Toto Oberon TS362P Installation instructions

Warranty Registration and Inquiry
For product warranty registration, TOTO U.S.A. Inc. recommends online warranty registration. Please visit
our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please con-
tact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260
[phone] or [phone] when calling from outside of U.S.A.
Installation and Owner’s Manual
Manual de instrucciones y del propietrario
Manuel d’installation et d’utilisation
Oberon® Pressure Balance Trim
Cubierta de equilibrio de presión Oberon®
Garniture d’equilibrage de pression Oberon®
TS363P
TS362P

2
ENGLISH
TABLE OF CONTENTS
THANKS FOR CHOOSING TOTO!
The mission of TOTO is to provide the world with healthy, hygienic and more
comfortable lifestyles. We design every product with the balance of form and
function as a guiding principle. Congratulations on your choice.
Thanks for Choosing TOTO! .............................................................................. 2
Before Installation................................................................................................ 2
Common Tools Needed...................................................................................... 2
Care & Cleaning................................................................................................... 2
Parts Included ...................................................................................................... 3
Installation Procedure.......................................................................................... 3
Warranty................................................................................................................ 5
Rough-In Dimensions ....................................................................................... 15
CARE & CLEANING
Your new trim is designed for years of trouble-free performance. Keep it
looking new by cleaning it periodically with mild soap, rinsing thoroughly with
warm water and drying with a clean, soft cloth. Do not use abrasive cleaners,
steel wool or harsh chemicals, as these will dull the finish. Failure to follow
these instructions may void your warranty.
COMMON TOOLS NEEDED
BEFORE INSTALLATION
Observe all local plumbing codes.
Make sure the water supply is shut off.
Read these instructions carefully to ensure proper installation.
TOTO reserves the right to update product design without notice.
Screwdriver Silicone Caulk

3
ENGLISH
INSTALLATION PROCEDURE
PARTS INCLUDED
Handle
Escutcheon* Collar
Set Screw and Allen
Wrench
Screw and Lock Washer
Adapter Screw
Long Screws (2)
Check to make sure that all these parts were included in your packaging:
* Actual product may differ in appearance from illustration depending on the model.
1. Confirm that the valve has been installed properly and pull the plaster
guard outwards to remove.
NOTE: The finished wall surface should be between the min and max
markings on the plaster guard. See the TSPTM installation manual for further
information.
2. Use the two long screws
to secure the collar to the
valve (ill. 1). Make sure the
screw hole of the collar is
oriented on the bottom.
Collar
Long screws
Valve
Finished wall
ill. 1
Correct Installation
Screw hole

4
ENGLISH
4. Secure the adapter
to the valve with
the screw and lock
washer (ill. 3).
6. Slide handle onto the adapter (ill. 5).
If handle position needs fine
adjustment, remove handle and
rotate to reposition on the adapter
one notch from the original position.
Tighten the handle onto the collar
using the set screw and allen
wrench.
7. Apply silicone caulk to perimeter
of escutcheon. Leave opening for
weep hole on bottom (ill. 6).
5. Manually turn the
adapter clockwise
until it stops (ill. 4).
INSTALLATION PROCEDURE
Valve
Adapter
Lock washer
Screw
Adapter
Adapter
Handle
Set screw
Screw
Escutcheon
Collar
Finished wall
3. Use the screw to
mount the escutcheon
to the collar (ill. 2).
Make sure that
the TOTO logo is
positioned on the
bottom center.
ill. 2
ill. 4 ill. 5
ill. 3
ill. 6

15
ROUGH-IN DIMENSIONS / DIMENSIONES PRELIMINARES /
DIMENSIONS BRUTE
Min: 1-⁄" [49mm]
Max: 2-⁄" [68mm]
3-⁄"80mm
3-⁄"80mm
Finished
Wall Surface
Valve
C
L
59mm2-⁄"
⁄"9mm
Finished
Wall Surface
Valve
C
L
2-⁄"59mm
⁄"9mm
7-⁄"180mm
7-⁄"180mm
7-⁄"180mm
Min: 1-⁄" [49mm]
Max: 2-⁄" [68mm]
TS363
TS362
