Toyotomi zibro LC-DX320 User manual

LC – DX320
GB OPERATING MANUAL .............................. PAGE 2
DE GEBRAUCHSANWEISUNG............................ PAGE 14
FR MANUAL D’UTILISATION ............................ PAGE 26
NL GEBRUIKSAANWIJZING ............................. PAGE 38
ES INSTRUCCIONES DE USO ............................ PAGE 50
IT ISTRUZIONI D’USO ................................. PAGE 62
PT MANUAL DE INTRUÇÕES ............................ PAGE 74
DK BRUGERVEJLEDNING ............................... PAGE 86
NO BRUKERINSTRUKSEN ............................... PAGE 98
SE INSTRUKTIONERNA INNAN ANVANDNING.............. PAGE 110
FI KÄYTTÖOHJEET ................................... PAGE 122

AFNOR CERTIFICATION - 11, RUE FRANCIS DE PRESSENSE
93571 LA PLAINE SAINT-DENIS CEDE
PRINCIPALES CARACTERISTIQUES CERTIFIEES:
CONSEILS D’UTILISATION ET D’ENTRETIEN
Référence et numéro de lot ou de série de l’article : se reporter au produit
Distributed in Europe by:
TOYOTOMI EUROPE SALES B.V.
Huygensweg 10,
5466 AN Veghel, The Netherlands
Si une difficulté subsistait, vous pouvez écrire à:
En cas d´insatisfaction, consultez d´abord:
La marque NF garantit
la qualité de cet article
suivant les normes françaises
et Référentiel de certification
de l’application NF 128
Se reporter à la notice jointe à l’appareil et à la plaque de sécurité sur
l’appareil
CONFORME A LA NORME NF D 35-300 : 1992, NF EN 60335-1 : Mai 2013,
NF EN 50106 : septembre 2009 ET AUX DECRET 92-1280 et DECRET 2004-954,
AUX SPECIFICATIONS COMPLEMENTAIRES DEFINIES PAR LES REGLES DE
CERTIFICATION DE LA MARQUE NF 128
• Sécurité du dispositif d’allumage
• Débit calorifique
• Efficacité des dispositifs de sécurité
• Stabilité
• Contrôle de la teneur en NOx dans les produits de combustion
• Contrôle de la qualité de la combustion (absence de CO)
• Endurance
• Intermittence
Email: [email protected] Website: www.toyotomi.eu
EUROVENT CERTITA CERTIFICATION
48/50, rue de la Victoire
75009 PARIS
FICHE INFORMATIVE

4
15 TIPS FOR SAFE USE
1Children should be supervised to ensure that they do not play
with the appliance.
2DO NOT move the heater when it is burning or still hot. DO
NOT refill nor service the heater when it is burning or still hot.
3Position the front of the heater at a distance of minimum
1.5 metres from walls, curtains, furniture, spray can and gas
cylinder. DO NOT store the fuel tank near the heater.
4DO NOT use the heater in dusty rooms. You will not have
optimum burning in such rooms. DO NOT use the heater in the
immediate surrounding of a bath, a shower or a swimmingpool.
5Switch off the heater, before you leave or go sleeping. Unplug
the heater as well, when you go away for a longer period of time (e.g. holidays).
6Store and move fuel only in suitable tanks and jerrycans.
7Make sure that the fuel is not exposed to heat or extreme temperature changes. ALWAYS store
the fuel in a cool, dry and dark place (sunlight will affect the quality).
8NEVER use the heater in places where harmful gasses or fumes may be present (e.g. exhaust
gasses or paint fumes).
9Beware that the grid of the heater becomes hot. If the appliance is covered there is a risk of
fire.
10 ALWAYS make sure that there is sufficient ventilation.
11 The heater must not be located immediately below a socket-outlet.
12 Children of less than 3 years should be kept away unless continuously supervised. Children
aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it
has been placed or installed in its intended normal operating position and they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate
and clean the appliance or perform user maintenance.
CAUTION - Some parts of this product can become very hot and cause burns. Particular
attention has to be given where children and vulnerable people are present.
13 Children shall not play with the appliance.
14 Cleaning and user maintenance shall not be made by children without supervision.
15 DO NOT stay near the heater for a long time.
Defective electrical devices and batteries must be kept separate from household
waste. Ensure that there is effective recycling where possible. Ask you local council
or dealer for expert advice on recycling.


15 TIPS ZUR SICHERHEIT
1Kinder sind zu beaufsichtigen, um sicherzugehen, dass sie nicht
mit dem Gerät spielen.
2Transportieren Sie den Ofen NICHT, wenn er brennt oder
noch heiß ist. In diesem Fall auch KEINE Wartungsarbeiten
durchführen.
3Stellen Sie den Heizofen so auf, daß er sich mit der Vorderseite
minimal 1,5 Meter von Mauern, Gardinen, Möbeln, Sprühdoce
und Gas Zylinder befindet. Bewahren Sie den Brennstofftank
NICHT neben dem Ofen auf.
4Benutzen Sie den Heizofen NICHT in staubigen Räumen und NICHT an Stellen, an denen es stark
zieht. In beiden Fällen erhalten Sie keine optimale Verbrennung. Benutzen Sie den Heizofen
nicht in unmittel- barer Umgebung einer Badewanne, Dusche oder eines Swimmingpools.
5Schalten Sie den Heizofen aus, bevor Sie das Haus verlassen oder zu Bett gehen. Bei längerer
Abwesenheit (z.B. Urlaub) den Stecker aus der Steckdose ziehen.
6Lagern und transportieren Sie den Brennstoff ausschließlich in den dazu bestimmten Tanks und
Kanistern.
7Achten Sie darauf, daß der Brennstoff nicht Hitze oder extremen Temperaturunterschieden
ausgesetzt wird. Lagern Sie den Brennstoff IMMER an einem kühlen, trockenen und dunklen
Ort (Sonnenlicht schadet der Qualität).
8Benutzen Sie den Heizofen NIEMALS an Stellen, an denen schädliche Gase oder Dämpfe
auftreten könnten (zum Beispiel Auspuffgase oder Farbdämpfe).
9Das Gitter des Heizofens wird heiß. Der Heizofen darf nicht abgedeckt werden (Brandgefahr).
10 Achten Sie IMMER auf ausreichende Belüftung.
11 Das Heizgerät darf nicht direkt unter einer Steckdose stehen.
12 Kinder unter 3 Jahren dürfen nicht in die Nähe kommen oder sind ständig zu beaufsichtigen.
Kinder von 3-8 Jahren dürfen das Gerät nur dann ein- oder ausschalten, wenn es in seiner
vorgesehenen Betriebsstellung aufgestellt bzw. installiert ist und wenn die Kinder in die
sichere Bedienung des Geräts eingewiesen wurden und die damit einhergehenden Gefahren
verstanden haben. Kinder von 3-8 Jahren dürfen das Gerät nicht anschließen, steuern, reinigen
oder instand halten.
ACHTUNG - Einige Teile dieses Produkts können sehr heiß werden und Verbrennungen
verursachen. Achten Sie besonders auf Kinder und andere gefährdete Menschen.
13 Kinder nicht mit dem Gerät spielen lassen.
14 Reinigungs- und Wartungsarbeiten sollten nicht von Kindern ohne Aufsicht ausge-führt werden.
15 Bleiben Sie NICHT zu lange neben dem Ofen stehen.
Defekte elektrische Geräte und Batterien gehören nicht in den Hausmüll. Bitte
entsorgen Sie den örtlichen Vorschriften gemäß. Erkundigen Sie sich eventuell bei
der Behörde oder bei Ihrem Fachhändler.


15 CONSEILS POUR UN USAGE EN TOUTE SÉCURITÉ
1Surveillez les enfants présents, ils ne doivent en aucun cas
jouer avec l’appareil.
2NE déplacez PAS l’appareil lorsqu’il chauffe ou s’il est encore
brûlant. Dans ces conditions, il NE faut PAS ajouter du
combustible ni entreprendre l’entretien de l’appareil.
3Placez l’avant de l’appareil a au moins 1,5 metre du mur, des
rideaux, des meubles, aerosol et bouteille de gaz. NE rangez
PAS le reservoir de combustible pres du poele.
4N’UTILISEZ PAS l’appareil dans des pièces poussiéreuse ni dans des endroits à fort courant
d’air. Dans ces deux cas, la combustion ne sera pas optimale. NE PAS utiliser l’appareil pres
d’un point d’eau (bain, douche, piscine, etc.).
5Eteignez l’appareil avant de sortir ou d’aller vous coucher. Si vous devez vous absenter
longtemps (vacances par exemple), retirez la fiche de la prise de courant.
6Conservez le combustible exclusivement dans des réservoirs et bidons adaptés.
7Veillez à ce que le combustible ne soit pas exposé à la chaleur ou à des écarts de température
extrêmes. Conservez le combustible TOUJOURS dans un endroit frais, sec et sombre (la lumière
solaire dégrade la qualité du combustible).
8N’UTILISEZ JAMAIS l’appareil dans des endroits où des gaz, solvants ou vapeurs nocifs (par
exemple: gaz d’échappement ou vapeurs de peinture) peuvent être présents.
9La grille de l’appareil devient brûlante. Ne pas couvrir l’appareil (risques d’incendie).
10 Aérez TOUJOURS suffisamment.
11 L’appareil de chauffage ne doit pas être situé immédiatement en dessous d’une prise de courant.
12 Les enfants de moins de 3 ans devraient être tenus à l’écart à moins d’être surveillés en
permanence. Les enfants âgés de 3 ans et de moins de 8 ans doivent uniquement allumer /
éteindre l’appareil à condition qu’il ait été placé ou installé dans sa position normale de
fonctionnement prévue et qu’ils soient sous surveillance ou qu’ils aient reçu des instructions
concernant l’utilisation de l’appareil de manière sûre et qu’ils comprennent les risques
encourus. Les enfants âgés de 3 ans et de moins de 8 ans ne doivent pas brancher, régler et
nettoyer l’appareil ni effectuer l’entretien d’utilisateur.
ATTENTION - Certaines parties de ce produit peuvent devenir très chaudes et provoquer
des brûlures. Une attention particulière doit être accordée aux endroits où les enfants et les
personnes vulnérables sont présents.
13 Ne pas laisser les enfants jouer avec l’appareil.
14 Les enfants ne doivent pas être chargés du nettoyage et de l’entretien de
l’appareil sauf s’ils sont encadrés.
15 NE demeurez PAS longtemps a proximite du poele.
Ne pas jeter vos appareils électriques avec vos ordures ménagères. Prière de
les déposer dans les lieux de dépôt prévus à cet effet. Pour toute information
concernant le recyclage, merci de vous informer auprès de votre distributeur ou des
autorités locales.

1
15 TIPS VOOR EEN VEILIG GEBRUIK
1Er dient toezicht te worden gehouden op kinderen om er zeker
van te zijn dat zij niet met het apparaat spelen.
2Verplaats de kachel NIET als deze brandt of nog heet is. In dat
geval ook NIET bijvullen en geen onderhoud verrichten.
3Plaats de voorkant van de kachel op minimaal 1,5 meter van
muur, gordijnen, meubels, spuitbus en gascylinder. De jerry can
NIET naast de kachel opslaan.
4Gebruik de kachel NIET in stoffige ruimtes, of op plaatsen
waar het sterk tocht. U krijgt dan geen optimale verbranding.
Gebruik de kachel NOOIT in natte ruimtes zoals in de nabijheid
van een bad, douche of zwembad.
5Zet de kachel uit voordat u vertrekt of naar bed gaat. Bent u langere tijd weg (bv. vakantie),
trek dan ook de stekker uit het stopcontact.
6Bewaar en vervoer de brandstof uitsluitend in de daarvoor bestemde tankjes en jerrycans.
7Zorg ervoor dat de brandstof niet bloot staat aan hitte of extreme temperatuurverschillen.
Bewaar de brandstof ALTIJD op een koele, droge en donkere plaats (zonlicht tast de kwaliteit
aan).
8Gebruik de kachel NOOIT op plaatsen waar schadelijke gassen of dampen aanwezig kunnen
zijn (bv. uitlaatgassen of verfdampen).
9Het rooster van de kachel wordt heet. De kachel mag niet afgedekt worden (brandgevaar).
11 De kachel mag niet direct onder een stopcontact geplaatst worden.
12 Houd kinderen jonger dan 3 jaar uit de buurt van de kachel, tenzij zij continu onder toezicht
staan. Kinderen in de leeftijd van 3 tot 8 jaar mogen het apparaat uitsluitend in-/uitschakelen
mits het in de beoogde, normale bedrijfsstand is geplaatst of geïnstalleerd en mits zij begeleid
worden of instructies hebben gekregen over het veilige gebruik van de machine en de gevaren
ervan begrijpen. Kinderen in de leeftijd van 3 tot 8 jaar mogen het apparaat niet aansluiten,
reguleren, reinigen of er onderhoud op uitvoeren.
LET OP - Een aantal onderdelen van dit product kan zeer heet worden en brandwonden veroorzaken.
Toezicht is met name belangrijk op plaatsen waar kinderen en kwetsbare personen aanwezig zijn.
13 Zorg ervoor dat kinderen niet met het apparaat spelen.
14 Reiniging en onderhoud dient niet te worden uitgevoerd door kinderen waarop geen toezicht
wordt gehouden.
15 Blijf NIET voor de kachel staan voor een langere tijd.
Defecte elektrische apparaten en batterijen horen niet bij het huisafval. Zorg voor
een goede recycling waar mogelijk. Vraag eventueel uw gemeente of uw lokale
handelaar voor een deskundig recycling advies.


15 SUGERENCIAS PARA UN USO SEGURO
1Se deberá vigilar a los niños para asegurar que no jueguen con
el aparato.
2NO transportar la estufa cuando esté encendida o esté aún
caliente, NI tampoco llenarla de combustible, ni efectuar
trabajos de mantenimiento.
3Ponga el frontal de la estufa a una distancia mínima de 1,5
metros de la pared, cortinas, muebles, aerosol y cilindro de gas.
NO guardar el depósito de combustible cerca de la estufa.
4NO utilice la estufa en habitaciones polvorientas, ya que la
combustión no será óptima. NO utilice la estufa cerca de un baño, una ducha o una piscina.
5Apague la estufa antes de salir de casa o al acostarse. En caso de abandonar el hogar por un
período largo de tiempo (p. ej., vacaciones), desenchufe la estufa.
6
Conserve y transporte el combustible únicamente en los depósitos y bidones destinados para ello.
7No exponga el combustible al calor o a cambios extremos de temperatura. SIEMPRE guarde el
combustible en un lugar oscuro, seco y fresco (la luz solar afecta a la calidad).
8NUNCA utilice la estufa en lugares donde gases o vapores nocivos puedan estar presentes (por
ej., gases de escape o vapores de pintura).
9La rejilla de la estufa se calienta. Al cubrir la estufa con algún material, se crea un riesgo de
incendio.
10 Asegúrese SIEMPRE de una ventilación suficiente.
11 La estufa no deberá colocarse justo debajo de una toma de corriente.
12 Deberá mantenerse el aparato fuera del alcance de menores de 3 años, a menos que
se encuentren bajo supervisión constante. Los niños entre 3 y 8 años de edad solo podrán
encender o apagar el aparato siempre y cuando este haya sido colocado o instalado en su
posición operativa normal y el menor esté supervisado o haya sido instruido sobre su uso
seguro y comprenda los riesgos que entraña. Los menores de 3 a 8 años de edad no deben
enchufar, ajustar, limpiar ni realizar tareas de mantenimiento en el aparato.
PRECAUCIÓN - Algunas partes de este producto pueden alcanzar temperaturas elevadas
y causar quemaduras. Se debe prestar especial atención cuando haya menores y personas
vulnerables.
13 Los niños no deben utilizar el aparato como un juguete.
14 Las tareas de limpieza y mantenimiento reservadas al usuario no deben ser realizadas por niños
sin supervisión.
15 NO permanezca cerca de la estufa durante mucho tiempo.
No deseche aparatos eléctricos y las pilas junto con la basura doméstica, sino
elimínelos a través de un Punto Limpio si existe. Consulte a las autoridades locales o
a su distribuidor acerca del reciclado adecuado.


15 CONSIGLI PER UN USO SICURO
1Occorre sorvegliare costantemente i bambini per essere sicuri
che non giochino con l’apparecchio.
2NON spostare la stufa se questa è accesa o se è ancora calda.
In tal caso, NON riempirla di combustibile e non eseguire la
manutenzione.
3Porre la parte anteriore della stufa ad una distanza minima di
1,5 metri da pareti, tende, mobili, spray can e cilindro a gas.
NON conservate il combustibile vicino alla stufa.
4NON usare la stufa in locali polverosi. Non si avrà una combustione ottimale. NON usare queste
stufa nelle vicinanze, di un bagno, di una doccia o di una piscina.
5Spegnere la stufa prima di uscire o prima di andare a letto. Se si rimane assenti per un lungo
periodo di tempo (ad es. per vacanze), staccare anche la spina dalla presa.
6Conservare e trasportare il combustibile nei contenitori e nelle latte apposite.
7Assicurarsi che il combustibile non sia esposto a fonti di calore o a forti escursioni termiche.
Conservare SEMPRE il combustibile in un luogo fresco, secco ed asciutto (la luce del sole ne
intacca la qualità).
8NON usare mai la stufa in luoghi dove possono essere presenti gas o vapori pericolosi (ad
esempio, gas di scarico o vapori di vernici).
9La griglia della stufa diventa calda. Non coprire l’apparecchio onde evitare rischi d’incendio.
10 Assicurarsi SEMPRE che la ventilazione sia sufficiente.
11 Non posizionare il dispositivo di riscaldamento immediatamente sotto ad una presa di corrente.
12 Tenere fuori dalla portata dei bambini di età inferiore ai 3 anni, se non continuamente sotto
la supervisione adulta. I bambini di età compresa tra i 3 e gli 8 anni possono solo accendere o
spegnere il dispositivo a condizione che questo sia stato posizionato o installato nella posizione
in cui dovrà rimanere una volta in funzione e a condizione che siano supervisionati o istruiti in
merito all’utilizzo sicuro del dispositivo e che comprendano i rischi connessi. I bambini di età
compresa tra i 3 e gli 8 anni non potranno collegare, regolare e pulire il dispositivo o eseguirne
la manutenzione.
ATTENZIONE - Alcuni componenti di questo prodotto possono diventare molto caldi e causare
scottature. È necessario prestare particolare attenzione in presenza di bambini e persone
vulnerabili.
13 I bambini non dovrebbero giocare col dispositivo.
14 Le operazioni di pulizia e manutenzione da parte dell’utente non vanno eseguite dai bambini
senza supervisione.
15 NON state vicino alla stufa per troppo tempo.
Gli apparecchi elettrici difettosi e le batterie usate non devono essere smaltiti come
rifiuti domestici. Se possibile utilizzarli per il riciclaggio. Eventualmente informarsi
presso il proprio comune o il rivenditore locale sulle possibilità di riciclaggio o di
smaltimento ecologico.


15 DICAS PARA UTILIZAÇÃO SEGURA
1Deve ter sempre em atenção às crianças, estas não devem
brincar com o aparelho.
2NÃO transportar o aquecedor quando está aceso ou ainda
quente, NEM encher de combustível ou fazer qualquer trabalho
de manutenção.
3Posicione a frente do aquecedor a uma distância mínima de
1.5m de paredes, cortinados e mobílias.
4NÃO utilize o aquecedor em recintos com poeira porque a
combustão não será a ideal. NÃO use o aquecedor perto da
banheira, chuveiro ou piscina.
5Desligue o aquecedor antes de sair de casa ou na hora de dormir. Se sair de casa por um longo
período de tempo (por exemplo, férias), desligue o aquecedor.
6Armazene e transporte o combustível somente em depósitos ou bidões destinados para o
efeito.
7Certifique-se de que o combustível não está exposto ao calor nem mudanças extremas de
temperatura. Guarde SEMPRE o combustível em lugar fresco, seco e escuro (a luz solar irá
afetar a qualidade do mesmo).
8NUNCA utilize o aquecedor em locais onde existam gases ou vapores nocivos (por exemplo
gases de escape ou vapores de tinta).
9A grelha do aquecedor fica quente, ao cobrir com algum material pode causar um incêndio.
10 Certifique-se SEMPRE de que existe ventilação suficiente.
11 O aquecedor não deve estar colocado imediatamente abaixo de uma tomada.
12 As crianças com idade inferior a 3 anos devem ser mantidas à distância, a não ser que sejam
continuamente vigiadas. As crianças com uma idade a partir dos 3 e inferior a 8 anos apenas
podem ligar/desligar o aparelho se o mesmo tiver sido colocado ou instalado na sua posição
operativa normal, e caso tenham recebido indicações ou instruções quanto à utilização do
aparelho com segurança, com conhecimento dos perigos aqui envolvidos. Crianças com uma
idade a partir dos 3 e inferior a 8 anos não devem ligar, regular e limpar o aparelho ou efetuar
a manutenção do utilizador.
CUIDADO - Algumas partes deste produto podem ficar muito quentes e provocar queimaduras.
Deve ser prestada especial atenção na presença de crianças e pessoas vulneráveis.
13 As crianças não devem brincar com o aparelho.
14 A limpeza e manutenção pelo utilizador não será feita por crianças sem supervisão.
15 NÃO permaneça demasiado tempo junto ao aquecedor.
Os eletrodomésticos avariados devem ser mantidos separados do lixo doméstico.
Certifique-se de que há reciclagem eficaz sempre que possível. Pergunte ao seu
revendedor quais os conselhos dos especialistas sobre reciclagem.

6
15 TIPS FOR SIKKER BRUG
1Børn bør være under opsyn, så det sikres, at de ikke leger med
apparatet.
2Flyt ALDRIG kaminen, når den brænder eller stadig er varm. I
dette tilfælde må den heller IKKE påfyldes eller vedligeholdes.
3Anbring kaminen så dens forkant er mindst 1,5 meter fra mure,
gardiner, møbler, spray dåse og gas cylinder. Opbevar IKKE
brændstoftanken i nærheden af ovnen.
4Brug IKKE kaminen i støvede rum, da der så ikke opnås en
optimal forbrænding. Brug IKKE kaminen i umiddelbar nærhed
af badekar, brusekabiner eller svømmebassiner.
5Sluk kaminen før De forlader huset eller går i seng. Hvis De er fraværende i længere tid (f.eks.
ferie), skal stikket også tages ud af stikkontakten.
6Opbevar og transporter altid brændstoffet i de dertil beregnede tanke og dunke.
7Sørg for, at brændstoffet ikke udsættes for varme eller ekstreme temperaturforskelle. Opbevar
ALTID brændstoffet et køligt, tørt og mørkt sted (sollys forringer kvaliteten af brændstoffet).
8Brug ALDRIG kaminen på steder, hvor der kan være skadelige gasser eller dampe (f.eks.
udstødningsgasser eller malingsdampe).
9Vær opmærksom på, at kaminens gitter bliver meget varmt. Hvis der anbringes ting oven på
kaminen, udgør det en brandfare.
10 Sørg ALTID for tilstrækkelig ventilation.
11 Varmeapparatet må ikke være placeret umiddelbart under en stikkontakt.
12 Børn under 3 år skal holdes væk, medmindre de løbende overvåges. Børn i alderen fra 3 år og
under 8 år må kun tænde/slukke for apparatet forudsat at den er anbragt eller installeret i den
tilsigtede normale driftsposition, og de har fået tilsyn eller instruktion om brugen af apparatet
på en sikker måde og forstår de involverede farer. Børn i alderen fra 3 år og under 8 år må ikke
tilslutte, regulere og rengøre apparatet eller udføre vedligeholdelse.
FORSIGTIG - Nogle dele af dette produkt kan blive meget varme og forårsage forbrændinger.
Særlig opmærksomhed skal udvises, hvor børn og udsatte personer er til stede.
13 Børn må ikke lege med apparatet.
14 Rengøring og brugervedligeholdelse må ikke foretages af børn uden vejledning.
15 Ophold dig IKKE tæt på ovnen i længere tid.
Elektrisk affald som defekte elektriske apparater og batterier bør ikke kasseres
sammen med husholdningsaffaldet. Indlever det venligst til et genbrugsanlæg.
Spørg de lokale myndigheder eller forhandleren til råds angående genbrug.


15 TIPS FOR SIKKER BRUK
1Barn må overvåkes for å sikre at de ikke bruker apparatet som
leketøy.
2IKKE flytt varmeovnen når den brenner eller fortsatt er varm.
IKKE fyll ovnen på nytt eller reparer den når den fortsatt er
varm.
3Plasser forsiden av ovnen slik at det er minst 1,5 meter
til vegger, gardiner, møbler, sprayboks og gassflaske.
Drivstofftanken skal IKKE oppbevares i nærheten av
varmeapparatet.
4IKKE bruk varmeovnen i støvete rom eller på svært trekkfulle steder. I begge tilfeller vil du ikke
oppnå optimal forbrenning. Ovnen må IKKE brukesi umiddelbar nærhet av badekar, dusj eller
svømmebasseng.
5Slå av varmeovnen før du går ut av huset eller legger deg. Trekk også støpselet ut av
stikkontakten når du reiser bort i lengre tid (for eksempel på ferie).
6Oppbevar og flytt drivstoff bare i egnede beholdere og jerrykanner.
7Påse at drivstoffet ikke utsettes for varme eller ekstreme temperaturforandringer. Oppbevar
ALLTID drivstoffet på et kjølig, tørt og mørkt sted (sollys påvirker kvaliteten).
8Bruk ALDRI ovnen på steder der det kan være farlige gasser eller damp (f.eks. eksosgass eller
damp fra maling).
9Vær oppmerksom på at gitteret på varmeovnen blir varmt. Det er fare for brann hvis
varmeovnen dekkes til.
10 Påse ALLTID at det er tilstrekkelig ventilasjon.
11 Varmeapparatet må ikke plasseres rett under en stikkontakt.
12 Barn på under 3 år må holdes på avstand hvis de ikke er under tilsyn hele tiden. Barn fra 3 år og
mindre enn 8 år skal kun slå på/av apparatet gitt at det er plassert eller installert i dets tiltenkte
normalt driftsposisjon, og at de er under tilsyn eller har blitt gitt instruksjon i sikker bruk av
apparatet, og forstår de involverte farene. Barn fra 3 år og mindre enn 8 år skal ikke plugge inn,
regulere og rengjøre apparatet eller utføre brukervedlikehold.
FORSIKTIG - Noen deler av dette produktet kan bli svært varme og forårsake brannskader.
Spesiell oppmerksomhet må gis hvor barn og sårbare personer er tilstede.
13 Barn skal ikke leke med produktet.
14 Rengjøring og vedlikehold skal aldri utføres av barn uten tilsyn.
15 IKKE opphold deg i nærheten av varmeapparatet i lang tid.
Mangelfulle elektriske apparater og batterier må holdes atskilt fra
husholdningsavfall. Pass på at du gjenvinner der dette er mulig. Kontakt de lokale
myndighetene eller forhandleren for råd om gjenvinning.


15 TIPS FÖR SÄKER ANVÄNDNING
1Barn bör övervakas för att garantera att de inte leker med
apparaten.
2Flytta INTE på värmaren när den är på eller när den fortfarande
är varm. Fyll inte på värmaren och ägna dig INTE åt underhåll
när den är på eller när den fortfarande är varm.
3Se till så att det minst är 1,5 meter mellan värmarens framsida
och väggar, gardiner, möbler, sprejflaska och gascylinder.
Förvara INTE bränsletanken nära brännaren.
4Använd INTE värmaren på platser där det är mycket drag eller
damm. I båda fallen fungerar INTE värmaren optimalt.
5Stäng av värmaren innan du går och lägger dig.
6Bränsle ska endast förvaras och förflyttas i lämpliga bränslebehållare eller bränsledunkar.
7Se till så att bränslet inte utsätts för värme eller extrema temperaturförändringar. Förvara
ALLTID bränslet på en sval, torr och mörk plats (kvaliteten påverkas av solljus).
8Använd INTE värmaren på ställen där det kan finnas skadliga gaser eller ångor (t.ex. avgaser
eller färgångor).
9Tänk på att värmarens galler blir mycket varmt. Om apparaten täcks över föreligger brandrisk.
10 Se ALLTID till så att ventilationen är tillräcklig.
11 Värmaren får inte placeras omedelbart nedanför ett eluttag.
12 Barn under 3 år ska hållas borta från objektet såvida de inte kontinuerligt övervakas. Barn
i åldern 3 till 8 år får endast stänga av/starta apparaten, förutsatt att den har placerats
eller installerats i sitt avsedda normala driftläge och att de övervakas eller instrueras om
användningen av apparaten på ett säkert sätt samt förstår de faror som är inblandade. Barn
i åldern 3 till 8 år ska inte koppla in, reglera, rengöra eller utföra användarunderhåll på
apparaten.
VARNING - Vissa delar av produkten kan bli mycket varma och orsaka brännskador. Särskild
uppmärksamhet måste ges när barn och utsatta personer är närvarande.
13 Barn får inte leka med enheten.
14 Rengöring och användarunderhåll får inte utföras av barn utan övervakning.
15 Vistas INTE nära brännaren någon längre tid.
Defekta elektriska enheter och batterier får inte slängas i hushållssoporna. Återvinn
alltid när så är möjligt. Du kan vända dig till din närmaste återvinningsstation för att
få råd.

*
15 OHJEITA TURVALLISTA KÄYTTÖÄ VARTEN
1Lapsia on valvottava, etteivät he leiki laitteen kanssa.
2ÄLÄ siirrä lämmitintä, kun se palaa tai on vielä kuuma. ÄLÄ
täytä tai huolla lämmitintä, kun se palaa tai on vielä kuuma.
3Sijoita lämmitin siten, että sen etupuoli on vähintään 1,5 metrin
etäisyydellä seinistä, verhoista, huonekaluista, ruiskupurkki ja
kaasusylinteri. ÄLÄ säilö polttoainesäiliötä lämmittimen lähelle.
4ÄLÄ käytä lämmitintä pölyisissä tai erityisen vetoisissa
paikoissa. Niissä palaminen ei tapahdu parhaalla mahdollisella
tavalla.
5Sammuta lämmitin ennen kuin menet nukkumaan.
6Säilytä ja siirrä polttoainetta vain sopivissa säiliöissä ja kanistereissa.
7Varmista, että polttoaine ei altistu lämmölle tai suurille lämpötilanvaihteluille. Säilytä
polttoainetta AINA viileässä, kuivassa ja pimeässä paikassa (auringonvalo heikentää laatua).
8ÄLÄ koskaan käytä lämmitintä paikoissa, joissa voi olla haitallisia kaasuja tai hajuja (esim.
pakokaasua tai maalinhajua).
9Muista, että lämmittimen ritilä kuumenee. Laitteen peittämisestä aiheutuu tulipalovaara.
10 Varmista AINA, että ilmanvaihto on riittävä.
11 Lämmitintä ei saa sijoittaa välittömästi pistorasian alapuolelle.
12 Alle 3-vuotiaat lapset on pidettävä etäällä laitteesta, ellei heitä valvota jatkuvasti.Yli 3-vuotiaat
mutta alle 8-vuotiaat lapset saavat kytkeä laitteen päälle ja pois sillä edellytyksellä, että se on
asennettu tarkoitettuun, normaaliin käyttöpaikkaansa, ja heille on annettu neuvontaa tai ohjeet
laitteen käytöstä turvallisella tavalla, ja he ymmärtävät siihen liittyvät vaarat. Yli 3-vuotiaat
mutta alle 8-vuotiaat lapset eivät saa kytkeä laitetta verkkoon, säätää sitä, puhdistaa sitä tai
tehdä huoltotöitä.
HUOMIO - Jotkin tämän tuotteen osat voivat lämmetä hyvin kuumiksi ja aiheuttaa
palovammoja. Erityistä huomiota on kiinnitettävä silloin, kun lapsia ja vaaranalaisia ihmisiä on
läsnä.
13 Lapset eivät saa leikkiä laitteella.
14 Lapset eivät saa suorittaa huolto- tai puhdistustoimenpiteitä laitteelle ilman valvontaa.
15 ÄLÄ oleskele pitkiä aikoja lämmittimen lähellä.
Vialliset sähkölaitteet ja paristot on erotettava kotitalousjätteestä. Huolehdi
mahdollisuuksien mukaan tehokkaasta kierrätyksestä. Asiantuntevia neuvoja
kierrätyksestä saat kunnalliselta jäteneuvojalta ja jälleenmyyjältäsi.

4
2
Thank you for choosing a “TOYOTOMI” product!
Toyotomi products are used by satisfied customers worldwide. In order to
assure the comfortable and safe use of our products by customers in each
country, our products conform to the safety standards not only in Japan but
also in every country around the world we do business with.
Toyotomi tailors its products to satisfy its customer’s needs by always
pursuing our business philosophy, “sharing joys in daily living”. We will
continue to research, develop and manufacture products that match people’s
lifestyle for efficiency, safety and comfort.
We hope that you’ll enjoy your Toyotomi appliance for years to come!
We invite you to read this instruction manual first, to ensure the maximum
lifetime for this appliance.
Get to know us better… visit us at www.toyotomi.eu for our full line of
products.
1 READ THE DIRECTIONS FORUSE FIRST.
2 IN CASE OF ANY DOUBT, CONTACT YOUR DEALER.
3 POUR LIRE, DÉPLIEZ LA DERNIÈRE PAGE.              3 BEFORE YOU START READING, CONSULT THE MAIN COMPONENTS LIST ON THE LAST PAGE.

4
3
GENERAL DIRECTIONS FOR USE
Below you will find the main steps to be taken for using your
heater. For more details, please refer to the MANUAL.
• As a fire precaution, the tank must be filled either hen the heater has
been switched off or in another room than the room where the heater is
installed.
• Alays ensure that the tank is closed properly after filling it at a safe
distance from all sources of heat and open flames (see Section B).
• The first time the heater is ignited it ill smell like “ne” for a short time.
• Store all fuel containers ith their original caps and seals in a cool and
dark place.
• uel ages. Use ne fuel at the start of every heating season.
• Only use high uality and ater-free pure paraffin in accordance ith
local legislation (TOYOTOMI fuel).
• Before changing brands and/or types of fuel make sure that the mobile
heater first completely empties all of the remaining fuel inside the heater.
Remove all packaging materials (refer to Section A, Fig. A).
ill the removable tank  (refer to Section B, Fig. C).
Insert the plug into the all-socket.
Ignite the heater using the key (refer to Section D).
If reuired, change the temperature using the adjustment keys
(refer to Section E).
Sitch off the heater by pressing the key .
1
2
3
4
5
6
3 POUR LIRE, DÉPLIEZ LA DERNIÈRE PAGE.              3 BEFORE YOU START READING, CONSULT THE MAIN COMPONENTS LIST ON THE LAST PAGE.

4
4
This transportation cap
is packed separately in
the box. Only this cap
ensures trouble-free
transportation of the
heater after use.
Store it well!
WHAT YOU NEED TO KNOW IN ADVANCE
VENTILATE SUFFICIENTLY
Read this user manual carefully before using the appliance and keep it for future
reference. Install this device only hen it complies ith local/national legislation,
ordinances and standards. This product is intended to be used as a heater
in residential houses and is only suitable for use in dry locations, in normal
household conditions, indoors in living room, kitchen and garage.
This heater is euipped ith an air uality control system . When there is
insufficient ventilation in the room or when the heater is being used in a room
which is too small, the heater will shut off automatically.
or comfortable and safe heating ensure that there is sufficient ventilation.
NOTE: To avoid unexpected shut off, we recommend to put a door or window
ajar when the heater is operating.
Regardless of the model, you must always make sure that the heater is used
in a room large enough to enable the heater to be used safely without extra
ventilation (refer to Section P). If the room is smaller than reuired, you must
always open a door or window slightly (ensuring an opening of approx. 2.5 cm).
It is important that every room where the heater is used has sufficient air intake
and efficient air outflow (both openings must have a minimum cross section of 50
cm2).
We also recommend doing this in highly insulated or draught-free rooms and/or
at high altitude. Do not use your heater in cellars or other underground areas.
No modifications to the safety system are allowed, as that will invalidate the
guarantee that the air probe will work properly. Consult your dealer in case of
doubt.
ESPECIALLY FOR FRANCE:Your heater was designed to operate exclusively on
fuel for liuid fuel-operated mobile heaters in accordance ith the Decrees of
18-0-2002 and 25-0-2010. The use of other fuels is forbidden.
Ask your dealer or check our ebsite for the addresses of our retailers.
The liuid fuel-operated mobile heater is intended as an etra heater, and not as a
continuous source of heat.
ESPECIALLY FOR UNITED KINGDOM: Only use Class C1 paraffin fuel in
accordance ith BS289 Part 2, or euivalent.
The user must comply with the following instructions for proper use:
DO NOT
- use petrol.
- use the liuid fuel-operated mobile heater in caravans, boats, and vehicle
cabins.
- use the liuid fuel-operated mobile heater in insufficiently ventilated rooms
(consult the table of properties for the minimum dimensions of the room to be
heated), underground rooms and / or at a height of over 1900 metres.
- modify the heater safety features.
The use of this type of heating in public rooms is subject to prior regulatory
permission. Obtain proper information on this in advance.
THE RIGHT FUEL
Your heater has been designed for use ith high-uality ater-free pure paraffin
oil (TOYOTOMI fuel). Only fuels of this kind will ensure clean and proper burning.
Loer uality fuel may result in:
increased possibility of malfunctioning
incomplete combustion
reduced heater lifetime
smoke and/or fumes
deposits on the grid or mantle
Using the right fuel is therefore essential for safe, efficient, and comfortable use
of your heater.
Damage and/or malfunctions of the heater due to the use of other than high-
uality ater-free pure paraffin oil is not covered by the warranty.
Alays refer to (.toyotomi.eu) for the right fuel for your heater.
Only the use of the
correct fuel will ensure
safe, efficient, and
comfortable use of
your heater.

!
4
5
MANUAL
A INSTALLING THE HEATER
1Carefully remove your heater from the box and check the contents.
In addition to the heater you also need to have:
a manual fuel pump
a transportation cap
these directions for use
Keep the bo and the packaging materials (ig. A) for storage and/or
transportation.
2Open the lid of the removable tank and remove the piece of cardboard.
3ill the removable tank as indicated in Section B.
4The floor should be firm and completely level. Reposition the heater, when it
is not level. Do not try to correct the situation by placing books or other
goods under the heater.
5Insert the plug  into the all-socket (230 Volts - AC / 50 H) and set the
correct time using the adjustment keys  (refer to Section C).
6Your heater is now ready for use.
SET ALTITUDE
1
If the heater is used at a height of 800 m to 1300 m, use the altitude mode 1.
Push the altitude button with thin rod like a clip and plug into the outlet
simultaneously. Then “1 ” will be shown on the display.
2
If the heater is used at a height of 1300 m to 1900 m, use the altitude mode
2. After setting the altitude mode 1, push the altitude button with thin rod
and plug into the outlet simultaneouosly again. Then “2 ” will be shown on
the display.
3
Sitch off the altitude mode by pressing the altitude button and into the
outlet simultaneously after setting altitude mode 2. Then “0” will be shown
on the display and “ ” will be disappeared.
NOTE: When the altitude mode 1 is set, the altitude mark “ ” is lit on the display.
When the altitude mode 2 is set, the altitude mark “ ” is blinking during
operation.
NOTE: In the event of power failure or disconnection of heater, the altitude setting
will remain.
Do not use the heater at a height of over 1900 meters.
SWITCH THE VOLUME
This heater can be sitched the buer sound volume. The initial setting is in
High level.
1
Push the SAVE key  and holding it don for more than 3 seconds, then the
buer sound volume is sitched from High to Lo.
2
Push the SAVE key  and holding it don for more than 3 seconds again,
then the buer sound volume is sitched from Lo to High.
NOTE: The volume level is Lo and High only, but the alarm by safety device
sounds in High level.
NOTE: When the heater has been unplugged or after a power failure, the volume
ill be the initial setting High.
A
B

!
4
6
G: The required tempe-
rature on the left, the
measured temperature
on the right.
F: When the 4-digit
stops blinking, the set-
ting has been locked to
the indicated value.
BFILLING FUEL
ill the removable tank in a suitable place since there can alays be some
spillage. ollo the procedure belo:
1Make sure that the heater is switched off.
2Open the upper lid and lift the removable tank out of the heater (ig. B).
Put don the removable tank (cap pointing upards, handle on floor) and
scre off the fuel cap (ig. C).
NOTE: Some drops may leak from the tank.
3 ill the removable tank using a fuel pump (refer to fuel pump operation
instructions.) Make sure that it is in a higher position than the removable tank
(ig. D). Insert the ribbed hose into the opening of the removable tank.
4Check the removable tank fuel gauge hile filling the tank (ig. E). Stop
filling once the gauge indicates that the tank is full. Never overfill the tank,
especially not when the fuel is very cold (fuel expands when it heats up).
5Let the remaining fuel in the pump flow back into the jerrycan and carefully
remove the pump. Carefully screw the fuel cap back on the tank. Clean off
any spilled fuel.
6Check whether the fuel cap is straight and tightened properly. Reinstall the
removable tank in the heater (cap down). Close the lid.
CSETTING THE CLOCK
It is only possible to set the correct time, when the heater is connected to the
mains and not burning. Use the adjustment keys  to set the time. irst press
either of the to keys to sitch on the function (the -digit  will start blinking).
Next, set the hours using the key on the left (hour) and the minutes using the
key on the right (min.). Press once to increase the value by one step. When you
hold down the key, the value will continue going up, until you release the key
again. After approimately 10 seconds the -digit ill stop blinking and the set-
ting ill be locked (ig. ). 5 minutes after sitching off the heater, the informa-
tion on the display will disappear and the heater will automatically switch into the
stand-by position.
When the heater has been unplugged (or after a power failure), the time needs
to be set again.
DIGNITING THE HEATER
When used for the first time, a new heater may give out a smell for a short while.
You should therefore provide extra ventilation.
Alays ignite the heater ith the
button  . Never use matches or a
cigarette lighter.
Just press the button  to ignite the heater. The POWER lamp ill start blinking,
indicating that the ignition procedure has started. This will take a short while.
Once the heater is burning, the POWER lamp ill remain lit (red). The information
display will show two numbers. The light next to them indicates that these
numbers refer to the temperatures (ig. ). The actual room temperature is
indicated belo ROOM, hile the temperature setting is indicated belo SET. The
latter can be changed with the adjustment keys (refer to Section E).
Prior to igniting the heater, alays check for sufficient fuel in the removable tank.
ESETTING THE REQUIRED TEMPERATURE
The temperature setting can only be adjusted, hen the heater is burning. Use
the adjustment keys  to adjust the temperature. irst press either of the to
keys to switch on the function (the °C mark  will start blinking). Next, adjust the
temperature using the key on the right (min.) to set the temperature to a higher
setting and the key on the left (hour) to loer the temperature. Press once to
increase the value one step. After approimately 10 seconds the C mark ill stop
blinking and the setting ill be locked (ig. ).
The available temperature settings range from C minimum to 28C maimum.
When the heater has been unplugged (or after a power failure), the temperature
will reset to the factory setting of 20°C.
E
empty full
C
D

!
4
7
H: The TIMER indicator
light indicates that the
timer function has been
switched on.
In case of any
malfunctioning the
information display will
tell you what is the
matter.
FUSING THE TIMER
The timer allows you to switch on the heater automatically at a preset time.
In order to switch on the timer, the correct time must have been set (refer to
Section C) and the heater should be off. ollo the procedure belo:
1Press the
button and then the TIMER key immediately after that.
The TIMER lamp  and the -digit will start blinking.
2Use the adjustment keys to set the time at which the heater must ignite.
Use the key on the left (hour) to set the hours and the key on the right
(min.) to set the minutes (interval of 5 minutes).
3After approimately 10 seconds the -digit ill sho CLOCK again and the
TIMER lamp will light up, indicating that the timer function has been
activated (ig. H).
4The timer will ensure that the room will have been heated to approximately
the reuired temperature at the set time.
When you want to switch off the heater and ignite it again with the timer, all you
have to do is press the TIMER key (refer to Section G).
Press the button once to clear the timer setting.
G SWITCHING OFF THE HEATER
There are two ways to switch off the heater:
1Press the button . The information display will show the CLOCK
signal. Within approximately one minute the flame will have extinguished.
2Press the TIMER key , when you want to switch off the heater and ignite it
again with the timer the next time. This not only switches off the heater, but
it also activates the timer function. You can change the reuired time ith
the adjustment keys (refer to Section F).
H THE INFORMATION DISPLAY
The information display not only serves as an indicator of the (set) time and
temperature (Sections C, E, and F), it also indicates any malfunctioning of the
heater. The code on the information display tells you what is the matter:
CODE INFORMATION WHAT TO DO
e - 0 Temperature ithin the heater too high. Cool-don and re-ignite.
f - 0 Poer interrupted. Re-ignite the heater.
e - 1 aulty thermostat. Contact your dealer.
f - 1 aulty burner thermistor. Contact your dealer.
e - 2 Starting problems. Contact your dealer.
e - 23
Re-ignite the heater immediately after
extinguishing.
Wait for appro. 30 sec.
and re-ignite after inserting
the plug again.
e - 5 Tipping-over protection. Re-ignite the heater.
e - 6 Poor burning. Contact your dealer.

4
8
e - 7 Room temperature If necessary,
above 32°C. re-ignite the heater.
e - 8 Defective booster. Contact your dealer.
e - 8 1 Abnormal frequency. Insert the plug into the wall-socket again.
Contact your dealer.
e - 9 Air filter dirty; or Clean filter.
Fuel pump dirty. Contact your dealer.
The heater has been in operation
continuously for a period of 65 hours
and has turned itself off automatically. Switch the heater back on.
-- : --
+
Out of fuel. Refill removable tank.
-- : --
+
Too little ventilation. Ventilate better.
e - 1 1
+
Too little ventilation. Ventilate better.
Always contact your dealer for any malfunctioning not listed above and/or when
the error keeps occuring after taking the corrective measure as described above.
autOMatic DeactivatiOn
This heater is fitted with a safety system that ensures that it switches off
automatically after 65 hours continuous operation. The following will then appear
in the display: . If desired, you can switch the heater on again by pressing
the button
L (see Section D).
autOMatic cleaninG MODe
When the heater has been burning continuously for two hours at its highest
setting, the burner will automatically start an autoclean procedure. The display
will show the autocleaningcode cl:05 running back to cl:01. The procedure takes 5
minutes, during which the heater will burn at its lowest setting, while the burner
autocleans. When the burner is clean again, the heater will automatically switch
back to the highest setting again.
i cHilDPROOf lOcK / PaRental cOntROl
The childproof lock can be used to prevent children accidentally changing the
heater settings. When the heater is burning and the childproof lock is on, the
heater can only be switched off. Other functions are blocked then. If the heater
has already been switched off, the childproof lock also prevents accidental ignition
of the heater.
Activate the childproof lock by pressing the appropriate key Mand
holding it down for more than 3 seconds. The KEY-LOCK indicator
will appear on
the information display (Fig. I), indicating that the childproof lock has been activated.
Switch off the childproof lock by pressing the key Mand holding it down for more
than 3 seconds once again.
J tHe cORRect use Of ‘save’
The ‘SAVE’ function allows you to limit the temperature. When this function is
activated, the heater will automatically switch off, when the room temperature exceeds
the set temperature by 3°C. Subsequently, when the room temperature has dropped
again to the set temperature, the heater will automatically switch on again.
Activate
the ‘SAVE’ setting by pressing the appropriate  key. The SAVE indicator light will
light up (Fig. J). Switch off the function by pressing the SAVE key once again.
I: When the mark
appears, the childproof
lock has been activated.
J: When the SAVE light
lights up, the heater will
automatically switch on
or off in order to remain
within a specified tem-
perature range.
