TP-Link VIGI C340-W User manual

Quick Start Guide
*Images may dier from actual products.
Appearance
RESET Button
5
Lens
4
White Light
3
IR LED
2
Power Supply Interface (12V DC)
10
9RJ45 Ethernet Port
7Status LED
8Speaker
6
Microphone
1
5
3
2
4
9
Package Contents
Network Camera Waterproof Cable
Attachments
Quick Start Guide
Anchors and Screws
Quick
Start
Guide
• Make sure your power supply matches your camera.
The camera’s standard power supply is 12V DC (7W).
• Make sure that the wall is strong enough to
withstand 4 times the weight of the camera and
mounting bracket.
• If you are uncertain or uncomfortable performing the
installation, consult a qualied electrician.
Safety First:
Installing Waterproof Cable Attachments
Install the waterproof cable attachments for the network
interface when the camera is installed outdoors.
Note: Make sure each part is securely attached and the waterproof
rings are ush to keep out water.
Done! The network interface is now waterproof.
1Mount Camera
Fix Nut Waterproof
Ring
O-ring Network
Interface
Waterproof
Jacket
1. Route the network cable through the following
components in order: x nut, waterproof ring, and then
the waterproof jacket.
2. Fix the O-ring to the network interface of the camera and
connect the network cables.
3. Attach the network interface with the waterproof jacket,
then twist to lock.
4. Insert the waterproof ring into the waterproof jacket.
Rotate the x nut to secure it to the waterproof jacket.
7
3
2
8
6
Note: Before inserting the
micro SD card or resetting
the camera, unfasten the two
xed screws to remove the
cover.
Mounting Template
1
Micro SD Card Slot
Insert a micro SD card for local storage. Initialize
the SD card via VIGI app before recording videos.
Option 1: Wall/Ceiling Mounting
1. Stick the mounting template to the desired mounting place.
Drill 4 screw holes according to the template.
2. Insert the anchors into the holes, use the provided screws to
x the camera’s bracket to the wall or ceiling.
Option 2: Pole Mounting
1. Thread each of the two cable ties through the slits on the
back of the camera’s bracket indicated below.
2. Slip the two cable ties through the pole. Tighten them to
rmly attach the pole.
OR
10
Long press the button to reset
the camera to factory settings.
Micro SD RESET
Status LED Indication
Status Description
Solid red Starting up
Blink red and green Ready for setup
Blink green slowly Connecting to Wi-Fi
Solid green Connected to Wi-Fi
Blink red slowly Wi-Fi connection lost
Blink red quickly Camera resetting
Blink green quickly Camera updating
VIGI Wi-Fi Network Camera
Power Adapter

2Set Up Camera
Here is a typical network topology. The camera works with an NVR for easier batch access and management.
Network Camera
Network Camera
Step 2. Power On the Camera
Connect your camera to the power source with the
provided power adapter.
Step 1. Download the TP-Link VIGI App
Get the TP-Link VIGI App from the Apple App Store
or Google Play.
Step 3. Set Up
1. Open the TP-Link VIGI app and log in with your
TP-Link ID. If you don’t have an account, sign up
rst.
2. Tap the + button on the top right and follow the app
instructions to activate and add your cameras.
Note: If you want to use the NVR for easier batch
access and management later, add the camera to
the same network as the NVR.
Done! You can now remotely view live video,
manage cameras, and get instant alerts.
or
More Management Methods
1. Download the VIGI Security Manager on your computer at
https://www.tp-link.com/support/download/vigi-security-manager/.
2. Install the VIGI Security Manager and open it.
3. Cameras on the same network as your computer can be
automatically discovered. Go to Settings > Discovered
Devices, click + Add to activate your discovered cameras by
setting passwords, and follow the instructions to add your
cameras.
Method 2: Via the VIGI Security Manager (Windows only)
You can also access and manage your cameras via any of the methods below.
View live video and modify camera settings on your computer.
Method 1: Use the camera with your VIGI NVR
Before you start, make sure the NVR is working properly.
1. Right click on the Live View screen and click Add Camera.
2. Select your camera and click + to add your camera directly.
If you have disabled Plug and Play on your NVR, create a
password or use a preset password for your camera.
If you are using your cameras with other NVR brands, refer to
the NVR’s User Manual to add cameras.
Frequently Asked Questions (FAQ)
Q1: What can I do if I fail to congure my camera?
• Check if the camera is powered on properly. The camera’s standard power
supply is 12V DC (7W).
• Make sure you have a 2.4 GHz wireless network for camera connection.
• Make sure your camera and NVR/computer/Phone are in the same subnet. If
not, use TP-Link VIGI app to add your camera to the same network
wirelessly or connect your camera to the same network via an Ethernet
cable.
• For other NVR brands, make sure you have activated the camera by setting a
password via the VIGI Security Manager or TP-Link VIGI app.
Q2: How do I reset the camera?
• Rotate the sphere and unfasten the two xed screws to remove the cover.
Long press the reset button until the Status LED starts blinking red quickly.
Q3: What should I do if I forgot the password of the camera?
• You can reset the password of the camera via VIGI NVR or VIGI Security
Manager. For more details, refer to NVR and Security Manager’s User
Guides.
• You can reset the camera and activate it again. During the activation process,
you can set a new password.
Q4: What should I do if the SD card is not working properly?
• Make sure you are using a micro SD card.
• Unplug the SD card and insert it again. Make sure you have inserted the SD
card correctly.
• It’s recommended to use a Class 10 micro SD card or higher, with storage
from 8 GB to 256 GB.
• Make sure you have initialized the microSD card in TP-Link VIGI app.
• If the problem still persists, contact our technical support.
For more questions, please refer to https://www.tp-link.com/support/faq/2850/
VIGI NVR
NVRNetwork Device
(e.g., Switch or Router)
Access Point
