Toto TBV01101U Installation instructions

Installation and Owner’s Manual
Manual de instalación y del propietario
Manuel d’installation et d’utilisation
Manual de Instalação e do Proprietário
TBV01101U TBV02101U TBV01102U TBV02102U
TBV01103U TBV02103U TBV01104U TBV02104U
Warranty Registration and Inquiry
For product warranty registration, TOTO U.S.A. Inc. recommends online warranty registration. Please visit
our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please contact
TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260
[phone] or [phone] when calling from outside of U.S.A.
Shower trim
Borde de ducha
Robinetterie de douche
Acabamento do chuveiro

THANK YOU FOR CHOOSING TOTO!
TABLE OF CONTENTS
WARNINGS
BEFORE INSTALLATION
For safe operation of the valve, please observe the following:
CARE AND CLEANING
2
Your new shower is designed for years of trouble-free performance. Keep it
looking new by cleaning it periodically with mild soap, rinsing thoroughly with
warm water and drying with a clean, soft cloth. Do not use abrasive cleaners,
steel wool or harsh chemicals, as thes will dull the finish. Failure to follow these
instructions may void your warranty.
The mission of TOTO is to provide the world with healthy, hygienic and more
comfortable lifestyles. We design every product with the balance of form and
function as a guiding principle. Congratulations on your choice.
Observe all local plumbing codes.
Make sure the water supply is shut off at the stop valve.
Read these instructions carefully to ensure proper installation.
TOTO reserves the right to update product design without notice.
Minimum Pressure....................20 psi (138 kPa), dynamic
Maximum Pressure...................80 psi (551 kPa), static
Do not solder the connections directly to the valve as damage to the
internal components may occur.
Do not use this product at an ambient temperature below 32°F (0°C).
For products TBV01104U and TBV02104U, the water
flow will be small and the product can not be used
when the handle rod are in the three positions shown
in the figure.
Operating Pressure:
Thank you for Choosing TOTO!.......... 2
Care and Cleaning................................ 2
Warnings................................................ 2
Before Installation................................. 2
Tools you will need............................... 3
Included parts.................................... 3
Installation Procedure........................ 4
Warranty............................................... 7
Rough-in dimensions........................ 26
ENGLISH
Handle rod
3
TOOLS YOU WILL NEED
INCLUDED PARTS
Check to make sure you have the following parts indicated below:
ENGLISH
Handle
Screw
Set screw
Cap
Lining plate
Trim
Handle
Set screw
Cap
Lining plate
Trim
Handle
Set screw
Cap
Lining plate
Trim
Handle
Set screw
Cap
Lining plate
Trim
ScrewdriverHacksawSilicon caulk
Hex wrench
(2.5mm)
TBV01101U / TBV02101UTBV01102U / TBV02102U
TBV01103U / TBV02103UTBV01104U / TBV02104U

THANK YOU FOR CHOOSING TOTO!
TABLE OF CONTENTS
WARNINGS
BEFORE INSTALLATION
For safe operation of the valve, please observe the following:
CARE AND CLEANING
2
Your new shower is designed for years of trouble-free performance. Keep it
looking new by cleaning it periodically with mild soap, rinsing thoroughly with
warm water and drying with a clean, soft cloth. Do not use abrasive cleaners,
steel wool or harsh chemicals, as thes will dull the finish. Failure to follow these
instructions may void your warranty.
The mission of TOTO is to provide the world with healthy, hygienic and more
comfortable lifestyles. We design every product with the balance of form and
function as a guiding principle. Congratulations on your choice.
Observe all local plumbing codes.
Make sure the water supply is shut off at the stop valve.
Read these instructions carefully to ensure proper installation.
TOTO reserves the right to update product design without notice.
Minimum Pressure....................20 psi (138 kPa), dynamic
Maximum Pressure...................80 psi (551 kPa), static
Do not solder the connections directly to the valve as damage to the
internal components may occur.
Do not use this product at an ambient temperature below 32°F (0°C).
For products TBV01104U and TBV02104U, the water
flow will be small and the product can not be used
when the handle rod are in the three positions shown
in the figure.
Operating Pressure:
Thank you for Choosing TOTO!.......... 2
Care and Cleaning................................ 2
Warnings................................................ 2
Before Installation................................. 2
Tools you will need............................... 3
Included parts.................................... 3
Installation Procedure........................ 4
Warranty............................................... 7
Rough-in dimensions........................ 26
ENGLISH
Handle rod
3
TOOLS YOU WILL NEED
INCLUDED PARTS
Check to make sure you have the following parts indicated below:
ENGLISH
Handle
Screw
Set screw
Cap
Lining plate
Trim
Handle
Set screw
Cap
Lining plate
Trim
Handle
Set screw
Cap
Lining plate
Trim
Handle
Set screw
Cap
Lining plate
Trim
ScrewdriverHacksawSilicon caulk
Hex wrench
(2.5mm)
TBV01101U / TBV02101UTBV01102U / TBV02102U
TBV01103U / TBV02103UTBV01104U / TBV02104U

4
INSTALLATION PROCEDURE
Within
1/16”
(2mm)
1. Use hacksaw to remove excess
portion of outer plaster guard that
extends from the wall surface. The
space between the convex edge of
the outer plaster guard and the
wall surface needs to be within
1/16” (2mm).
2. Apply silicone caulk uniformly and
cover the gap between the outer
plaster guard and the wall surface.
Make sure adhesive is applied
evenly and not convex to the wall
surface.
3. Remove and discard the inner
plaster guard.
I. Preparing the Trim installation area
Hacksaw
Outer plaster guard
Silicon caulk
Outer plaster guard Inner plaster guard
WARNING:
●Keep a neat edge and make
sure no edges are recessed
into the wall surface when
removing the outer plaster
guard for the valve.
●When cutting, the plaster
guard may get scratched, this
does not adversely affect the
product.
ENGLISH
5
INSTALLATION PROCEDURE
1. Position and insert lining plate according to
the "UP" label on product.
2. Use a screwdriver to manually fasten the
screws on the lining plate.
3. Align and insert the trim through the cartridge
sleeve cover and over the lining plate. Make sure
the water discharge port is facing downward.
4. Keep the trim within 1/16” (1mm) of wall surface.
II. Installation of Trim Lining plate
Screw
Water discharge
port
Cartridge sleeve
Trim
Water discharge
port
WARNING:
●Before installing lining plate, perform
a pressure test and verify that both
(HOT and COLD)
water valves are
completely open.
●Pay attention to the direction of
the lining plate when installing.
The water discharge port is
located at the BOTTOM of the
plate.
●DO NOT apply sealant to lining
plate as this may block water
discharge port. Lining plate
includes a foam sealing strip.
●When fastening the screws on the
lining plate, make sure to com-
press firmly. There should be no
gap between the lining plate and
the wall surface.
●DO NOT use an electric wrench to
fasten screws, these should be
tightened manually.
WARNING:
●DO NOT scratch the cartridge
sleeve when installing the trim.
●DO NOT apply waterproof caulk
around the trim as this may interfere
with the water discharge port
located underneath the trim.
ENGLISH

4
INSTALLATION PROCEDURE
Within
1/16”
(2mm)
1. Use hacksaw to remove excess
portion of outer plaster guard that
extends from the wall surface. The
space between the convex edge of
the outer plaster guard and the
wall surface needs to be within
1/16” (2mm).
2. Apply silicone caulk uniformly and
cover the gap between the outer
plaster guard and the wall surface.
Make sure adhesive is applied
evenly and not convex to the wall
surface.
3. Remove and discard the inner
plaster guard.
I. Preparing the Trim installation area
Hacksaw
Outer plaster guard
Silicon caulk
Outer plaster guard Inner plaster guard
WARNING:
●Keep a neat edge and make
sure no edges are recessed
into the wall surface when
removing the outer plaster
guard for the valve.
●When cutting, the plaster
guard may get scratched, this
does not adversely affect the
product.
ENGLISH
5
INSTALLATION PROCEDURE
1. Position and insert lining plate according to
the "UP" label on product.
2. Use a screwdriver to manually fasten the
screws on the lining plate.
3. Align and insert the trim through the cartridge
sleeve cover and over the lining plate. Make sure
the water discharge port is facing downward.
4. Keep the trim within 1/16” (1mm) of wall surface.
II. Installation of Trim Lining plate
Screw
Water discharge
port
Cartridge sleeve
Trim
Water discharge
port
WARNING:
●Before installing lining plate, perform
a pressure test and verify that both
(HOT and COLD)
water valves are
completely open.
●Pay attention to the direction of
the lining plate when installing.
The water discharge port is
located at the BOTTOM of the
plate.
●DO NOT apply sealant to lining
plate as this may block water
discharge port. Lining plate
includes a foam sealing strip.
●When fastening the screws on the
lining plate, make sure to com-
press firmly. There should be no
gap between the lining plate and
the wall surface.
●DO NOT use an electric wrench to
fasten screws, these should be
tightened manually.
WARNING:
●DO NOT scratch the cartridge
sleeve when installing the trim.
●DO NOT apply waterproof caulk
around the trim as this may interfere
with the water discharge port
located underneath the trim.
ENGLISH
