Toto RENESSE TL170SD User manual

Warranty Registration and Inquiry
For product warranty registration, TOTO U.S.A. Inc. recommends online warranty registration. Please visit
our web site http://www.totousa.com. If you have questions regarding warranty policy or coverage, please con-
tact TOTO U.S.A. Inc., Customer Service Department, 1155 Southern Road, Morrow, GA 30260
[phone] or [phone] when calling from outside of U.S.A.
Installation and Owner’s Manual
Manual de Instrucciones y del Propietrario
Manuel D’Installation et D’Utilisation
Single Handle Lavatory Faucet
Grifería de Lavabo Monocomando
Robinet de Cuvette à Poignée Unique
Renesse®
TL170SD
TL170SDA
TL170SDLQ
TL170SDALQ

2
ENGLISH
TABLE OF CONTENTS
THANKS FOR USING TOTO!
The mission of TOTO is to provide the world with healthy, hygienic and more
comfortable lifestyles. We design every product with the balance of form and
function as a guiding principle. Congratulations on your choice.
Thanks for Choosing TOTO®! ............................................................................. 2
Warnings ............................................................................................................... 2
Included Parts ...................................................................................................... 3
Before Installation ................................................................................................ 3
Installation Procedure .......................................................................................4-5
Care and Cleaning ............................................................................................... 5
Warranty................................................................................................................ 6
Rough-In Dimensions ....................................................................................... 17
Spare Parts.......................................................................................................... 18
WARNINGS
For safe operation of the faucet, please observe the following:
Operating pressure:
Minimum Pressure……………20 psi (flowing pressure)
Maximum Pressure…………...80 psi (non-flowing pressure)
Do not reverse the hot and cold water inlets.
Do not use a hot water supply that is higher than 185˚F (85˚C).
 Do not disassemble or modify the faucet in any way not described in this
manual.
 While using the hot water, do not touch the spout or spout body directly.
Do not strike or kick the faucet.
Check for water leakage or looseness in the pipes regularly.
 If the water supply pressure is higher than 80psi (0.55MPa), you should
buy a reducing valve to reduce the pressure to the range of 20-45psi
(0.2-0.3MPa). The recommended pressure for normal, comfortable use is
about 0.2-0.3MPa.
 To prevent being scalded due to malfunction, the water supply pressure
must be higher than the hot water pressure, or you can make them equal.
In addition, if you increase the pressure of the hot water, it must still be
lower than that of water supply side.
 To prevent being scalded due to malfunction, the recommended hot
water supply temperature is 140°F (60°C).

3
ENGLISH
BEFORE INSTALLATION
Observe all local plumbing codes.
Make sure that the water supply is shut off.
Read these instructions carefully to ensure proper installation.
 For new lavatory installation, install the faucet before installing the
lavatory.
TOTO reserves the right to update the product design without notice.
Check to make sure you have all these parts from the package:
INCLUDED PARTS
Spout * Flex Hoses
(Hot & Cold) Drain
(TL170SDLQ only)
Spout Mounting Flange Spout Key Connector Assembly
Flat Gasket Winged Gasket Gasket
Flat Washer Slot Washer Spout Mounting Nut
* Actual product may vary in appearance depending on the model.

4
ENGLISH
INSTALLATION PROCEDURE
IM PORTANT: Before installation, any
dirt and debris in the cold/hot water
supply pipes must be washed out.
1) Wipe any dirt away from around the
installation hole.
Measure the installation holes and
select the gasket that will fit the hole
diameter:
Hole more than
1-7/16” (36mm)
Hole less than
1-7/16” (35mm)
Winged Gasket Flat Gasket
Spout
Gasket
Faucet Mounting Shaft
Hot Water
Supply Hose
Spout Mounting
Flange
Cold Water
Supply Hose
Flat Washer
Lock Washer
Nut
Faucet Mounting Shaft
SECTION
4) Insert one gasket in each connector and
fasten to each of the supply stop valves. Use
a wrench to tighten them.
5) Place one gasket in each cap nut of the cold/
hot flex hoses and fasten to each of the con-
nectors. Use a wrench to fasten them.
WARNINGS:
• The minimum bending radius of the hose is
2-3/8” (60mm). Bending it further may cause
damage.
• During installation, do not bend the hose
from the end surface of the main faucet body
too far.
• Do not pull the hose violently as this may
break the hose.
• Avoid unnecessary contact of similar hoses, as
friction may cause damage.
Flex Hose (Hot)
Flex Hose
(Cold)
Cap Nut
Gasket
Connector
Gasket
Stop Valve
2) Place the correct gasket around both supply hoses and move it up against the bot-
tom surface of the faucet body. Insert the hoses into the mounting hole until the
spout rests on the surface.
3) Place the mounting flange on the shaft of the faucet as shown. Place the flat washer
and lock washer onto the shaft and fasten the nut until it is snug. Double-check the
faucet alignment and tighten the nut to secure it.
Good Bad Bad Bad
R=2-3/8” (60mm)
and higher
Cold Water
Flex Hose
Hot Water
Supply Hose
R=2-3/8”
(60mm) and
higher

5
ENGLISH
Installation of the Pop-up Drain with Cable
(For TL170SDLQ only)
1) Apply pipe tape to the threads of the
drain body.
2) Insert the drain body into the drain
hole of the lavatory.
3) Assemble the gasket, flange nut and
lock nut to the drain body.
4) Apply pipe tape to the end threads
of the drain body and fasten the tail
piece.
NO TE: Make sure that the cable faces
towards the faucet.
5) Connect the cable base connector
with the cable handle connector.


Drain Lever
Cable Handle
Connector
Press the clip
to be able to
connect
Cable
Cable Base
Connector
Clip
Groove, to which
the connection is
to be made.
Clip
Flange
Drain Gasket
Flange Nut
Drain Body
Lock Nut
Lavatory
Cable
Drain Body
Lock Nut
Tailpiece
Faucet
Handle
Drain Lever
Cable Handle
Connector
Cable Base
Connector
Cable
Drain Body
U-cup Seal
Tailpiece
CARE & CLEANING
Your new faucet is designed for years of trouble-free performance. Keep it
looking new by cleaning it periodically with mild soap, rinsing thoroughly
with warm water and drying with a clean, soft cloth. Do not use abrasive
cleaners, steel wool or harsh chemicals, as these will dull the finish. Failure
to follow these instructions may void your warranty.
