INSTRUCTION MANUAL
16”3 –IN –1 ADJUSTABLE STAND FAN
MODEL : FS 4076
230V~50Hz
POWER: 60W
Read all Instructions before Using

WARNING: To reduce the risk of fire, electrical shock, and injury to
person, the following must be adhered to:
1. This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
2. Children should be supervised to ensure that they do not play with the
appliance.
3. The product is for household use only.
4. Connect the appliance to a single-phase AC supply voltage, specified on
the rating plate.
5. Never leave the fan un-attended while it is in use. Always turn the fan to
the “OFF” position, and unplug the fan from the electrical outlet socket,
when not in use.
6. Extreme caution is necessary when any fan is used by or near children,
invalids or elderly persons, and whenever the fan is left operating
un-attended.
7. The fan cord must not be placed under carpets, or covered with throw
rugs. Arrange the cord away from the traffic area, and where it will not be
tripped over.
8. Do not operate the fan with a damaged cord or plug, or after the fan
malfunctions, or has been dropped, or damaged in any manner.
9. If the supply cord is damaged, either the manufacturer, or the service
agent, or a similarly qualified person, must replace it, to avoid a hazard.
10. Use the fan in a well ventilated area. While in use, ensure that the
airtakes or exhaust openings are not blocked un-expectedly, and the fan

distance from the wall or corner must be no less than 20cm. The fan
should not be placed below or besides any curtains or similar
11. To avoid mechanical danger when in use, do not insert, or allow fingers,
or any other objects into the grill. Do not block the air-intakes or the
exhaust openings in any manner.
12. The fan must only be placed, and used on a flat dry floor.
For household use only
Structure and parts
1. Front grill
2. Blade fasten nut
3. Blade
4. Grill fasten nut
5. Back grill
6. Dam-board
7. Motor cover
8. Back control box
9. Control panel
10. Bolt
11. Power cable
12. top tube
13. Bolt
14. Bottom tube
15. Base
16. Gasket

17. L shape screw
Assembly Instructions
The fan is packaged with its grills un-attached. You must attach the grills
before operating the fan.
WARNING: Never operate the fan without its foundation and other
parts. The fan must only operate in the up-right position, and any
other position will be hazardous.
Do operate the fan only in upright position; any other position could create
a hazardous situation.
Assemble the foundation and other parts of the appliance in the following
sequence:
Used as Stand fan
a). Unpack the fan and remove all parts from the package
b). Insert the bottom tube(14) into the hole of base(15), put the gasket(16)
under the base and tighten the base by L shape screw(17) in clockwise
way.
c). Insert the top tube(12) into the hole of bottom tube(14), and align the
bolt at the screw holes and tighten the bolt(13)
d). Insert the fan head into the hole of top tube(12) and align the screw hole,
screw and tighten the bolt(10)
c). Use the fasten nut(4) for the back grill(5) to attach the back grill to the
fan head, and then use the fasten nut(2) for the blade(3) to hold the blade
in place.
d). To attach the front grill(1) to the back grill(5), you must use the grill ring
carefully to hold them together, and fasten the grill ring with the screw
provided.

Used as Desk-stand fan
The step is same as above and just remove the top tube(12), and screw
the fan head to bottom tube(14).
Used as Desk fan
The step is same as above and just remove the top tube(12) and the
bottom tube(14), then screw the fan head to base(15).
Operating Instructions
1. Before using the fan, make sure that it is on a flat and stable surface.
Damage may occur if the fan is placed on an incline or decline.
2. Set all the switches to the “OFF” position, and then insert the plug
directly into a standard AC socket-outlet. Be sure that the plug fits tightly
into the socket-outlet.
3. Turn the speed switch on control panel to start the fan. “1” means low
speed, “2” means medium speed, “3” means high speed, “0” means turn
off the fan.
4. Press the oscillation switch on the top of motor cover, the fan will
oscillate from left to right automatically. Pull out the oscillation switch, it will
stop to oscillate.
Cleaning / Maintenance Instructions
To safely take care of your fan, please remember to follow these
instructions below:

1. Always remove the plug from the socket-outlet, and allow the fan to stop
completely before cleaning the fan.
2. Do not allow water to drip on, or enter into the fan housing.
3. Always use a soft cloth, moistened with a mild soap solution.
4. Do not use any of the following agents as a cleaner: Gasoline, Thinners,
or Benzene.
5. In case of malfunction or doubt, do not try to repair the fan yourself, it
may result in a fire hazard or electric shock.
FAN Cleaning
Clean the fan grill, housing and base with a soft damp cloth. Do not attempt
to remove the fan blades. Please use caution around the motor housing
area. Do not allow the motor, or other electrical components to be exposed
to water.
FAN Storage
When storing your fan in the off-season, it is important to keep it in a safe
dry location. It is important to protect the fan head from any dust. We
strongly recommend using the original box, when storing the fan away.

SERVICE & IMPORTANT NOTICE
●If the supply cord is damaged, it must be replaced by the manufacturer
or its service agent or a similarity qualified person in order to avoid a hazard.
●WARNING: This appliance is not intended for use by persons
(including children) with reduce physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
IMPORTED BY NATIONAL ELECTRICAL TRADERS
