Service
a. Have your power tool serviced by a qualified person and use replacement
parts recommended by the manufacturer. This will ensure that the safety
of the power tool is maintained.

4
Safety rules for correct use
Double insulation for additional protection
Please read the instruction manual before use.
CE conformity.
Wear safety glasses, hearing protection and a dust mask.
Waste electrical products must not be disposed of with household waste.
Please recycle at the appropriate facilities. Check with your local authority or
retailer for recycling advice.
Security alert. Use only accessories supported by the manufacturer.
Charge the battery only below 40ºc
Always recycle batteries
Do not expose the battery to fire or high temperatures
Do not expose battery to water
Additional security warnings
•Always assume that the tool contains fasteners. Careless handling of the nailer
can result in unexpected firing of fasteners and personal injury.
•Do not point the tool at yourself or someone nearby. An unexpected shot will
discharge the fasteners causing injury.
•Do not operate the tool unless it is firmly against the work piece. If the tool is not
in contact with the workpiece, the fixture can drift off target.
•Disconnect the tool from the power source when the fastener gets stuck in the
tool. While removing a stuck fastener, the nailer can be accidentally activated if
it is plugged in.

5
•Be careful when removing a stuck zipper. The mechanism may be under
compression and the fastener may be forcefully unloaded when attempting to
release a jammed condition.
*Note: This warning can be ignored for nailers that do not use stored potential energy to
drive fasteners.
•When fixing the electrical cables, make sure that the cables are not energized.
Hold nailer by insulated gripping surfaces only. Use only fasteners designed for
the installation of electrical cables.
•Do not use this nailer to fasten electrical cables. It is not designed for the
installation of electrical cables and may damage the insulation of electrical
cables, thus causing electric shock or fire hazards.
•Check that the nail has not damaged the insulation of the electrical cables. A
fastener that damages the insulation of electric wires can cause electric shock
and fire.
*Note: This warning applies to nailers suitable for fastening electrical cables.
•Do not use this nailer for fastening electrical cables. It is not designed for the
installation of electrical cables and may damage the insulation of electrical
cables, thus causing electric shock or fire hazards.
*Note: This warning applies to nailers not suitable for fastening electrical cables.
•Hold power tool by insulated gripping surfaces when performing an operation
where the nail may contact hidden wiring. Nails coming in contact with a "live"
wire can make exposed metal parts of the power tool "live" and could cause an
electric shock to the operator.
•Please read the manual carefully and be aware of its applications and limitations,
as well as the specific potential hazards associated with this power tool.
Compliance with this rule will reduce the risk of electric shock or serious injury.
•Always wear suitable eye protection. Everyday glasses only have impact
resistant lenses. They are not safety glasses. Compliance with this rule will
reduce the risk of serious personal injury.
•The operator and others in the work area should wear proper eye protection that
protects them from frontal and side rays when loading, using, or maintaining this
tool.
Eye protection is necessary to prevent fasteners and debris from becoming
dislodged, which could cause serious eye injury.
•The wide vision safety facepiece is recommended to be worn over standard
safety glasses or goggles which provide protection against flying particles from
both the front and the side. Always wear proper eye protection.
•In some environments additional security protection will be required. For
example, the work area may include exposure to a noise level that can cause
hearing damage.
•Use safety equipment. Always wear eye protection. Dust mask, non-slip safety
shoes, hard hat, or hearing protection should be worn under appropriate
conditions.
The user must ensure that the operator and other people present in the work area
have and use the necessary protection for correct use.
•Keep fingers away from trigger when not driving fasteners to prevent accidental
firing.
•Battery tools do not have to be plugged into an outlet, so they are always in
working condition. Be aware of possible hazards when not using your battery tool

6
or when changing accessories. Compliance with this standard will reduce the risk
of electric shock, fire, or serious personal injury.
•Do not place battery tools or their batteries near fire or heat. This will reduce the
risk of explosion and possible injury.
•Use the tool only for its intended use. Do not unload fasteners outdoors.
•Use the tool only for its intended use.
•Use only the recommended nails for this tool. Using the wrong nails can result in
poor nail feeding, nail binding, and nails coming out of the tool at erratic angles.
•Never use this tool in a way that could drive a nail into anything other than the
workpiece.
•Do not use the tool as a hammer and always carry the tool by the handle.
•Do not alter or modify this tool from its original design or function.
•Always keep in mind that misuse and improper handling of this tool can cause
injury to yourself and others.
•Never clamp or tape the trigger or workpiece contact in an actuated position.
•Never leave the tool unattended if the battery is installed.
•Keep the tool and its handle dry, clean and free of oil and grease. Always use a
clean cloth for cleaning. Never use brake fluid, gasoline, petroleum products, or
any other strong solvents to clean the tool. Compliance with this standard will
reduce the risk of loss of control and deterioration of the plastic of the housing.
Start up
•Do not use tool if trigger does not actuate properly. Any tool that cannot be
controlled with the trigger is dangerous and must be repaired.
•Frequently check the operation of the workpiece contact mechanism. Do not use
the tool if the workpiece contact mechanism is not working properly, as accidental
nailing may occur. Do not interfere with the proper functioning of the workpiece
contact mechanism.
•Do not use a tool that is not working properly.
•Always assume that the tool contains nails.
•Do not carry the tool from one place to another holding the trigger. An accidental
discharge could occur.
•Always handle the tool with care:
oRespect the tool as a work instrument.
oNever pull the trigger unless attention is directed to the work.
oKeep others at a safe distance from the tool while it is in operation, as
accidental operation could result and could cause injury.
•The choice of drive method is important. See the manual for shooting options.
•Do not hold the tool by the front of the charger. Do not place hands, head, or
other body parts near the bottom of the magazine where the nail exits the tool,
as serious personal injury could result.
•Do not point the tool at yourself or anyone, whether it contains nails or not.
•Do not activate the tool if you do not intend to drive a nail into the piece.
•Always make sure the workpiece contact is fully positioned above the workpiece.
If you position the workpiece, contact only partially above the workpiece, the nail
may miss the workpiece completely and cause serious personal injury.
•Do not drive nails close to the edge of the material. The workpiece can split and
cause the nail to ricochet, injuring you or a co-worker.
•Be aware that the nail may follow the grain of the wood, causing it to protrude
unexpectedly from the side of the work material or defect, potentially causing
injury.
•Keep hands and body parts away from immediate work area.

7
•Support the workpiece with clamps when necessary to keep hands and body
away from possible injury. Make sure the work piece is securely clamped before
pressing the fastener into the material. Contact with the work piece can cause
the work material to move unexpectedly.
•Keep face and body parts away from back of tool cap when working in restricted
areas. Sudden kickback can cause body impact, especially when driving into hard
or dense material.
•During normal use, the tool will recoil immediately after driving a fastener. This is
a normal function of the tool. Do not try to prevent kickback by holding the nailer
against the work. Recoil restriction may cause the nailer to drive in a second
fastener.
•Keep a firm grip on the handle, let the tool do the work, and do not place your
second hand on top of the tool or near the exhaust at any time. Failure to heed
this warning can result in serious personal injury.
•Do not drive fasteners over other fasteners or with the tool at too sharp an angle
as this may cause the fasteners to deflect which could cause injury.
Tool load
•Do not load the tool with fasteners when any of the operating controls are
activated.
•When you load the tool:
oNever place a hand or any part of the body in the discharge area of the
tool's fasteners.
oNever point the tool at anyone.
oDo not pull the trigger or apply pressure to the workpiece contact, as
accidental actuation may occur and could cause injury.
Save these instructions
•Please refer to them frequently and use them to educate others who may use this
tool. If you lend someone this tool, lend them these instructions as well.
Other risks
Even when the power tool is used as prescribed, it is not possible to eliminate all residual
risk factors:
a. Health defects resulting from vibration emission if the power tool is used for a
longer period of time or if it is not managed and maintained properly.
b. Injuries and property damage due to broken fixtures breaking suddenly.
Caution
This power tool produces an electromagnetic field during operation.
This field can, in some circumstances, interfere with active or passive
medical implants.
To reduce the risk of serious injury, we recommend that persons with
medical implants consult their physician before using this power tool.
If the cable is damaged or cut during work, do not touch the cable, immediately unplug
the tool. Never use the machine with a damaged cable.

8
The machine must not be damp and must not be used in a humid
environment.
Attention
Safe operation of this machine is only possible when the operating or
safety information is fully read and the instructions contained therein
are strictly followed.
Technical data
Data sheet
Applicable nails
18Ga
Nail length
15mm-50mm (5/8”-2”)
Nail load capacity (nails)
100 (1 strip)
Shooting mode
simple sequence
contact actuation
Cycle speed (nails/second)
2.5
Battery
Guy
Lithium-ion technology
Voltage
20V
Weight (without battery)
2.3kg
Dimension (length x height x width)
13-3/8” x 9-3/8” x 4-1/4”
(339mm x 238mm x109mm)
Product description
A. trigger switch
B. mode selector
C. side loader
D. Magazine release button
E. belt hole
F. Non-marking pad
G. Contact with the part
H. Low Nail Indicators
I. LED work lights
J. clearing jams
K. Depth adjustment wheel

9
Note: Not all accessories illustrated or described may not be included in the standard delivery.
Note 2: Double insulation: The tool is double insulated. This means that all external metal parts
are electrically isolated from the mains. This is done by placing isolation barriers between
electrical and mechanical components, making it unnecessary to ground the tool.
Set up
Mounting
Warning
Do not use this product if it is not fully assembled or if any parts appear to be missing or
damaged. Using a product that is not properly and completely assembled, or with
damaged or missing parts, could result in serious personal injury.
Do not attempt to modify this product or create accessories or add-ons not recommended
for use. Any such alteration or modification constitutes misuse and could result in a
hazardous situation that could result in serious personal injury.
Start up
Warning
Don't let familiarity with the products cause you to be careless. Remember that a careless
fraction of a second is enough to inflict serious injury.
Always remove the battery pack from the tool when assembling parts, making
adjustments, cleaning, or when not in use. Removing the battery pack will prevent
accidental starting, which could cause serious personal injury.
Always wear proper eye protection. Failure to do so may result in serious injury.
Applications
You can use this tool for the following purposes:
•Finishes and moldings (interior
and exterior)
•Door and window cladding
•door jambs
•Plinth
•crown molding
•cabinets
•cap and shoe molding
•Molding
•Ladders
•Door and window moldings
•chair rails
•brick molding
•hardwood floors
•panels
•Furniture
To install/remove the battery pack
To install the battery pack:
•Put the battery pack in the tool.
•Align the raised rib inside the tool with the groove on the battery pack.
•Make sure the latches on the back of the battery pack snap into place and the
battery pack is secure in the tool before you start to use it.

10
To remove the battery pack:
•Locate the battery pack latches and press to release the battery pack from the
tool.
•For complete charging instructions, refer to your battery pack and charger
operator's manuals.
Non-marking pad
The anti-marking pad attached to the tip of the tool helps prevent marking and gouging
when working with softer woods.
•Remove the battery.
•Remove the pad by pulling it down and away from the tip.
•To reattach the pad, snap it into place over the tip and push up to reattach.
The pad stores in the tool magazine. An extra pad is provided in the onboard storage
area.
Load nails into the tool
Warning
Keep the tool away from yourself and other people when loading nails. Failure to do so
may result in possible serious personal injury.
•Remove the battery pack from the tool, if installed.
•With the tip of the tool pointing away from you, squeeze the magazine release
button on the rear of the magazine and slide the magazine cover open.
•Place the nails in the channel with the nail pointing down and resting on the
bottom of the channel.
•Push the charger cover closed until it clicks into place.
•Make sure the charger is securely locked in place.
•Reinstall the battery and reactivate the nailer by pressing the grip switch on the
work light.
Nailing depth adjustment
Nailing depth can be adjusted beyond air pressure. It is advisable to test the depth on a
piece of scrap to determine the depth needed for the application. To determine the nailing
depth, first adjust the air pressure and drive a test nail.
To achieve the desired depth, use the drive depth setting on the tool. Harder materials
and longer nails will require more force to drive.
•Remove the battery from the tool, if installed.
•Turn the nailing depth adjustment left or right to change the nailing depth.
•Reinstall the battery and reactivate the tool by pressing the work light grip switch.
•After each adjustment, test drive until the desired depth is achieved.
Note: Set the nailing depth to the lowest depth that meets your needs.
Warning
Never chock or hold the workpiece contact mechanism during tool operation. Doing so
could result in possible serious injury.
Simple jog mode
Unique sequential drive provides the most precise nail placement.
•Slide the selector to position (T)
