Toyotomi Zibro LC-32 User manual

LC – 32
GB OPERATING MANUAL ..............................PAGE 2
DE GEBRAUCHSANWEISUNG............................PAGE 14
FR MANUAL D’UTILISATION ............................PAGE 26
NL GEBRUIKSAANWIJZING .............................PAGE 38
ES INSTRUCCIONES DE USO ............................PAGE 50
IT ISTRUZIONI D’USO .................................PAGE 62
PT MANUAL DE INTRUÇÕES ............................PAGE 74
DK BRUGERVEJLEDNING ...............................PAGE 86
NO BRUKERINSTRUKSEN ...............................PAGE 98
SE INSTRUKTIONERNA INNAN ANVANDNING..............PAGE 110
FI KäyTTöOHJEET ...................................PAGE 122

Thank you for choosing a “TOYOTOMI” product!
Toyotomi products are used by satisfied customers worldwide. In order to
assure the comfortable and safe use of our products by customers in each
country, our products conform to the safety standards not only in Japan but
also in every country around the world we do business with.
Toyotomi tailors its products to satisfy its customer’s needs by always
pursuing our business philosophy, “sharing joys in daily living”. We will
continue to research, develop and manufacture products that match people’s
lifestyle for efficiency, safety and comfort.
We hope that you’ll enjoy your Toyotomi appliance for years to come!
We invite you to read this instruction manual first, to ensure the maximum
lifetime for this appliance.
Get to know us better… visit us at www.toyotomi.eu for our full line of
products.
1 Read the diRections foR Use fiRst.
2 in case of anY doUbt, contact YoUR dealeR.
3 PoUR liRe, déPliez la deRnièRe Page. e e e e e e e e e e e e e 3 befoRe YoU staRt Reading, consUlt the Main coMPonents list on the last Page.
4
2

GENERAL DIRECTIONS FOR USE
Below you will find the main steps to be taken for using your
heater. For more details, please refer to the MANUAL.
• As a fire precaution, the tank must be filled either when the heater has
been switched off or in another room than the room where the heater is
installed.
• Always ensure that the tank is closed properly after filling it at a safe
distance from all sources of heat and open flames (see Section B).
• The first time the heater is ignited it will smell like “new” for a short time.
• Store all fuel containers with their original caps and seals in a cool and
dark place.
• Fuel ages. Use new fuel at the start of every heating season.
• Only use high quality and water-free pure paraffin in accordance with
local legislation.
• Before changing brands and/or types of fuel make sure that the mobile
heater first completely empties all of the remaining fuel inside the heater.
Remove all packaging materials (refer to Section A, Fig. A).
Fill the removable tank 6 (refer to Section B, Fig. C).
Insert the plug into the wall-socket.
Ignite the heater using the key L(refer to Section D).
If required, change the temperature using the adjustment keys
(refer to Section E).
Switch off the heater by pressing the key L.
1
2
3
4
5
6
1 Read the diRections foR Use fiRst.
2 in case of anY doUbt, contact YoUR dealeR.
3 PoUR liRe, déPliez la deRnièRe Page. e e e e e e e e e e e e e 3 befoRe YoU staRt Reading, consUlt the Main coMPonents list on the last Page.
4
3

This transportation cap
is packed separately in
the box. Only this cap
ensures trouble-free
transportation of the
heater after use.
Store it well!
WHAT YOU NEED TO KNOW IN ADVANCE
VENTILATE SUFFICIENTLY
Read this user manual carefully before using the appliance and keep it for future
reference. Install this device only when it complies with local/national legislation,
ordinances and standards. This product is intended to be used as a heater
in residential houses and is only suitable for use in dry locations, in normal
household conditions, indoors in living room, kitchen and garage.
For comfortable and safe heating ensure that there is sufficient ventilation.
NOTE: To avoid unexpected shut off, we recommend to put a door or window
ajar when the heater is operating.
Regardless of the model, you must always make sure that the heater is used
in a room large enough to enable the heater to be used safely without extra
ventilation (refer to Section P). If the room is smaller than required, you must
always open a door or window slightly (ensuring an opening of approx. 2.5 cm).
It is important that every room where the heater is used has sufficient air intake
and efficient air outflow (both openings must have a minimum cross section of 50
cm2).
We also recommend doing this in highly insulated or draught-free rooms and/
or at altitudes above 1300 metres. Do not use your heater in cellars or other
underground areas.
No modifications to the safety system are allowed, as that will invalidate the
guarantee that the air probe will work properly. Consult your dealer in case of
doubt.
ESPECIALLY FOR FRANCE: Your heater was designed to operate exclusively on
fuel for liquid fuel-operated mobile heaters in accordance with the Decrees of
18-07-2002 and 25-06-2010. The use of other fuels is forbidden.
Ask your dealer or check our website for the addresses of our retailers.
The liquid fuel-operated mobile heater is intended as an extra heater, and not as a
continuous source of heat.
ESPECIALLY FOR UNITED KINGDOM: Only use Class C1 paraffin fuel in
accordance with BS2869; Part 2, or equivalent.
The user must comply with the following instructions for proper use:
DO NOT
- use the liquid fuel-operated mobile heater in caravans, boats, and vehicle
cabins.
- use the liquid fuel-operated mobile heater in insufficiently ventilated rooms
(consult the table of properties for the minimum dimensions of the room to be
heated), underground rooms and / or at a height of over 1300 metres.
- modify the heater safety features.
The use of this type of heating in public rooms is subject to prior regulatory
permission. Obtain proper information on this in advance.
THE RIGHT FUEL
Your heater has been designed for use with high-quality water-free pure paraffin
oil. Only fuels of this kind will ensure clean and proper burning. Lower quality
fuel may result in:
increased possibility of malfunctioning
incomplete combustion
reduced heater lifetime
smoke and/or fumes
deposits on the grid or mantle
Using the right fuel is therefore essential for safe, efficient, and comfortable use
of your heater.
Damage and/or malfunctions of the heater due to the use of other than high-
quality water-free pure paraffin oil is not covered by the warranty.
Always refer to your local dealer for the right fuel for your heater.
Only the use of the
correct fuel will ensure
safe, efficient, and
comfortable use of
your heater.
4
4

4
5
14 TIPS FOR SAFE USE
1Children should be supervised to ensure that they do
not play with the appliance.
2DO NOT move the heater when it is burning or still
hot. DO NOT refill nor service the heater when it is
burning or still hot.
3Position the front of the heater at a distance of
minimum 1.5 metres from walls, curtains, and
furniture.
4DO NOT use the heater in dusty rooms. You will not
have optimum burning in such rooms. DO NOT use
the heater in the immediate surrounding of a bath, a
shower or a swimmingpool.
5Switch off the heater, before you leave or go sleeping. Unplug the heater as
well, when you go away for a longer period of time (e.g. holidays).
6Store and move fuel only in suitable tanks and jerrycans.
7Make sure that the fuel is not exposed to heat or extreme temperature changes.
ALWAYS store the fuel in a cool, dry and dark place (sunlight will affect the
quality).
8NEVER use the heater in places where harmful gasses or fumes may be present
(e.g. exhaust gasses or paint fumes).
9Beware that the grid of the heater becomes hot. If the appliance is covered
there is a risk of fire.
10 ALWAYS make sure that there is sufficient ventilation.
11 This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
12 This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of
the appliance in a safe way and understand the hazards involved.
13 Children shall not play with the appliance.
14 Cleaning and user maintenance shall not be made by children without
supervision.
Defective electrical devices and batteries must be kept separate from household
waste. Ensure that there is effective recycling where possible. Ask you local council or
dealer for expert advice on recycling.

!
4
6
MANUAL
A INSTALLING THE HEATER
1Carefully remove your heater from the box and check the contents.
In addition to the heater you also need to have:
a manual fuel pump
a transportation cap
these directions for use
Keep the box and the packaging materials (Fig. A) for storage and/or
transportation.
2Open the lid of the removable tank Dand remove the piece of cardboard.
3Fill the removable tank as indicated in Section B.
4The floor should be firm and completely level. Reposition the heater, when it
is not level. Do not try to correct the situation by placing books or other
goods under the heater.
5Insert the plug J into the wall-socket (230 Volts - AC / 50 Hz) and set the
correct time using the adjustment keys N (refer to Section C).
6Your heater is now ready for use.
SET ALTITUDE
If the heater is used at a height of over 800 m, use the altitude mode.
Push the altitude button with thin rod like a clip and plug into the outlet
simultaneously.
NOTE: When the altitude mode is set, the altitude mark “ “ is shown on the
display.
NOTE: In the event of power failure or disconnection of heater, the altitude setting
will remain.
Do not use the heater at a height of over 1300 meters.
BFILLING FUEL
Fill the removable tank in a suitable place since there can always be some
spillage. Follow the procedure below:
1Make sure that the heater is switched off.
2Open the upper lid and lift the removable tank out of the heater (Fig. B).
Put down the removable tank (cap pointing upwards, handle on floor) and
screw off the fuel cap (Fig. C).
NOTE: Some drops may leak from the tank.
3 Fill the removable tank using a fuel pump (refer to fuel pump operation
instructions.) Make sure that it is in a higher position than the removable tank
(Fig. D). Insert the ribbed hose into the opening of the removable tank.
A
B
C
D

!
G: The required tempe-
rature on the left, the
measured temperature
on the right.
F: When the 4-digit
stops blinking, the set-
ting has been locked to
the indicated value.
4Check the removable tank fuel gauge while filling the tank (Fig. E). Stop
filling once the gauge indicates that the tank is full. Never overfill the tank,
especially not when the fuel is very cold (fuel expands when it heats up).
5Let the remaining fuel in the pump flow back into the jerrycan and carefully
remove the pump. Carefully screw the fuel cap back on the tank. Clean off
any spilled fuel.
6Check whether the fuel cap is straight and tightened properly. Reinstall the
removable tank in the heater (cap down). Close the lid.
CSETTING THE CLOCK
It is only possible to set the correct time, when the heater is connected to the
mains and not burning. Use the adjustment keys N to set the time. First press
either of the two keys to switch on the function (the 4-digit K will start blinking).
Next, set the hours using the key on the left (Nhour) and the minutes using the
key on the right (Mmin.). Press once to increase the value by one step. When you
hold down the key, the value will continue going up, until you release the key
again. After approximately 10 seconds the 4-digit will stop blinking and the set-
ting will be locked (Fig. F). 5 minutes after switching off the heater, the informa-
tion on the display will disappear and the heater will automatically switch into the
stand-by position.
When the heater has been unplugged (or after a power failure), the time needs
to be set again.
DIGNITING THE HEATER
When used for the first time, a new heater may give out a smell for a short while.
You should therefore provide extra ventilation.
Always ignite the heater with the
button L . Never use matches or a
cigarette lighter.
Just press the button L to ignite the heater. The POWER lamp will start blinking,
indicating that the ignition procedure has started. This will take a short while.
Once the heater is burning, the POWER lamp will remain lit (red). The information
display Kwill show two numbers. The light next to them indicates that these
numbers refer to the temperatures (Fig. G). The actual room temperature is
indicated below ROOM, while the temperature setting is indicated below SET. The
latter can be changed with the adjustment keys (refer to Section E).
Prior to igniting the heater, always check for sufficient fuel in the removable tank.
ESETTING THE REQUIRED TEMPERATURE
The temperature setting can only be adjusted, when the heater is burning. Use
the adjustment keys N to adjust the temperature. First press either of the two
keys to switch on the function (the °C mark K will start blinking). Next, adjust the
temperature using the key on the right (Mmin.) to set the temperature to a higher
setting and the key on the left (Nhour) to lower the temperature. Press once to
increase the value one step. After approximately 10 seconds the °C mark will stop
blinking and the setting will be locked (Fig. G).
4
7
E
empty full

!
4
8
H: The TIMER indicator
light indicates that the
timer function has been
switched on.
In case of any
malfunctioning the
information display will
tell you what is the
matter.
The available temperature settings range from 6°C minimum to 28°C maximum.
When the heater has been unplugged (or after a power failure), the temperature
will reset to the factory setting of 20°C.
FUSING THE TIMER
The timer allows you to switch on the heater automatically at a preset time.
In order to switch on the timer, the correct time must have been set (refer to
Section C) and the heater should be off. Follow the procedure below:
1Press the
button Land then the TIMER key Oimmediately after that.
The TIMER lamp  and the 4-digit Kwill start blinking.
2Use the adjustment keys Nto set the time at which the heater must ignite.
Use the key on the left (Nhour) to set the hours and the key on the right
(Mmin.) to set the minutes (interval of 5 minutes).
3After approximately 10 seconds the 4-digit will show CLOCK again and the
TIMER lamp will light up, indicating that the timer function has been
activated (Fig. H).
4The timer will ensure that the room will have been heated to approximately
the required temperature at the set time.
When you want to switch off the heater and ignite it again with the timer, all
you have to do is press the TIMER key (refer to Section G).
Press the button Lonce to clear the timer setting.
GSWITCHING OFF THE HEATER
There are two ways to switch off the heater.
1Press the button L. The information display will show the CLOCK
signal. Within approximately one minute the flame will have extinguished.
2Press the TIMER key O, when you want to switch off the heater and ignite it
again with the timer the next time. This not only switches off the heater, but
it also activates the timer function. You can change the required time with
the adjustment keys N(refer to Section F).
H THE INFORMATION DISPLAY
The information display Knot only serves as an indicator of the (set) time and
temperature (Sections C, E, and F), it also indicates any malfunctioning of the
heater. The code on the information display tells you what is the matter:

CODE INFORMATION WHAT TO DO
e - 0 Temperature within the heater too high. Cool-down and re-ignite.
f - 0 Power interrupted. Re-ignite the heater.
e - 1 Faulty thermostat. Contact your dealer.
f - 1 Faulty burner thermistor. Contact your dealer.
e - 2 Starting problems. Contact your dealer.
e - 5 Tipping-over protection. Re-ignite the heater.
e - 6 Poor burning. Contact your dealer.
e - 7 Room temperature If necessary,
above 32°C. re-ignite the heater.
e - 8 Defective booster. Contact your dealer.
e - 9 Air filter dirty; or Clean filter.
Fuel pump dirty. Contact your dealer.
The heater has been in operation
continuously for a period of 65 hours
and has turned itself off automatically. Switch the heater back on.
-- : --
+
Out of fuel. Refill removable tank.
-- : --
+
Too little ventilation. Ventilate better.
Always contact your dealer for any malfunctioning not listed above and/or when
the error keeps occuring after taking the corrective measure as described above.
AUTOMATIC DEACTIVATION
This heater is fitted with a safety system that ensures that it switches off
automatically after 65 hours continuous operation. The following will then appear
in the display: . If desired, you can switch the heater on again by pressing
the button
L (see Section D).
AUTOMATIC CLEANING MODE
When the heater has been burning continuously for two hours at its highest
setting, the burner will automatically start an autoclean procedure. The display
will show the autocleaningcode cl:05 running back to cl:01. The procedure takes 5
minutes, during which the heater will burn at its lowest setting, while the burner
autocleans. When the burner is clean again, the heater will automatically switch
back to the highest setting again.
I CHILDPROOF LOCK / PARENTAL CONTROL
The childproof lock can be used to prevent children accidentally changing the
heater settings. When the heater is burning and the childproof lock is on, the
heater can only be switched off. Other functions are blocked then. If the heater
has already been switched off, the childproof lock also prevents accidental ignition
of the heater.
Activate the childproof lock by pressing the appropriate key Mand
holding it down for more than 3 seconds. The KEY-LOCK indicator
will appear on
the information display (Fig. I), indicating that the childproof lock has been activated.
Switch off the childproof lock by pressing the key Mand holding it down for more
than 3 seconds once again.
I: When the mark
appears, the childproof
lock has been activated.
4
9

!
4
10
J THE CORRECT USE OF ‘SAVE’
The ‘SAVE’ function allows you to limit the temperature. When this function is
activated, the heater will automatically switch off, when the room temperature exceeds
the set temperature by 3°C. Subsequently, when the room temperature has dropped
again to the set temperature, the heater will automatically switch on again.
Activate
the ‘SAVE’ setting by pressing the appropriate P key. The SAVE indicator light will
light up (Fig. J). Switch off the function by pressing the SAVE key once again.
Without the ‘SAVE’ setting your heater will maintain the set temperature by
approximation as well, by adjusting its heating capacity. ‘SAVE’ is an economy
setting, which you can use when, for instance, you are not present in the room
or to keep it frost-free.
K THE ‘FUEL’ INDICATOR
When the FUEL indicator appears, it means that there is only fuel left for 10
more minutes. The count-down of the remaining heating time can be seen in the
information display K (Fig. K). Now you have two options:
you remove the fuel tank and refill it outside the living room (Section B) or
you push the button extension . By pushing this button, the remaining
heating time will extend to 60 minutes.
The heater will automatically switch back to its lowest position. In the display
the number 60 will appear, which will decline to 10. At the arrival of 10,
you will hear an alarm signal every two minutes, warning you to refill the
removable tank. If you do not react, the heater will extinguish by itself. The
heater will also sound a warning signal, when it switches off. The fuel
indicator will blink, while four lines (--:--) are blinking in the information
display. You can stop this by pressing the button L once more.
Once the heater has used up all its fuel and extinguished, it will take some time,
after the refill, before the heater is completely ready for use again.
L THE ‘VENT’ INDICATOR
When the VENT indicator starts blinking, this is a sign that the room is not vented
sufficiently (Fig. L). The heater will switch off automatically. If the indicator continues
blinking after extra ventilation, please contact your dealer..
MMAINTENANCE
Switch off the heater and let it cool down, before you start any maintenance
work. Also disconnect the plug from the mains. Your heater needs hardly any
maintenance. It is, however, important that you clean the vent filter 8with a
vacuum cleaner and the grid 2 with a damp cloth, both on a weekly basis.
Regularly inspect the fuel filter as well:
1Remove the removable tank 6from the heater and remove the fuel filter
(Fig. M). Some drops may leak from the filter; keep a cloth at hand.
2Remove the dirt by tapping the fuel filter upside-down against a hard surface.
(Never clean it with water!)
M
Fuel filter
K: When the FUEL
indicator has appeard,
the information display
will show the number of
minutes of fuel left in
the tank.
L: A blinking VENT
indicator is a sign
that you need extra
ventilation.
J: When the SAVE light
lights up, the heater will
automatically switch on
or off in order to remain
within a specified tem-
perature range.
