SAFETY AND INSTRUCTION MANUAL PLEASE READ CAREFULLY
T548005
TSC10
AQUAJETPLUS
SPOT PRO CLEANER

2
This box contains:
Instruction Manual
Hose
Hose Hook
Accessory Attachments:
• Suction Nozzle
• Brush with water suction cover
1. Handle
2. ON/OFF button
3. Clean Water Bucket
4. Hose
5. Hose Hook
6. Watering Button
7. Hose Handle
8. Water Level Indicator
9. Sewage Bucket
10. Power Cord Hook
11. Air Outlet
12. Air Outlet
13. Brush With Water Suction Cover
14. Suction Nozzle
Specifications:
3
4
10
8
9
5
12
5
1
11
16
67
13 14
2
Technical Data:
Model: T548005
Voltage: 220-240V
Wattage: 400W
Frequency: 50Hz
Clean Water Tank: 1.2Ltr
Dirty Water Tank: 1.2Ltr (Working Volume: 0.5L)

3
DISPOSAL OF THE UNIT
Appliances bearing the symbol shown here may not be disposed of in domestic rubbish.
You are required to dispose of old electrical and electronic appliances like this separately.
Please visit www.recycle-more.co.uk or www.recyclenow.co.uk for access to information about the
recycling of electrical items.
Please visit www.weeeireland.ie for access to information about the recycling of
electrical items purchased in Ireland.
The WEEE directive, introduced in August 2006, states that all electrical items must be
recycled, rather than taken to landfill.
Please arrange to take this appliance to your local Civic Amenity site for recycling,
once it has reached the end of its life.
Wiring Safety for UK Use Only
IMPORTANT
As the colours in the mains lead of this
appliance may not correspond with the
coloured markings identifying the terminals in
your plug, please proceed as follows:
The wires in the mains lead are labelled in
accordance with the following code:
Blue neutral [N] Brown live [L] Green/
Yellow [EARTH]
Plug Fitting Details (Where Applicable).
The wire labelled blue is the neutral and must
be connected to the terminal marked [N].
The wire labelled brown is the live wire and
must be connected to the terminal marked [L].
The wire labelled green/yellow must be
connected to the terminal marked with the
letter [E].
On no account must either the brown or the
blue wire be connected to the [EARTH] terminal.
Always ensure that the cord grip is fastened
correctly.
The plug must be fitted with a fuse of the same
rating already fitted and conforming to BS 1362
and be ASTA approved.
If in doubt consult a qualified electrician who
will be pleased to do this for you.
Non-Rewireable Mains Plug.
If your appliance is supplied with a non-
rewireable plug fitted to the mains lead and
should the fuse need replacing, you must use
an ASTA approved one (conforming to BS 1362
of the same rating).
If in doubt, consult a qualified electrician who
will be pleased to do this for you.
If you need to remove the plug - disconnect it
from the mains - then cut it off of the mains
lead and immediately dispose of it in a safe
manner. Never attempt to reuse the plug or
insert it into a socket outlet as there is a danger
of an electric shock.
FUSE
Earth
(Green/Yellow)
Fuse
Neutral
(Blue)
Live
(Brown)
WARNING:
This appliance MUST be earthed!

4
Please read these notes carefully BEFORE using your
Tower appliance
Important Safety Information:
• Check that the voltage
of the main circuit
corresponds with the
rating of the appliance
before operating.
• If the supply cord or
appliance is damaged,
stop using the appliance
immediately and
seek advice from the
manufacturer, its service
agent or a similarly
qualified person. Do not
disassemble, repair or
modify.
• DO NOT let the cord
hang over the edge of a
table or counter or let it
come into contact with
any hot surfaces.
• DO NOT carry the
appliance by the power
cord.
• DO NOT pull the plug
out by the cord as this
may damage the plug
and/or the cable.
• DO NOT pull cord, use
cord as a handle, close
a door on cord, or pull
cord around sharp
edges or corners.
• DO NOT use any
extension cord with this
appliance.
• Switch off at the wall
socket then remove
the plug from the
socket before fitting
or removing tools/
attachments, when
not in use or before
cleaning.
• WARNING: Always
switch off and unplug
your machine from the
electrical outlet before
filling the clean water
tank, emptying the
dirty water tank, before
assembling, opening,
before connecting/
disconnecting the
attachments, or carrying
out maintenance or
troubleshooting checks.
• DO NOT leave the
appliance unattended
when plugged in.
• DO NOT handle the
plug or appliance with
wet hands.
• Close supervision is
necessary when any
appliance is used by or
near children.
• Children should not play
with the appliance.

5
• This appliance can
be used by children
aged from 8 years and
above and persons
with reduced physical,
sensory or mental
capabilities or lack
of experience and
knowledge if they have
been given supervision
or instruction
concerning use of the
appliance in a safe way
and understand the
hazards involved.
• Cleaning and user
maintenance should
not be undertaken
by children without
supervision.
• Take care when any
appliance is used near
pets.
• Not suitable for carpets
with long fibres as the
bristles will damage the
fibres.
• Keep the appliance
moving over the carpet
surface at all times to
avoid damaging the
carpet fibres.
• DO NOT use this
product for anything
other than its intended
use.
• DO NOT immerse cords,
plugs or any part of the
appliance in water or
any other liquid.
• This appliance is for
household use only and
NOT for commercial or
industrial use.
• DO NOT use the
appliance outdoors.
• Keep hair, loose
clothing, fingers and all
body parts away from
openings.
• DO NOT put any objects
into openings.
• DO NOT operate with
openings blocked, keep
them free of anything
that may reduce
suction.
• DO NOT use to pick
up flammable or
combustible liquids
such as petrol or use in
an area where they may
be present.
• DO NOT use the
appliance on any
glowing, burning or
smoking particles.
• DO NOT use the
appliance to pick up
fine particles such as
powder, sand or dust.
• DO NOT use the
appliance to pick up
sharp items such as
needles, pins and glass.

6
• DO NOT use the
appliance without the
solution tank and dirty
water tank in place.
• DO NOT sit on the
appliance.
• Use extra care when
cleaning on stairs.
• Use only manufacturer’s
recommended
accessories.
• To prevent dirty water
from running into the
motor, keep the unit on
the floor, DO NOT hold
the appliance upside-
down or lay on its side.
Use the appliance in
a normal cleaning
position.
• DO NOT use the
appliance to clean
arts and crafts, non-
waterproof fibers (nets,
acetic acid, rayon,
etc.), non-waterproof
products (furs, leather
products, white wood
furniture, tea sets, etc.)
and vulnerable surfaces
(floors, tables).
• Keep the appliance
away from heat sources.
• In the unlikely event
the appliance develops
a fault, stop using
it immediately and
seek advice from the
Customer Support
Team:
[phone]

7
Before First Use:
Read all instructions and safety information carefully before first use. Please retain this information
for future reference.
1. Remove any packaging from the product and retain until you have checked all the parts are
present and checked for any visible damage to the appliance or cord.
2. Prepare the appliance, as instructed below.
3. Vacuum the carpet thoroughly. Use a vacuum cleaner with a rotating brush bar for best
results.
4. Test a small area of the carpet for colour fastness. To do this, dampen a white cloth with the
carpet cleaning solution, rub it gently over a small, hidden test area and check for any colour
bleeding. Check each colour. If the cloth remains clean and there is no colour bleeding, the
carpet should be safe to clean.
5. Dispose of the packaging in a responsible manner.
Preparing the appliance:
1. Insert the hose hook into the body of the appliance.
2. Slide the lock catch and lift the clean water tank from the unit.
3. Unscrew the cap and fill the clean water tank with clean water up to the maximum level. Use
tap water or alkali ionized water below 40ºC.
4. Screw the cap tightly to prevent leakage.

8
5. Re-install the clean water tank onto the appliance, sliding the tank into the unit until there is
an audible click and the lock catch reengages.
6. Insert the handle into the chosen accessory attachment, ensuring that the water outlet hole is
aligned.
Attaching the water suction cover:
1. Align the holes on the front of the cover with the pins on the brush head and press the back of
the cover until is engages with the brush head and there is an audible click.
Note: To remove the accessory from the hose handle, press the button on the handle and pull the
accessory away from the handle.
To remove the water suction cover, lift the tab on the cover and pull away from the brush head.
2. Fix the hose and the power cord to their respective hooks before moving the appliance.

9
Accessories:
Brush - To agitate stubborn stains and suck up spills on e.g. carpets
Suction Nozzle - For difficult to reach places such as the back of a chair
Using your Appliance:
• This portable carpet cleaner uses powerful suction to remove stains, spots and stubborn dirt in
tricky spots around your home and car and is suitable for carpets, hard floors, stairs, upholstery
and car interiors.
• This product is used to remove dirt by rinsing.
• Take care not to tilt the machine whilst water is in the tanks, in order to avoid spillage.
• Stop use and empty the dirty water tank when the ‘max.’ level is reached. If the appliance
continues to be used after the tank exceeds the maximum water level, the floating ball will
activate and the suction will stop.
• Be aware that fibrous carpets may block the air outlet, causing the appliance to stop
operating.
• If the hose becomes blocked, turn off the appliance unplug before clearing the blockage.
1. Plug the cord in to an electrical socket and turn the socket on.
2. Press the on/off button to turn the appliance on.
3. Press the water spray button to activate the water spray.
Spray the stain with the clean water and allow it to soak in to the fibres. Do not spray
continuously at the same spot.
4. After spraying, absorb the dirty water, so as not to cause mildew and odour.
Press the water suction inlet on to the stain and pull backwards in order to bring the water and
dirt up. Allow the appliance to suck up the dirty water.
Spray clean water while absorbing the dirty water.
Stop spraying, and absorb the dirty water.
5. Use an absorbent cloth to dry the surface further and then allow to air dry.
6. Press the on/off button to turn off the appliance and then unplug.
7. Hang the cord on the unit’s cord hook.
8. Empty the dirty water tank and any remaining water in the clean water tank. Refer to the
Cleaning and Care section.

10
Stubborn Dirt:
Clean the area with cleaning solvent first, prior to scrubbing.
CAUTION! DO NOT put cleaning solvent in to the clean water tank.
CAUTION! Ensure that the solvent is not harmful to the carpet before use. For the amount and
usage of the cleaning solvent, please read and follow the manufacturer’s instructions carefully.
DO NOT use diluents, aniline, chloroform and flammable solvents.
Recommended:
• Alkali ionized water
• Citric acid
• Hydrochloric acid water
• Not recommended:
• Neutral detergent for the kitchen
• Alkaline detergent
• Acid detergent
1. Apply the cleaning solvent to the carpet and rub the dirt with the brush to lift it up.
2. Spray the cleaning solvent with water and pull the water suction inlet backwards and forwards
across the stain in order to suck up the water, solvent and dirt.
3. Do not leave any solvent.
Safety Cut-off:
The motor is equipped with a thermal cut-out. If for any reason, the appliance should over-heat, the
thermostat will automatically turn the unit off. Should this occur:
1. Press the power switch and unplug the appliance from the electrical outlet.
2. Check for any blockages.
3. Clean the filters.
4. Allow the appliance to cool for approximately one hour.
5. Re-start the appliance; plug into an electrical outlet and switch back on.

11
Troubleshooting
Problem Possible Solution
The appliance does
not work after the
switch is turned on
Ensure that the plug is properly connected.
Check that the power cord is not damaged.
The overheat protection has activated. Refer to the Safety Cut-off section.
When the water spray
button is pressed,
there is no or little
water.
Ensure that the nozzle is not blocked. Remove and rinse with clean
water.
Check that the handle or pump is not damaged.
The suction does not
work or is very weak. Ensure that the power switch is turned on.
Ensure that the dirty water tank is correctly installed.
Empty the dirty water tank. If this tank is full, the floating ball may have
activated in the tank.
Ensure that he hose is not twisted, damaged or blocked.
Ensure that the inlet air sponge is not clogged. Clean or replace the
sponge.
Cleaning & Care
WARNING! Always switch off the appliance and unplug from the mains socket before carrying out
and cleaning and care.
DO NOT use chemical cleaners or abrasives to clean the appliance.
DO NOT immerse the appliance, cord or plugs in water or any other liquid.
Cleaning the Dirty Water Tank:
Note: This unit is equipped with an overflow protection feature, which will filter water out of the
front of the appliance whenever the dirty water tank is left full. This helps protect the electronics
inside the appliance from accidental water damage when the tank is left full.
1. Empty the dirty water tank when full or when cleaning is complete, in order to prevent
bacteria and bad odours.
2. Remove the dirty water tank taking care not to shake and tip the tank in order to prevent
leakage.
3. Open the upper cover of the dirty water tank, lifting the locking tab, and pour away the
contents.

12
4. Clean the tank, upper cover and sealing strip.
5. Re- install the sealing ring and upper cover, ensuring the tabs at the rear of the cover fit into
the slots of the tank. Press down until the locking tab reengages and there is an audible click.
6. Slide the dirty water tank into the unit until the locking tab engages and there is an audible
click.
Cleaning the Clean Water Tank:
1. After use, pour away the residual water in the clean water tank to prevent leakage and mildew.
2. Remove the clean water tank.
3. Unscrew the screw cap and pour away the remaining water.
4. Re-install the empty tank and then plug in and turn on the power again.
5. Press the water spray button to remove the remaining water from the appliance. When water
is no longer discharged, turn off the power switch and unplug the appliance.

13
6. Remove the clean water tank once more , tilt the appliance and pour away any remaining
water in the base of the unit.
Cleaning the Housing:
Wipe the housing with a soft, damp cloth. Add a little detergent to remove any stubborn dirt.
Cleaning the Accessories:
Remove the used accessories from the appliance and rinse thoroughly with clean water. Allow to air
dry.
Checking the Hose:
Always check the hose for breakage and leakage.
Cleaning the Inlet Air and Filter Sponges:
Rinse the inlet air sponge and filtering sponge after use, and replace them if they are damaged.
To access the inlet air sponge, remove the dirty water tank. The sponge is located in the unit
beneath the tank.
To access the filter sponge, remove the clean water tank. The sponge is located in the unit beneath
the tank.
Tip:
• Use a pair of tweezers to remove the sponges.
• Allow the sponges to dry after cleaning.
• Replace the sponges as necessary.
Storing the Appliance:
• Store in a dry place at room temperature, and avoid direct sunlight.
• Do not store in cold environments with water in the tanks, in order to prevent damage from
freezing.

14

15

0821.V1
thank you!
We hope you enjoy your appliance for many years
This product is guaranteed for 12 months from the date of original purchase.
If any defect arises due to faulty materials of workmanship, the faulty products must be returned to
the place of purchase.
Refund or replacement is at the discretion of the retailer.
The Following Conditions Apply:
The product must be returned to the retailer with proof of purchase or a receipt.
The product must be installed and used in accordance with the instructions contained in this
instruction guide.
It must be used only for domestic purposes.
It does not cover wear and tear, damage, misuse or consumable parts.
Tower has limited liability for incidental or consequential loss or damage.
This guarantee is valid in the UK and Eire only.
The standard one year guarantee is only extended to the maximum available for each particular
product upon registration of the product within 28 days of purchase. If you do not register the
product with us within the 28 day period, your product is guaranteed for 1 year only.
To validate your extended warranty, please visit
www.towerhousewares.co.uk and register with us online.
Please note that length of extended warranty offered is dependent on product type and that each
qualifying product needs to be registered individually in order to extend its warranty past the
standard 1 year.
Extended warranty is only valid with proof of purchase or receipt.
Your warranty becomes void should you decide to use non Tower spare parts.
Spare parts can be purchased from
www.towerhousewares.co.uk
Should you have a problem with your appliance, or need any spare parts,
please call our Customer Support Team on:
[phone]
