TPI 810 User manual
Fiber Optic Inspection Tool 810
Test Products International, Inc.
TheValueLeader
Visit www.testproductsintl.com
A. INTRODUCTION
1. Congratulations: Thank you for purchasing TPI products. The 810 is
easy to use and built to last. It is backed by a one year warranty. Please
remember to complete and return your product warranty registration
card.
2. Product Description: The 810 is a fiber optic inspection tool used to look
in confined or internal constricted areas previously deemed inaccessible.
The 810 has a built-in LED light source for illuminating the viewing area
and a 45 degree mirror for looking at sides and walls. Is is easy to use
and fits comfortably in your hand.
B. SAFETY CONSIDERATIONS
WARNING
Read instructions before operating:
Be sure these instructions accompany the tool when passed
from one user to a new or inexperienced user.
Risk of entanglement: Turn off all moving parts before inserting
fiber optic shaft.
CAUTION
Do not bend fiber optic shaft into a tight radius. Damage to the
glass fiber optics may result. Do not use internally on humans
or animals.
C. TECHNICAL DATA
Field of View 45°
Image Size 8000 pixels
Scope Mirror 45° machined brass + glass mirror
Minimum Focus Distance 1 inch (25mm)
Focus Knurled focus adjustment ring
Fiber Optic Shaft Diameter 0.4 inches (10.2mm)
Fiber Optic Shaft Length 48 inches (1.2 meters)
Maximum Bend Radius 4 inches (100mm)
Light Source 7 super bright LED
Light Power Supply 1 each “AA” alkaline battery
Battery Life 36 hours continuous use
Maximum Tip Temperature 176 °F (80°C)
Resistant to Fluids Gas, Oil, Coolant, Water
Operating Temperature 50° to 120°F (10° to 60°C)
D. OPERATING TECHNIQUES
1. Visually inspect the fiber optic shaft, lens and housing of the 810
making sure it is free from defects.
2. Test the condition of the light battery by depressing the ON/OFF
switch on the end of the light housing. The light at the end of the
fiber optic shaft should turn ON and OFF. If not, replace the “AA”
battery.
3. Hold the light source handle in the left hand and the end of the fiber
optic shaft in the right hand. Manipulate the focus ring with your
thumb on your left hand.
4. Looking into the the lens on the housing, rotate the focus ring until
you can see a honeycomb pattern (this shows each fiber optic cable
in the lens) and you can bring it into sharp focus.
5. Insert the tip of the fiber optic shaft into the object to be observed. If
there is not enough light to clearly see the object, press the ON switch
at the end of the handle to turn on the LED light source.
6. If you want to look around corners or bends, pre-shape the fiber optic
shaft before inserting it into the object.
7. Install the 45 degree mirror at the end of the fiber optic shaft if you
need to look at the side or wall of the object.
LED flashlight
ON/OFF
Switch
Wrist
strap
Knurled
focus
adjustment
ring
Eyepiece
Coated
Fiber Optic
Shaft
45 degree
mirror
(removable)
Machined
aluminum
housing
A. INTRODUCTION
1. Congratulations: Thank you for purchasing TPI products. The 810 is
easy to use and built to last. It is backed by a one year warranty. Please
remember to complete and return your product warranty registration
card.
2. Product Description: The 810 is a fiber optic inspection tool used to look
in confined or internal constricted areas previously deemed inaccessible.
The 810 has a built-in LED light source for illuminating the viewing area
and a 45 degree mirror for looking at sides and walls. Is is easy to use
and fits comfortably in your hand.
B. SAFETY CONSIDERATIONS
WARNING
Read instructions before operating:
Be sure these instructions accompany the tool when passed
from one user to a new or inexperienced user.
Risk of entanglement: Turn off all moving parts before inserting
fiber optic shaft.
CAUTION
Do not bend fiber optic shaft into a tight radius. Damage to the
glass fiber optics may result. Do not use internally on humans
or animals.
C. TECHNICAL DATA
Field of View 45°
Image Size 8000 pixels
Scope Mirror 45° machined brass + glass mirror
Minimum Focus Distance 1 inch (25mm)
Focus Knurled focus adjustment ring
Fiber Optic Shaft Diameter 0.4 inches (10.2mm)
Fiber Optic Shaft Length 48 inches (1.2 meters)
Maximum Bend Radius 4 inches (100mm)
Light Source 7 super bright LED
Light Power Supply 1 each “AA” alkaline battery
Battery Life 36 hours continuous use
Maximum Tip Temperature 176 °F (80°C)
Resistant to Fluids Gas, Oil, Coolant, Water
Operating Temperature 50° to 120°F (10° to 60°C)
D. OPERATING TECHNIQUES
1. Visually inspect the fiber optic shaft, lens and housing of the 810
making sure it is free from defects.
2. Test the condition of the light battery by depressing the ON/OFF
switch on the end of the light housing. The light at the end of the
fiber optic shaft should turn ON and OFF. If not, replace the “AA”
battery.
3. Hold the light source handle in the left hand and the end of the fiber
optic shaft in the right hand. Manipulate the focus ring with your
thumb on your left hand.
4. Looking into the the lens on the housing, rotate the focus ring until
you can see a honeycomb pattern (this shows each fiber optic cable
in the lens) and you can bring it into sharp focus.
5. Insert the tip of the fiber optic shaft into the object to be observed. If
there is not enough light to clearly see the object, press the ON switch
at the end of the handle to turn on the LED light source.
6. If you want to look around corners or bends, pre-shape the fiber optic
shaft before inserting it into the object.
7. Install the 45 degree mirror at the end of the fiber optic shaft if you
need to look at the side or wall of the object.
LED flashlight
ON/OFF
Switch
Wrist
strap
Knurled
focus
adjustment
ring
Eyepiece
Coated
Fiber Optic
Shaft
45 degree
mirror
(removable)
Machined
aluminum
housing
E. ACCESSORIES
Item # Description
A002 ..............................1.5 Volt “AA” Alkaline Battery
A811 ..............................45 Degree Glass Inspection Mirror
A810 ..............................Aluminum Carrying Case, Padded Interior
A812 ..............................Replacement LED Flashlight
A813 ..............................Replacement Carrying Case Key
F. MAINTENANCE
1. Clean the surface of the instrument with a damp cloth.
2. Clean the lens with gauze dipped in rubbing alcohol.
3. Replace the AA battery in the light source when low or dead.
G. WARRANTY
This product is warranted to the purchaser against defects in material and
workmanship for one year from the date of purchase.
Covered by Warranty: Repair parts and labor; or replacement of the product
at company’s option. Normal transportation charges to the purchaser are also
covered.
Not Covered by Warranty: Damages to the product which are the result of
abuse, improper use or maintenance are not covered. Any other expense,
consequential damages, incidental damages, or incidental expenses including
damages to property are not covered. Transportation expenses to the company
are not covered.
Some states do not allow the exclusion or limitation of incidental or
consequential damages, so the above limitations or exclusions may not apply
to you.
To Obtain Warranty Performance: Include with the product: your name,
address, phone number, written description of the problem and proof of
purchase date. Carefully package and return to:
TPI, Inc. TPI, Ltd. TPI, Europe Ltd..
9615 SW Allen Blvd. 342 Bronte Rd. S., Unit 9 Longley House, East Park
Beaverton, OR 97005 Milton, Ontario L9T 5B7 Crawley
USA Canada West Sussex RH10 6AP
England
Implied Warranties: Any implied warranties including implied warranties of
merchantability and fitness for a particular purpose, are limited in duration to
three years from date of purchase. To the extent any provision of this warranty
is prohibited by federal or state law and cannot be preempted, it shall not be
applicable. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
