CWT4263056CMFGA
AP WASHLET®+ S550e Wall-Hung Toilet, 1.28GPF & 0.9GPF
FEATURES
AP Bowl
• DYNAMAX TORNADO FLUSH®system, high
efficiency (1.28GPF/0.9GPF)
• CEFIONTECT®ceramic glaze - prevents debris, mold
from sticking to ceramic surfaces
• Universal Height
• Elongated shape front bowl
S550e WASHLET
• Contemporary elongated WASHLET
DuoFit In-Wall Tank
• Dual flushing system, high-efficiency
(1.28 GPF/4.8 LPF & 0.9 GPF/3.4 LPF) Avg. flush 1.03 GPF
• Adjustable 15”-19” mounting height
• Saves up to 9” of floor space compared to standard
floor-mounted toilet
• Supports up to 880lbs
• Commercial 2” x 6” or optional residential installation
with 2” x 4” wall studs with waste outlet kit
• Copper supply line
Push Plate
• YT930#MS
Matte Silver Basic Round Push Plate
CODES/STANDARDS
• Meets or exceeds:
-Bowl: ASME A112.19.2/CSA B45.1, ASME A112.19.14
-Carrier System: ASME A112.6.2
-Tank Trim: IAPMO PS50, CSA B125.3, ASSE1002
• Certifications: IAPMO (cUPC), EPA WaterSense State
of Massachusetts, City of Los Angeles and others
• Legislative compliance: California AB715, California
Green Building Code, City of Los Angeles Water
Efficiency Ordinance
• Code Compliance: UPC, IPC, NSPC, NPC Canada,
and others
• Complies with CA Prop 65 warning requirements
Certified by
IAPMO R&T
KIT COMPONENTS
• CT426CFGT40#01
AP Wall-Hung Toilet
• WT173MA
• In-Wall Tank System (Copper Pipe)
• SW3056AT40#01
S550e WASHLET
Elongated WASHLET
• THU794
WASHLET connection kit
• YT930#MS
Matte Silver Basic Round Push Plate
COLORS/FINISHES
• Standard
#01 Cotton
CEFIONTECT
DYNAMAX
TORNADO FLUSH Skirted Design
Available Options
• YT920#WH - White Matte Basic Square Push Plate
• YT920#MS - Matte Silver Basic Square Push Plate
• YT930#WH - White Matte Basic Round Push Plate
• YT970#SS - Stainless Steel Wall Square Push Plate
• YT980#SS - Stainless Steel Wall Round Push Plate
EWATER+
AUTO FLUSH

PRODUCT SPECIFICATIONS
PRODUCT DIMENSIONS
CWT4263056CMFGA
AP WASHLET®+ S550e Wall-Hung Toilet, 1.28GPF & 0.9GPF
CT426CFGT40
This universal height, high efficiency
DYNAMAX TORNADO flushing system
toilet shall be 1.28GPF & 0.9GPF. Toilet
shall have CEFIONTECT®ceramic
glaze. Toilet shall be mounted to in-
wall tank system,elongated front bowl
and wall-mounted push-button type
trip lever. Toilet shall be TOTO Model
CT426CFGT40#01.
CT426CFGT40
WT173MA
This universal height, high-efficiency,
dual flushing, in-wall tank system toilet
shall be1.28GPF & 0.9GPF. Requires
TOTO toilet model CT426CFGT40. In-
Wall tank system shall be TOTO Model
WT173MA.
16 1/8"
[410mm] 5 1/2"
[140mm]
7 1/8"
[180mm]
18 1/2"
[470mm]
15"
[380mm]
3 1/2"
[90mm]
21 1/4"
[540mm]
4 3/4"
[120mm]
1 3/4"
[45mm]
10 7/8"
[278mm]
12 5/8"
[320mm]
8 5/8"
[220mm]
14"
[355mm]
3 3/8"
[85mm]
16 1/2"
[419mm]
5 1/4"
[135mm]
Ø5 7/8"
[Ø150mm]
Ø2 1/8"
[Ø55mm]
Ø1"
[Ø25mm]
Ø5/8"
[Ø15mm]
Ø2"
[Ø50mm]
S550e
Contemporary elongated WASHLET
YT930#MS
Dual Button Push Plate
#MS Matte Silver
CT426CFGT40 S550e WT173MA
Water Use 1.28 GPF & 0.9 GPF
(4.8 LPF & 3.4 LPF)
1.28 GPF & 0.9 GPF
(4.8 LPF & 3.4 LPF)
Flush System DYNAMAX TORNADO FLUSH®Dual flushing
Min. Water Pressure 8 psi (static) 8 psi (static)
Max. Water Pressure 108.75 psi (static) 108.75 psi (static)
Water Surface 5-1/2” X 4-1/8”
Trap Diameter 2-1/8”
Installation Height 15” to 19” 15” to 19”
Trap Seal 2-1/8”
Warranty One Year Limited Warranty One Year Limited Warranty One Year Limited Warranty
Material Vitreous China Various
Shipping Weight 68 lbs 9 lbs 38 lbs
Shipping Dimensions 22” L x 14.6” W x 16.5 H 20-5/8” L x 19-1/8” W x 3-1/4” H 48” L x 26-1/2” W x 6” H
5 1/2"
[140mm]
15 1/16"
[383mm]
20 15/16"
[531mm]
11 13/16"
[300mm]
7 7/8"
[200mm]
4 13/16"
[122mm]
23 3/16"
[588mm]
1 7/16"
[37mm]
1/4"
[7mm]
S550e

CWT4263056CMFGA
AP WASHLET®+ S550e Wall-Hung Toilet, 1.28GPF & 0.9GPF
#SS-01473 v.03Ph: [phone] | Fax: [phone] | www.totousa.com | © TOTO USA
These dimensions and specications are subject to change without notice
DIMENSIONS
INSTALLATION NOTES
Proper
Installation
Impr
Installation
Baseboard
Uneven wall gap
Back of toilet even
with installation surface
1
16 " Wall gap
Finish wall Finish wall
9½"
[243mm]
6¼"
[159mm]
1"
[25mm]
⅜"
[10mm]
YT930 Basic Round
YT930
9½"
[243mm]
6¼"
[159mm]
1"
[25mm]
⅜"
[10mm]
YT930 Basic Round
2"
[51mm]
7"
[180mm]
45
⅜
" - 50
⅜
"
[1150 - 1280 mm]
Drain Hole ℄:
15"
[381mm]
1
3
4
" from front of frame
using 2"x4" installation kit
THU343
2"x4"
[51mm x 102mm]
Installation
Drain Hole ℄:
1
3
4
" or 3
1
4
" from front
of frame using
Ø90mm Outlet Pipe
2"x6"
[51mm x 152mm]
or with Back Access
Installation
Finished Floor
*Refer to
Installation Manual
on the specific
Carrier height for
the desired height
of the toilet
Frame Work
Follow wall framing code
around the Carrier
233
4"
[603mm]
31
2"
[89mm]
51
2"
[140mm]
Finished Wall
thickness
1
2
" to 2"
Finished Wall
thickness
1
2
" to 2"
45
15
16"
[1167mm]
233
8"
[593mm]
16 7
16"
[418mm]
19"
[483mm]
20 7
16"
[520mm]
1
2
" NPT Water
Supply to
Washlet
1
2
" NPT
Water
Supply
WT173MA
• Adequate structural bracing is required
• Framing support should be capable of supporting 880 lbs load
without damage to the wall. See installation manual for more
details.
