Toto EGO II TX447SES User manual

"EGO II" 4 HOLES BATH & SHOWER SET TX447SES
G½
240
175.5
max.30 331.5
Ø54
Ø54 Ø54
C
H
120 120 120
SPECIFICATIONS
OPERATING CONDITIONS
S06247R
MAINTENANCE
TROUBLESHOOTING
INSTALLATION
1.
3.
5.
Lock Nut
Wavy
Washer
2.
Shower Holder
Ø35
4.
6.
Packing
Spout
Joint
Nut
Ø40
Hose Spring
Packing
Packing
Hand
Shower
Ø35Ø35
Packing
Lock Nut
Body
Ceramic
Head Work
Handle *
Lock Nut
C
L
I
CK
R6
Lock Nut
Holder
Packing
Packing
2. AERATOR
Hose
Stopper
Base
Handle
Base**
ATTENTION
Flow Regulator
Inside
(Don t remove)
3. CERAMIC
HEAD WORK
Rain Spray
Button
Massage Spray
Button
CHECK
POINT
Unsatisfactory spray 1 Clean
Flow rate unsatisfactory 2 Remove and clean
Water leaks around the handle 3 Tighten
PROBLEM
SOLUTION
1. NOZZLES
All Finishes : Clean the finish with mild soapand warm water. Wipe
entire surface completely dry with clean soft cloth. Manycleaners may
contain chemicals, such as ammonia, chlorine, toilet cleaner etc. which
couldadversely affect the finish and are not recommended forcleaning
Don t use abrasive cleaners or solventson faucets and fittings.
FlowRegulator should not be remove because it could
damage the system
As the product model is constantly updated, the actual product
maynot look the same as it shown in the diagram, but the
basic installation principles are thesame.
1.
2.
3.
1. Watersupply pressure : 0.05 ~ 0.75 MPa.
2. Ensure that watersupply is clean ( NoSand, Dirt, Etc. )
Ø35
Hole
Ø40Hole
Hot
Water
Supply
Cold
Water
Supply
Flexible Hose
* The red handle for left position
and the blue handle for right
position.
**Tighten thehandle baseby hand
Ø35
Hole

"EGO II" 4 HOLES BATH & SHOWER SET TX447SES
G½
240
175.5
max.30 331.5
Ø54
Ø54 Ø54
C
H
120 120 120
SPESIFIKASI
KONDISI OPERASIONAL
S06247R
PEMELIHARAAN
PEMASANGAN
1.
3.
5.
Lock Nut
Wavy
Washer
2.
Shower Holder
Ø35
4.
6.
Packing
Spout
Joint
Nut
Ø40
Hose Spring
Packing
Packing
Hand
Shower
Ø35Ø35
Packing
Lock Nut
Body
Ceramic
Head Work
Handle *
Lock Nut
C
L
I
CK
R6
Lock Nut
Holder
Packing
Packing
2. AERATOR
Hose
Stopper
Base
Handle
Base**
PERHATIAN
3. CERAMIC
HEAD WORK
Rain Spray
Button
Massage Spray
Button
1. NOZZLES
Seluruh lapisan: Bersihkan lapisan akhir dengan sabun lembut dan air
hangat. Lap seluruh permukaan hingga benar-benarkering dengan kain
lembut yang bersih. Kebanyakan bahan pembersih mungkin mengandung
bahan kimia,seperti amonia, klorin, pembersih toilet, dll. yang dapat
mempengaruhi hasil akhir dan tidak disarankanuntuk dibersihkan
Ø35
Hole
Ø40Hole
Hot
Water
Supply
Cold
Water
Supply
Flexible Hose
* Handle merah untuk posisi kiri
dan handle biru untuk posisi kanan
**Kencangkan handle base
dengan tangan
Ø35
Hole
PENYELESAIAN MASALAH
Pancaran tidak memuaskan 1 Bersihkan
Laju aliran tidakmemuaskan 2 Lepas dan bersihkan
Air bocor disekitar handle 3 Kencangkan
MASALAH
SOLUSI
POIN
PERIKSA
Jangan gunakan pembersih atau pelarut abrasif pada faucet dan fitting.
FlowRegulator tidak boleh dilepas karena dapat merusak sistem
Karena model produk terus mengalami pembaharuan, aktual produk
mungkin tidak sama dengan gambar,tapi prinsip dasar pemasangan
adalah sama.
1.
2.
3.
1. Tekanan sumber air: 0.05 ~ 0.7.5 MPa.
2. Pastikan kondisi sumber air adalah bersih
(tidak ada pasir, kotoran dan lain lain)
Flow Regulator
Inside
(Jangan dilepas)
