Tower Hobbies CW20 Operator's manual

BMT131000BLG
CW20
Cordless Window cleaner
SAFETY AND INSTRUCTION MANUAL
PLEASE READ CAREFULLY
*Subject to registering your Extended Guarantee online at www.towerhousewares.co.uk.

2
GREAT BRITISH DESIGN, INNOVATION
AND EXCELLENCE SINCE 1912
Since the turn of the 20th century, Tower has been
designing, developing and manufacturing housewares and
small appliances used by millions of households throughout
the UK and beyond. During the 1960s, the rise in popularity
of pressure cooking saw Tower become the UK’s largest
producer of pressure cookers, right through into the late
1980s. In recent years the Tower brand has been reborn with
an exciting and varied range of housewares and electrical
appliances that have quickly reinstated the brand’s richly
deserved status as a household name.
Visit
www.towerhousewares.co.uk
for more fantastic products.

3
Contents:
Thank you for purchasing this appliance from the
Tower range.
Please read this manual carefully BEFORE using the
appliance for your own safety.
It has been designed to provide many years of
trouble-free use.
There are many benets to using a Tower Cordless
Window cleaner:
• Powerful 2 Kpa suction.
• 20W motor.
• 150ml removable water tank.
• 30 minute run timer from a single charge.
• Long-life lithium battery.
• Includes spray bottle, squeegee and wiper.
1. Specications
Components and
structure
2. Technical Data
3. Important Safety
Information
4. Before First Use
5. Using your Appliance
6. Troubleshooting
7. Recycling
8. Cleaning & Care
9. Wiring Safety
10. Warranty Information
See back page for Customer
Service Information.

4
This box contains:
Instruction Manual
Window Vacuum
Charger
Spray Bottle
Squeegee
Microbre Cloth
1. Squeegee
2. ON/OFF switch
3. Water tank
4. Charger port
5. Charging/ON/OFF indicator
6. Bottle
7. Cloth head attachment
8. Cloth head securing ring
9. Microbre cloth
1 - Specications:
Structure of your appliance:
2
4
3
5
6
1
7
8
9

5
Description: CW20 Cordless Window cleaner
Model: BMT131000BLG
Mains Charger: DC 5V
Battery: Rechargeable 3.7V 2200mAh
Charging Time: 3h
Running Time: 30min
Product Power: 20W
Documentation
We declare that this product conforms to the following product legislation in
accordance with the following directive(s):
2014/30/EU Electromagnetic Compatibility Directive.
2014/35/EU Low Voltage Directive.
2011/65/EU Restriction of Hazardous Substances Directive.
RK Wholesale LTD Quality Assurance, United Kingdom.
2 - Technical Data:
Should you encounter problems or require a replacement part, contact the Tower
Customer Support Team: [phone].
Some spare parts may be ordered from the Tower website.
Your warranty becomes void should you decide to use non Tower spare parts.
Spare parts can be purchased from www.towerhousewares.co.uk
Guarantee for spare parts:
The spares and accessories are guaranteed for 1 year from date of purchase.
The main body and housing are guaranteed for the extended free warranty subject
to registration.
If any defect arises due to faulty materials of workmanship, the faulty products must
be returned to the place of purchase within 12 months from the date of purchase.
Refund or replacement is at the discretion of the retailer.

6
Please read these notes carefully BEFORE using your
Tower appliance
3 - Important Safety Information:
• Check that the voltage
of the main circuit
corresponds with the
rating of the appliance
before operating.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and
seek advice from the
manufacturer, its service
agent or a similarly
qualied person.
• DO NOT let the cord
hang over the edge of a
table or counter or let it
come into contact with
any hot surfaces.
• DO NOT carry the
appliance by the power
cord.
• The use of accessory
attachments is not
recommended by the
appliance manufacturer
apart from those
supplied with this
product. DO NOT use
extension cords with the
appliance.
• DO NOT pull the plug
out by the cord as this
may damage the plug
and/or the cable.
• Switch off at the wall
socket then remove the
plug from the socket
when not in use or
before cleaning.
• Switch off and
unplug before tting
or removing tools/
attachments, after use
and before cleaning.
• Close supervision is
necessary when any
appliance is used by or
near children.
• Children should not play
with the appliance.
• This appliance can
be used by children
aged from 8 years and
above and persons
with reduced physical,
sensory or mental
capabilities or lack
of experience and
knowledge if they have
been given supervision
or instruction
concerning use of the
appliance in a safe way
and understand the
hazards involved.
• Cleaning and user
maintenance should
not be undertaken
by children without
supervision.

7
• Take care when any
appliance is used near
pets.
• Not suitable for carpets
with long bres as the
bristles will damage the
bres.
• Keep the vacuum
cleaner moving over
the carpet surface
at all times to avoid
damaging the carpet
bres.
• DO NOT use this
product for anything
other than its intended
use.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or
any other liquid.
• This appliance is for
household use only.
• DO NOT use the
appliance outdoors.
• Keep hair, loose
clothing, ngers and all
body parts away from
moving parts.
• DO NOT use to pick up
ammable liquids such
as gasoline or use in an
area where they might
be present.
• DO NOT use the
appliance without the
dust container lter in
place.
• DO NOT pick up
anything that is burning
or smoking such as
cigarettes, matches or
hot ashes.
• Use extra care when
cleaning on stairs.
• Use only manufacturer’s
recommended
accessories.
• DO NOT pull cord, use
cord as a handle, close
a door on cord, or pull
cord around sharp
edges or corners.
• DO NOT run vacuum
cleaner over the cord.
Keep cord away from
heated surfaces.
• This product is tted
with a thermal cut-out,
which will activate if the
motor overheats due
to blocked air inlets. If
the appliance cuts out,
allow it to cool for 1 hour,
then empty the dust
container and clean all
of the lters.
• In the unlikely event
the appliance develops
a fault, stop using
it immediately and
seek advice from the
Customer Support
Team:
[phone]

8
Read all instructions and safety information carefully before rst use. Please retain
this information for future reference.
1. Remove the product from the box.
2. Remove any packaging from the product.
3. Please retain all packaging until you have checked and counted all the parts
and the contents against the parts list.
4. Dispose of the packaging in a responsible manner.
4 - Before First Use
Assembling the Unit:
1. To use the unit, begin by assembling it.
2. To assemble the window vacuum, clip the squeegee onto the main body of
the unit. To do this, align the 2 tabs at the back of the squeegee with the 2
corresponding slots on the main body of the unit.
3. Once the parts are lined up, push down on the grooved tab at the underside of
the squeegee and push the attachment onto the main body of the unit until
both tabs click into place.
4. The window vacuum is now ready for normal use.
Charging the Unit:
1. This unit can be charged from the mains, using the included mains adaptor.
2. To charge the unit, insert the mains adaptor into its corresponding jack at the
back of the unit and plug it into an active mains socket, ensuring the socket
switch is turned to the ON position. The LED indicator above the charging port
will ash blue to indicate the unit is charging.
Note: The normal charging time for this unit is of approximately 3 hours.
3. The unit will be fully charged when the LED indicator changes from ashing
blue to solid blue. This indicates the window vacuum is ready for normal use.
4. When the unit’s battery is running low, the LED indicator will begin to ash
blue. This indicates the battery has reached 5% capacity. When the battery is
fully at, the indicator will ash quicker and the motor will stop running. When
this occurs, charge up the unit as detailed above.
Note: A rapidly ashing blue indicator and stopped motor when the unit is fully
charged may also indicate the unit’s automatic safety cut-off system has activated.
Should this occur, check that the vents are not being blocked and that the water
reservoir is rmly secured to the unit before attempting to use the unit again.
5 - Using Your Appliance

9
Using the Window Vacuum:
1. Once the window vacuum has been assembled, press the On/Off button to
turn it on. The motor will start up and the LED indicator light on the lower part
of the unit will light up blue to indicate the unit has been turned on.
2. Press the On/Off button again while the unit is in operation to turn it off. The
motor will stop working and the LED indicator light on the lower part of the
unit will go out to indicate the unit has been turned off.
3. To use the vacuum cleaner, turn it on and run it over the area to be cleaned
in a straight line, from top to bottom or from side to side. The vacuum will
automatically absorb any water or moisture contained within that area and
store it in the water tank. Repeat this process as many times as necessary until
the relevant area has been fully cleaned.
Using the Spray Bottle:
1. This unit comes complete with a spray bottle, which can be lled with water or
a soft, non-abrasive detergent to clean windows or glass surfaces.
2. To ll this bottle, unscrew the spray nozzle and put it to one side. Fill the bottle
with water, replace the spray nozzle and turn it clockwise to tighten it and
secure it into place.
3. To use the spray bottle, press the trigger on the nozzle. Water will spray out
onto the surface to be cleaned.
Using the Cloth Head Attachment:
1. This unit comes complete with a cloth head attachment and microbre cloth
attachment, for use with the included spray bottle.
2. To use the cloth head attachment, begin by attaching it to the spray bottle.
To do this, remove the spray nozzle from the bottle and thread it through the
opening at the front of the cloth head attachment until it sits ush inside it.
3. Once the nozzle is securely positioned inside the opening, gently press the
two tabs on either side inwards and t the nozzle into the securing ring. The
securing ring is correctly installed when the protruding part is aligned with the
back part of the cloth head attachment. If the two parts are correctly aligned,
they will automatically click into place.
4. Once the cloth head attachment is correctly installed, t the microbre cloth
over the top of it using the included straps and Velcro pad.
5. The cloth head attachment is now ready for normal use.
Note: Ensure the spray bottle has been lled with water before attempting to use
the cloth head attachment.
6. To use the cloth head attachment, begin by spraying water onto the surface
to be cleaned, as described in the ‘Using the Spray Bottle’ section above. Once
the surface is wet, run the cloth head attachment over the areas to be cleaned,
as required. Once the surface has been cleaned, use the main unit to dry out
the affected areas if necessary.

10
Problem Possible Solution
The unit is not
working.
Ensure the unit is fully charged. If necessary, connect the included
mains adaptor into the unit and plug it into an active mains socket.
Ensure the unit is not clogged and that the water tank is correctly
placed within the main body of the appliance.
The automatic cut-off system may have activated. Wait for the ap-
pliance to cool down, then attempt to use it again.
The unit is streaking
surfaces when
cleaning.
Pull the upper silicone wiping lip out of the squeegee, rinse it, and
re-insert it into the unit in the reverse position. Ensure the lip is
fully inserted into the slot when replacing it onto the squeegee,
otherwise the process will have to be started again from the
beginning.
Use less cleaning solution when spraying the surfaces to be cleaned.
Water is leaking
from the air louvers.
The water tank is full. Drain the water tank as instructed in the
Cleaning and Care section of this manual.
6 - Troubleshooting
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic
rubbish. You are required to dispose of old electrical and electronic appliances like
this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to
information about the recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must
be recycled, rather than taken to landll.
Please arrange to take this appliance to your local Civic Amenity site
for recycling, once it has reached the end of its life.
7 - Recycling

11
Cleaning the Unit Body:
1. Before cleaning the unit body, ensure the unit is disconnected from the mains
supply and not in operation.
2. Use a damp cloth to clean the unit body. Never use any abrasive cleaning
materials or solvents, as these could cause damage to the surface of the unit.
WARNING! DO NOT allow any liquids into any part of the unit other than the water
tank, as this could cause damage to the electrical components and cause it to
malfunction.
Draining the Water Tank:
1. Any water or moisture picked up by the unit while in normal operation is
stored in the removable water tank. When this tank is full, it will need to be
drained.
2. To drain the water tank, open the tab at the front of it and insert a hose or tube
(not included) into the drain plug opening. Drain out the water in the tank,
then clean it, as described below.
Cleaning the Water Tank:
1. To clean the water tank, begin by removing it from the main body of the unit.
To do this, press down on the grooved tab at the top of the water tank and
pull it rmly towards you and away from the main body of the unit until it
detaches.
2. Once the water tank has been detached from the unit, separate the top half
from the bottom half to open it.
3. When the water tank is open, carefully pull the tube separator out until it
detaches from the bottom half of the tank.
4. Rinse the separator and the two halves of the water tank under running water
to clean them. Allow the parts to dry thoroughly before reassembling the water
tank.
WARNING! The water tank is NOT dishwasher safe. DO NOT attempt to clean the
water tank in the dishwasher.
5. Once the tank has been cleaned, re-assemble it by connecting the tube
separator to the bottom half of the tank, then attaching the top half of the
tube to the lower half so that the two are secured together.
6. When the water tank has been reassembled, press down on the grooved tab at
the top of the tank and align it with its corresponding notch on the main body
of the unit. Once the two parts are aligned, push the water tank back into the
appliance until it slots into place. When the water tank is in place, release the
grooved tab; it will automatically slot into place as well and secure the water
tank to the main unit.
Storing the Appliance:
1. Ensure the appliance is fully dry and the water tank has been drained before
storing.
2. Once the appliance is dry and the water tank has been drained, store it in a
cool dry place out of the reach of children, preferably in its original packaging.
8 - Cleaning & Care

12
9 - Wiring Safety for UK Use Only
WARNING:
Do not attempt to open any part of the power adaptor or plug.
(Power adapters only)
Never open the power adapter, you risk getting an electric shock.
Only use the power adapter that is supplied with your product.
You must always connect the power adapter to the product before connecting to
the mains power supply.
The power adapter must be used indoors only, and must not be subjected to damp
conditions.
The power adapter does not have any user serviceable parts.
If in doubt, consult a qualied electrician who will be pleased to do this for you.
If you need to remove the plug – disconnect it from the mains – and then cut it off
of the mains lead and immediately dispose of it in a safe manner. Never attempt
to reuse the plug or insert it into a socket outlet as there is a danger of an electric
shock.

13
This product is guaranteed for 12 months
from the date of original purchase.
If any defect arises due to faulty materials
of workmanship, the faulty products must
be returned to the place of purchase.
Refund or replacement is at the discretion
of the retailer.
The Following Conditions Apply:
• The product must be returned to the
retailer with proof of purchase or a
receipt.
• The product must be installed and
used in accordance with the
instructions contained in this
instruction guide.
• It must be used only for domestic
purposes.
• It does not cover wear and tear,
damage, misuse or consumable parts.
• Tower has limited liability for incidental
or consequential loss or damage.
This guarantee is valid in the UK and Eire
only.
The standard one year guarantee is only
extended to the maximum available for
each particular product upon registration
of the product within 28 days of purchase.
If you do not register the product with us
within the 28 day period, your product is
guaranteed for 1 year only.
To validate your extended warranty, please
visit www.towerhousewares.co.uk and
register with us online.
Please note that length of extended
warranty offered is dependent on product
type and that each qualifying product
needs to be registered individually in order
to extend its warranty past the standard
1 year.
Extended warranty is only valid with proof
of purchase or receipt.
As a thank you for purchasing
one of our fantastic products,
we are offering you an extra
2 years peace of mind in
addition to your 1 year
guarantee.
To receive your extra 2 year
guarantee, register your
appliance online within 28
days of purchase by visiting
www.towerhousewares.co.uk
10 - Warranty

14
Notes:

15
Notes:

thank you!
We hope you enjoy your appliance for many years. As a thank you for
purchasing one of our fantastic products, we are offering you an extra
2 years peace of mind.
*To receive your extra 2 years guarantee, register your appliance online
within 28 days of purchase by visiting:
www.towerhousewares.co.uk
Should you have a problem with your appliance, or need any spare parts,
please call our Customer Support Team on:
[phone]
0120.V2
Your warranty becomes void should you
decide to use non Tower spare parts.
Spare parts can be purchased from
www.towerhousewares.co.uk
