TQ TQMx130 User manual

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page i
TQMx130
User's Manual
TQMx130 UM 0101
04.10.2023

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page i
TABLE OF CONTENTS
1. ABOUT THIS MANUAL ........................................................................................................................................................................5
1.1 Copyright and License Expenses ....................................................................................................................................................5
1.2 Registered Trademarks ......................................................................................................................................................................5
1.3 Disclaimer...............................................................................................................................................................................................5
1.4 Imprint.....................................................................................................................................................................................................5
1.5 Service and Support............................................................................................................................................................................5
1.6 Tips on Safety........................................................................................................................................................................................6
1.7 Symbols and Typographic Conventions.......................................................................................................................................6
1.8 Handling and ESD Tips.......................................................................................................................................................................6
1.9 Naming of Signals................................................................................................................................................................................7
1.10 Further Applicable Documents / Presumed Knowledge.........................................................................................................7
2. INTRODUCTION ....................................................................................................................................................................................8
2.1 Overview.................................................................................................................................................................................................8
2.2 Compliance......................................................................................................................................................................................... 10
2.3 Versions................................................................................................................................................................................................ 11
2.4 Accessories.......................................................................................................................................................................................... 15
3. FUNCTION ........................................................................................................................................................................................... 16
3.1 Block Diagram.................................................................................................................................................................................... 16
3.2 Electrical Characteristics ................................................................................................................................................................. 16
3.2.1 Supply Voltage .................................................................................................................................................................................. 16
3.2.2 Power Consumption........................................................................................................................................................................ 17
3.2.3 Real Time Clock Power Consumption ........................................................................................................................................ 20
3.3 Environmental Conditions ............................................................................................................................................................. 20
3.4 System Components........................................................................................................................................................................ 21
3.4.1 Processor ............................................................................................................................................................................................. 21
3.4.1.1 Intel®Turbo Boost Technology .................................................................................................................................................... 24
3.4.1.2 Intel®Configurable Thermal Design Power.............................................................................................................................. 24
3.4.2 Graphics............................................................................................................................................................................................... 24
3.4.3 Chipset ................................................................................................................................................................................................. 24
3.4.4 Memory................................................................................................................................................................................................ 25
3.4.4.1 DDR5 SDRAM SO-DIMM.................................................................................................................................................................. 25
3.4.4.2 SPI Boot Flash..................................................................................................................................................................................... 25
3.4.4.3 SPI General Purpose......................................................................................................................................................................... 25
3.4.4.4 EEPROM ............................................................................................................................................................................................... 25
3.4.5 Real Time Clock ................................................................................................................................................................................. 26
3.4.6 Trusted Platform Module ............................................................................................................................................................... 26
3.4.7 Hardware Monitor ............................................................................................................................................................................ 26
3.4.8 TQ Flexible I/O Configuration (TQ-flexiCFG)............................................................................................................................. 26
3.5 Interfaces............................................................................................................................................................................................. 27
3.5.1 PCI Express.......................................................................................................................................................................................... 27
3.5.2 PCI Express Graphics (PEG-Port)................................................................................................................................................... 27
3.5.3 2.5 Gigabit Ethernet ......................................................................................................................................................................... 28
3.5.4 Serial ATA ............................................................................................................................................................................................ 28
3.5.5 Digital Display Interface.................................................................................................................................................................. 28
3.5.6 LVDS / eDP Interface........................................................................................................................................................................ 28
3.5.7 USB 2.0 and USB 3.2 Interfaces ..................................................................................................................................................... 29
3.5.8 USB4 interface.................................................................................................................................................................................... 29
3.5.9 General Purpose Input / Output................................................................................................................................................... 29
3.5.10 High Definition Audio Interface ................................................................................................................................................... 29
3.5.11 LPC / eSPI Bus..................................................................................................................................................................................... 30
3.5.12 I2C Bus................................................................................................................................................................................................... 30
3.5.13 SMBus................................................................................................................................................................................................... 30
3.5.14 MIPI-CSI Camera Serial Interface .................................................................................................................................................. 30
3.5.15 Serial Ports .......................................................................................................................................................................................... 31
3.5.16 Watchdog Timer................................................................................................................................................................................ 31
3.6 Connectors.......................................................................................................................................................................................... 32
3.6.1 .............................................................................................................................................................. 32
3.6.2 Debug Header.................................................................................................................................................................................... 32
3.6.3 TQM Debug Card .............................................................................................................................................................................. 33
3.6.4 Debug Module LED .......................................................................................................................................................................... 33
3.7 ................................................................................................................................................ 34
3.7.1 Signal Assignment Abbreviations ............................................................................................................................................... 34

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page ii
3.7.2 ............................................................................................................................... 35
4. MECHANICS ........................................................................................................................................................................................ 43
4.1 Dimensions......................................................................................................................................................................................... 43
4.2 Component Placement and Labels............................................................................................................................................. 44
4.3 Heat Spreader .................................................................................................................................................................................... 45
4.4 Mechanical and Thermal Considerations.................................................................................................................................. 45
4.5 Protection against External Effects.............................................................................................................................................. 45
5. SOFTWARE .......................................................................................................................................................................................... 46
5.1 System Resources ............................................................................................................................................................................. 46
5.1.1 I2C Bus Devices................................................................................................................................................................................... 46
5.1.2 SMBus Devices................................................................................................................................................................................... 46
5.1.3 Memory Mapping ............................................................................................................................................................................. 46
5.1.4 Interrupt Mapping............................................................................................................................................................................ 46
5.2 Operating Systems ........................................................................................................................................................................... 47
5.2.1 Supported Operating Systems ..................................................................................................................................................... 47
5.2.2 Driver Download............................................................................................................................................................................... 47
5.3 TQ-Systems Embedded Application Programming Interface (EAPI) ................................................................................ 47
5.4 Software Tools ................................................................................................................................................................................... 47
6. BIOS MENU ...................................................................................................................................................................................... 48
6.1 Continue.............................................................................................................................................................................................. 48
6.2 Boot Manager .................................................................................................................................................................................... 48
6.3 Device Manager ................................................................................................................................................................................ 49
6.3.1 Driver Health Manager.................................................................................................................................................................... 49
6.3.2 Network Device List ......................................................................................................................................................................... 49
6.4Boot from File..................................................................................................................................................................................... 49
6.5 Administer Secure Boot .................................................................................................................................................................. 49
6.6Setup Utility........................................................................................................................................................................................ 50
6.6.1 Main ...................................................................................................................................................................................................... 50
6.6.2 Advanced ............................................................................................................................................................................................ 51
6.6.2.1 Boot Configuration........................................................................................................................................................................... 51
6.6.2.2 USB Configuration............................................................................................................................................................................ 52
6.6.2.3 Chipset Configuration ..................................................................................................................................................................... 52
6.6.2.4 ACPI Table/Features Control ......................................................................................................................................................... 52
6.6.2.5 CPU Configuration............................................................................................................................................................................ 53
6.6.2.6 Power & Performance...................................................................................................................................................................... 53
6.6.2.7 Memory Configuration.................................................................................................................................................................... 57
6.6.2.8 System Agent (SA) Configuration................................................................................................................................................ 58
6.6.2.9 PCH-IO Configuration...................................................................................................................................................................... 61
6.6.2.10 PCH-FW Configuration.................................................................................................................................................................... 65
6.6.2.11 ACPI D3Cold settings....................................................................................................................................................................... 65
6.6.2.12 SIO TQMx86 ........................................................................................................................................................................................ 65
6.6.2.13 SIO Hardware Monitor Nuvoton NCT7802Y ............................................................................................................................. 66
6.6.2.14 Console Redirection......................................................................................................................................................................... 67
6.6.2.15 SIO F81214E........................................................................................................................................................................................ 69
6.6.3 Security ................................................................................................................................................................................................ 69
6.6.4 Power.................................................................................................................................................................................................... 69
6.6.5 Boot....................................................................................................................................................................................................... 69
6.6.6 Exit......................................................................................................................................................................................................... 70
6.7 BIOS Update.................................................................................................................................................................................... 71
6.7.1 Step 1: Preparing USB Stick............................................................................................................................................................ 71
6.7.2 Step 2: Preparing Management Engine (ME) FW for update .............................................................................................. 71
6.7.3 Step 3a: Updating uEFI BIOS via EFI Shell.................................................................................................................................. 73
6.7.4 Step 3b: Updating uEFI BIOS via Windows Operating System ........................................................................................... 74
6.7.5 Step 4: BIOS update check on the TQMx130 Module............................................................................................................ 74
7. SAFETY REQUIREMENTS AND PROTECTIVE REGULATIONS.................................................................................................. 75
7.1 EMC ....................................................................................................................................................................................................... 75
7.2 ESD ........................................................................................................................................................................................................ 75
7.3 Shock & Vibration ............................................................................................................................................................................. 75
7.4 Operational Safety and Personal Security................................................................................................................................. 75
7.5 Reliability and Service Life.............................................................................................................................................................. 75
7.5.1 RoHS...................................................................................................................................................................................................... 75
7.5.2 WEEE®................................................................................................................................................................................................... 75
7.6 REACH®................................................................................................................................................................................................ 75
7.7 EuP......................................................................................................................................................................................................... 75
7.8 Battery .................................................................................................................................................................................................. 75

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page iii
7.9 Packaging............................................................................................................................................................................................ 75
7.10 Other Entries....................................................................................................................................................................................... 76
8. APPENDIX............................................................................................................................................................................................ 77
8.1 Acronyms and Definitions.............................................................................................................................................................. 77
8.2 References........................................................................................................................................................................................... 79

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page iv
TABLE DIRECTORY
Table 1: Terms and Conventions .............................................................................................................................................................6
Table 2: ....... 11
Table 3: ....... 12
Table 4: ....... 13
Table 5: 14
Table 6: TQMx130 Power Consumption Turbo Mode ON........................................................................................................... 18
Table 7: TQMx130 Power Consumption Turbo Mode OFF ......................................................................................................... 18
Table 8: RTC Current Consumption...................................................................................................................................................... 20
Table 9: 13th Generation Intel®-Series................................................................... 21
Table 10: 13th Generation Intel®-Series ................................................................... 22
Table 11: 13th Generation Intel®ndustrial U-Series................................................................... 23
Table 12: 13th Generation Intel®-Series............................................................................... 23
Table 13: Maximum Resolution Display Configuration.................................................................................................................... 24
Table 14: PCI Express port 0 7 Configuration Options ..................................................................................... 27
Table 15: PCI Express Graphics port Configuration Options ............................................................................. 27
Table 16: ............................................................................................................................ 31
Table 17: LED Boot Messages................................................................................................................................................................... 33
Table 18: Signal Assignment Abbreviations ........................................................................................................................................ 34
Table 19: ....................................................................................................................... 35
Table 20: Labels on TQMx130 .................................................................................................................................................................. 44
Table 21: I2 2C Port ................................................................................................................... 46
Table 22: I2........................................................................................................... 46
Table 23: Acronyms..................................................................................................................................................................................... 77
Table 24: Further Applicable Documents and Links ......................................................................................................................... 79
FIGURE DIRECTORY
Figure 1: TQMx130 block diagram ......................................................................................................................................................... 16
Figure 2: TQM Debug Card....................................................................................................................................................................... 33
Figure 3: Debug Module LED................................................................................................................................................................... 33
Figure 4: TQMx130 three view drawing ............................................................................................................................................... 43
Figure 5: TQMx130 Bottom View Drawing .......................................................................................................................................... 43
Figure 6: TQMx130 Component Placement Top ............................................................................................................................... 44
Figure 7: TQMx130 Component Placement Bottom........................................................................................................................ 44
Figure 8: TQMx130-HSP Heat Spreader................................................................................................................................................ 45
Figure 9: InsydeH2O BIOS Front Page................................................................................................................................................... 48
Figure 10: PCH-FW Configuration menu ................................................................................................................................................ 72
Figure 11: Firmware Update Configuration menu .............................................................................................................................. 72
Figure 12: ME FW Image Re-Flash option............................................................................................................................................... 72
Figure 13: EFI Shell......................................................................................................................................................................................... 73
Figure 14: EFI Shell uEFI BIOS Update...................................................................................................................................................... 73
Figure 15: Screen during BIOS Update.................................................................................................................................................... 73
Figure 16: TQMx130 Debug LED ............................................................................................................................................................... 74
Figure 17: EFI BIOS Main Menu.................................................................................................................................................................. 74
REVISION HISTORY
Rev.
Date
Name
Pos.
Modification
0100
12.09.2023
KG
First release
0101
04.10.2023
KG
2.1
Temperature range supplemented

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page 5
1. ABOUT THIS MANUAL
1.1 Copyright and License Expenses
Copyright protected © 2023 by TQ-Systems GmbH.
This User's Manual may not be copied, reproduced, translated, changed or distributed, completely or partially in electronic,
machine readable, or in any other form without the written consent of TQ-Systems GmbH.
The drivers and utilities for the components used as well as the BIOS are subject to copyrights of the respective manufacturers.
The licence conditions of the respective manufacturer are to be adhered to.
BIOS-licence expenses are paid by TQ-Systems GmbH and are included in the price.
Licence expenses for the operating system and applications are not taken into consideration and have to be calculated/declared
separately.
1.2 Registered Trademarks
TQ-Systems GmbH aims to adhere to copyrights of all graphics and texts used in all publications, and strives to use original
or license-free graphics and texts.
All brand names and trademarks mentioned in this User's Manual, including those protected by a third party, unless specified
otherwise in writing, are subjected to the specifications of the current copyright laws and the proprietary laws of the present
registered proprietor without any limitation. One should conclude that brand and trademarks are rightly protected by
a third party.
1.3 Disclaimer
TQ-Systems GmbH does not guarantee that the information in this User's Manual is up-to-date, correct, complete or of good
quality. Nor does TQ-Systems GmbH assume guarantee for further usage of the information. Liability claims against
TQ-Systems GmbH, referring to material or non-material related damages caused, due to usage or non-usage of the information
given in this User's Manual, or due to usage of erroneous or incomplete information, are exempted, as long as there is no proven
intentional or negligent fault of TQ-Systems GmbH.
TQ-Systems GmbH explicitly reserves the rights to change or add to the contents of this User's Manual or parts of it without
special notification.
1.4 Imprint
TQ-Systems GmbH
Gut Delling, Mühlstraße 2
D-82229 Seefeld
Tel: [phone]
Fax: [phone]
E-Mail: Info@TQ-Group
Web: TQ-Group
1.5 Service and Support
Please visit our website www.tq-group.com for latest product documentation, drivers, utilities and technical support.
You can register on our website www.tq-group.com to have access to restricted information and automatic update services.
For direct technical support you can contact our FAE team by email: [email protected].
Our FAE team can also support you with additional information like 3D-STEP files and confidential information, which is not
provided on our public website.
For service/RMA, please contact our service team by email ([email protected]) or your sales team at TQ-Systems GmbH.

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page 6
1.6 Tips on Safety
Improper or incorrect handling of the product can substantially reduce its life span.
1.7 Symbols and Typographic Conventions
Table 1: Terms and Conventions
Symbol
Meaning
This symbol represents the handling of electrostatic-sensitive modules and / or components. These
components are often damaged / destroyed by the transmission of a voltage higher than about 50 V.
A human body usually only experiences electrostatic discharges above approximately 3,000 V.
This symbol indicates the possible use of voltages higher than 24 V.
Please note the relevant statutory regulations in this regard.
Non-compliance with these regulations can lead to serious damage to your health and also cause
damage / destruction of the component.
This symbol indicates a possible source of danger. Acting against the procedure described can lead to
possible damage to your health and / or cause damage / destruction of the material used.
This symbol represents important details or aspects for working with TQ-products.
Command
A font with fixed-width is used to denote commands, contents, file names, or menu items.
1.8 Handling and ESD Tips
General handling of your TQ-products
The TQ-product may only be used and serviced by certified personnel who have taken note of the
information, the safety regulations in this document and all related rules and regulations.
A general rule is: do not touch the TQ-product during operation. This is especially important when
switching on, changing jumper settings or connecting other devices without ensuring beforehand
that the power supply of the system has been switched off.
Violation of this guideline may result in damage / destruction of the TQMx130 and be dangerous
to your health.
Improper handling of your TQ-product would render the guarantee invalid.
Proper ESD handling
The electronic components of your TQ-product are sensitive to electrostatic discharge (ESD).
Always wear antistatic clothing, use ESD-safe tools, packing materials etc., and operate your TQ-
product in an ESD-safe environment. Especially when you switch modules on, change jumper settings,
or connect other devices.

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page 7
1.9 Naming of Signals
A hash mark (#) at the end of the signal name indicates a low-active signal.
Example: RESET#
If a signal can switch between two functions and if this is noted in the name of the signal, the low-active function is marked
with a hash mark and shown at the end.
Example: C / D#
If a signal has multiple functions, the individual functions are separated by slashes when they are important for the wiring.
The identification of the individual functions follows the above conventions.
Example: WE2# / OE#
1.10 Further Applicable Documents / Presumed Knowledge
•Specifications and manual of the modules used:
These documents describe the service, functionality and special characteristics of the module used.
•Specifications of the components used:
The manufacturer's specifications of the components used, for example CompactFlash cards, are to be taken note of.
They contain, if applicable, additional information that has to be taken note of for safe and reliable operation.
These documents are stored at TQ-Systems GmbH.
•Chip errata:
It is the user's responsibility to make sure all errata published by the manufacturer of each component are taken note of.
•Software behaviour:
No warranty can be given, nor responsibility taken for any unexpected software behaviour due to deficient components.
•General expertise:
Expertise in electrical engineering / computer engineering is required for the installation and the use of the device.
Implementation information for the carrier board (3), maintained by the
PICMG®
It includes detailed information with schematics and detailed layout guidelines.
Please refer to the official PICMG®documentation for additional information (2), (4).

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page 8
2. INTRODUCTION
Based on the internationally established PICMG®(COM.0 Rev. 3.1), the TQMx130 enables the design of
not only powerful but also economical x86 based systems. The user has access to all essential interfaces of the CPU at the Type 6
compliant pin out connector. Hence all features of the 13th Generation Intel®can be used. The direct access to all
interfaces gives the user the freedom to use the features of the CPU in the most suitable way for his application.
The compact and robust design as well as the option of conformal coating extends the use cases to applications within rugged
industry, transportation and aviation environments. Based on the very low-power consumption and the extended temperature
support it is also possible to realize outdoor applications in an easy and reliable way.
2.1 Overview
The following key functions are implemented on the TQMx130:
Processor:
13th Generation Inte embedded H-series (Raptor Lake-P / H45) with up to 14 processor cores
•Intel®i7-13800HE 6P+8E / 96EU, 24 MB Cache, up to 5.0 GHz , 45 W (cTDP 35 W), 0 °C 100 °C
•Intel®i5-13600HE 4P+8E / 80EU, 18 MB Cache, up to 4.8 GHz , 45 W (cTDP 35 W), 0 °C 100 °C
•Intel®i3-13300HE 4P+4E / 48EU, 12 MB Cache, up to 4.6 GHz , 45 W (cTDP 35 W), 0 °C 100 °C
13th Generation Inte industrial H-series (Raptor Lake-P / H45) with up to 14 processor cores
•Intel®i7-13800HRE 6P+8E / 96EU, 24 MB Cache, up to 5.0 GHz , 45 W (cTDP 35 W), -40 °C 100 °C
•Intel®i5-13600HRE 4P+8E / 80EU, 18 MB Cache, up to 4.8 GHz , 45 W (cTDP 35 W), -40 °C 100 °C
•Intel®i3-13300HRE 4P+4E / 48EU, 12 MB Cache, up to 4.6 GHz , 45 W (cTDP 35 W), -40 °C 100 °C
13th Generation Inte P-series (Raptor Lake-P / P28) with up to 14 processor cores
•Intel®i7-1370PE 6P+8E / 96EU, 24 MB Cache, up to 4.8 GHz , 28 W (cTDP 35 W / 20 W), 0 °C 100 °C
•Intel®i5-1350PE 4P+8E / 80EU, 12 MB Cache, up to 4.6 GHz , 28 W (cTDP 35 W / 20 W), 0 °C 100 °C
•Intel®i5-1340PE 4P+8E / 80EU, 12 MB Cache, up to 4.5 GHz , 28 W (cTDP 35 W / 20 W), 0 °C 100 °C
•Intel®i3-1320PE 4P+4E / 48EU, 12 MB Cache, up to 4.5 GHz , 28 W (cTDP 35 W / 20 W), 0 °C 100 °C
13th Generation Inte P-series (Raptor Lake-P / P28) with up to 14 processor cores
•Intel®i7-1370PRE 6P+8E / 96EU, 24 MB Cache, up to 4.8 GHz , 28 W (cTDP 35 W / 20 W), -40 °C 100 °C
•Intel®i5-1350PRE 4P+8E / 80EU, 12 MB Cache, up to 4.6 GHz , 28 W (cTDP 35 W / 20 W), -40 °C 100 °C
•Intel®i3-1320PRE 4P+4E / 48EU, 12 MB Cache, up to 4.5 GHz , 28 W (cTDP 35 W / 20 W), -40 °C 100 °C
13th Generation Inte and Processor embedded U-series (Raptor Lake-P / U15) with up to 10 processor cores
•Intel® i7-1365UE 2P+8E / 96EU, 12 MB Cache, up to 4.9 GHz , 15 W (cTDP 28 W / 12 W), 0 °C 100 °C
•i5-1345UE 2P+8E / 80EU, 12 MB Cache, up to 4.6 GHz , 15 W (cTDP 28 W / 12 W), 0 °C 100 °C
•i5-1335UE 2P+8E / 80EU, 12 MB Cache, up to 4.5 GHz , 15 W (cTDP 28 W / 12 W), 0 °C 100 °C
•Intel® i3-1315UE 2P+4E / 64EU, 10 MB Cache, up to 4.3 GHz , 15 W (cTDP 28 W / 12 W), 0 °C 100 °C
•Intel®Processor U300E 1P+4E / 48EU, 8 MB Cache, up to 4.3 GHz , 15 W (cTDP 28 W / 12 W), 0 °C 100 °C
13th Generation Inte -series (Raptor Lake-P / U15) with up to 10 processor cores
•Intel® i7-1365URE 2P+8E / 96EU, 12 MB Cache, up to 4.9 GHz , 15 W (cTDP 28 W / 12 W), -40 °C 100 °C
•i5-1345URE 2P+8E / 80EU, 12 MB Cache, up to 4.6 GHz , 15 W (cTDP 28 W / 12 W), -40 °C 100 °C
•Intel® i3-1315URE 2P+4E / 64EU, 10 MB Cache, up to 4.3 GHz , 15 W (cTDP 28 W / 12 W), -40 °C 100 °C

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page 9
Memory:
•2 × DDR5 SO-DIMM socket with max. 64 Gbyte, dual channel DDR5 up to 5200 MT/s SO-DIMM modules
•EEPROM: 32 kbit (24AA32) (optional)
Graphics:
•3 × Digital Display Interface / DP++ with up to 8K; DisplayPort 1.4a with support for Multi-Stream Transport (MST)
•1 × Embedded Digital Display Interface (eDP) or dual channel LVDS interface (eDP 1.4b or dual LVDS)
Peripheral interfaces:
•1 × 2.5 Gigabit Ethernet (Intel®i226)
•4 × USB 3.2 Gen 2 (up to 10 Gb/s) with USB 3.0 compatibility
•2 × USB4 Support, pins shared with Digital Display Interface (optional)
•8 × USB 2.0
•2 × SATA Gen 3 (up to 6 Gb/s) or 2x PCIe Gen 3 (up to 8 Gb/s)
•4 × PCIe Gen 3 (up to 8 Gb/s) (4 (×1), 2 (×2), or 1 (×4))
•4 × PCIe Gen 4 (up to 16 Gb/s) (1 (×1), 1 (×2), or 1 (×4))
•1 × PCIe PEG port Gen 4 (up to 16 Gb/s) (1 (×4) and 1 (x8) H series only)
•1 × LPC or eSPI bus
•1 × Intel®HD audio (HDA)
•1 × I2C (2nd I2C optional)
•1 × SMBus
•1 × SPI for external uEFI BIOS flash
•1 × SPI general purpose interface (optional)
•2 × Serial port (Rx/Tx, legacy compatible), 4-wire (Rx/Tx/RTS/CTS) optionally through TQ-flexiCFG
•8 × GPIO through TQ-flexiCFG
•1 × MIPI-CSI Camera input interface connector (option)

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page 10
Security components:
•Internal firmware TPM (FTPM) controller or discrete TPM with SLB9670 TPM 2.0 or SLB9672 TPM 2.0 controller
Others:
•TQMx86 board controller with Watchdog and TQ-flexiCFG
•Hardware monitor
Power supply voltage:
•Wide input: 8.5 V to 20 V maximum input ripple: ±100 mV (P, U embedded processor series)
•Standard input: nominal voltage 12 V (11.4 V to 12.6 V) (H embedded and industrial temperature range)
•Standard input: nominal voltage 12 V (11.4 V to 12.6 V) (P, U industrial temperature range)
•5 V Standby (optional) 5 V (4.75 V to 5.25 V)
•3 V Battery for RTC
Environment:
•Operating standard temperature: 0 °C to +60 °C
•Operating industrial temperature: -40 °C to +85 °C (P, U industrial processor series)
-40 °C to +60 °C (H industrial processor series)
(Details see chapter 2.3)
•Storage temperature: -40 °C to +85 °C
•Relative humidity (operation): 10 % to 90 % (non-condensing)
•Relative humidity (storage): 5 % to 95 % (non-condensing, with conformal coating)
Form factor / dimensions:
•COMExpress Compact, Type 6, 95 mm × 95 mm
2.2 Compliance
The TQMx130 complies with PICMG®e Base Specification (COM.0 Rev. 3.1).

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page 11
2.3 Versions
The TQMx130 is available in several standard configurations.
Table 2: TQMx130HC 13th Generation Inte / Industrial Series configurations and features
Feature
TQMx130HC-AA
TQMx130HC-AB
TQMx130HC-AC
Intel
i7-13800HE / HRE
i5-13600HE / HRE
i3-13300HE / HRE
CPU
6P + 8E
4P + 8E
4P + 4E
CPU TDP
45 / 35 W
45 / 35 W
45 / 35 W
CPU Clock (Base)
2.5 GHz
2.7 GHz
2.1 GHz
GfX
96 EU
80 EU
48 EU
L2 Cache
24 MB
18 MB
12 MB
Heat spreader
TQMx130-HSP-AA
TQMx130-HSP-AA
TQMx130-HSP-AA
Heatsink incl. fan
TQMx130-KK-AA
TQMx130-KK-AA
TQMx130-KK-AA
DRAM / SO-DIMM
16 / 32 / 64 GB
16 / 32 / 64 GB
16 / 32 / 64 GB
Use Condition
Embedded
Embedded
Embedded
Operating Temperature
0 °C to +60 °C
(Turbo ON)
0 °C to +60 °C
(Turbo ON)
0 °C to +60 °C
(Turbo ON)
Use Condition
Industrial
Industrial
Industrial
Operating Temperature
-40 °C to +60 °C
(Turbo OFF)
-40 °C to +60 °C
(Turbo OFF)
-40 °C to +60 °C
(Turbo OFF)
vPro
Yes
Yes
No
TPM 2.0
1
1
1
Independent displays
4
4
4
LVDS or eDP
1
1
1
DP or HDMI
3
3
3
2.5 GbE
1
1
1
USB 2.0 host
8
8
8
USB 3.2 host
4
4
4
SATA Gen 3
2
2
2
PCIe Gen 3 ×1
8
8
8
PEG Gen 4 x4 / x8
1 / 1
1 / 1
1 / 1
I2C / SPI
1 / 1
1 / 1
1 / 1
HDA
1
1
1
LPC or eSPI
1
1
1
UART / GPIO
2 / 8
2 / 8
2 / 8

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page 12
Table 3: TQMx130PC 13th Generation Inte Embedded / Industrial Series configurations and features
Feature
TQMx130PC-AA
TQMx130PC-AB
TQMx130PC-AD
TQMx130PC-AC
Intel
-1370PE / PRE
-1350PE / PRE
-1340PE
-1320PE / PRE
CPU
6P + 8E
4P + 8E
4P + 8E
4P + 4E
CPU TDP
28 / 35 / 20 W
28 / 35 / 20 W
28 / 35 / 20 W
28 / 35 / 20 W
CPU Clock (Base)
1.9 GHz
1.8 GHz
1.8 GHz
1.7 GHz
GfX
96 EU
80 EU
80 EU
48 EU
L2 Cache
24 MB
12 MB
12 MB
12 MB
Heat spreader
TQMx130-HSP-AA
TQMx130-HSP-AA
TQMx130-HSP-AA
TQMx130-HSP-AA
Heatsink incl. fan
TQMx130-KK-AA
TQMx130-KK-AA
TQMx130-KK-AA
TQMx130-KK-AA
DRAM / SO-DIMM
16 / 32 / 64 GB
16 / 32 / 64 GB
16 / 32 / 64 GB
16 / 32 / 64 GB
Use Condition
Embedded
Embedded
Embedded
Embedded
Operating Temperature
0 °C to +60 °C
(Turbo ON)
0 °C to +60 °C
(Turbo ON)
0 °C to +60 °C
(Turbo ON)
0 °C to +60 °C
(Turbo ON)
Use Condition
Industrial
Industrial
Industrial
Industrial
Operating Temperature
-40 °C to +85 °C
(Turbo OFF)
-40 °C to +85 °C
(Turbo OFF)
N/A
-40 °C to +85 °C
(Turbo OFF)
vPro
Yes
Yes
No
No
TPM 2.0
1
1
1
1
Independent displays
4
4
4
4
LVDS or eDP
1
1
1
1
DP or HDMI
3
3
3
3
2.5 GbE
1
1
1
1
USB 2.0 host
8
8
8
8
USB 3.2 host
4
4
4
4
SATA Gen 3
2
2
2
2
PCIe Gen 3 ×1
8
8
8
8
PEG Gen 4 x4 / x8
1 / --
1 / --
1 / --
1 / --
I2C / SPI
1 / 1
1 / 1
1 / 1
1 / 1
HDA
1
1
1
1
LPC or eSPI
1
1
1
1
UART / GPIO
2 / 8
2 / 8
2 / 8
2 / 8

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page 13
Table 4: TQMx130UC 13th Generation Inte Embedded / Industrial Series configurations and features
Feature
TQMx130UC-AA
TQMx130UC-AB
TQMx130UC-AC
Intel
-1365UE / URE
-1345UE / URE
-1315UE / URE
CPU
2P + 8E
2P + 8E
2P + 4E
CPU TDP
15 / 28 / 12 W
15 / 28 / 12 W
15 / 28 / 12 W
CPU Clock (Base)
1.7 GHz
1.4 GHz
1.2 GHz
GfX
96 EU
80 EU
64 EU
L2 Cache
12 MB
12 MB
10 MB
Heat spreader
TQMx130-HSP-AA
TQMx130-HSP-AA
TQMx130-HSP-AA
Heatsink incl. fan
TQMx130-KK-AA
TQMx130-KK-AA
TQMx130-KK-AA
DRAM / SO-DIMM
16 / 32 / 64 GB
16 / 32 / 64 GB
16 / 32 / 64 GB
Use Condition
Embedded
Embedded
Embedded
Operating Temperature
0 °C to +60 °C
(Turbo ON)
0 °C to +60 °C
(Turbo ON)
0 °C to +60 °C
(Turbo ON)
Use Condition
Industrial
Industrial
Industrial
Operating Temperature
-40 °C to +85 °C
(Turbo OFF)
-40 °C to +85 °C
(Turbo OFF)
-40 °C to +85 °C
(Turbo OFF)
vPro
Yes
Yes
No
TPM 2.0
1
1
1
Independent displays
3
3
3
LVDS or eDP
1
1
1
DP or HDMI
3
3
3
2.5 GbE
1
1
1
USB 2.0 host
8
8
8
USB 3.2 host
4
4
4
SATA Gen 3
2
2
2
PCIe Gen 3 ×1
8
8
8
PEG Gen 4 x4 / x8
1 / --
1 / --
1 / --
I2C / SPI
1 / 1
1 / 1
1 / 1
HDA
1
1
1
LPC or eSPI
1
1
1
UART / GPIO
2 / 8
2 / 8
2 / 8

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page 14
Table 5: TQMx130UC 13th Generation Inte and Processor Embedded Series configurations and features
Feature
TQMx130UC-AE
TQMx130UC-AD
Intel
-1335UE
Intel® Processor U300E
CPU
2P + 8E
1P + 4E
CPU TDP
15 / 28 / 12 W
15 / 28 / 12 W
CPU Clock (Base)
1.3 GHz
1.1 GHz
GfX
80 EU
48 EU
L2 Cache
12 MB
8 MB
Heat spreader
TQMx130-HSP-AA
TQMx130-HSP-AA
Heatsink incl. fan
TQMx130-KK-AA
TQMx130-KK-AA
DRAM / SO-DIMM
16 / 32 / 64 GB
16 / 32 / 64 GB
Use Condition
Embedded
Embedded
Operating Temperature
0 °C to +60 °C
(Turbo ON)
0 °C to +60 °C
(Turbo ON)
Use Condition
Industrial
Industrial
Operating Temperature
N/A
N/A
vPro
No
No
TPM 2.0
1
--
Independent displays
3
3
LVDS or eDP
1
1
DP or HDMI
3
3
2.5 GbE
1
1
USB 2.0 host
8
8
USB 3.2 host
4
4
SATA Gen 3
2
2
PCIe Gen 3 ×1
8
8
PEG Gen 4 x4 / x8
1 / --
1 / --
I2C / SPI
1 / 1
1 / 1
HDA
1
1
LPC or eSPI
1
1
UART / GPIO
2 / 8
2 / 8
Please refer to www.tq-group.com/ for a full list of standard versions.
Other configurations are available on request.
Hardware and software configuration features on request:
•Conformal coating
•Customized BIOS
•USB4 support
•SPI general purpose support

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page 15
2.4 Accessories
•TQMx130-HSP
ALU Heat spreader with copper inlay for TQMx130,
•Evaluation platform MB-COME6-4
and Compact, Type 6, 170 mm × 170 mm, with the following interfaces:
- 3 × DP (2x up to 8k HBR3, 1x up to 4k HBR2)
- 1 x dual LVDS
- 1 x eDP (up to 4k HBR2)
- 2 × 2.5 Gbit Ethernet
- 2 x USB 3.2 USB-A
- 1 x USB 3.2 USB-C
- 3 x USB 2.0 internal
- 2 × Serial Port RS232
- 1x High Definition Audio (Line In, MIC In, HP Out)
- 1x M.2 Socket Key E (Wi-Fi/BT),
- 1x M.2 Socket Key B with µSIM (WWAN or SATA SSD)
- 1x M.2 Socket Key M PCIe x4 (SSD)
- 1x M.2 Socket Key M PCIe x2 (SSD)
- 1x PCIExpress x16 PEG port
- 1x SATA connector
- Fan header
- Debug header
•Debug module
POST debug card for TQMx130, see 3.6.3. It is no standard accessory.

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page 16
3. FUNCTION
3.1 Block Diagram
The following figure shows the TQMx130 block diagram.
Figure 1: TQMx130 block diagram
3.2 Electrical Characteristics
3.2.1 Supply Voltage
The TQMx130 supports a wide-range voltage input from 8.5 V to 20 V.
The following supply voltages are
Wide input: 8.5 V to 20 V maximum input ripple: ±100 mV (P, U embedded processor series)
Standard input: 11.4 V to 12.6 V maximum input ripple: ±100 mV (H embedded and industrial temperature range)
Standard input: 11.4 V to 12.6 V maximum input ripple: ±100 mV (P, U industrial temperature range)
VCC_5V_SBY: 4.75 V to 5.25 V maximum input ripple: ±50 mV
VCC_RTC: 2.0 V to 3.3 V maximum input ripple: ±20 mV
The input voltages shall rise from 10 % to 90 % of nominal within 0.1 ms to 20 ms ( ).
The increase of each DC output voltage has to be smooth and continuous from 10 % to 90 % of its final set point within the
regulation range.
Note: Power source
For single supply operations, the 5 V Standby voltage is not required.
VCC_5V_SBY can be left unconnected.

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page 17
3.2.2 Power Consumption
The power consumption values below show the TQMx130 voltage and power specifications.
The values were measured with two power supplies; one for the TQMx130 and the other one for the MB-COME6-4
carrier board.
The power consumption of each TQMx130 version was measured running Windows®10, 64-bit and a dual DDR5 SO-DIMM
configuration (2 × 16 Gbyte). All measurements were done at a temperature of +25 °C and an input voltage of +12 V.
The power consumption of the TQMx130 depends on the application, the mode of operation and the operating system.
The power consumption was measured under the following test modes:
•Suspend mode:
The system is in S5/S4 state, Ethernet port is disconnected.
•Windows®10, 64-bit, idle state:
Desktop idle state, Ethernet port is disconnected.
•Windows®10, 64-bit, maximum workload (cTDP down mode enabled):
These values show the maximum cTDP down power consumption using the Intel®stress test tool to stress the
processor and graphic engine.
•Windows®10, 64-bit, maximum workload (nominal configuration):
These values show the maximum worst case power consumption using the Intel®stress test tool to stress the processor
and graphic engine.
•Windows®10, 64-bit, maximum workload (cTDP up mode enabled):
These values show the maximum cTDP up power consumption using the Intel®stress test tool to stress the processor
and graphic engine.
•Windows®10, 64-bit, maximum workload (turbo mode first seconds)
These values show the maximum worst case power consumption using the Intel®stress test tool to stress the processor
and graphic engine. This value was measured only for a short time (below 28 s) when the processor is in the turbo
mode. This value should be used for designing the power supply for the TQMx130 module.
The following table shows the TQMx130 power consumption with different CPUs.
The power consumption in the S5/S4 state is 490 mW (5 V standby voltage).

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page 18
Table 6: TQMx130 Power Consumption Turbo Mode ON
CPU
Mode
Win10, 64-bit
idle
Average load
Win10, 64-bit
cTDP down 35 W
max. load
Win10, 64-bit
nominal 45 W
max. load
Win10, 64-bit
cTDP up
max. load
Win10, 64-bit
Max load
(Turbo mode)
H-series
6.0 W
43.0 W
55.0 W
--
148.0 W
CPU
Mode
Win10, 64-bit
idle
Average load
Win10, 64-bit
cTDP down 20 W
max. load
Win10, 64-bit
nominal 28 W
max. load
Win10, 64-bit
cTDP up 35 W
max. load
Win10, 64-bit
Max load
(Turbo mode)
P-series
6.0 W
25.0 W
36.0 W
43.0 W
81.0 W
CPU
Mode
Win10, 64-bit
idle
Average load
Win10, 64-bit
cTDP down 12 W
max. load
Win10, 64-bit
nominal 15 W
max. load
Win10, 64-bit
cTDP up 28 W
max. load
Win10, 64-bit
Max load
(Turbo mode)
U-series
6.0 W
16.0 W
20.0 W
36.0 W
69.0 W
Table 7: TQMx130 Power Consumption Turbo Mode OFF
CPU
Mode
Win10, 64-bit
idle
Average load
Win10, 64-bit
cTDP down 35 W
max. load
Win10, 64-bit
nominal 45 W
max. load
Win10, 64-bit
cTDP up
max. load
Win10, 64-bit
Max load
(Turbo mode)
H-series
6.0 W
33.0 W
43.0 W
--
--
CPU
Mode
Win10, 64-bit
idle
Average load
Win10, 64-bit
cTDP down 20 W
max. load
Win10, 64-bit
nominal 28 W
max. load
Win10, 64-bit
cTDP up 35 W
max. load
Win10, 64-bit
Max load
(Turbo mode)
P-series
6.0 W
21.0 W
31.0 W
33.0 W
--
CPU
Mode
Win10, 64-bit
idle
Average load
Win10, 64-bit
cTDP down 12 W
max. load
Win10, 64-bit
nominal 15 W
max. load
Win10, 64-bit
cTDP up 28 W
max. load
Win10, 64-bit
Max load
(Turbo mode)
U-series
6.0 W
12.5 W
18.0 W
31.0 W
--

User's Manual l TQMx130 UM 0101 l © 2023, TQ-Systems GmbH Page 19
Note: Power requirement
The power supplies on the carrier board for the TQMx130 must be designed with sufficient reserves.
The carrier board should be able to provide at least twice the maximum TQMx130 workload power.
The TQMx130 supports multiple low-power states. The power supply of the carrier board must be
stable, even with no load.
Carrier power supply recommendation:
-series max. load Turbo ON
Power Consumption = 148.0 W
Carrier power design = 180.0 W
-series max. load Turbo OFF
Power Consumption = 43.0 W
Carrier power design = 80.0 W
-series max. load Turbo ON
Power Consumption = 81.0 W
Carrier power design = 110.0 W
-series max. load Turbo OFF
Power Consumption = 33.0 W
Carrier power design = 60.0 W
U-series max. load Turbo ON
Power Consumption = 69.0 W
Carrier power design = 100.0 W
U-series max. load Turbo OFF
Power Consumption = 31.0 W
Carrier power design = 50.0 W
