Toto CURIO TX411SCV3 User manual

OPERATING CONDITIONS
SPECIFICATIONS
S06070-3S
"CURIO" FLOOR STANDING BATH & SHOWER SET TX411SCV3
TX 411 SCV3
"Curio" Cross Handle Floor Standing Bath &Shower Set
OPTIONAL HANDLE
TX 411 SCLV3
"Curio" Lever Handle Floor Standing Bath & Shower Set
TX 411 SCSV3
"Curio" Simple Cross HandleFloor Standing Bath & Shower Set
Ø8
54+8
0
123
229
Ø72.5
820 0
-8
150
93
Ø80
40
G½
18
7
Body
Packing
MAINTENANCE
TROUBLESHOOTING
CHECK
POINT
Unsatisfactory spray 1 Clean
Flow rate unsatisfactory 2 Remove and clean
Water leaks around the handle 3 Tighten
Handle is loose 4 Tighten
PROBLEM
SOLUTION
2. AERATOR
4. BOLT
8Shower
Flexible
Hose
Packing Packing
6
5
43
INSTALLATION
1
Make sure the floor is flat
* Remove the cover after the
mortar has dry
2
Pipe
Cover
Ring
Pipe
Flexible Hose
Nut
* Cover
Mortar
Maximum
Mortar
Minimum
Mortar
Base
Drill
Hot Water
Supply *
Sleeve
Anchor
6 - Hole 8
Base
Cold Water
Supply *
Screw
* Pipesupplied by owner
3. CERAMIC
HEAD WORK
R5
ATTENTION
Flow Regulator Inside
(Don t remove)
1. NOZZLES
1. Water supply pressure : 0.05 ~ 0.75 MPa
2. Ensure that water supply is clean ( No Sand, Dirt, Etc.).
All Finishes : Clean the finish with mild soap and warm water.
Wipe entire surface completely dry with clean soft cloth. Many
cleaners may contain chemicals, such as ammonia, chlorine,
toilet cleaner etc. which could adversely affect the finish and
are not recommended for cleaning
Don t use abrasive cleaners or solvents on faucets and fittings.
Flow Regulator should not be remove because it could
damage the system
As the product model is constantly updated, the actual product
may not look the same as it shown in the diagram, but the
basic installation principles are the same.
The hot water supply side of the faucets is in a condition of
high temperature. Do not allow skin to contact with the
hardware surface directly. Otherwise, scalding may occur.
1.
2.
3.
4.

KONDISI OPERASIONAL
S06070-3S
"CURIO" FLOOR STANDING BATH & SHOWER SET TX411SCV3
TX 411 SCV3
"Curio" Cross Handle Floor Standing Bath & Shower Set
OPTIONAL HANDLE
TX 411 SCLV3
"Curio" Lever Handle Floor Standing Bath & Shower Set
TX 411 SCSV3
"Curio" Simple Cross Handle Floor Standing Bath & Shower Set
Ø8
54+8
0
123
229
Ø72.5
820 0
-8
150
93
Ø80
40
G½
18
7
Body
Packing
PEMELIHARAAN
PENYELESAIAN MASALAH
Pancaran tidak memuaskan 1 Bersihkan
Aliran tidak memuaskan 2 Lepas dan bersihkan
Air bocor disekitar handle 3 Kencangkan
Handle longgar 4 Kencangkan
MASALAH
SOLUSI
POIN
PERIKSA
2. AERATOR
4. BOLT
8Shower
Flexible
Hose
Packing Packing
6
5
43
PEMASANGAN
1
Pastiksn lantainya rata
* Lepas cover setelah
mortar mengering
2
Pipe
Cover
Ring
Pipe
Flexible Hose
Nut
* Cover
Mortar
Maximum
Mortar
Minimum
Mortar
Base
Drill
Hot Water
Supply *
Sleeve
Anchor
6 - Hole 8
Base
Cold Water
Supply *
Screw
* Pipa disediakan oleh pemilik
3. CERAMIC
HEAD WORK
R5
PERHATIAN
1. NOZZLES
1. Tekanan sumber air: 0.05 ~ 0.75 MPa.
2. Pastikan kondisi sumber air adalah bersih
(tidak ada pasir, kotoran dan lain lain)
Seluruh lapisan : Bersihkan lapisan akhir dengan sabun lembut
dan air hangat. Lap seluruh permukaan hingga benar-benar
kering dengan kain lembut yang bersih. Kebanyakan bahan
pembersih mungkin mengandung bahan kimia, seperti amonia,
klorin, pembersih toilet, dll. yang dapat mempengaruhi hasil
akhir dan tidak disarankan untuk dibersihkan
Jangan gunakan pembersih atau pelarut abrasif pada faucet
dan fitting.
Flow Regulator tidak boleh dilepas karena dapat merusak
sistem
Karena model produk terus mengalami pembaharuan, aktual
produk mungkin tidak sama dengan gambar, tapi prinsip
dasar pemasangan adalah sama.
Sisi pasokan air panas pada kran faucet berada dalam kondisi
suhu tinggi. Jangan biarkan kulit menyentuh permukaan
benda secara langsung. Kalau tidak, bisa terjadi kepanasan.
1.
2.
3.
4.
SPESIFIKASI
Flow Regulator Didalam
(Jangan dilepas)
